Phone 1-970-351-6100 | Fax 1-970-351-0355 | www.rubadue.com



































Basic (1 layer) Insulation FEP .002”




























Product Information

Temperature Rating:

155°C







Conductor:



Tin plated copper, Solid or Stranded (ASTM B-33/ASTM B-286)

Insulation:

   DuPont™ Teflon® FEP







   Bare copper and other conductors available

Compliances:



UL OBJT2 File No. E206198



Size Range:

18 AWG – 40 AWG



UL 60950-1 (Ed.2), Annex U



Voltage:



     600 V



       System approvals: UL 1446



Breakdown:



Approx. 3000 V





RXT-2 Class F





OD Tolerances:

18 -24 AWG +0.0015”/-0.001”



       RoHS Compliant







         25-40 AWG +0.001”/-0.0005”





























Insulation Information:

Insulation Type:



Fluoropolymer

Thermal:



Continuous Operating Temperature, 200°C

UL Flammability Rating:



V-0

Dielectric Constant:

  2.03



Tensile Strength (psi):



3000+







Elongation (%):



300

Abrasion Resistance:



Good



Bondability:



Poor









UV Resistance:



Excellent

Chemical Resistance:



Excellent

Water Resistance:



Excellent









Underground Resistance:



Excellent

Long Term Stability:



Excellent


FEP is a Fluoropolymer compound with exceptional dielectric properties, heat resistance, chemical resistance, and flexibility.  Commonly used in
winding wires, UL AWM wires, and cable jacketing.




























Insulated Wire Information:

Conductor OD

Insulated Wire OD

Part Number

AWG

Inches

MM

Inches

MM

Weight LB/KFT

S18A01FX-2

18

0.0403

1.024

0.0443

1.125

5.17

S18A19FX-2

18(19/30)

0.0476

1.209

0.0516

1.311

6.17

S20A01FX-2

20

0.0320

0.813

0.0360

0.914

3.29

S20A19FX-2

20(19/32)

0.0385

0.978

0.0425

1.080

3.99

S22A01FX-2

22

0.0253

0.643

0.0293

0.744

2.10

S22A19FX-2

22(19/32)

0.0295

0.749

0.0335

0.851

2.52

S24A01FX-2

24

0.0201

0.511

0.0241

0.612

1.35

S24A19FX-2

24(19/36)

0.0242

0.615

0.0282

0.716

1.63

S25A01FX-2

25

0.0179

0.455

0.0219

0.556

1.18

S26A01FX-2

26

0.0159

0.404

0.0199

0.505

0.89

S27A01FX-2

27

0.0142

0.361

0.0182

0.462

0.71

S28A01FX-2

28

0.0126

0.320

0.0166

0.422

0.57

S29A01FX-2

29

0.0113

0.287

0.0153

0.389

0.47

S30A01FX-2

30

0.0100

0.254

0.0140

0.356

0.38

S31A01FX-2

31

0.0089

0.226

0.0129

0.328

0.31

S32A01FX-2

32

0.0080

0.203

0.0120

0.305

0.25

S33A01FX-2

33

0.0071

0.180

0.0111

0.282

0.21

S34A01FX-2

34

0.0063

0.160

0.0103

0.262

0.17

S35A01FX-2

35

0.0056

0.142

0.0096

0.244

0.14

S36A01FX-2

36

0.0050

0.127

0.0090

0.229

0.12

S37A01FX-2

37

0.0045

0.114

0.0085

0.216

0.10

S38A01FX-2

38

0.0040

0.102

0.0080

0.203

0.08

S39A01FX-2

39

0.0035

0.089

0.0075

0.191

0.07

S40A01FX-2

40

0.0031

0.079

0.0071

0.180

0.06
































Rubadue/basic1layerinsulation-html.html
background image







Phone 1-970-351-6100 | Fax 1-970-351-0355 | www.rubadue.com





Bare Core Wire Specifications:

DCR per 10’ @ 20°C

Core Wire Diameter

DC Resistance

AWG

Min. Dia.

Nom. Dia.

Max. Dia.

Min. Res.*

Nom. Res.

Max. Res.

16

0.0503

0.0508

0.0523

0.0388

0.0418

0.0440

17

0.0448

0.0453

0.0467

0.0487

0.0526

0.0555

18

0.0399

0.0403

0.0415

0.0617

0.0664

0.0699

19

0.0355

0.0359

0.0370

0.0776

0.0837

0.0883

20

0.0317

0.0320

0.0330

0.0975

0.1053

0.1108

21

0.0282

0.0285

0.0294

0.1229

0.1328

0.1400

22

0.0250

0.0253

0.0261

0.1559

0.1685

0.1781

23

0.0224

0.0226

0.0233

0.1956

0.2112

0.2219

24

0.0199

0.0201

0.0207

0.2478

0.2669

0.2811

25

0.0177

0.0179

0.0184

0.3137

0.3366

0.3554

26

0.0157

0.0159

0.0164

0.3948

0.4266

0.4517

27

0.0141

0.0142

0.0146

0.4982

0.5349

0.5600

28

0.0125

0.0126

0.0130

0.6283

0.6793

0.7125

29

0.0112

0.0113

0.0116

0.7892

0.8446

0.8875

30

0.0099

0.0100

0.0103

1.0009

1.0785

1.1359

31

0.0088

0.0089

0.0092

1.2546

1.3616

1.4376

32

0.0079

0.0080

0.0083

1.5414

1.6852

1.7838

33

0.0070

0.0071

0.0074

1.9392

2.1395

2.2720

34

0.0062

0.0063

0.0066

2.4378

2.7173

2.8962

35

0.0055

0.0056

0.0059

3.0506

3.4391

3.6803

36

0.0049

0.0050

0.0053

3.7803

4.3140

4.6368

37

0.0044

0.0045

0.0048

4.6089

5.3259

5.7505

38

0.0039

0.0040

0.0043

5.7431

6.7406

7.3195

39

0.0034

0.0035

0.0038

7.3539

8.8041

9.6306

40

0.0030

0.0031

0.0034

9.1860

11.2227

12.3700

*ASTM B33 sets no standard for minimum resistance.  This is only an indicator to investigate other aspects such as tin-thickness and tin
coverage.
