Mining & Coal Preparation

Coal-Fired Power Plants

Pulp & Paper

Cement Processing

Steel Processing

Wear & Abrasion Solutions

2

Table of Contents

About ITW Wear & Abrasion Group

4



Product Technologies

5



Wearing Compounds

6

Belting & Rubber Repair

10

Urethane Casting Compounds

12

Corrosion Repair Compounds

14

Metal Repair Epoxies

16

Crusher Backing Compounds

20

Surface Preparation

22

Agency Approvals

24

Product Index

25

3

About ITW Wear & Abrasion Group

4

ITW Wear & Abrasion Group is a global Sales, Marketing, and Technical Support group that markets, supports and promotes

well-recognized brands such as Densit®, Devcon® and Korrobond.

We are utilizing ITW’s global network of R&D facilities, technology centers, and manufacturing facilities within the ITW Polymers

Division to develop and provide one of the most extensive lines of wear and abrasion products available. Our target industries

include, but are not limited to: Mining, Coal Preparation, Cement Plants, Coal-Fired Power Plants, Pulp & Paper and Chemical

Processing.

In industrial plants, unexpected or unscheduled plant shutdowns caused by wear in processing machinery, are costly and thus

reduce competitiveness. Wear and abrasion or corrosion is especially familiar in those industries that process or use large

quantities of abrasive material in their production process. ITW Wear & Abrasion Group’s experienced sales team has detailed

knowledge and experience to solve your problem. ITW Wear & Abrasion Group has the solution; whether you need to rebuild

equipment to original specs or prevent failures from occurring in a preventative maintenance program.

About ITW, Our Parent Company

Illinois Tool Works Inc. (NYSE: ITW), a Fortune 200 company, is a diversified manufacturing company that delivers specialized ex-

pertise, innovative thinking and value-added products to meet critical customer needs in a variety of industries.  ITW businesses

serve local customers and markets around the globe, with a significant presence in developed as well as emerging markets. With

$17.8 billion in 2011 revenues, ITW employs approximately 60,000 women and men in 58 countries who adhere to the highest

ethical standards. These talented individuals, many of whom have specialized engineering or scientific expertise, contribute to

our global leadership in innovation. We are proud of our broad portfolio of nearly 12,000 active patents. For more information

about ITW, please visit www.ITW.com.

Danvers, U.S.A

São Paulo

Moscow

Rushden, U.K

Medak District A.P.

Osaka

Shanghai

Sydney

5

Belting and Rubber Repair Compounds

 are flexible urethane

structural technologies for repairing worn or damaged SBR conveyor

belts, rubber lined equipment such as pipes and tanks in mines,

quarries, and coal-fired power plants.  These products are in a non-

sag putty for patching and repairing linings along with self-leveling

thixotropic versions that create a smooth surface for repairing

conveyor belts.

Metal Repair Epoxies

are metal-filled epoxy technology that allows

for fast, economical, permanent repairs to power plant and mining

equipment.  The epoxies cure quickly; can be machined, tapped and

corrosion resistant to harsh chemicals.  These products are

available in liquid formulas that can be used for mold patterns,

holding fixtures and forming dies.

Wearing Compounds

are specially formulated wear-resistant

epoxy coatings that protect dry materials handling and storage

equipment from sliding abrasion, impact and wear. These products

are trowelable, non-sag putties available in large particulate, high

impact, and high temperature formulas.

Tile Adhesives are high strength, room temperature curing,

trowelable adhesives that bond ceramic tiles to metal.

Corrosion Repair Compounds

 are ceramic filled epoxy technology to

make permanent repairs to pumps, shafts, pipes, and tanks where a

corrosion-resistant polymer is needed to protect all metals against

corrosion and erosion in slurry applications.  These products apply

easily with a brush or in a creamy putty consistency that allows you to

be back in service within 3-5 hours.

Product Technologies

Devcon

®

 DFense Blok

™



A bead-filled epoxy compound formulated

to significantly outlast traditional wear and

abrasion products while providing superior

protection.

• 4X better abrasion resistance than

    competition

• 7X better drop impact strength than

    ceramic tile

Item #

  Size

11330          30lb

Devcon

®

 DFense Blok

™

  Fast

Cure (FC)

A bead-filled epoxy compound that allows

equipment to be returned to service in 2

hours.

• Non-sagging , good adhesion

• Withstands operating temperature, as

    high as 300°F

Item #

 Size

11350        9lb

Devcon

®

 DFense Blok

™

 Surface

Wetting Agent

A thixotropic epoxy gel system that

improves the ease of application and

cured adhesion properties of DFense

Blok™

• Zero wait time before applying DFense

   Blok™

• Orange color for easy visual inspection



Item #

 Size

11340   1lb

Devcon

®

 DFense Blok

™

 Quick

Patch



The only ceramic bead-filled wear and

abrasion resistant epoxy for emergency

repair.

• Eliminates down-time with exceptionally

    fast cure

• Repairs holes, leaks and cracks



Item #

  Size

11320    1lb

Specially formulated wear-resistant epoxy coatings that protect dry materials handling and storage equipment from

abrasion, corrosion and wear. The DFense Blok™ product line is truly an advanced epoxy technology with quicker

functional cure times and better abrasion resistance.

Wearing Compounds

Devcon

®

DFense Blok

™

 Power

Mixer

Recommended for most effective way to

thoroughly mix DFense Blok™ Wearing

Compound.

• Durable steel paddle with three blades;

    2X faster than drill-style mixers

• Plugs into standard 120V outlet.

Item #

Size

11301   81lb

Watch our



Impact Test!

6

7

Physical

Properties

Devcon

®



DFense Blok™

Devcon

®



DFense Blok™

Surface Wetting Agent

Devcon

®



DFense Blok™

Fast Cure (FC)

Devcon

®



DFense Blok™

Quick Patch

Color

Grey

Orange

Grey

Grey

Mix ratio by weight / volume

resin:hardener

2:1 / 100:45

2:1/100:44

2:1/2:1

1:1/1:1

Mixed viscosity   cP

Putty

Thixotropic Gel

Putty

Putty

Functional cure  hours

4-5

4-5

2-3

30 minutes

Pot life  minutes @ 75˚F

25

12-15

15

4

Specific volume inches

3

 /pound

12.6

24.7

13.8

14.89

Coverage per pound

inches

2

  @ 1⁄4" thickness

47

1860 @ 12mils

53

60

Cured hardness

 (ASTM D2240)   Shore D

77

71

80

84

Cured shrinkage

 (ASTM D2566) inch/inch

0.0005

N/A

0.0008

0.0010

Adhesive tensile shear

(ASTM D1002)    psi

2,616

2,616

2,764

2,495

Compressive strength

 (ASTM D695)    psi

7,145

5,032

7,178

6,166

Flexural strength

(ASTM D790)    psi

7,876

6,700

7,488

4,880

Coefficient of thermal expansion

(ASTM D696)[(in)/(in x ˚F)] x 10

-6

29

N/A

33

31

Dielectric constant (ASTM D150)    1 kHz

49.0

N/A

45

51

Maximum continuous dry

service temperature   ˚F

300

300

300

200

Technical Information

Chemical Resistance

Devcon

®



DFense Blok™

Devcon

®



DFense Blok™ Surface

Wetting Agent

Devcon

®



DFense Blok™

Fast Cure (FC)

