Specifications:

Ratio Tolerance:  See ordering information.
Absolute Tolerance:  ±1.0% for all resistors.
Ratio  Temperature  Coefficient:  See ordering

information.
Absolute Temperature Coefficient:  30 ppm/°C

referenced to +25°C,

∆

R taken at -55°C and

+125°C.
Voltage  Rating:  Rated voltage applied to R

1



and R

2

 in series.

Load  Life:    Ratio  change  with  rated  voltage

applied for 1,000 hours at +125°C, 0.4% max.
Overvoltage:    1.5  times  rated  voltage  for

5 seconds, ratio change 0.5% max.
Thermal  Shock:    Mil-Std-202, Method 107,

Cond. C, ratio change 0.25% max.
Moisture Resistance:  Mil-Std-202, Method 106,

ratio change 0.5% max.
Solderable Leads
Encapsulation:  High Temperature Silicone

Conformal with Dielectric Withstanding Voltage of

750 volts.
Insulation Resistance:  10,000 Megohms, min.

Type THV Precision High Voltage Divider Networks

CADDOCK ELECTRONICS

THV10 - A100M - 1.0 - 10

1227

.025

±

.002

(.64

±

.05) DIA.

  .120

±

.030

(3.05

±

.76)

A

  .710

±

.040

(18.03

±

1.02)

1.000

±

.125

(25.40

±

3.18)

  .200

±

.015

(5.08

±

.38)

.100

(2.54)

PIN 1

R

2

R

1

PIN 1

B

Ratio TC to 10 ppm/°C, Ratio Tolerance to ±0.25%, Voltage Ratings of 10 KV or 15 KV

  The Type THV Precision High Voltage Divider Networks

introduce Caddock's advanced high voltage resistor tech-

nology which doubles the allowable working voltage over the

length of the high voltage section.  This technology combines

Caddock's Tetrinox®  resistance  films  with  a  patented  laser-

generated V-Notch Geometry which optimizes the voltage

gradient over the length of the resistance pattern.
  Type THV networks provide tighter ratio temperature

coefficients  and  tighter  ratio  tolerances  than  have  previously

been available in standard high voltage divider products.

•

 Ratio Temperature Coefficients of 10 ppm/°C or 25 ppm/°C

  from -55°C to +125°C.

•

 Ratio Tolerances of ±0.25%, ±0.5%, or ±1.0% at

  Rated Voltage.

•

 Voltage Ratings of 10 KVDC or 15 KVDC

•

 Standard Voltage Division Ratios of 1,000:1 or 100:1, with

  custom ratios available.

  These  specifications  can  provide  important  improvements

in performance in many types of advanced electronic systems,

including, TWT power supplies, radar systems, X-ray systems,

analytical equipment, and high resolution CRT displays.

B

1.100

±

.015

(27.94

±

.38)

1.650

±

.015

(41.91

±

.38)

Voltage

Division

Voltage

Rating

Model

No.

A

Dimensions  inches (mm)

Resistance

R

1

R

2

THV10

1.500

±

.030

(38.10

±

.76)

THV15

2.050

±

.030

(52.07

±

.76)

10 KVDC

15 KVDC

A

B

A

B

99.9 Meg

99 Meg

149.85 Meg

148.5 Meg

100 K

1 Meg

150 K

1.5 Meg

Total

100 Meg

100 Meg

150 Meg

150 Meg

1,000:1

100:1

1,000:1

100:1

Ratio Code

Letter

DiMeNSioNS iN iNCHeS AND (MiLLiMeTeRS)

Standard Type THV Precision High Voltage Divider Networks

Standard Ratio Tolerance at Rated Voltage:

            -1.0 = 1.0%         -0.25 = 0.25%

            -0.5 = 0.5%

THV10 - A  100M - 1.0 - 10

Model Number:

Ratio Code Letter:

Ratio Temperature Coefficient

from -55

°

C to +125

°

C:

-25 = 25 ppm/

°

C       -10 = 10 ppm/

°

C

Total Resistance Value of the Divider:

  For complete information on price and delivery of both

evaluation and production quantities, contact Caddock

Applications engineering.

Derating Curve:

RATED VOLTAGE, %

AMBIENT TEMPERATURE,

°

C

100

80

60

40

20

0

25

75 125 175 225

Ordering Information:

Precision High Voltage Dividers:  For assistance in specifying precision high voltage dividers

for your application please contact Caddock Applications engineering.  We can offer high

voltage divider solutions based on the combination of catalog high voltage resistors, or by using

our well established capability to provide more precision in a Matched Resistor Set.  Depending

on the performance you require, a precision high voltage divider solution can be formed using

Caddock Type USG and USF resistors, or Caddock Type TG and TK resistors, or a combination

of Type MG resistors.
