274

Fuse Holders and Blocks

Global Modular Fuse Holders

CH Series - 8x32, 10x38, 14x51, 22x58,
Class CC

Specifications
Description:

The ‘CH’ line of modular fuse holders

accommodates many fuses from around the world, including
North American Class-CC, Midget, Class gR, aR HSF, and
IEC Industrial Ferrule (Class gG and aM) in four physical
sizes: 8x32, 10x38, 14x51 and 22x58mm.

With

Indicator

Without

Indicator

CHM1DIU

CHM1DU

CHM2DIU

CHM2DU

CHM3DIU

CHM3DU

CHM4DIU

CHM4DU

CHM1DNIU

CHM1DNU

1 pole + 1

neutral

CHM3DNIU

CHM3DNU

3 poles +

1 neutral

CHM1DI-48U

UL 48Vdc/30A;

IEC

48Vdc/32A

CHM1DNXU

IEC 690V/32A

IEC60269-2

1 neutral

n/a

CHPV1IU

CHPV1U

CHPV2IU CHPV2U

CHCC1DIU

CHCC1DU

CHCC2DIU

CHCC2DU

CHCC3DIU

CHCC3DU

CHCC1DI-48U

UL 48Vdc/30A

SCCR

Rating

Cooper Bussmann

Fuses

Voltage &

Current

Catalog Number

Agency

Markings

Number

of Poles

Terminal

Rating

Series &

Size

CHPV

CHCC

Class CC

CHM

10x38

and

Midget

UL & IEC;

1000Vdc/30A

UR, CSA,

UL4248-18,

IEC60269-1

Solid,

Stranded,

Fine

Stranded,

Spade

Lug, Comb

Bus Bar;

Single and
Dual Wire;

75ºC and

90ºC Cu

wire

33kA rms

sym

UL 600V/30A

200kA

rms sym

600V/30A;

IEC

690V/32A

cURus; IEC

60269-2

LP-CC, FNQ-R,

KTK-R

cULus

100kA

rms sym

FNQ, KLM, FNM,

KTK, BAF, FWA,

DCM, C10 SERIES,

AGU, BAN, FWC

Solar PV series

60269-2

Agency Information:

UL File E14853

Guide IZLT Listed, IZLT2 Recognized
CSA: File 47235, CHPV and CHM - Class 6225-30,
CHCC - Class 6225-01

Ratings:

600V/30A (UL)
690V/32A (IEC)

Wire Range:

#18 to #4 (0.8mm

to 21.1mm

)

Torque Ratings:

30 Lb-In (3.4 N•m) maximum

Flammability Ratings:

UL 94V0, self-extinguishing

Storage & Operating Temperature Range:

-20ºC to +90ºC (indicating)
-20ºC to +120ºC (non-indicating)

Features/Benefits

• High SCCR rated, UL Listed Class CC holder with indicator

option for 600Vac/dc and 48Vdc.

• UL Recognized midget and 10 x 38 holders with factory

assembled neutral pole option.

• Agency ratings up to 1000Vdc for use with solar PV fuses.

• Available remote PLC indication with the CH-PLC module.

• Terminals rated for use with 75ºC or 90ºC wire, fine

stranded wire, spade terminals and comb-bus bars. Use
any higher temperature rated wire with appropriate
derating.

• Complete range of UL Listed and high SCCR rated

1-phase and 3-phase finger-safe comb-bus bars and
power feed lugs.

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

275

Fuse Holder

& Blocks

For additional information see reorder #3185

Fuse Holders and Blocks

CHPV & CHPVI

CHM & CHMI

CHCC & CHCCI

Wire Range

Conductor

No. of

Torque

Type

Conductors

18-14 AWG

20 in-lbs

(0.8-2.0mm

)

Single

2.3 Nm

18-16 AWG

25 in-lbs

(0.8-1.3mm

)

Solid,

Dual

2.8 Nm

14-10 AWG

Stranded

(2.0-5.2mm

)

12-10 AWG

(3.3-5.2mm

)

8-4 AWG

Stranded,

30 in-lbs

(8.3-21.1mm

)

Fine

3.4 Nm

Stranded

18-14 AWG

Spade

Single

(0.8-2.0mm

)

Terminal

N/A

Comb Bus

USE MIDGET / 10X38 FUSE

75ºC OR 90ºC CU WIRE

DO NOT OPEN UNDER LOAD

Rated: 600V, 30A 50/60Hz

200kA RMS SYM 3W

Indication Min Voltage: 90V

IEC: 60269-2 32A

690Vac 120kA 3W

Degree of Protection IP20

Series: CHM

MADE IN

CHINA

GB13539

Rated: 600V, 30A 50/60Hz

200kA RMS SYM

Indication Min Voltage: 90V

Degree of Protection IP20

MADE IN

CHINA

Series: CHCC

430P

USE CLASS CC FUSE

75ºC OR 90ºC CU WIRE

DO NOT OPEN UNDER LOAD

Wire Range

Conductor

No. of

Torque

Type

Conductors

18-14 AWG

20 in-lbs

(0.8-2.0mm

)