Devcon

®



DFense Blok™

Quick Patch

ACIDS
Acetic 10%
Hydrochloric 10%
Sulfuric 10%
ALCOHOLS
Methanol
Isopropanol

KETONES
Acetone
Methyl ethyl ketone

ALKALIS

Ammonium hydroxide 20%

Sodium hydroxide 10%

 HYDROCARBONS
Gasoline (unleaded)
Mineral spirits

CHLORINATED

HYDROCARBONS
1-1-1 Trichloroethane

SALTS
Sodium chloride
Trisodium phosphate

Key:               Excellent               Very Good              Fair               Poor

NOTES:





1



Coverage in inches

2

 / 20.4 pound unit ,

2



Three-part system, beads separate

Devcon

®

 Wear Guard

™

 Fine Load



High-density, micro-alumina ceramic

bead-filled epoxy system for

protecting equipment that handles

particulate smaller than 1⁄ 8".

• Withstands operating temperatures

    as high as 300°F

• Outstanding resistance to a wide

   range of chemicals

Item #

Size

11470  30lb

Devcon

®

 Wear Guard

™

 High Temp

High-density, ceramic bead-filled

epoxy system for maximum wear and

abrasion resistance in high temperature

applications.

• Heat-cured, trowelable system that

   gives up to 30% improvement over

   conventional wear compounds

• Withstands continuous service

   temperatures to 450°F



Item #

Size

11480  30lb

Devcon

®

 Tile Adhesive

High-strength, trowelable adhesive that

cures at room temperature.

• Bonds ceramic tile to vertical, curved,

    and overhead surfaces and repairs

    loose ceramic tiles

• Excellent chemical resistance to acids

    and alkalis

Item #

Size

11495  20lb

Specially formulated wear-resistant epoxy coatings that protect dry materials handling and storage equipment

from abrasion, corrosion and wear. These products are trowelable, non-sag putties available in large particulate,

high impact, and high temperature formulas.

Devcon

®

 Wear Guard

™

 High Load

Alumina ceramic bead-filled epoxy system

with outstanding abrasion resistance for

severe service conditions with particulate

greater than 1⁄8".

• Trowels onto overhead or vertical

    surfaces without sagging

• Ideal for repairing scrubbers, ash

    handling systems, pipe elbows,

    screens, and chutes

Item #

Size

11490  30lb

Devcon

®

 Wear Guard

™

 High Impact



High density micro alumina ceramic

bead-filled epoxy system with a flexible

additive for superior impact and abrasion

resistance

• Non sagging putty in a creamy



    consistency

• High compression and impact strength

Item #

Size

11460  30lb

Devcon

®

 Combo Wear FC

High-tech, three-component (2 bead

sizes plus silicon carbide) compound for

repairing process equipment quickly and

returning it to service in as little as 1-1/2

hours.

• Excellent adhesion to metal, ceramic,

    and concrete surfaces

• Ideal for cracks in large coal fuel lines

Item #

Size

11450  9lb

Devcon

®

 Wear Guard

™

 Ultra

Alumina ceramic bead-filled epoxy system

with outstanding abrasion resistance for

severe service conditions.

• Outstanding Wear Resistance

• Extends Equipment Operating Cycles



Item #

Size

11475  30lb

Devcon

®

 Carbide Putty

Silicone carbide-filled epoxy putty for

economical protection against sliding wear

and abrasion.

• Excellent abrasion resistance in



    aggressive industrial  environments

• Handles particulates less than 1/16”

Item #

Size

10050   3lb

10080 20lb

8

Wearing Compounds

Devcon

®

HV Tile Adhesive

High-strength, trowelable adhesive

compound for bonding tile, with a 35

minute working time.

• High viscosity, great non-sag adhesive

• Fills gaps and joints in crushers prior to

    backing compounds

Item #

Size

11489      20llb

Technical Information

Key:               Excellent               Very Good              Fair               Poor

Chemical

Resistance

Devcon

®



Wear Guard™

Fine Load

Devcon

®



Wear Guard™

High Load

Devcon

®

Wear Guard™

High Temp

Devcon

®



Wear Guard

™



High Impact

Devcon

®



Wear Guard

™



Ultra

Devcon

®



Combo Wear FC

(Fast Cure)

Devcon

®



Tile Adhesive

Devcon

®



HV Tile Adhesive

Devcon

®



Carbide Putty

ACIDS
Acetic 10%
Hydrochloric 10%
Sulfuric 10%

ALCOHOLS
Methanol
Isopropanol

KETONES
Acetone
Methyl ethyl ketone

ALKALIS

Ammonium hydroxide 20%

Sodium hydroxide 10%

 HYDROCARBONS
Gasoline (unleaded)
Mineral spirits

CHLORINATED

HYDROCARBONS
1-1-1 Trichloroethane

SALTS
Sodium chloride
Trisodium phosphate

9

NOTES:





2



Three-part system, beads separate

Physical

Properties

Devcon

®



Wear Guard™

Fine Load

Devcon

®



Wear Guard™

High Load

Devcon

®



Wear Guard™

 High Temp

Devcon

®



Wear Guard

™



High Impact

Devcon

®



Wear Guard

™



Ultra

Devcon

®



Combo Wear FC

(Fast Cure)

Devcon

®



Tile Adhesive

Devcon

®



HV Tile

Adhesive

Devcon

®



Carbide Putty

Color

Grey

Grey

Grey

Dark Grey

Grey

Grey

White

Grey

Grey

Mix ratio by weight /volume

resin:hardener

2:1 / 2:1

2:1 / 2:1

13.7:1 / 6:1

2.5:1 / 2.5:1

2.15:1:5.65

2

2:1 / 2:1

 1.1:1 / 1:1

 1.1:1 / 1:1

8:1 / 4:1

Mixed viscosity   cP

Putty

Putty

Putty

Putty

Putty

Putty

Putty

Putty

Putty

Functional cure hours

6-8

6-8

Heat Cured

6-8

16

2-3

12

12

16

Pot life minutes @ 75˚F

30

30

120

30

20

7

240

35

50

Specific volume inches

1

/pound

12.4

12.9

14.3

12.4

11.4

12.4

19.2

19

15.9

Coverage per pound

inches

2

  @ 1⁄4" thickness

50

50

60

50

46

50

76.8

76

64

Cured hardness

 (ASTM D2240)   Shore D

87

87

87

85

87

87

81

81

85

Cured shrinkage

(ASTM D2566) inch/inch

0.0006

0.0006

0.0010

0.0006

0.0004

0.0008

0.0010

0.0010

0.0009

Adhesive tensile shear

(ASTM D1002)    psi

1,375

1,474

2,300

2,567

1,425

1,450

2,890

1,825

1,350

Compressive strength

(ASTM D695)    psi

11,000

11,000

13,200

7,250

13,910

11,000

9,620

11,800

8,160

Flexural strength

(ASTM D790)    psi

7,190

7,140

8,220

6,144

7,220

7,140

5,480

5,400

5,480

Coefficient of thermal

expansion (ASTM D696)[(in)/(in

x ˚F)] x 10

-6

34

32

27

34

26

34

14

14

14

Dielectric constant

(ASTM D150)    1 kHz

46.0

41.0

38.0

46.0

40.0

41.0

46.0

45.0

25.0

Maximum continuous dry

service temperature   ˚F

300

300

450

300

300

300

200

200

250

10

Devcon

®

 Flexane

®

 80 Putty

Trowelable urethane for repairing and

lining process equipment exposed to wear,

abrasion, vibration or

expansion/contraction.

• Service temperatures to 180°F in dry

    environments and  120°F in wet

    environments

• Bonds to metal, concrete, rubber,



    wood, and fiberglass surfaces

Item #

Size

15820 1lb

15850  4lb

Devcon

®

Flexane

®

 High

Performance Putty

Trowelable lining for maximum protection

against abrasion, gouging and impact.

• Cures to a tough (tear strength 400

    pli), resilient rubber compound

    (Hardness 78 Shore A)

• Bonds to metal, rubber, wood,



    fiberglass, and concrete

Item #

Size

15330 1lb

Flexible urethane technologies for repairing worn or damaged SBR conveyor belts, rubber lined equipment such as pipes

and tanks in mines, quarries, and coal-fired power plants.  These products are in a non-sag putty for patching and

repairing linings along with self-leveling thixitropic versions that create a smooth surface for repairing conveyor belts.

Devcon

®

 Flexane

®

 Belt Repair Kit

Flexane

®

 80 Putty belt repair kit for

repairing holes and tears in conveyor belts.

• Makes belt repairs covering up to 188

    square inches at ¼” thickness

• Repairs and bonds to metals, concrete,

    rubber, wood, and  fiberglass

Item #

Size

15165 Kit

Belting & Rubber Repair

Devcon

®

400ml Dispensing

System

Manual dispensing gun and custom design

mixing nozzle for 4:1 400 ml systems.

• Used with Flexane

®

 Fast Cure Putty

   #15049  &  Flexane

®

 Fast Cure Liquid

   #15050

Item #

     Size

15043  400ml gun

15047

Nozzle (Ø.394” 4:1 ratio)



Devcon

®

Flexane

®

 Fast Cure

Putty

Black Flexane

®

 Fast Cure thickens to a

putty in seconds providing superior

flexibility, elongation and adhesion to

rubber.

• Light service duty in 3 hours

• Thixotropic , creamy formula which



    thickens in time

• Dispenser #15043

 (manual)

    Nozzle #15047

Item #

     Size

15049

     400ml cartridge



Devcon

®

Flexane

®

 FC Liquid

A convenient, time-saving method of

filling expansion joints and repairing

rubber.

•8-minute working time

•No-mess dispensing with fast, easy,



  400ml reusable cartridges

• Dispenser: #15043

 (manual)

   Nozzle #15047

Item #

     Size

15050

      400ml cartridge

Devcon

®

Flexane

®

 Brushable

High-performance brushable urethane for

protection against abrasion and impact.

• Excellent for repairing/coating



   rubber-lined pumps, tanks  and valves

• Applies in thicknesses of 50 mils in



    one application



Item #

Size

15350 1lb

Devcon

®

 R-Flex™

NEW! The newest belt repair product in the

market place. A self-leveling urethane kit

for repairing holes and tears in conveyor

belts. Also used to cover and protect clips /

pins from scrapers.

• Functional cure in 90 minutes

• High adhesion with surface pull of the

    SBR rubber

• Kit includes surface conditioner

Item #

Size

15550  4lb

11

Technical Information

Physical Properties

Devcon

®

 R-Flex

™

Devcon

®

 Flexane

®

Belt Repair Kit

Devcon

®

 Flexane

®



 80 Putty

Devcon

®

 Flexane

®



Brushable

Devcon

®

 Flexane

®



High Performance

Putty

Devcon

®

 Flexane

®



Fast Cure Putty

Devcon

®

 Flexane

®



 Fast Cure Liquid

Color

Black

Black

Black

Black

Black

Black

Grey

Mix ratio by weight

resin:hardener

88:12

72:28

72:28

80:20

94:6

80:20

80:20

Mixed viscosity   cP

Putty

Putty

Putty

40,000

Putty

Putty

5,800

Pot life minutes @ 75˚F

4

20

20

45

10

8

8

Specific volume inches

3

/

pound

27.4

23.5

23.5

26.0

23.5

23.5

26.5

Coverage per pound inches

2



@ 1/4" thickness

110

94

94

104

94

94

106

Functional cure hours

1 1/2

12

12

18

16

3

2

Demolding time hours

N/A

N / A

N/A

N/A

N/A

N/A

N/A

Cured hardness

(ASTM D2240)    Shore A

92

87

87

86

78

88

94

Cured shrinkage

(ASTM D2566)    inch/inch

NA

0.0014

0.0014

0.232

0.12

2

0.0014

0.0018

Tensile strength

(ASTM D412)    psi

1,462

1,700

1,700

3,500

4,500

2,400

3,300

Tear resistance

(ASTM D624)    pli

270

300

300

400

400

275

430

Abrasion resistance

weight loss

1

270

280

280

90

140

220

330

Maximum elongation

(ASTM D412)    %

421

300

300

600

600

500

450

Dielectric strength

(ASTM D149 )    volts/mil

350

350

350

340

350

350

350

Maximum continuous wet

service temperature   ˚F

120

120

120

120

120

120

120

Maximum continuous dry

service temperature   ˚F

180

180

180

180

180

180

180

Key:               Excellent               Very Good              Fair               Poor

NOTES:





1



Taber H-18 wheel (mg/ 1,000 revolutions @ 1,000 gram load)

2



Due to solvent loss

Chemical Resistance

Devcon

®

 R-Flex™

Devcon

®

 Flexane

®

Belt Repair Kit

Devcon

®

 Flexane

®



 80 Putty

Devcon

®

 Flexane

®



Brushable

Devcon

®

 Flexane

®



High Performance

Putty

Devcon

®

 Flexane

®



Fast Cure Putty

Devcon

®

 Flexane

®



 Fast Cure Liquid

ACIDS
Acetic 10%
Hydrochloric 10%
Sulfuric 10%
Sulfuric 50%
Phosphoric 10%

ALCOHOLS
Methanol
Isopropanol



KETONES
Acetone
Methyl ethyl ketone

ALKALIS
Ammonium hydroxide 20%
Sodium hydroxide 10%

HYDROCARBONS
Gasoline (unleaded)
Mineral spirits

SALTS
Sodium chloride
Trisodium phosphate
Aluminum sulfate 10%
Sodium carbonate 10%

Belting & Rubber Repair

Flexible urethane technologies for repairing worn or damaged SBR conveyor belts, rubber lined equipment such as pipes

and tanks in mines, quarries, and coal-fired power plants.  These products are in a non-sag putty for patching and

repairing linings along with self-leveling thixotropic versions that create a smooth surface for repairing conveyor belts.

Devcon

®

 Flexane

®

 80 Liquid

Medium-viscosity (10,000 cP) urethane

fills voids completely and faithfully

reproduces mold detail.

• Cures to semi-rigid rubber



   (Shore A 87)

• Cures at room temperature to a

   semi-rigid rubber material

Item #

Size

15800 1lb

15810 10lb

Devcon

®

 Flexane

®

 94 Liquid

Low-viscosity (6,000 cP) urethane fills

voids completely and faithfully reproduces

mold detail.

• Similar to Flexane

®

 80 Liquid, but

   cures to (Shore A 97)

• Requires only a five hour demolding

    time

Item #

Size

15250 1lb

15260 10lb

Devcon

®

 Flex-Add

™



Used with Flexane

®

 80 Liquid to produce

a more flexible urethane.

• Creates a lower durometer



   castable urethane

• Can match existing hardness of

   rubber

Item #

Size

15940  8oz

Devcon

®

Liquid Release Agent

Silicone release agent prevents Devcon’s

epoxy and urethane compounds from

sticking to patterns or mold surfaces.

• Produces a high gloss finish

• Facilitates the accurate duplication

    of intricate details

Item #

Size

19600 1pt



Devcon

®

Flexane

®

 Primer

Required for maximum adhesion of

Flexane

®

 products.

FL-10 Primer for all metals.

FL-20 Primer for rubber, wood, fiberglass

and concrete.

FL-40 Primer for rubber. Ensures ultimate

peel strength (greater than 80 psi)

Item #

Primer

Size

15980  FL-10

4oz

15985  FL-20

4oz

15984  FL-40

4oz

12

13

Physical Properties

Devcon

®

 Flexane

®



80 Liquid

Devcon

®

 Flexane

®



94 Liquid

Color

Black

Black

Mix ratio by weight  resin:hardener

77:23

69:31

Mixed viscosity   cP

10,000

6,000

Pot life minutes @ 75˚F

30

10

Specific volume inches

3

/pound

26.5

26.5

Coverage per pound inches

2

  @ 1/4" thickness

106

106

Functional cure hours

16

16

Demolding time hours

10

5

Cured hardness (ASTM D2240)    Shore A

87

97

Cured shrinkage (ASTM D2566)    inch/inch

0.0018

0.0014

Tensile strength (ASTM D412)    psi

2,100

2,800

Tear resistance (ASTM D624)    pli

350

415

Abrasion resistance weight loss

1

285

330

Maximum elongation (ASTM D412)    %

650

500

Dielectric strength (ASTM D149 )    volts/mil

350

350

Maximum continuous wet service temperature   ˚F

120

120

Maximum continuous dry service temperature   ˚F

180

180

Technical Information

Key:               Excellent               Very Good              Fair               Poor

Chemical Resistance

Devcon

®

 Flexane

®



 80 Liquid

Devcon

®

 Flexane

®



 94 Liquid

ACIDS
Acetic 10%
Hydrochloric 10%
Sulfuric 10%
Sulfuric 50%
Phosphoric 10%









ALCOHOLS
Methanol
Isopropanol









KETONES
Acetone
Methyl ethyl ketone









ALKALIS
Ammonium hydroxide 20%
Sodium hydroxide 10%









HYDROCARBONS
Gasoline (unleaded)
Mineral spirits







SALTS
Sodium chloride
Trisodium phosphate
Aluminum sulfate 10%
Sodium carbonate 10%









NOTES:





1



Taber H-18 wheel (mg/ 1,000 revolutions @ 1,000 gram load)

Devcon

®

Titanium Putty

High-performance, nonrusting

titanium-reinforced epoxy putty for making

repairs that can be precision machined.

• Withstands heavy loads in harsh

    chemical environments

• High compressive strength

Item #

Size

10760   1lb

10770   2lb

Devcon

®

Ceramic Repair Putty

Trowelable,  alumina-filled epoxy

compound for rebuilding, smoothing and

protecting processing equipment exposed

to corrosion, erosion, cavitation, chemicals

and acids.

• Temperature range up to 350°F

• Excellent for filling voids and



   rebuilding metal castings

Item #

Size

11700   3lb

Devcon

®

Ceramic Repair

Compound

Trowelable, alumina-filled epoxy

compound with a 45-minute pot life and

larger kit size for bigger jobs of



rebuilding, smoothing and protecting

processing equipment.

• Temperature range up to 350°F

• Excellent for filling voids and



    rebuilding metal castings

Item #

Size

11730 32lb

Devcon

®

Brushable Ceramic

When applied in a 15-20 mil coating, this

low-viscosity, alumina-filled, brushable

epoxy compound produces a smooth,

protective barrier against wear, abrasion,

corrosion, erosion and chemical attack.

• Temperature range up to 350°F

• Brushable Ceramic white is NSF 61

    Certified.



Item #

Size

11760

2lb (red)

11762

12lb (red)

11765 2lb (blue)
11767 12lb (blue)
11770

2lb (white)

Ceramic filled epoxy technology used to make permanent repairs to pumps, shafts, pipes, and tanks where a

corrosion-resistant polymer is needed to protect all metals against corrosion and erosion in slurry applications.

These products apply easily with a brush or trowel.

Corrosion Repair Compounds

14

15

Technical Information

Physical Properties

Devcon

®

Titanium

Putty

Devcon

®

Brushable Ceramic

Red, Blue

Devcon

®

Brushable Ceramic

White

Devcon

®

Ceramic Repair

Putty

Devcon

®

Ceramic Repair

Compound

Color

Grey

Red, Blue

White

Dark Blue

Dark Blue

Mix ratio by weight / volume

resin:hardener

4.3:1 / 3:1

5.6:1 / 3.4:1

8:5:1 / 5:6:1

7:1 / 4.3:1

4.7:1 / 3.3/1

Mixed viscosity   cP

Putty

32,000

40,000

Putty

Putty

Functional cure hours

16

16

16

16

16

Pot life minutes @ 75˚F

21

40

21

25

45

Specific volume inches

3

/pound

11.7

17.5

16.5

16.4

17.9

Coverage per pound inches

2

 @ 1⁄4" thickness

47

7.6

1

7.6

1

66

72

Cured hardness

(ASTM D2240)    Shore D

87

90

87

90

86

Cured shrinkage

(ASTM D2566)    inch/inch

0.0010

0.0020

0.0020

0.0022

0.0024

Adhesive tensile shear

(ASTM D1002)    psi

2,000

2,000

2,000

2,000

2,231

Compressive strength

(ASTM D695)    psi

15,200

15,200

15,200

12,700

10,240

Flexural strength

(ASTM D790)    psi

7,700

3,800

3,800

6,475

5,870

Modulus of elasticity

(ASTM D638)    psi x 105

9.5

8,000

8,000

9.0

8.1

Coefficient of thermal expansion (ASTM D696)

[(in)/(in x ˚F)] x 10

-6

22

9.0

9.0

17

20

Thermal conductivity (ASTM C177)

[(cal x cm)/(sec x  cm2 x ˚C)]  x 10

-3

1.95

19

19

1.88

1.72

Dielectric constant

(ASTM D150 )    1 kHz

44.8

1.92

1.92

41.0

38.0

Dielectric strength

(ASTM D149 )    volts/mil

56

382

382

370

350

Maximum continuous dry

service temperature   ˚F

350

350

350

350

350

Chemical Resistance

Devcon

®

Titanium

Putty

Devcon

®

Brushable Ceramic

Red, Blue

Devcon

®

Brushable Ceramic

White

Devcon

®



Ceramic Repair

Putty

Devcon

®



Ceramic Repair

Compound

ACIDS
Acetic 10%
Hydrochloric 10%
Sulfuric 10%

ALCOHOLS
Methanol
Isopropanol

KETONES
Acetone
Methyl ethyl ketone

ALKALIS
Ammonium hydroxide 20%
Sodium hydroxide 10%

HYDROCARBONS
Gasoline (unleaded)
Mineral spirits

CHLORINATED HYDROCARBONS
1-1-1 Trichloroethane

SALTS
Sodium chloride
Trisodium phosphate

Key:               Excellent               Very Good              Fair               Poor

NOTES:





1



Coverage (feet

2

 @ 15mils)

Metal Repair Epoxies

16

Devcon

®

Plastic Steel

®

 Liquid (B)

A pourable steel-filled epoxy that provides

accurate detail reproduction in making

holding fixtures, light gauge forming dies

and molds.

• Can be drilled, tapped and machined

• Qualifies under Federal Specification

    MMM-A-1754, Adhesive/Sealing



Item #

Size

10210 1lb

10220  4lb

10230 25lb

Devcon

®

Aluminum Liquid (F-2)

Aluminum-filled pourable epoxy for making

molds, patterns and holding fixtures.

• It can be drilled, tapped and machined

• Hardens in just over 1 hour; cures in 16

    hours

• Qualifies under Federal Specification

    MMM-A-1754, Adhesive/Sealing

Item #

Size

10710 1lb

10720 3lb

Devcon

®

 Plastic Steel

®

 Putty (A)

The original metal-filled epoxy putty, it is

ideal for repairing areas where welding or

brazing would be impractical.

• Can be drilled, tapped and machined.

• Conforms to the requirements of



    MIL-PRF-24176C, Type I

Item #

Size

10110 1lb

10120  4lb

10130 25lb

Devcon

®

Plastic Steel

®

 5 Minute

®



Putty (SF)

Fast-curing, steel-filled epoxy for

emergency repairs at temperatures as low

as 40°F.

• Repaired parts can be returned to



    service within one hour

• Mixes, applies, and cures at

    tempera tures as low as 40°F

Item #

Size

10240   1lb

Devcon

®

Stainless Steel Putty

(ST)

Stainless steel-filled epoxy putty for

patching, repairing and rebuilding stainless

steel surfaces as well as food processing

equipment.

• Bonds to ferrous and non-ferrous metals

• NSF 61 Certified

Item #

Size

10270   1lb

Devcon

®

 Aluminum Putty

Aluminum-filled epoxy putty for

dependable nonrusting repairs to

aluminum castings, machinery and

equipment.

• Can be machined drilled or tapped using



    conventional metalworking tools

• Widely used in HVAC applications, it

    conforms to requirements of

    MIL-PRF-24176C, Type II

Item #

Size

10610 1lb

10620 3lb

Metal-filled epoxy technology that allow for fast economical permanent repairs to power plant and mining equipment.

They can be machined, tapped and drilled, and corrosion resistant to harsh chemicals.  These products are available in

pourable versions that can be used to provide accurate detail reproductions for short run prototype mold patterns,

holding fixtures and forming dies.

17

Technical Information

Physical Properties

Devcon

®

Plastic Steel

®



Putty

(A)

Devcon

®

Plastic Steel

®

Liquid (B)

Devcon

®

Plastic Steel

®



5 Minute

®

 Putty

(SF)

Devcon

®

Stainless Steel

Putty

(ST)

Devcon

®

Aluminum

Putty

(F)

Devcon

®

Aluminum

Liquid (F-2)

Color

Dark Grey

Dark Grey

Dark Grey

Grey

Aluminum

Aluminum

Mix ratio by weight / volume

resin:hardener

9:1 / 2.5:1

9:1 / 3:1

1.7:1 / 1:1

11:1 / 3.75:1

9:1 / 4:1

9:1 / 5:1

Mixed viscosity   cP

Putty

15 / 25,000

Putty

Putty

Putty

15 / 25,000

Functional cure hours

16

16

1

16

16

16

Pot life minutes @ 75˚F

45

45

5

58

60

75

Specific volume inches

3

/pound

11.9

13.1

12.2

12.4

17.5

17.5

Coverage per pound inches

2

@ 1⁄4"

thickness

48

52

49

50

70

70

Cured hardness

(ASTM D2240)    Shore D

85

85

85

85

85

85

Cured shrinkage

(ASTM D2566)    inch/inch

0.0006

0.0006

0.0006

0.0010

0.0008

0.0009

Adhesive tensile shear

(ASTM D1002)    psi

2,800

2,800

2,026

2,385

2,600

2,700

Compressive strength

(ASTM D695)    psi

8,260

10,200

10,400

8,400

8,420

9,820

Flexural strength

(ASTM D790)    psi

5,600

7,480

7,680

5,280

6,760

7,180

Modulus of elasticity

(ASTM D638)    psi x 10

5



8.5

8.5

7.5

8.0

8.0

7.5

Coefficient of thermal

expansion (ASTM D696)

[(in)/(in x ˚F)] x 10

-6

48

38

34

34

29

50

Thermal conductivity (ASTM C177)

[(cal x cm)/(sec x  cm

2

 x ˚C)]  x 10

-3

1.37

1.39

2.65

1.23

1.73

1.58

Dielectric constant

(ASTM D150 )    1 kHz

67.5

67.5

35.0

75.0

21.4

8.6

Dielectric strength

(ASTM D149 )    volts/mil

30

30

30

30

100

100

Maximum continuous dry

service temperature   ˚F

250

250

200

250

250

250

Chemical Resistance

Devcon

®

Plastic Steel

®



Putty

(A)

Devcon

®

Plastic Steel

®

Liquid (B)

Devcon

®

Plastic Steel

®



5 Minute

®

 Putty

(SF)

Devcon

®

Stainless Steel

Putty

(ST)

Devcon

®

Aluminum

Putty

(F)

Devcon

®

Aluminum

Liquid (F-2)

ACIDS
Acetic 10%
Hydrochloric 10%
Sulfuric 10%

ALCOHOLS
Methanol
Isopropanol



KETONES
Acetone
Methyl ethyl ketone

ALKALIS
Ammonium hydroxide 20%
Sodium hydroxide 10%

HYDROCARBONS
Gasoline (unleaded)
Mineral spirits

CHLORINATED
HYDROCARBONS
1-1-1 Trichloroethane

SALTS
Sodium chloride
Trisodium phosphate

Key:               Excellent               Very Good              Fair               Poor

18

Devcon

®

 Bronze Putty

Bronze-filled epoxy putty for repairing

bronze and brass bushings, shafts,

castings and equipment parts.

• Repairs and rebuilds areas where



    brazing would be  undesirable or

    impossible

• Bonds securely to bronze alloys, brass,

    copper, and ferrous metals

Item #

Size

10260 1lb

Devcon

®

 FasMetal

™

High-performance, alumina-filled epoxy

for making fast, dependable emergency

repairs to leaks in pipes.

• Hardens in 5 minutes

• Economical and convenient



Item #

Size

10780 1lb

Devcon

®

 Wear Resistant Putty

(WR2)

Smooth, non-rusting, all-purpose epoxy

putty for repairs requiring low-friction

finishes, such as machine lathe beds.

• Bonds to steel, iron, aluminum, ceramic,

    concrete, brass, and   some plastics

• Contains wear-resistant fillers for low

    friction applications

Item #

Size

11410

1lb

11420

3lb

Devcon

®

 HVAC Repair (Special F)

Aluminum-filled epoxy adhesive for HVAC

repairs.

• Repairs coils in compressors

• Hardens to a rigid bond that can be

    ground, drilled or tapped

Item #

Size

19770 1lb

Devcon

®

 Underwater Repair (UW)

High-performance technology for repairing,

patching, and rebuilding equipment in

habitually wet environments, including

under water.

• Non-rusting; easy-to-mix and apply

• Eliminates the need for substrate to be

    thoroughly dry before repair

Item #

Size

10260 1lb

Metal-filled epoxy technology that allow for fast economical permanent repairs to power plant and mining equipment.

They can be machined, tapped and drilled, and corrosion resistant to harsh chemicals.  These products are available in

pourable versions that can be used to provide accurate detail reproductions for short run prototype mold patterns,

holding fixtures and forming dies.

Devcon

®

Cleaner Blend 300

Safe, multi-purpose, nontrichloroethane

based degreaser for removing heavy

grease and oil from metal surfaces.

• Needs no rinsing; leaves no residue

• Evaporates fast

Item #

Size

19510 1pt

Devcon

®

Liquid Release Agent

Silicone release agent prevents Devcon’s

epoxy and urethane compounds from

sticking to patterns or mold surfaces.

• Produces a high gloss finish

• Facilitates the accurate duplication

    of intricate details

Item #

Size

19600 1pt

Metal Repair Epoxies

19

Key:               Excellent               Very Good              Fair               Poor

Physical Properties

Devcon

®

Bronze Putty

(BR)

Devcon

®

Wear Resistant

Putty

(WR-2)

Devcon

®

Underwater

Repair Putty (UW)

Devcon

®

FasMetal

™

Devcon

®

HVAC Repair

(Special F)

Color

Bronze

Dark Grey

Grey

Grey

Grey

Mix ratio by weight / volume

resin:hardener

9:1 / 3:1

9:1 / 4:1

1.4:1 / 1:1

 1.07:1 / 1:1

 0.9:1 / 1:1

Mixed viscosity   cP

Putty

Putty

Putty

Putty

40,000

Functional cure hours

16

16

24

1

16

Pot life minutes @ 75˚F

35

45

45

4

60

Specific volume inches

3

/pound

12.4

13.9

17.0

17.2

16.1

Coverage per pound  inches

2

@ 1⁄4"

thickness

50

56

68

69

64

Cured hardness

(ASTM D2240)    Shore D

85

85

82

90

85

Cured shrinkage

(ASTM D2566)    inch/inch

0.0010

0.0005

0.0020

0.0093

0.0008

Adhesive tensile shear

(ASTM D1002)    psi

2,680

2,200

2,685

2,000

2,500

Compressive strength

(ASTM D695)    psi

8,540

9,800

5,625

12,700

8,420

Flexural strength

(ASTM D790)    psi

6,180

6,500

4,990

7,700

6,260

Modulus of elasticity

(ASTM D638)    psi x 10

5



8.0

7.5

7.5

8.5

7.8

Coefficient of thermal expansion

(ASTM D696)

[(in)/(in x ˚F)] x 10

-6

33

32

18

32

29

Thermal conductivity (ASTM C177)

[(cal x cm)/(sec x  cm

2

 x ˚C)]  x 10

-3

1.57

1.67

1.41

2.04

1.73

Dielectric constant

(ASTM D150 )    1 kHz

75.0

6.3

8.6

18.6

21.4

Dielectric strength

(ASTM D149 )    volts/mil

25

400

150

370

100

Maximum continuous dry

service temperature   ˚F

250

250

250

250

250

Chemical Resistance

Devcon

®

Bronze Putty

(BR)

Devcon

®

Wear Resistant

Putty

(WR-2)

Devcon

®

Underwater

Repair Putty (UW)

Devcon

®

FasMetal

™

Devcon

®

HVAC Repair

(Special F)

ACIDS

Acetic 10%

Hydrochloric 10%

Sulfuric 10%

ALCOHOLS

Methanol

Isopropanol

KETONES

Acetone

Methyl ethyl ketone

ALKALIS

Ammonium hydroxide 20%

Sodium hydroxide 10%

HYDROCARBONS

Gasoline (unleaded)

Mineral spirits

CHLORINATED

HYDROCARBONS

1-1-1 Trichloroethane

SALTS

Sodium chloride

Trisodium phosphate

Technical Information

Korrobond crusher backing compounds are two component products used as shock absorbing compounds in

cone crushing machines. Extensively used within the quarrying and mining industries, Korrobond has a

worldwide reputation for reliability.  Korrobond products are formulated to produce a low viscosity, tough and

flexible backing. Korrobond serves as a backing and reinforcing layer between machine parts and as a damper

when subjected to impact and shock loads.

The Korrobond 95 product maintains cone-crushing machinery to an optimal level, ensuring peak performance and

reliable solutions that;

• Prolong the life of the machinery while protecting against impact and shock vibrations

• Enhance productivity

• Offers maximum savings on labor

• Are easily applied by engineering personnel with minimal training

• Has a proven track record to perform in all types of cone crushers and climates

Crusher Backing Compounds

NOW AVAILABLE IN NORTH AMERICA

20

Technical Information

Korrobond 95

High-strength epoxy liquid for use in rod, ball, pebble

and autogenous mills, as well as in cone and gyratory

crushers.

