141 Mount Bethel Road

Warren, NJ 07059



www.anadigics.com

(908) 791-6000

RF Solutions for CATV Subscriber and Infrastructure Applications

January 2005

ANADIGICS CATV Subscriber and Infrastructure Products

SOLUTIONS

From our industry leading tuner components to our widely deployed reverse amplifiers and line amplifiers,
ANADIGICS subscriber and infrastructure ICs for the CATV market offer best of breed performance, with the
best prices and reliability in the industry.

Our line of video tuner, data tuner and reverse amplifier products provide turnkey solutions for your set
top box, cable modem and residential gateway platforms. For your CATV infrastructure needs, we offer a
complete selection of 12V and 24V line amplifiers, and 5V and 8V drop amplifiers.

TECHNOLOGY

Our state of the art 6-inch GaAs manufacturing facility allows us to produce cost-effective MESFET and HBT
based products with superior performance, and our strategic foundry partnerships give us access to other
process technologies that have become increasingly vital to the industry.

SUPPORT AND DELIVERY

At ANADIGICS, we deliver.  As a proven high-volume manufacturing leader, we have the muscle to meet your
production needs.  And our design, applications and sales personnel provide world-class support to help you

make your CATV designs a production reality.



SUBSCRIBER ICs

SUBSCRIBER ICs

INFRASTRUCTURE AMPLIFIER ICs

Note 1:  110 channel flat output, +34 dBmV per channel





Note 2:  110 channel flat output, +44 dBmV per channel





Note 3:  77 channels, +56 dBmV output per channel,
            13.5 dB tilt at 870 MHz





Note 4:  110 channel flat output, +40 dBmV per channel





Note 5:  160 channel flat output, +17 dBmV per channel
Note 6:  80 channel flat output, +19 dBmV per channel





Note 7:  160 channel flat output, +23 dBmV per channel





Note 8:  77 channels, +58 dBmV output per channel, 13.5 dB tilt at 870 MHz





Note 9:  132 channels flat output, +25 dBmV per channel



Note 10:  132 channels flat input, +15 dBmV per channel at input





Note 11:  77 channel flat output, +42 dBmV per channel
Note 12:  New product under development

Note 1:  New product under development

Note 1:  New product under development

Name

Part #

RF Input

Frequency

(MHz)

Typical

Gain (dB)

Max Output

Noise @ Max

Attenuation

(160KHz BW)

Typical

2nd Harmonic

Level ( 10 MHz)

Typical

3rd Harmonic

Level ( 10 MHz)

Typical 1dB

Compression

Point (dBmV)

Attenuation

Range/Step

Size (dB)

ARA05050

5-100

32

-54.6 dBmV

-60 dBc (5 MHz)

-63 dBc (25 MHz)

-63 dBc (5 MHz)

-63 dBc (25 MHz)

+70

30/2

ARA1400

5-100

32

-54.6 dBmV

-57 dBc

-64 dBc

+70

56/4

ARA2000

5-100

29.3

-53.8 dBmV

-75 dBc

-60 dBc

+68.5

58/1

ARA2004

5-100

29.3

-53.8 dBmV

-75 dBc

-60 dBc

+68.5

58/1

ARA2005

5-100

29.3

-53.8 dBmV

-75 dBc

-60 dBc

+68.5

58/4

Reverse Amplifier

for IP Telephony

ARA3000

5-100

16

(3.5 dB typ NF)

-55 dBc

-60 dBc

+70

56/2

Note 1:  New product under development

Reverse Amplifiers

for CATV and Cable

Modems

(1)

Name

Part #

RF Input

Frequency

(MHz)

RF Output

Frequency

(MHz)

Typical

Conversion

Gain (dB)

Typical

Noise Figure

 (dB)



Typical CSO/CTB

or IMD3 (dBc)

Typical

10 KHz Offset

Phase Noise

(dBc/Hz)

Supply

Voltage

(V)

Typical Power

Consumption

(W)

CATV/TV/

Cable Modem

UpConverter

ACU50752

50-860

900-1200

8

6.5

-60/-60

-84

+5

0.600

Tuner UpConverter

ACU2109

50-860

900-1200

8

6.5

-60/-60

-89

+5

0.770

DBS Tuner

ADC20013

950-2050

480

11

6.5

-40

-70

+5

0.300

ACD0900

900-1200

35-150

9.5

8

-59

-89

+5

0.400

ACD2202

900-1200

35-150

10

8

-53 max

-90

+5

0.565

ACD2206

900-1200

35-150

31

8

-53 max

-90

+5

1.065

2-Wire Interface

Tuner

Downconverter

ACD2203

ACD2205

900-1200

900-1200

35-150

35-150

10

31

8

8

-53 max

-53 max

-90

-90

+5

+5

0.565

1.065

ABA3100

12

2.5

-72/-75

NA

+5

0.750

ABA3115

15

2.5

-72/-75

NA

+5

0.750

Tuner

Downconverters

(3-wire interface)

50-1000

50-1000

Low Noise

Amplifiers

Note 1: New product under development

(1)

Name

 Part #

No. of

Outputs

Operating

Freq. (MHz)

Typical

Gain (dB)

Typical AGC

Range (dB)

Typical

Noise Figure

(dB)

Typical

CSO/CTB

(dBc)

Supply

Voltage

(V)

Supply

Current

(mA)

 APS3600

(1)



4

50 to 1000

5

28

4.8

 -70/-70

+5

230



Active

Splitter



APS3604

3

50 to 1100

5

28

4.8

 -66/-66

+5

175

(1) new product under development

Note 1:  New product under development

SUBSCRIBER ICs

Name

Part #

Maximum

CSO (dBc)

Maximum

CTB (dBc)

Typical  Gain

(dB)

Typical

Noise Figure (dB)

Minimum

Return Loss

(dB)

Supply Voltage

(V)

Max Current

Consumption

(mA)

ACA1205

-66

(1)

-64

(1)

15

2.5

18

+12

200

ACA0861A

-66

(1)

-64

(1)

11.9

3

18

+12

200

ACA0861B

-60

(2)

-57

(2)

12

3

18

+12

330

ACA0861C

-68

(1)

-68

(1)

12

3

18

+12

275

ACA0861D

-68

(2)

-66

(2)

12.1

3

18

+12

490

ACA2404

(12)

-78

(8)

-75

(8)

21.3

5

18

+24

500 typ

ACA2407

-69

(3)

-74

(3)

21.3

4

18

+24

435

ACA2407E

-64

(3)

-66

(3)

21.3

4

18

+24

440

ACA2402

-70

(4)

-71

(4)

21.8

3.5

18

+24

260

ACA2402E

-62

(11)

-68

(11)

21.8

3.5

18

+24

265

ACA2408

-60 typ

(4)

-60 typ

(4)

34.5

3.5

18

+24

290 typ

ADA1200

-63 typ

(10)

-70 typ

(10)

10

2.5

(see data sheet)

+5

75 typ

ADA10000

-60

-62

-65

-74

15

2

(see data sheet)

+8

150

ADA10001

-60

(7)

-65

(7)

15

2

(see data sheet)

+8

150

ABA3100

-72 typ

(9)

-75 typ

(9)

12

2.5

10

+5

170

ABA3115

-72 typ

(9)

-75 typ

(9)

15

2.5

10

+5

170

Drop Amplifiers

Low Noise Amplifiers

24 V Push-Pull

Line Amplifiers

24 V Power Doubler

Line Amplifiers

12 V Power Doubler

Line Amplifiers

12 V Push-Pull

Line Amplifiers

(5)
(6)

(5)
(6)