Single

2.3 Nm

18-16 AWG

25 in-lbs

(0.8-1.3mm

)

Solid,

Dual

2.8 Nm

14-10 AWG

Stranded

(2.0-5.2mm

)

12-10 AWG

(3.3-5.2mm

)

8-4 AWG

Stranded,

30 in-lbs

(8.3-21.1mm

)

Fine

3.4 Nm

Stranded

18-14 AWG

Spade

Single

(0.8-2.0mm

)

Terminal

N/A

Comb Bus

GB13539

4GY1

UL4248-18

Rated: 1000Vdc, 30A 33kA RMS SYM

Indication Min Voltage: 90V

IEC: 60269-1 32A

1000Vdc 33kA 3.5W

Degree of Protection IP20

MADE IN

CHINA

Series: CHPV

Wire Range

Conductor

No. of

Torque

Type

Conductors

18-14 AWG

20 in-lbs

(0.8-2.0mm

)

Single

2.3 Nm

18-16 AWG

25 in-lbs

(0.8-1.3mm

)

Solid,

Dual

2.8 Nm

14-10 AWG

Stranded

(2.0-5.2mm

)

12-10 AWG

(3.3-5.2mm

)

8-4 AWG

Stranded,

30 in-lbs

(8.3-21.1mm

)

Fine

3.4 Nm

Stranded

18-14 AWG

Spade

Single

(0.8-2.0mm

)

Terminal

N/A

Comb Bus

USE PHOTOVOLTAIC 10X38 FUSE

75ºC OR 90ºC CU WIRE

DO NOT OPEN UNDER LOAD

GB13539

Rail Mount Fuse Blocks and Holders

Multi-Pole Ganging

Use multi-pole connection kit part number
JV-L to gang multiple poles together. One
JV-L kit is sufficient to gang up to 4 poles.

4mm
Lockout
Feature in
Fuse Carrier

Toolless
Ganging of
Multiple
Poles

Toolless DIN Rail
Mounting

Wire Strip
Length
Indicator

6mm Wire
Clamp Lug and
open bus bar
connection
(#4 to #18)

Captive, Fully
Backed Out
Phil-Slot Screw

Spade lug
connection

Self-Extinguishing,
UL 94V0 Rated
Polyester
Material

Label Slot

Optional
Open Fuse
Indicator

Hole for Wire
Security Tag

Features

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

277

Fuse Holder

& Blocks

Global Modular Fuse Holders

For additional information see reorder #3185

Fuse Holders and Blocks

Catalog Numbers

Max

No. of

Without

With*

Voltage

17.5mm

Indication

Size

& Current

IEC

Phase Configuration

Modules Wire Range

Maximum Torque

CH081D

CH081DI

•

1-pole

1-16mm

(18-8 AWG)

2.5 N•m (22LB-In)

CH081DNX

•

1 Neutral Pole

CH081DNS

CH081DNSI

•

1-pole + Neutral

1-10mm

(18-8 AWG)

2.0 N•m (17.5LB-In)

CH081DN

CH081DNI

CH08

IEC

•

1-pole + Neutral

CH082D

CH082DI

8x32

400Vac

•

2-pole

CH083D

CH083DI

25A

•

3-pole

1-16mm

(18-8 AWG)

2.5 N•m (22LB-In)

CH083DNS

CH083DNSI

•

3-pole + Neutral

CH083DN

CH083DNI

•

3-pole + Neutral

CH084D

CH084DI

•

4-pole

CHM1DU

CHM1DIU

•

1-pole

CHM2DU

CHM2DIU

•

2-pole

CHM3DU

CHM3DIU

CHM

600V/30A;

•

3-pole

CHM4DU

CHM4DIU

10X38

IEC

•

4-pole

CHM1DNU

CHM1DNIU

and

690V/32A

•

1-pole + Neutral

CHM3DNU

CHM3DNIU

Midget

•

3-pole + Neutral

1-21mm

(18-4 AWG)

3.4 N•m (30LB-In)

UL 48Vdc/30A;

–

CHM1DI-48U

IEC

•

1-pole

48Vdc/32A

CHM1DNXU

–

IEC 690V32A

•

1-pole + Neutral

CHPV1U

CHPV1IU

CHPV

UL & IEC;

•

†††

1-pole

CHPV2U

CHPV2IU

1000Vdc/30A

•

†††

2-pole

CHCC1DU

CHCC1DIU

1-pole

CHCC2DU

CHCC2DIU

CHCC

2-pole

1-21mm

(18-4 AWG)

3.4 N•m (30LB-In)

CHCC3DU

CHCC3DIU

Class CC

600V/30A

3-pole

CHCC1DI-48U

–

UL 48Vdc/30A

1-pole

CH141D

CH141DI

•

1-pole

1.5

CH141DMS

•

1-pole + Microswitch

1.5

CH141DNX

600Vac/dc

•

1 Neutral Pole

1.5

CH141DN

CH141DNI

40A

•

1-pole + Neutral

CH142D

CH142DI

CH14

(5 Watt)

•

†

2-pole

2.5-16mm

(14-6 AWG)

3.0 N•m (26LB-In)

CH143D

CH143DI

14x51

IEC

•

†

3-pole

4.5

CH143DMS

690Vac,

•

3-pole + Microswitch

4.5

CH143DN

CH143DNI

50A

•

3-pole + Neutral

CH143DNMS

•

3-pole + Neutral + Microswitch

CH144D

CH144DI

•

4-pole

CH221D

Not

•

†

1-pole

CH221DMS

Available

•

1-pole + Microswitch

CH221DNX

with

•

1 Neutral Pole

CH221DN

local

600Vac/dc,

•

1-pole + Neutral

CH222D

neon

CH22

100A

•

†

2-pole

2.5-50mm

(14-1 AWG)

4.0 N•m (35LB-In)

CH223D

indication

22x58

(9.5 Watt)

•

†

3-pole

CH223DMS

(remote

IEC

•

3-pole + Microswitch

CH223DN

microswitch

690Vac,

•

†

3-pole + Neutral

CH223DNMS

only)

125A

•

3-pole + Neutral + Microswitch

CH224D

•

4-pole

Class J

Neon

easy

ID™ Indication

Indication

CH30J1

CH30J1I

CH30J

UL/CSA

††

1-pole

—

1-50mm

(18-1 AWG)

1-8 AWG 4.0 N•m (35LB-In)

CH30J2

CH30J2I

30A

600Vac

††

2-pole

—

10-18 AWG 2.7N•m (24LB-IN)

CH30J3

CH30J3I

Class J

††

3-pole

—

CH60J1

CH60J1I

CH60J

UL/CSA

††

1-pole

—

1-50mm

(18-1 AWG)

1-8 AWG 4.0 N•m (35LB-In)

CH60J2

CH60J2I

60A

600Vac

††

2-pole

—

10-18 AWG 2.7N•m (24LB-In)

CH60J3

CH60J3I

Class J

††

3-pole

—

† UL Recognized (cURus)

†† UL LIsted (cULus)

††† UL Recognized, Standard 4248-18, CSA

For further details see Data Sheets 2053 (CH08, CHM, CHCC, CH14 AND CH22) and 2144 (CHJ Class J)
*90V miminum required for illumination
***12V mininum required for illumination

8x32 IEC

14x51 IEC

22x58 IEC

IEC

Class J 30A

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

281

Fuse Holder

& Blocks

Fuse Holders and Blocks

Class J Modular Fuse Holders

CH _ _ J _

Specifications
Description:

IP20 finger-safe, 1- to 3-pole Class J fuse

holder with DIN-Rail or panel mounting.

Ratings:

Volts: — 600Vac/dc (or less)

Amps: — 30A (30A version)

— 60A (60A version)

SCCR: — 200kA

Wire Range:

Cu solid and stranded conductors with single

(1-18AWG) and dual (3-18AWG) wire ratings. See Catalog
Numbers table for details.

Torque Rating:

10-18AWG 24 lb-in.

1-8AWG 35 lb-in.

Poles:

1-, 2- or 3-Pole.

Storage & Operating Temperature Range*:

-20°C to 75°C.

Agency Information:

CE, UL 4248/CSA 22.2 No. 4248.P

UL Listed, Guide IZLT, File E14853.

Flammability Rating:

UL 94V0.

Catalog Numbers

See Catalog Numbers table below.

Features and Benefits

• Choice of local fuse indication;

easy

ID™ viewing window (for

seeing indicator on LPJ-SPI indicating fuse) or neon lamp.

• Versatile 1-, 2- and 3-pole versions for 0-30A and 35-60A

fuses with dual wire rated connections simplify wiring.

• Improved electrical safety with IP20 finger-safe construction

with lock-out/tag-out feature. 3-phase fuse extraction
assures all phases are opened for service work.

• Flexible panel/35mm DIN-Rail mounting mounting options

*For fuse selection on applications above or below 25ºC, consult derating charts in

Bussmann publication “Selecting Protective Devices” (SPD).

Catalog Numbers

Catalog

# of

Local

Amp

Volts

IP20

AWG Single

Numbers

Poles

Indication

Rating (AC/DC) Finger-Safe Wire Range

Padlockable

Mounting

CH30J1

easy

ID**

CH30J1I

Neon Lamp***

CH30J2

easy

ID**

600

Yes

1-18

Yes

35mm DIN/ Panel

CH30J2I

Neon Lamp***

CH30J3

easy

ID**

CH30J3I

Neon Lamp***

CH60J1

easy

ID**

CH60J1I

Neon Lamp***

CH60J2

easy

ID**

600

Yes

1-18

Yes

35mm DIN/ Panel

CH60J2I

Neon Lamp***

CH60J3

easy

ID**

CH60J3I

Neon Lamp***

easy

ID™ viewing window, requires use of Bussmann LPJ_SPI permanent indication fuses.

*** Indication non-fuse dependent, minimum voltage 90Vac/115Vdc.

Dimensions (mm):

30 Amp Version

60 Amp Version

Data Sheet: 2144

Fuse Size

Poles

115

0-30A

115

125

35-60A

125

120

125

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

282

Fuse Holders and Blocks

Optima

™

Fuse Holder Module and Disconnect Switch

4.25

∑

(

0.03)

(108.0mm) (

0.76)

(6.9mm)

(18.8mm)

(7.9mm)

BUSS

5.72

∑

(

.045)

(145.3mm) (

1.14)

0.43

∑

(

0.03)

(10.9mm) (

0.76)

1.38

∑

(35.0mm)

0.23

∑

1.86

∑

(5.8mm)

3.17

∑

(80.5mm)

1.312

∑

(

0.01)

(33.3mm)

(

0.25)

Panel Mounting

Hole Pattern

(47.2mm)

Panel Mounting
Hole Pattern

3.74

∑

(

0.03)

(95.0mm) (

0.76)

0.57

∑

(

0.03)

(14.5mm) (

0.76)

0.27

∑

0.31

∑

Communication
Port

0.74

∑

0.50

∑

(12.7mm)

Communication
Port

0.44

∑

(11.2mm)

2T1

1L1

3L2

5L3

4T 2

6T3

1.76

∑

3.60

∑

(91.4mm)

(44.7mm)

0.224

∑

(5.6mm)

Data Sheet: 1103

Specifications
Description:

3-pole load break modular fuse holder and

disconnect switch for

⁄

x 1

⁄

˝ (10 x 38mm) fuses.

Dimensions:

See Dimensions illustration.

Poles:

Agency Information:

CE, UL (see table), CSA Certified,

C22.2 No. 39, Class 6225-01, File 47235, IEC (see table).

Flammability Rating:

UL 94V0.

Horsepower Rating of Switch

Volts

240

480

600

3-Phase

Recommended Fuse Types

Class CC

Midget (Non-Rejection)

European

LP-CC

KTK

C10M

KTK-R

FNM

C10G

FNQ-R

FNQ

Physical Characteristics

• Small size matches 45mm IEC starter width
• Accepts #8-18 AWG stranded, #10-18 AWG solid wire
• 3-pole
• Handle and shaft required for through the door operation

Features/Benefits

• Padlockable with finger-safe terminals for safety. Qualified

as IP20 per IEC 60529.

• Cam-action handle for easy module removal, offered with

Class CC rejection clips or European 10 x 38mm clips to
meet global needs

• Wire ready with 35mm DIN-Rail or screw panel mounting

(#8 screw, 1

⁄

” long) saves installation time

• Fuse indication lights with option for remote fuse status

available. See Data Sheet for additional wiring details.

Typical Applications

• Industrial Control
• Process Control Systems
• Automated Warehouse Systems
• Individual Control Circuits

Dimensions

Catalog Numbers

Catalog

SCCR**

Remote Open

UL Information

Numbers

Electrical Rating

Rating

Clips

Fuse Indication

Std.

File

Guide

IEC

OPM-1038SW

30A, 600Vac UL/CSA

Non-rejection,

Recognized

10x38mm or

32A, 660Vac IEC

⁄

” x 1

⁄

”

UL 508

E161278

NLRV2

IEC 60947-3

Yes

OPM-1038RSW

30A, 600Vac UL/CSA

100kA

Rejection,

Listed

Class CC

UL 508

E161278

NLRV

Yes

OPM-1038SWC

30A, 600Vac UL/CSA

Non-rejection,

Yes

Recognized

10x38mm or

32A, 660Vac IEC

⁄

” x 1

⁄

”

UL 508

E161278

NLRV2

IEC 60947-3

OPM-1038RSWC

30A, 600Vac UL/CSA

100kA

Rejection,

Yes

Listed

Class CC

UL 508

E161278

NLRV

*Rating varies depending on fuse used in module; 100kA maximum
**Short-Circuit Current Rating

O P M -

0 3

S W

Series

Fuse Type

Communication

Communication
Feature

Catalog Number Build-A-Code

OPM-1038 With Disconnect Switch

Blank

= 10 x

38mm or

⁄

” x 1-

⁄

”

= Class CC

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

283

Fuse Holder

& Blocks

Fuse Holders and Blocks

Optima

™

Fuse Holder Module

BUSS

3.74

∑

(

0.03)

(95.0mm)

(

0.76)

0.57

∑

(14.5mm)

0.23

∑

(5.8mm)

3.17

∑

(80.5mm)

3.22

∑

(

0.03)

0.27

∑

0.31

∑

(81.8mm) (

0.76)

3.60

∑

(

0.03)

(91.4mm) (

0.76)

1.76

∑

(

0.03)

(44.7mm) (

0.7 )

1.65

∑

(

0.03)

(41.9mm) (

± 0

.76)

1.312

∑

(

0.01)

(33.3mm)

(

0.25)

Panel Mount
Hole Pattern

1.86

∑

(

0.03)

(47.2mm)

(

0.76)

Panel Mount
Hole Pattern

3.60

∑

(

0.03)

(91.4mm) (

0.76)

Communication
Port

0.74

∑

Communication
Port

(6.9mm)

(18.8mm)

(7.9mm)

0.50

∑

(12.7mm)

0.44

∑

(11.2mm)

2T1

4T2

6T3

IL1

3L2

5L3

0.224"

(5.6mm)

Data Sheet: 1102

Specifications
Description:

3-pole modular fuse holder for

⁄

” x 1

⁄

”

(10 x 38mm) fuses.

Dimensions:

See Dimensions illustration.

Poles:

Agency Information:

CE, UL (see table), CSA Certified,

C22.2 No. 4248, Class 6225-01, File 47235, IEC (see table).

Flammability Rating:

UL 94V0.

Recommended Fuse Types

Class CC

Midget (Non-Rejection)

European

LP-CC

KTK

C10M

KTK-R

FNM

C10G

FNQ-R

FNQ

Physical Characteristics

• Small size matches 45mm IEC starter width
• Accepts #8-18 AWG stranded, #10-18 AWG solid wire
• 3-pole

Features/Benefits

• Padlockable with finger-safe terminals for safety. Qualified

as IP20 per IEC 529.

• Cam-action handle for easy module removal.
• Offered with Class CC rejection clips or European 10 x

38mm clips to meet global needs

• Wire ready with 35mm DIN-Rail or screw panel mounting

(#8 screw, 1

⁄

˝ long) saves installation time

• Fuse indication lights with option for remote fuse status

indication. See Data Sheet for additional wiring details.

Typical Applications

• Industrial Control
• Process Control Systems
• Automated Warehouse Systems
• Individual Control Circuits

Dimensions

O P M

Series

Fuse Type

Communication

C =
Communication
Feature

Blank

= 10 x

38mm or

⁄

˝ x 1

⁄

= Class CC

Catalog Number Build-A-Code

OPM-1038

Catalog Numbers

Catalog

SCCR**

Remote Open

UL Information

Numbers

Electrical Rating

Rating

Clips

Fuse Indication

Std.

File

Guide

IEC

OPM-1038

30A, 600Vac/dc UL/CSA

Non-rejection,

Recognized

E14853

IZLT2

IEC 60269-2-1

Yes

(Max 3 Watts per fuse)

10 x 38mm or

UL 4248

32A, 660V IEC

⁄

˝ x 1

⁄

OPM-1038R

30A, 600Vac/dc UL/CSA

200kA

Rejection,

Listed

E14853

IZLT

Yes

Class CC

UL 4248

OPM-1038C

30A, 600Vac/dc UL/CSA

Non-rejection,

Yes

Recognized

E14853

IZLT2

IEC 60269-2-1

(Max 3 Watts per fuse)

10 x 38mm or

UL 4248

32A, 660V IEC

⁄

˝ x 1

⁄

OPM-1038RC

30A, 600Vac/dc UL/CSA

200kA

Rejection,

Yes

Listed

E14853

IZLT

Class CC

UL 4248

*Rating varies depending on fuse used in module; 200kA maximum.

**Short-Circuit Current Rating

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

Fuse Holder Wire Range:

— 75°Cu Only
— #18-12 Single/Dual, torque 15lb-in
— #10-8

Single/Dual, torque 20lb-in

— Dual wire with same gauge and type

AWu

[mm2]

(N•m)/lb-in

Solid

#18-8 x 1

1-6 x 1

18-12 Single/Dual

#18-8 x 2

1-6 x 2Strld

#18-8 x 1

1-6 x 1

#18-8 x 2

1-6 x 2

10-8 Single/Dual

Ferrules

1-4 x 1

20in-lb (2.5 N•m)

1-4 x 2

Input Power Terminal Wire Range:

Wiring

Solid

(1) #14 to #2 (1.5 to 25mm

) conductor or

Conductor

(2) #14 to #6 (1.5 to 10mm

) conductors

Stranded

(1) #14 to #2 (1.5 to 25mm

) conductor or

Conductor

(2) #12 to #6 (2.5 to 10mm

) conductors

Tightening

Connector

20lb-in (2.2 N•m)

Torque:

Screw Clamp

15lb-in (1.7 N•m)

Materials:

—

Housing:

Thermoplastic - ULV2

—

Clip:

Tin-plated copper alloy

—

Contact lubricant:

Fluoroether grease

—

Saddle screw:

Plated steel

—

DIN rail springs:

Stainless steel

Optional Accessories:

Comb Bar (Max current rating = 63A)

GV2G245A46

2 circuit, 45mm between same phases

GV2G254A46

2 circuit, 54mm between same phases

GV2G272A46

2 circuit, 72mm between same phases

GV2G345A46

3 circuit, 45mm between same phases

GV2G354A46

3 circuit, 54mm between same phases

GV2G445A46

4 circuit, 45mm between same phases

GV2G454A46

4 circuit, 54mm between same phases

GV2G472A46

4 circuit, 72mm between same phases

GV2G554A46

5 circuit, 54mm between same phases

Input Terminal Block (Max current rating = 63A)

GV2G05

Input/Feed Through Power Terminal, Supports feed through to

another system, DIN-Rail mount only

GVG09

Input Power Terminal

Cover

GV1G10

Protective Cover for unused terminals on comb bar

Auxiliary Contacts

GVAE11

NO/NC

GVAE20

NO/NO

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

284

Fuse Holders and Blocks

Optima

™

Three-pole Overcurrent Protection Module

Data Sheet: 1109

Specifications
Description:

OPM-NG-SC3:

3-pole Class CC fuse holder for use with

Class CC fuses (Bussmann Types LP-CC,
FNQ-R, KTK-R).

OPM-NG-SM3:

3-pole fuse holder for use with

⁄

˝ x 1

⁄

˝ and

10.3 x 38mm fuses (Bussmann Types:

⁄

˝ x 1

⁄

˝; KTK, FNQ, KLM, 10 x 38mm;

FWA, FWC, C10G_ _, C10M_ _).

Ratings:

Volts: — OPM-NG-SC3: 600Vac (or less)

— OPM-NG-SM3: 600Vac (or less) UL and CSA 30A

— OPM-NG-SM3: 690Vac (or less) IEC 32A

Amps: — OPM-NG-SC3: 0-30A

— OPM-NG-SM3: 0-30A

SCCR:— OPM-NG-SC3: 200kA

— OPM-NG-SM3: Same as fuse IR, 200kA maximum

Agency Information:

CE, UL; OPM-NG-SC3 UL Listed, UL

4248, File E14853, Guide IZLT. OPM-NG-SM3, UL
Recognized, UL 4248, File E14853, Guide IZLT2. CSA
Certified, C22.2 No. 4248, Class 6225-01, File 47235. IEC
60947-3 Utilization Category AC20B.

Handling & Storage Temperature:

-10° to 65°C.

Features/Benefits

• 45mm width matches IEC starters
• 35mm DIN-Rail or panel mounting feature. Maximum screw

size #8 (M4)

• Pressure plate terminations with dual-wire rated terminals

(see Wire Table) and optional auxiliary contacts

• Integrated collapsible handle and fuse carrier cannot be

removed from holder base

• Padlockable and IP20 finger-safe to IEC60529

Typical Applications

• Mass Produced Control Systems
• Process Control Systems
• Automated Warehouse Systems
• Individual Control Circuits

OPM-NG-

75º Cu Only

AWG

[mm2]

(N•m)/lb-in

Solid

#18-8 x 1

1-6 x 1

18-12 Single/Dual

#18-8 x 2

1-6 x 2

15lb-in (1.7 N•m)

Stranded

#18-8 x 1

1-6 x 1

#18-8 x 2

1-6 x 2

10-8 Single/Dual

Ferrules

1-4 x 1

20lb-in (2.5 N•m)

1-4 x 2

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

287

Fuse Holder

& Blocks

Class J (Finger-safe) Fuse Holders

JT(N)600 Series fuse blocks can be dovetailed together within the same current rating to provide multiple pole block
configurations.

NOTE: JT(N)60030 cannot be dovetailed to JT(N)60060.

3.10

(78.7)

3.06

(77.7)

1.31

(33.3)

1.25

(31.8)

Din-rail

Slot

MOUNTING

Shown without fuse

pullout cover

4.40

(111.7)

2.96

(75.2)

1.52

(38.1)

.10

(2.6)

BUSS

35 – 60A
600VAC

USE CLASS J

FUSES

DO NOT REMOVE

UNDER LOAD

JT60060

BUSS

35 – 60A
600VAC

USE CLASS J

FUSES

DO NOT REMOVE

UNDER LOAD

JT60060

BUSS

35 – 60A
600VAC

USE CLASS J

FUSES

DO NOT REMOVE

UNDER LOAD

JT60060

1 pole

2 pole

3 pole

Data Sheet: 1152

Dimensions for JT60060 & JTN60060 — in (mm)

1.14

(29.0)

1.05

(26.7)

Slot

MOUNTING

Shown without fuse

pullout cover

BUSS

0 – 30A

600VAC

USE CLASS J

FUSES

DO NOT REMOVE

UNDER LOAD

JT60030

BUSS

0 – 30A

600VAC

USE CLASS J

FUSES

DO NOT REMOVE

UNDER LOAD

JT60030

BUSS

0 – 30A

600VAC

USE CLASS J

FUSES

DO NOT REMOVE

UNDER LOAD

JT60030

3.60

(91.4)

2.42

(61.3)

1.23

(31.2)

.07

(1.8)

1 pole

2 pole

3 pole

2.75

(69.9)

2.52

(64.1)

Din-rail

Dimensions for JT60030 & JTN60030 — in (mm)

Fuse Holders and Blocks

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

288

Fuse Holders and Blocks

SAMI™ Fuse Covers

Specifications
Description:

Indicating and non-indicating fuse covers for

Class J, RK1, RK5, H, K5, CC, G (0-30A) and midget-type
fuses. Indicating feature requires a minimum of 90Vac or
115Vdc to illuminate lamp. One cover required for each pole.

WARNING:

To avoid electrical shock, turn power off before

installing, removing or servicing.

Dimensions:

See Dimensions illustration.

Ratings:

Volts: — Non-Indicating

- 0-600Vac/dc

— Indicating

- 90 to 600Vac

-115 to 600Vdc

Amps: — 0-100A

Agency Information:

CE, UL Listed; SAMI-1I through

SAMI-6I, SAMI-8I and SAMI-9I, SAMI-1N through SAMI-6N,
SAMI-8N and SAMI-9N, UL Recognized; Guide JDVS2, File
E58836, SAMI-7I and SAMI-7N, CSA Certified,
File LR47235-93C.

Catalog Numbers

Catalog

Dimensions - in

Numbers*

Description

SAMI-1_

600V, J (0-30A) and 600V, T (35-60A)**

5.02

1.03

1.94

250V, RK, K5, H (35-60A)

SAMI-2_

600V, RK, K5, H (0-30A)

7.03

1.30

2.07

SAMI-3_

600V, J (65-100A)

7.03

1.30

2.33

SAMI-4_

250V, RK, K5, H (65-100A)

8.20

1.30

2.18

SAMI-5_

600V, RK, K5, H (35-60A)

8.20

1.30

2.18

SAMI-6_

600V, J (35-60A)

4.98

1.17

2.14

SAMI-7_

600V, Midget, Class CC, G (0-30A)

3.82

0.75

1.72

SAMI-8†_

600V, RK††, K5, H (65-100A)

10.38

1.50

2.33

SAMI-9_

250V, RK, K5, H (0-30A) and 600V,

3.82

0.75

1.72

T (0-30A)

*For indicating cover, add suffix “I”, for non-indicating cover, add suffix “N”.
Example: SAMI-7I = Indicating, SAMI-7N = Non-indicating.
**Available in non-indicating only.
†SAMI-8A adapter available for small Fusetron

™

body design. SAMI-8I and SAMI-8N come

standard with adapter (SAMI-8A).
††Not for use with KTS-R fuses.

Features and Benefits

• Insulated cover allows field conversion of fuses mounted in

open fuse blocks to dead front configuration.

• Optional open fuse indicating light aids in system

troubleshooting.

• Units are re-usable.
• Allows visual marking of line and load side of fuses.

Typical Applications

• Class H, R and J fuse blocks up to 100A
• Class T fuse blocks up to 60A
• Class CC, G and Midget, 30A fuse blocks

Dimensions

LINE

Buss

SAMI

-2

LOAD

TEST PROBE

FUSE

Data Sheet: 1204 (Trimming Guides: 12041, 12042, 12043, 12044, 12045, 12046, 12048, 12049)

SAMI-1I

SAMI-3I

SAMI-4I

SAMI-2I

SAMI-6I

SAMI-8I

SAMI-7I

SAMI™ Series

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

290

Fuse Holders and Blocks

Modular Knifeblade Fuse Blocks Part Number Table

Catalog Number

Covers*

Fuse Range

Number

Wire Range

Torque

Cooper Bussmann

Class H(K)

Class R

w/o Indication

w/ Indication

Volts

(amps)

of Poles

(solid and stranded)***

(fine stranded Cu)

N•m (Lb-in)

Fuses

HM25100-1CR RM25100-1CR

–

1-3 AWG

6.2 (55)

70-

1/0-3 AWG; (2) Cu 4-6 AWG

4-6 AWG

5.6 (50)

Class H(K):

HM25100-2CR RM25100-2CR CVR-RH-25100 CVRI-RH-25100

100

4-6 AWG; (2) Cu 8 AWG

8 AWG

5.1 (45)

NON

HM25100-3CR RM25100-3CR

8 AWG; (2) Cu 10-14 AWG

–

4.5 (40)

Cu 10-14 AWG; Al 10-12 AWG

–

4.0 (35)

HM25200-1CR RM25200-1CR

110-

250 MCM-1 AWG

3/0-1 AWG

42 (375)

