U.S. TOYO FAN CORPORATION
TF120RX Series
AC / Ball Bearing
ULTRA THIN FAN
FEATURES:
•
The thinnest axial fan available - .787” (20mm) thick
•
High Performance
•
Low noise level
•
Precision ball bearings provide long service life
•
Durable die cast aluminum frame
•
Choice of 115VAC or 230 VAC
•
Impedence protected
•
U.L. recognized - File Number E75082
•
CSA certified - File Number 48371M2
MATERIAL:
Frame
-
Die Cast Aluminum
Black paint finish
Impeller
-
Black polycarbonate
Bearings
- Ball bearings
WEIGHT:
0.29kg (10.2 ounces)
DIMENSIONS:
Millimeters (inches)
TOLERANCES:
Millimeters - .x = ± .05, .xx = ± 0.3
(Inches) --.xx = ± .02, .xxx = ±.010
PERFORMANCE CURVES:
(Obtained with test chamber and methods in accordance with A M C A Std. 210-74)
PART NUMBERS AND SPECIFICATIONS:
