X463

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  sales@ascapacitor.com

Fax:  (308) 284-8324

web:  www.ascapacitor.com

50VDC

50VDC

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

CAP
(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

0.0010

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.02

0.082

0.220"

(5.6mm)

0.532"

(13.5mm)

24

1.48

0.0012

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.02

0.10

0.235"

(6.0mm)

0.532"

(13.5mm)

24

1.80

0.0015

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.03

0.12

0.251"

(6.4mm)

0.532"

(13.5mm)

24

2.16

0.0018

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.03

0.15

0.251"

(6.4mm)

0.532"

(13.5mm)

24

2.70

0.0022

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.04

0.18

0.266"

(6.8mm)

0.532"

(13.5mm)

24

3.24

0.0027

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.05

0.22

0.235"

(6.0mm)

0.657"

(16.7mm)

24

1.65

0.0033

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.06

0.27

0.235"

(6.0mm)

0.657"

(16.7mm)

24

2.03

0.0039

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.07

0.33

0.251"

(6.4mm)

0.657"

(16.7mm)

24

2.48

0.0047

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.08

0.39

0.266"

(6.8mm)

0.657"

(16.7mm)

24

2.93

0.0056

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.10

0.47

0.282"

(7.2mm)

0.657"

(16.7mm)

24

3.53

0.0068

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.12

0.56

0.313"

(8.0mm)

0.657"

(16.7mm)

24

4.20

0.0082

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.15

0.68

0.313"

(8.0mm)

0.782"

(19.9mm)

22

3.40

0.010

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.18

0.82

0.328"

(8.3mm)

0.782"

(19.9mm)

22

4.10

0.012

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.22

1.00

0.359"

(9.1mm)

0.782"

(19.9mm)

22

5.00

0.015

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.27

1.25

0.375"

(9.5mm)

0.782"

(19.9mm)

22

6.25

0.018

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.32

1.50

0.422"

(10.7mm)

0.782"

(19.9mm)

22

7.50

0.022

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.40

1.80

0.391"

(9.9mm)

0.907"

(23.0mm)

22

6.30

0.027

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.49

2.00

0.391"

(9.9mm)

0.907"

(23.0mm)

22

7.00

0.033

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.59

3.00

0.469"

(11.9mm)

0.907"

(23.0mm)

22

10.50

0.039

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.70

4.00

0.547"

(13.9mm)

0.907"

(23.0mm)

22

14.00

0.047

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.85

5.00

0.563"

(14.3mm)

1.094"

(27.8mm)

20

15.00

0.056

0.188"

(4.8mm)

0.532"

(13.5mm)

24

1.01

8.00

0.594"

(15.1mm)

1.344"

(34.1mm)

20

16.00

0.068

0.204"

(5.2mm)

0.532"

(13.5mm)

24

1.22

10.0

0.641"

(16.3mm)

1.344"

(34.1mm)

20

20.00

PAGE 1 OF 5

METALLIZED POLYCARBONATE
TAPE WRAP AND EPOXY FILL CASE

LIMITED AVAILABILITY!! - SEE AVAILABILITY NOTE ON PAGE 5

X463

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  sales@ascapacitor.com

Fax:  (308) 284-8324

web:  www.ascapacitor.com

100VDC

100VDC

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

CAP
(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

0.0010

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.03

0.082

0.219"

(5.6mm)

0.657"

(16.7mm)

24

1.1

0.0012

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.04

0.10

0.235"

(6.0mm)

0.657"

(16.7mm)

24

1.4

0.0015

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.05

0.12

0.251"

(6.4mm)

0.657"

(16.7mm)

24

1.7

0.0018

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.06

0.15

0.266"

(6.8mm)

0.657"

(16.7mm)

24

2.1

0.0022

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.07

0.18

0.282"

(7.2mm)

0.657"

(16.7mm)

24

2.5

0.0027

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.09

0.22

0.313"

(8.0mm)

0.657"

(16.7mm)

24

3.1

0.0033

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.11

0.27

0.328"

(8.3mm)

0.782"

(19.9mm)

22

2.3

0.0039

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.12

0.33

0.359"

(9.1mm)

0.782"

(19.9mm)

22

2.8

0.0047

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.15

0.39

0.375"

(9.5mm)

0.782"

(19.9mm)

22

3.3

0.0056

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.18

0.47

0.422"

(10.7mm)

0.782"

(19.9mm)

22

4.0

0.0068

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.22

0.56

0.438"

(11.1mm)

0.782"

(19.9mm)

22

4.8

0.0082

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.26

0.68

0.391"

(9.9mm)

0.907"

(23.0mm)

22

4.4

0.010

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.32

0.82

0.422"

(10.7mm)

0.907"

(23.0mm)

22

5.3

0.012

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.38

1.00

0.454"

(11.5mm)

0.907"

(23.0mm)

22

6.5

0.015

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.48

1.25

0.485"

(12.3mm)

0.907"

(23.0mm)

22

8.1

0.018

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.58

1.50

0.547"

(13.9mm)

0.907"

(23.0mm)

22

9.8

0.022

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.70

1.80

0.547"

(13.9mm)

1.094"

(27.8mm)

20

9.0

0.027

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.86

2.00

0.594"

(15.1mm)

1.094"

(27.8mm)

20

10.0

0.033

0.204"

(5.2mm)

0.532"

(13.5mm)

24

1.1

3.00

0.641"

(16.3mm)

1.344"

(34.1mm)

20

10.5

0.039

0.220"

(5.6mm)

0.532"

(13.5mm)

24

1.2

4.00

0.750"

(19.1mm)

1.344"

(34.1mm)

20

14.0

0.047

0.235"

(6.0mm)

0.532"

(13.5mm)

24

1.5

5.00

0.718"

(18.2mm)

1.594"

(40.5mm)

20

12.5

0.056

0.251"

(6.4mm)

0.532"

(13.5mm)

24

1.8

8.00

0.766"

(19.5mm)

1.907"

(48.4mm)

18

16.0

0.068

0.266"

(6.8mm)

0.532"

(13.5mm)

24

2.2

10.0

0.859"

(21.8mm)

1.907"

(48.4mm)

18

20.0

PAGE 2 OF 5

METALLIZED POLYCARBONATE
TAPE WRAP AND EPOXY FILL CASE

LIMITED AVAILABILITY!! - SEE AVAILABILITY NOTE ON PAGE 5

X463

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  sales@ascapacitor.com

Fax:  (308) 284-8324

web:  www.ascapacitor.com

200VDC

200VDC

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

CAP
(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

0.0010

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.06

0.082

0.344"

(8.7mm)

0.657"

(16.7mm)

24

1.9

0.0012

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.07

0.10

0.282"

(7.2mm)

0.782"

(19.9mm)

22

1.5

0.0015

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.08

0.12

0.313"

(8.0mm)

0.782"

(19.9mm)

22

1.8

0.0018

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.10

0.15

0.344"

(8.7mm)

0.782"

(19.9mm)

22

2.3

0.0022

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.12

0.18

0.375"

(9.5mm)

0.782"

(19.9mm)

22

2.7

0.0027

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.15

0.22

0.391"

(9.9mm)

0.782"

(19.9mm)

22

3.3

0.0033

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.18

0.27

0.391"

(9.9mm)

0.907"

(23.0mm)

22

3.0

0.0039

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.21

0.33

0.422"

(10.7mm)

0.907"

(23.0mm)

22

3.6

0.0047

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.26

0.39

0.454"

(11.5mm)

0.907"

(23.0mm)

22

4.3

0.0056

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.31

0.47

0.484"

(12.3mm)

0.907"

(23.0mm)

22

5.2

0.0068

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.37

0.56

0.484"

(12.3mm)

1.094"

(27.8mm)

20

4.8

0.0082

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.45

0.68

0.547"

(13.9mm)

1.094"

(27.8mm)

20

5.8

0.010

0.204"

(5.2mm)

0.532"

(13.5mm)

24

0.55

0.82

0.578"

(14.7mm)

1.094"

(27.8mm)

20

7.0

0.012

0.220"

(5.6mm)

0.532"

(13.5mm)

24

0.66

1.00

0.625"

(15.9mm)

1.094"

(27.8mm)

20

8.5

0.015

0.235"

(6.0mm)

0.532"

(13.5mm)

24

0.83

1.25

0.594"

(15.1mm)

1.344"

(34.1mm)

20

7.5

0.018

0.251"

(6.4mm)

0.532"

(13.5mm)

24

1.0

1.50

0.641"

(16.3mm)

1.344"

(34.1mm)

20

9.0

0.022

0.266"

(6.8mm)

0.532"

(13.5mm)

24

1.2

1.80

0.719"

(18.3mm)

1.344"

(34.1mm)

20

10.8

0.027

0.282"

(7.2mm)

0.532"

(13.5mm)

24

1.5

2.00

0.750"

(19.1mm)

1.344"

(34.1mm)

20

12.0

0.033

0.313"

(8.0mm)

0.532"

(13.5mm)

24

1.8

3.00

0.812"

(20.6mm)

1.594"

(40.5mm)

20

13.5

0.039

0.251"

(6.4mm)

0.657"

(16.7mm)

24

0.90

4.00

0.906"

(23.0mm)

1.594"

(40.5mm)

20

18.0

0.047

0.266"

(6.8mm)

0.657"

(16.7mm)

24

1.1

5.00

0.906"

(23.0mm)

1.907"

(48.4mm)

18

20.0

0.056

0.282"

(7.2mm)

0.657"

(16.7mm)

24

1.3

8.00

1.016"

(25.8mm)

2.407"

(61.1mm)

18

24.0

0.068

0.313"

(8.0mm)

0.657"

(16.7mm)

24

1.6

10.0

1.110"

(28.2mm)

2.407"

(61.1mm)

18

30.0

PAGE 3 OF 5

METALLIZED POLYCARBONATE
TAPE WRAP AND EPOXY FILL CASE

LIMITED AVAILABILITY!! - SEE AVAILABILITY NOTE ON PAGE 5

X463

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  sales@ascapacitor.com

Fax:  (308) 284-8324

web:  www.ascapacitor.com

400VDC

400VDC

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

CAP
(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

0.0010

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.11

0.056

0.422"

(10.7mm)

0.782"

(19.9mm)

22

1.7

0.0012

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.13

0.068

0.375"

(9.5mm)

0.907"

(23.0mm)

22

1.5

0.0015

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.16

0.082

0.422"

(10.7mm)

0.907"

(23.0mm)

22

1.8

0.0018

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.20

0.10

0.454"

(11.5mm)

0.907"

(23.0mm)

22

2.2

0.0022

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.24

0.12

0.501"

(12.7mm)

0.907"

(23.0mm)

22

2.6

0.0027

0.188"

(4.8mm)

0.532"

(13.5mm)

24

0.29

0.15

0.501"

(12.7mm)

1.094"

(27.8mm)

20

2.6

0.0033

0.220"

(5.6mm)

0.532"

(13.5mm)

24

0.36

0.18

0.563"

(14.3mm)

1.094"

(27.8mm)

20

3.1

0.0039

0.220"

(5.6mm)

0.532"

(13.5mm)

24

0.43

0.22

0.610"

(15.5mm)

1.094"

(27.8mm)

20

3.7

0.0047

0.235"

(6.0mm)

0.532"

(13.5mm)

24

0.51

0.27

0.687"

(17.4mm)

1.094"

(27.8mm)

20

4.6

0.0056

0.251"

(6.4mm)

0.532"

(13.5mm)

24

0.61

0.33

0.641"

(16.3mm)

1.344"

(34.1mm)

20

4.0

0.0068

0.251"

(6.4mm)

0.532"

(13.5mm)

24

0.74

0.39

0.719"

(18.3mm)

1.344"

(34.1mm)

20

4.7

0.0082

0.235"

(6.0mm)

0.657"

(16.7mm)

24

0.38

0.47

0.766"

(19.5mm)

1.344"

(34.1mm)

20

5.6

0.010

0.251"

(6.4mm)

0.657"

(16.7mm)

24

0.46

0.56

0.750"

(19.1mm)

1.594"

(40.5mm)

20

5.3

0.012

0.266"

(6.8mm)

0.657"

(16.7mm)

24

0.55

0.68

0.828"

(21.0mm)

1.594"

(40.5mm)

20

6.5

0.015

0.282"

(7.2mm)

0.657"

(16.7mm)

24

0.69

0.82

0.906"

(23.0mm)

1.594"

(40.5mm)

20

7.8

0.018

0.313"

(8.0mm)

0.657"

(16.7mm)

24

0.83

1.00

0.874"

(22.2mm)

1.907"

(48.4mm)

18

7.5

0.022

0.344"

(8.7mm)

0.657"

(16.7mm)

24

1.0

1.25

1.000"

(25.4mm)

1.907"

(48.4mm)

18

9.4

0.027

0.282"

(7.2mm)

0.782"

(19.9mm)

22

0.81

1.50

1.094"

(27.8mm)

1.907"

(48.4mm)

18

11.3

0.033

0.344"

(8.7mm)

0.782"

(19.9mm)

22

0.99

1.80

1.172"

(29.8mm)

1.907"

(48.4mm)

18

13.5

0.039

0.359"

(9.1mm)

0.782"

(19.9mm)

22

1.2

2.00

1.063"

(27.0mm)

2.407"

(61.1mm)

18

11.0

0.047

0.375"

(9.5mm)

0.782"

(19.9mm)

22

1.4

3.00

1.250"

(31.8mm)

2.407"

(61.1mm)

18

16.5

PAGE 4 OF 5

METALLIZED POLYCARBONATE
TAPE WRAP AND EPOXY FILL CASE

LIMITED AVAILABILITY!! - SEE AVAILABILITY NOTE ON PAGE 5

X463

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  sales@ascapacitor.com

Fax:  (308) 284-8324

web:  www.ascapacitor.com

PAGE 5 OF 5

GENERAL SPECIFICATIONS

PHYSICAL CHARACTERISTICS

CONSTRUCTION:

 NON-INDUCTIVE WOUND METALLIZED POLYCARBONATE.

CASE:

  FLAME RETARDANT TAPE WRAP CASE AND EPOXY FILL.

LEAD MATERIAL:

  AXIAL SOLDER COATED OR TINNED SOLID WIRE, AWG AS SPECIFIED IN TABLES.

DIMENSIONS:

 AS SPECIFIED IN TABLES.

ELECTRICAL CHARACTERISTICS

CAPACITANCE:

  AS SPECIFIED IN TABLES ± REQUESTED TOLERANCE WHEN MEASURED AT OR

REFERRED TO 1000 ± 20 HZ AND 25 ± 5 °C.

TOLERANCE:

  ±1%, ±2%, ±5%, ±10%, AND ±20% AVAILABLE.  OTHER TOLERANCES AVAILABLE UPON

REQUEST.

DISSIPATION FACTOR:

  SHALL NOT BE GREATER THAN 0.3% WHEN MEASURED AT OR REFERRED TO

1000 ± 20 HZ AND 25 ± 5 °C.

INSULATION RESISTANCE:

  SHALL BE GREATER THAN 100,000 M

Ω

 FOR CAPACITANCE VALUES 0.50 µF

AND LESS OR 50,000 M

Ω

 X µF FOR CAPACITANCE VALUES GREATER THAN 0.50 µF WHEN MEASURED

AFTER 2 MINUTES ELECTRIFICATION AT RATED VOLTAGE AND 25 ± 5 °C.

DIELECTRIC STRENGTH:

  200% RATED VOLTAGE FOR 1 MINUTE THROUGH A LIMITING RESISTANCE

OF 100 OHMS/VOLT AT 25 ± 5 °C.

RATED VOLTAGE:

  50VDC, 100VDC, 200VDC, AND 400VDC AVAILABLE.

TEMPERATURE:

  -55 °C TO +125 °C AT FULL RATED VOLTAGE OPERATIONAL TEMPERATURE, +125 °C

MAX STORAGE TEMPERATURE.

ADDITIONAL INFORMATION

ORDERING INFORMATION:

  ALL ASC CAPACITORS ARE ORDERED BY "FAMILY CAP-TOL-VOLT"

DESIGNATION.  (I.E.  TO ORDER A X463 0.01µF, ±5%, 400VDC CAPACITOR, REQUEST PART NUMBER
"X463 .01-5-400")

SEE ALSO:

  "GENERAL INFORMATION - POLYCARBONATE CAPACITORS" DOCUMENT FOR ADDITIONAL

PHYSICAL, ELECTRICAL, AND PERFORMANCE CHARACTERISTICS NOT MENTIONED IN THIS FILE.

WARNING:

  INFORMATION ON THIS FILE IS SUBJECT TO CHANGE WITHOUT NOTICE AT ASC'S

DISCRETION.

AVAILABILITY:

  POLYCARBONATE DIELECTRIC IS NO LONGER MANUFACTURED FOR CAPACITOR

PRODUCTION.  AVAILABILITY IS LIMITED TO REMAINING ASC RAW MATERIAL AND FINISHED GOODS
STOCK.  POLYCARBONATE DIELECTRIC IS NOT RECOMMENDED FOR NEW OR ONGOING DESIGNS.

LAST MODIFIED:  09/26/01

METALLIZED POLYCARBONATE
TAPE WRAP AND EPOXY FILL CASE