• Easy to pour, low viscosity liquid

• Negligible shrink and low exothermic reaction,

    which assures consistent interface between

    epoxy and manganese or steel surfaces

Item #

Size

81095        20lb kit

Chemical Resistance

Korrobond 95

ACIDS
Acetic 10%
Hydrochloric 10%
Sulfuric 10%

ALCOHOLS
Methanol
Isopropanol

KETONES
Acetone
Methyl ethyl ketone

ALKALIS
Ammonium hydroxide 20%
Sodium hydroxide 10%

HYDROCARBONS
Gasoline (unleaded)
Mineral spirits

CHLORINATED HYDROCARBONS
1-1-1 Trichloroethane

SALTS
Sodium chloride
Trisodium phosphate

Physical Properties

Korrobond 95

Color

Red

Mix ratio by weight /

volume resin:hardener

100:5.94 / 9.9:1

Mixed viscosity   cP

10,320

Functional cure hours

8-10

Pot life minutes @ 75˚F

56

Specific volume

inches

3

/pound

17.2

Coverage per kit

inches

2

@ 1⁄4" thickness

349

1

Cured hardness

(ASTM D2240)    Shore D

85

Cured shrinkage

(ASTM D2566)    inch/inch

0.0006

Adhesive tensile shear

(ASTM D1002)    psi

5,300

Lap Sheer (psi)

1,179

Compressive strength

(ASTM D695)    psi

13,510

Flexural strength

(ASTM D790)    psi

10,310

Coefficient of thermal

expansion (ASTM D696)

[(in)/(in x ˚F)] x 10

-6

22

Side Impact
(in - lbs)

41

Maximum continuous dry

service temperature ˚F

250



1



Coverage in inches

2

 / 20.4 pound unit

21

Crusher Backing Compounds

Surface Preparation

General Surface Preparation
In general, the following steps will help

you properly prepare a surface prior to

applying Devcon

®

 products:

1)  Make sure the surface is completely

dry. Moisture will adversely affect the

strength of the bond to the surface.

2)  Remove all surface contamination

(paint, rust and grime) by abrasive blast-

ing, sanding or other

mechanical means.

3)  Degrease with Devcon

®

 Cleaner Blend

300.

4)  Abrade the surface to roughen it and

create a surface profile.

5) Use the appropriate Devcon

®

 primer.

For detailed surface preparation

procedures, refer to the appropriate

substrate category and tech data sheet.

Metal

To properly prepare a metal surface:

1)  If the surface is oily or greasy, degrease

it with Devcon

®

 Cleaner Blend 300.

2)  Abrasive-blast the surface with 25-40

grit (or coarser) to produce a good

surface profile. If you cannot

abrasive-blast the surface, use a 60

grit or coarser sandpaper to achieve a

similar result.

3)  Immediately coat the metal surface with

Flexane

®

 FL-10 Primer to prevent it from

rusting.

4)  Make repairs as soon as possible after

blasting the substrate to avoid oxidation

or flash rusting.

Rubber

To properly prepare a rubber surface:

1)  Abrade the surface using a rubber rasp

or a grinder with a wire wheel to produce

a good surface profile. (Oils and con-

taminants imbedded in the rubber

surface are typically released in this

process.)

2)  Remove all oil and grease from the rub-

ber surface with Devcon

®

 Cleaner Blend

300 and an abrasive pad.

3)  Wipe the surface with a clean, lint-free

cloth continuously until black residue is

no longer picked up by the white cloth.

4)  Prime the surface as follows:


  Rubber to metal:

 Coat all metal sur-

faces (including stainless steel and alu-

minum) with two coats of Flexane

®

 FL-10

Primer. The primer will significantly

improve adhesion of Devcon products

to metal.

Aluminum Surfaces

Oxidation on aluminum surfaces reduces

epoxy adhesion. This oxidation film must

be removed before repairing aluminum

with Devcon

®

 Metal Repair Epoxies.

To properly prepare an aluminum surface:

1)  Remove oxidation by mechanical means

such as

grit-blasting or by chemical means such

as acid etching.

2)  Follow the General Surface Preparation

guidelines.

The key to a successful repair is proper preparation and thorough cleaning prior to applying repair products or protective

coatings.

22

     Rubber



  Rubber to metal (for immersion

service):



Coat any metal that will be immersed

in an aqueous solution with Flexane

®



FL-10 Primer and Flexane

®

 FL-20

Primer. First apply the FL-10 Primer and

let dry for 60 minutes. Next, coat with

the FL-20 Primer. Let dry for 30 minutes

before applying the Devcon

®

 product.



Rubber to rubber:

 Coat all gum rub-

bers, neoprene or cured urethanes with

a thin coat of Flexane

®

 FL-20 Primer.

For ultimate peel strength, use Surface

Conditioner  (on rubber only).



 Rubber to concrete:

 Coat concrete

with Flexane

®

 FL-20 Primer. Multiple

coats may be necessary because

concrete is very porous. Let the primer

dry for 30 minutes between coats.



 Rubber to wood or fiberglass:

 Coat

these surfaces with Flexane

®

 FL-20

Primer. Soft woods will require a second

coat due to their absorption

characteristics.

     When bonding rubber to other surfaces,

contact Technical Service for a recom-

mendation on primers and surface

preparation procedures.

If you have questions, please contact Technical Service: 1-855-489-7262

23

Concrete

To properly prepare a concrete surface:

1)  Degrease the surface with Devcon

®



Cleaner Blend 300 or any

water-based emulsifying cleaner

and rinse thoroughly. Multiple

cleanings may be necessary. Power

washers or steam cleaners are very

effective and can reduce the number

of passes needed to clean the surface.

Let the surface dry thoroughly before

proceeding.

2)  Remove any cap-curing agents that were

applied to the concrete when it was

poured. These agents form a dense,

impenetrable finish, making it almost

impossible for coatings to adhere to

them.

3)  Shot blast (Blastrac

®

) the concrete to

create a porous surface profile. This

will improve surface “wetting” and

coating or repair product adhesion.

Wet Surfaces

In general, Devcon

®

 repair products and

protective coatings will not adhere to wet

surfaces.

To properly repair a wet surface:

1)  Review the General Surface Preparation

guidelines.

2)  Thoroughly dry the surface. (If you are

using Devcon

®

 Underwater Repair Putty

(UW), refer to Underwater Surfaces

section.)

3)  Stop all leaks or seepage as follows:




t

 Shut off the flow or pressure;



t

  Fit a wooden peg or a sheet metal

screw into the hole; or



t

  Stuff wax, cork, plumber’s caulk,

Mortite or a cloth into the opening.

     If the leak is caused by corrosion, the

sidewall might be weak. Open the orifice

until sound metal is exposed and the wall

is thick enough to be plugged.

4)  Remove surface condensation

(sweating) or dampness with a heat gun

or similar device.

Underwater Surfaces

To properly prepare an underwater surface:

1)  Remove all dirt, barnacles, flaking paint

or algae/seaweed from the surface.

2)  Wipe the surface with a clean cloth to

remove any film. Although you cannot

degrease underwater, wiping and

 turning a clean cloth will often remove

any film from the surface.

3)  Abrade the surface if possible. (Use a

file or other mechanical means.)

