CAD
K
DOC
Specifications:
Resistance Tolerance:
±0.025%, ±0.05%,
±0.10% or ±1.0%.
Absolute Temperature Coefficient:
5ppm/°C, 10ppm/°C, or 20ppm/°C
referenced to +25°C,
Δ
R taken at 0°C and
+70°C.
Load Life Stability at +70°C:
Shelf Life (Typical):
25 ppm/year.
Storage Temperature:
-55°C to +105°C.
Encapsulation:
Transfer Molded.
Leadwire:
Tinned Copper.
Derating Curve:
Type TN Lab Grade Low TC Precision Film Resistors
Type TN Lab Grade Low TC Film Resistors were specifically
developed for use in 0°C to +70°C applications which require a
low temperature coefficient and a high degree of precision.
These resistors combine the outstanding characteristics of
Caddock's Tetrinox® resistance system with a space efficient,
non-inductive, radial-lead design. These resistors are intended
for precision analog designs where the system is not exposed to
full military or space grade operating conditions. For full military
or space grade operating conditions, we recommend Caddock's
Type TK Low TC Precision Radial-Lead Film Resistors.
For
lab grade applications which require higher voltage ratings (up to
1,400 volts) and power ratings (up to 0.75 Watt), we recommend
Caddock's
Type TF Low TC Ultra-Precision Film Resistors
.
The performance features of the Type TN Lab Grade Low TC
Precision Film Resistors are:
•
Low Temperature Coefficient
- 5, 10, or 20 ppm/°C.
•
Ultra-Precision
- Tolerances from ±0.025% to ±1%.
•
Resistance Range
- from 1 K to 1 Meg.
•
Non-Inductive Design
.
•
Radial-Lead Design
- conserves board space.
Low TC of 5 ppm/°C, 10 ppm/°C, or 20 ppm/°C from 0°C to +70°C
Tolerance of ±0.025%, ±0.05%, ±0.1%, to ±1%, Values from 1 Kohm to 1 Meg
AMBIENT TEMPERATURE,
°
C
80
100
60
40
20
0
RATED LOAD, %
35
70
105
ALL DIMENSIONS IN INCHES
AND (MILLIMETERS)
Temperature Coefficient Identification:
5 ppm/°C White Stripe; 10 ppm/°C No Stripe; 20 ppm/°C Green Stripe
Type TN Lab Grade Low TC Precision Film Resistors
Dimensions
Max.
Working
Voltage
Model
No.
Wattage
@
+70
°
C
Temperature
Coefficient
ppm/
°
C
Dielect.
Strength
Resistance
Min.
Max.
Ref. Case "A" Dwg.
TN
130
0.3
200
5, 10, or 20
400
1 K
1 Meg
Ref. Case "B" Dwg.
TN
137
0.3
200
5, 10, or 20
400
1 K
1 Meg
Ref. Case "C" Dwg.
TN
130V
0.3
200
5, 10, or 20
400
1 K
1 Meg
Comments
With Standoff
Case "C"
Model TN130V
.025
±
.002
(.64
±
.05) DIA.,
LEADWIRE
OFFSET
.012 (.31) FROM
CENTERLINE
.250
±
1.27)
±
.050
(6.35
.290
±
.010
(7.37
±
.26)
.200
±
.015
(5.08
±
.38)
(CENTERED)
.090
(2.29)
.030
±
.004
(.76
±
.10)
.095
±
.005
(2.41
±
.13)
.290
±
.010
(7.37
±
.26)
10.0 K
TN130V
1%
Model TN130
.290
±
.010
(7.37
±
.26)
1.50
+3.18)
-0.00)
+.125
-.000
(38.10
.095
±
.005
(2.41
±
.13)
.025
±
.002
(.64
±
.05) DIA.,
LEADWIRE
OFFSET
.012 (.31)
FROM
CENTERLINE
.290
±
.010
(7.37
±
.26)
.200
±
.015
(5.08
±
.38)
(CENTERED)
10.0 K
TN130
1%
Case "A"
Case "B"
.150
±
.015
(3.81
±
.38)
(CENTERED)
.305
±
.010
(7.75
±
.26)
.105
±
.005
(2.67
±
.13)
.305
±
.010
(7.75
±
.26)
Model TN137
1.50
+3.18)
-0.00)
+.125
-.000
(38.10
.025
±
.002
(.64
±
.05) DIA.,
LEADWIRE
OFFSET
.012 (.31)
FROM
CENTERLINE
1.00 MEG
TN137
1%
TN130 - 10.0 K - 0.025% - 10 ppm/
°
C
Model Number
Tolerance
Resistor Value
Temperature
Coefficient
Ordering Information:
0.03%
0.02%
0.01%
80
100
60
40
20
0
RATED LOAD, %
MAXIMUM %
∆
R per 2,000 HOURS
