Specifications

Power Series Connectors

1. Power connector series: Panel Mount(Male/Female)/ Field Wiring with

    Solder Pin is one of our main product series of Singatron waterproof

    connector and are available in bulkhead, inline and over-mould

    configurations.

2. Our Products is built to the highest quality and specifications and fulfills

    European Union regulations for RoHS, UL and major worldwide

    safety requirements.

3. Applications for PV Solar, Outdoor Displays, Outdoor Signs, Outdoor

    Lighting of Transportation/ Tunnel/ Building, and Heavy Machineries.

Applications

Brand Story

Certifications and Membership

Singatron Group, established in 1976 proudly announce SGconn as a new

brand identity for its growing line of rugged and waterproof connectors.

The logo brings all these characteristics together in a name that is easier

to identify as well as reinforces SGconn’s commitment towards growing

this product line in ways which respond to the harsh demands of this

product category.

The newly designed logo for SGconn is simple, and yet bold, red sans

serif text, capturing the same essence of efficiency and rugged hardiness

required by the customers and market segments SGconn serves.

Manufacturer Identifications

■ Power Connector

Description

■ Panel mount

■ Field Wiring with Solder Pin

Current Rating

■ 12A

■ 18A

Pin Configuration

■ 2, 5 Connectors

Material

■ Contact: Copper Alloy, Gold Plated

■ Connector Body: Nylon+GF, PC, UL Recognized

Temperature Range

■ Connector Body: -40°

C

 to +100°

C

IP Rating

■ IP67

■ IP68 (when properly mated)

Contact Resistance

■ ≤30mΩ

Insulation Resistance

■ ≥100MΩ at DC 500V

Durability

■ 100 cycles minimum

Breakdown Voltage

■ ≥AC 1000V/ 1 minute

Corrosion

■ 48 hours salt spray contact

Introduction

Specifications

Singatron Waterproof Connector

Singatron Waterproof Connector

Singatron reserves the right to make any changes and updates for design and specification at any time without notice.

More information please visit www.sgconn.com.tw or contact us.
