DATA SHEET
Ametherm, Inc
. 3111 N. Deer Run Road #4 Carson City, NV 89701
Telephone: (800) 808-2434 (775) 884-2434 Fax: (775) 884-0670
www.ametherm.com
Part Number: SL08 50001
Ordering Different Lead Types:
For example: to order an inside kinked lead use part number SL08 50001
-A
Electrical
Specifications:
Mechanical
Specifications:
Current vs. Hot Resistance Table:
CSA File #: CA 118061
Revision Date: March 19, 2003
Inside Kinked Leads
Use
-A
after Ametherm’s part #
Outside Kinked Leads
Not Available
Resistance @ 25°C
50.0
Ω
±
20 %
Max Steady State Current Up to 65°C
1.10 A
Max Recommended Energy Rating (Joules)
18.0 J
Actual Failure Point of Instantaneous Energy (Joules)
30.0 J
Body Temperature @ 100% Current Rating
138 °C
Dissipation Constant
5.2mW/°C
Thermal Time Constant
20 Seconds
Material Type
“H”
Max Recommended Capacitance @ 120VAC/240VAC
900µF/225µF
Power Consumption @ Max Current
0.990 watts
D
8.0
±
0.3 mm
T
3.5
±
0.3 mm
Lead Diameter
0.5
±
0.1 mm
S
6.35
±
0.6 mm
L
9.90
±
0.90 mm
B
6.35
±
0.60 mm
C
2.82
±
0.5 mm
Current
Hot R /Body Temp
0.25 A
8.27
Ω
, 63.2
°C
0.50 A
3.73
Ω
, 88°C
0.75 A
2.14
Ω
, 103
°C
1.10 A
0.90
Ω
, 138°C
L
OUTSIDE
KINKED LEADS
S
STRAIGHT
LEADS
B
INSIDE
KINKED LEADS
S
S
D
D
D
C
T