4)  Remove oxidation by mechanical means

such as high-pressure water or grit-

blasting, or by chemical means such as

acid etching.

Blastrac

®

 is a registered trademark of Blastrac, NA

Before

After

24

Agency Approvals

Specification

Product

Part #

Size

MIL-PRF-24176C, Type I

Plastic Steel

®

 Putty (A)

10110, 10120, 10130

1lb, 4lb, 25lb

MIL-PRF-24176C, Type I

Titanium Putty

10760, 10770

1lb, 2lb

MIL-PRF-24176C, Type I

Ceramic Repair Putty

11700

3lb

MIL-PRF-24176C, Type II

Aluminum Putty (F)

10610, 10620

1lb, 3lb

MMM-A-1754

Plastic Steel

®

 Liquid (B)

10210, 10220, 10230

1lb, 4lb, 25lb

MMM-A-1754

Aluminum Liquid (F-2)

10710, 10720

1lb, 3lb

ABS

Flexane

®

 Brushable

15350

1lb

ABS

Plastic Steel

®

 Putty (A)

10110, 10120, 10130

1lb, 4lb, 25lb

ABS

Plastic Steel

®

 5 Minute

®

 Putty (SF)

10240

1lb

ABS

Titanium Putty

10760, 10770

1lb, 2lb

ABS

Stainless Steel Putty (ST)

10270

1 lb

ABS

Bronze Putty

10260

1 lb

ABS

Ceramic Repair Putty

11700

3lb

ABS

Plastic Steel

®

 Liquid (B)

10210, 10220, 10230

1lb, 4lb, 25lb

ABS

Aluminum Liquid (F2)

10710, 10720

1lb, 3lb

ABS

Brushable Ceramic Red

11760, 11762

2lb, 12lb

ABS

Brushable Ceramic Blue

11765, 11767

2lb, 12lb

ABS

Brushable Ceramic White

11770

2lb

NSF/ANSI 61

Stainless Steel Putty

10270

1 lb

NSF/ANSI 61

Brushable Ceramic White

11770

2 lb

ANSI/NSF 61

NSF

®

Product Name







 Item #



 Size

            Page

Devcon

®

 400ml Dispensing System





15043, 15047



Gun/Mix Nozzle



Devcon

®

 Aluminum Liquid (F-2)







10710, 10720



1lb, 3lb

16

Devcon

®

 Aluminum Putty (F)







10610, 10620



1lb, 3lb

16

Devcon

®



Bronze

Putty

(BR)    10260

  1lb

18

Devcon

®

 Brushable Ceramic Blue







11765, 11767



2lb, 12lb

14

Devcon

®

 Brushable Ceramic Red







11760, 11762



2lb, 12lb

14

Devcon

®



Brushable

Ceramic

White

   11770

  2lb

14

Devcon

®

 Carbide Putty







10050, 10080



3lb, 20lb

               8

Devcon

®

Ceramic

Repair

Compound

   11730

  32lb

14

Devcon

®



Ceramic

Repair

Putty

   11700

  3lb

14

Devcon

®



Cleaner

Blend

300

   19510

  1pt

18

Devcon

®

 Combo Wear (FC)







11450





9lb



              8

Devcon

®

 DFense Blok

™



    11330

  30lb

6

Devcon

®

 DFense Blok

™



Fast

Cure

(FC)

   11350

  9lb



6

Devcon

®

 DFense Blok

™

Power Mixer





   11301

  81lb

6

Devcon

®

 DFense Blok

™



Quick

Patch

   11320

  1lb

6

Devcon

®

 DFense Blok

™

 Surface Wetting Agent (SWA)



11340





1 lb

6

Devcon

®

 FasMetal

™





    10780

  1lb

18

Devcon

®

 Flex-Add

™



    15940

  8oz



12

Devcon

®

 Flexane

®

 80 Liquid







15800, 15810



1lb, 10lb

12

Devcon

®

 Flexane

®

 80 Putty







15280, 15850



1lb, 4lb

10

Devcon

®

 Flexane

®

 94 Liquid







15250, 15260



1lb, 10lb

12

Devcon

®

 Flexane

®



Belt

Repair

Kit

   15165

  Kit

10

Devcon

®

 Flexane

®



Brushable

   15350

  1lb

10

Devcon

®

 Flexane

®

 Fast Cure Liquid





15050





400ml cartridge

             10

Devcon

®

 Flexane

®

 Fast Cure Putty







15049





400ml cartridge

             10



Devcon

®

 Flexane

®

 High Performance Putty





15330





1lb

 10

Devcon

®

 Flexane

®

Primer

FL-10

   15980

  4oz

12

Devcon

®

 Flexane

®

Primer FL-20

15985

4oz

12

Devcon

®

 Flexane

®

Primer FL-40

15984

4oz

12

Devcon

®

 HVAC Repair (Special F)







19770





1lb



            18

Devcon

®



HV

Tile

Adhesive    11489

  20lb

8

Devcon

®



Liquid

Release

Agent

   19600

  1pt

18

Devcon

®

 Plastic Steel

®

 5 Minute

®

 Putty (SF)





10240





1lb

16

Devcon

®

 Plastic Steel

®

 Liquid B







10210, 10220, 10230

1lb, 4lb, 25lb

             16

Devcon

®

 Plastic Steel

®

 Putty A







10110, 10120, 10130

1lb, 4lb, 25lb                                    16

Devcon

®



Stainless

Steel

Putty

   10240

  1lb

16

Devcon

®



Tile

Adhesive

    11495

  20lb



8

Devcon

®



Titanium

Putty

    10760,

10770

 1lb,

2lb

14

Devcon

®

 Wear Guard

™



Fine

Load

   11470

  30lb



8

Devcon

®

 Wear Guard

™



High

Impact

   11460

  30lb



8

Devcon

®

 Wear Guard

™



High

Load

   11490

  30lb



8

Devcon

®

 Wear Guard

™



High

Temp

   11480

  30lb



8

Devcon

®

 Wear Guard

™



Ultra

   11475

  30lb



8

Devcon

®

 Wear Resistant Putty (WR-2)





11410, 11420



1lb, 3lb

18

Devcon

®

Underwater

Repair

Putty

(UW)   11800

  1lb

18

Korrobond 95









81095





20lb kit



             21

10

Product Index

25

Devcon

®

 R-Flex

™



15550

4lb

10

MSDS/TDS

All MSDS and TDS are available on our website at www.devcon.com

Customer Service

All purchase orders are placed with ITW Polymers Adhesives North America.

Warranty

Warranty:  ITW Polymers Adhesives, North America will replace any material found defective.  Because of

the storage, handling and application of this material is beyond our control, we can accept no liability for the

reults obtained.

Disclaimer

All information is based on laboratory testing and is not intended for design purposes.  ITW Polymers

Adhesives North America makes no representations or warranties of any kind concerning this data.

26

27

30 Endicott Street

Danvers, MA  01923

855-489-7262

www.itwwagroup.com

©2013 ITW Wear & Abrasion Group. All rights reserved. All trademarks are the property of Illinois Tool Works.
