UL AWM Style 10086




























Product Information

Temperature Rating:

200°C

Conductor:



 Tin plated copper “A” in part number

Insulation:

  ETFE













Solid or Stranded (ASTM B-33/ASTM B-286)

Compliances:



UL AWM Style 10086







   Silver plated copper “B” in part number



       File No. E78621







   Solid or Stranded (ASTM B-298)







CSA AWM C22.2 No. 210.2 – M90



Size Range:

10 AWG – 36 AWG

  License

No.

LL84686-1

Voltage:



     600 V





150°C / 600 V









       RoHS Compliant





























Insulation Information:

Insulation Type:



Fluoropolymer

Thermal:



Continuous Operating Temperature, 150°C

UL Flammability Rating:



V-0

Dielectric Constant:

 2.6



Tensile Strength (psi):



6500



Elongation (%):



150-300

Abrasion Resistance:



Excellent

Bondability:



Poor









UV Resistance:



Excellent

Chemical Resistance:



Excellent

Water Resistance:



Excellent



Underground Resistance:



Excellent

Long Term Stability:



Excellent


ETFE is a Fluoropolymer compound with excellent electrical properties, heat resistance, chemical resistance, and abrasion resistance.
Commonly used in winding wires, UL AWM wires, and medical applications.




























Insulated Wire Information:

Conductor OD

Insulated Wire OD

Part Number

AWG

Inches

MM

Inches

MM

Weight LB/KFT

S10A37ZX-16

10(37/26)

0.1070

2.718

0.1390

3.531

34.78

S12A19ZX-16

12(19/25)

0.0862

2.189

0.1182

3.002

23.71

S14B19ZX-11

14(19/27)

0.0679

1.725

0.0899

2.283

14.40

S16A01ZX-11

16

0.0508

1.290

0.0728

1.849

9.85

S16B19ZX-11

16(19/29)

0.0539

1.369

0.0759

1.928

9.63

S18A01ZX-11

18

0.0403

1.024

0.0623

1.582

6.61

S18B19ZX-11

18(19/30)

0.0476

1.209

0.0696

1.768

7.80

S20A01ZX-11

20

0.0320

0.813

0.0540

1.372

4.51

S20B19ZX-11

20(19/32)

0.0385

0.978

0.0605

1.537

5.38

S22A01ZX-11

22

0.0253

0.643

0.0473

1.201

3.14

S22B19ZX-11

22(19/34)

0.0295

0.749

0.0515

1.308

3.67

S24A01ZX-11

24

0.0201

0.511

0.0421

1.069

2.25

S24B19ZX-11

24(19/36)

0.0242

0.615

0.0462

1.173

2.63

S26A01ZX-11

26

0.0159

0.404

0.0379

0.963

1.65

S26B19ZX-11

26(19/38)

0.0190

0.483

0.0410

1.041

1.88

S28A01ZX-11

28

0.0126

0.320

0.0346

0.879

1.26

S28B07ZX-11

28(7/36)

0.0150

0.381

0.0370

0.940

1.35

S28B19ZX-11

28(19/40)

0.0152

0.386

0.0372

0.945

1.43

S30A01ZX-11

30

0.0100

0.254

0.0320

0.813

1.00

S30B07ZX-11

30(7/38)

0.0120

0.305

0.0340

0.864

1.07

S30B19ZX-11

30(19/42)

0.0120

0.305

0.0340

0.864

1.13
































Bare Core Wire Specifications:

Rubadue/ulawmstyle10086-html.html
background image







Phone 1-970-351-6100 | Fax 1-970-351-0355 | www.rubadue.com





DCR per 10’ @ 20°C

Core Wire Diameter

DC Resistance

AWG

Min. Dia.

Nom. Dia.

Max. Dia.

Min. Res.*

Nom. Res.

Max. Res.

10

0.1009

0.1019

0.1050

0.0096

0.0104

0.0109

11

0.0898

0.0907

0.0934

0.0122

0.0131

0.0138

12

0.0800

0.0808

0.0832

0.0153

0.0165

0.0174

13

0.0713

0.0720

0.0742

0.0193

0.0208

0.0219

14

0.0635

0.0641

0.0660

0.0244

0.0262

0.0276

15

0.0565

0.0571

0.0588

0.0307

0.0331

0.0349

16

0.0503

0.0508

0.0523

0.0388

0.0418

0.0440

17

0.0448

0.0453

0.0467

0.0487

0.0526

0.0555

18

0.0399

0.0403

0.0415

0.0617

0.0664

0.0699

19

0.0355

0.0359

0.0370

0.0776

0.0837

0.0883

20

0.0317

0.0320

0.0330

0.0975

0.1053

0.1108

21

0.0282

0.0285

0.0294

0.1229

0.1328

0.1400

22

0.0250

0.0253

0.0261

0.1559

0.1685

0.1781

23

0.0224

0.0226

0.0233

0.1956

0.2112

0.2219

24

0.0199

0.0201

0.0207

0.2478

0.2669

0.2811

25

0.0177

0.0179

0.0184

0.3137

0.3366

0.3554

26

0.0157

0.0159

0.0164

0.3948

0.4266

0.4517

27

0.0141

0.0142

0.0146

0.4982

0.5349

0.5600

28

0.0125

0.0126

0.0130

0.6283

0.6793

0.7125

29

0.0112

0.0113

0.0116

0.7892

0.8446

0.8875

30

0.0099

0.0100

0.0103

1.0009

1.0785

1.1359

*ASTM B33 sets no standard for minimum resistance.  This is only an indicator to investigate other aspects such as tin-thickness and tin
coverage.
