Customer Value Proposition
Parker Chomerics SOFT-SHIELD
®
4850
is a true multi-planar, Z-axis electrically
conductive foam for indoor applications.
It is based on the unique integration
of electrically conductive silver-plated
fibers into a low-density urethane foam,
providing for a performance-driven, cost-
effective EMI shielding solution. It offers
greater EMI shielding performance from
other SOFT-SHIELD products which may
only consist of an electrically conductive
jacket over traditional urethane foam.
Through the optimization of conductive
fiber construction, loading and dispersion
within the foam matrix, SOFT-SHIELD
4850 provides superb Z-axis conductivity
with extremely short ground paths.
Since the integrity of the base foam is
uncompromised, SOFT-SHIELD 4850
offers exceptional physical and
mechanical properties.
SOFT-SHIELD 4850 is flammability
rated to UL 94 V-0 and is available in
cut sheets, bulk rolls or custom die cut
SOFT-SHIELD
®
4850
Multi-Planar Electrically Conductive
Foam EMI Shielding Gaskets
shapes. A uniform (silver plated, copper
particle) electrically conductive acrylic
pressure sensitive adhesive (PSA) is
available on one side to help secure
after installation.
Product Features
•
95 dB shielding effectiveness
from 20 MHz to 10 GHz
•
Low compression set of less
than 15%
•
Stable electrical performance
(through resistance) after multiple
closure cycles
•
Excellent through resistance (< 30
milliohm @ 25% gasket deflection)
•
Non-nickel bearing material (silver
plated fibers)
•
Available in cut sheets, bulk rolls or
custom die cut shapes
•
Z-axis conductivity allows
compartmental shielding
•
At low deflection (15%) demonstrates
optimal electrical performance
•
Offered with or without electrically
conductive acrylic pressure sensitive
adhesive (PSA)
•
RoHS, REACH and UL 94 V-0
compliant
Typical Applications
•
I/O panels, backplanes, connectors,
access panels and rectangular/
square strip gasket seals
•
Telecom Infrastructure rack and
enclosure components
•
Servers and desktop PCs
•
LCD/PDP large screen TVs
•
Indoor electronics applications
requiring UL94 V-0 rating