Class R:

HM25200-2CR RM25200-2CR CVR-RH-25200 CVRI-RH-25200

200

2-6 AWG; (2) Cu 2-6 AWG

2-6 AWG

31 (275)

LPN-RK_SP

HM25200-3CR RM25200-3CR

250

PN-RK_SPI**

HM25400-1CR RM25400-1CR

600kcmil

57 (500)

FRN-R

HM25400-2CR RM25400-2CR CVR-RH-25400 CVRI-RH-25400

225-

500kcmil-4 AWG

N/A

51 (450)

KTN-R

HM25400-3CR RM25400-3CR

400

(2) Cu 3/0 - 4 AWG

57 (500)

(2) Al 3/0 - 4 AWG

34 (300)

HM25600-1CR RM25600-1CR

450-

HM25600-2CR RM25600-2CR CVR-RH-25600 CVRI-RH-25600

600

(2) 500kcmil-4 AWG

N/A

51 (450)

HM25600-3CR RM25600-3CR

HM60100-1CR RM60100-1CR

–

1-3 AWG

6.2 (55)

HM60100-2CR RM60100-2CR CVR-RH-60100 CVRI-RH-60100

70-

1/0-3 AWG; (2) Cu 4-6 AWG

4-6 AWG

5.6 (50)

Class H(K):

100

4-6 AWG; (2) Cu 8 AWG

8 AWG

5.1 (45)

NOS

HM60100-3CR RM60100-3CR

8 AWG; (2) Cu 10-14 AWG

–

4.5 (40)

Cu 10-14 AWG; Al 10-12 AWG

–

4.0 (35)

HM60200-1CR RM60200-1CR

110-

250 MCM-1 AWG

3/0-1 AWG

42 (375)

Class R:

HM60200-2CR RM60200-2CR CVR-RH-60200 CVRI-RH-60200

200

2-6 AWG; (2) Cu 2-6 AWG

2-6 AWG

31 (275)

LPS-RK_SP

HM60200-3CR RM60200-3CR

600

PS-RK_SPI**

HM60400-1CR RM60400-1CR

600kcmil

57 (500)

FRS-R

HM60400-2CR RM60400-2CR CVR-RH-60400 CVRI-RH-60400

225-

500kcmil-4 AWG

N/A

51 (450)

KTS-R

HM60400-3CR RM60400-3CR

400

(2) Cu 3/0 - 4 AWG

57 (500)

KWS-R

(2) Al 3/0 - 4 AWG

34 (300)

PVS-R

HM60600-1CR RM60600-1CR

450-

HM60600-2CR RM60600-2CR CVR-RH-60600 CVRI-RH-60600

600

(2) 500kcmil-4 AWG

N/A

51 (450)

HM60600-3CR RM60600-3CR

Catalog Number

Covers*

Fuse Range

Number

Wire Range

Torque

Cooper Bussmann

Class J

w/o Indication

w/ Indication

Volts

(amps)

of Poles

(solid and stranded)

(fine stranded) N•m (Lb-in)

Fuses

JM60100-1CR

–

1-3 AWG

6.2 (55)

1/0-3 AWG; (2) Cu 4-6 AWG

4-6 AWG

5.6 (50)

JM60100-2CR CVR-J-60100

CVRI-J-60100

70-

4-6 AWG; (2) Cu 8 AWG

8 AWG

5.1 (45)

JM60100-3CR

100

8 AWG; (2) Cu 10-14 AWG

–

4.5 (40)

Cu 10-14 AWG; Al 10-12 AWG

–

4.0 (35)

JM60200-1CR

110-

250 MCM-1 AWG

3/0-1 AWG

42 (375)

JM60200-2CR CVR-J-60200

CVRI-J-60200

200

2-6 AWG; (2) Cu 2-6 AWG

2-6 AWG

31 (275)

LPJ_SP

JM60200-3CR

600

PJ_SPI**

JM60400-1CR

600kcmil

57 (500)

JKS

JM60400-2CR CVR-J-60400

CVRI-J-60400

225-

500kcmil-4 AWG

N/A

51 (450)

DFJ

JM60400-3CR

400

(2) Cu 3/0 - 4 AWG

57 (500)

(2) Al 3/0 - 4 AWG

34 (300)

JM60600-1CR

450-

JM60600-2CR CVR-J-60600

CVRI-J-60600

600

(2) 500kcmil-4 AWG

N/A

51 (450)

JM60600-3CR

*Covers sold serarately. Blown fuse indication requires 90 volts minimum and closed circuit to operate.
**With

easy

ID™ blown fuse indication. ***Ratings for copper and aluminum wire except where otherwise noted.

250V Class R & H(K)

600V Class R & H(K)

Class J

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For engineering drawings, go to www.cooperbussmann.com/KnifebladeFuseBlocks

294

Fuse Holders and Blocks

Class H(K) and R Fuse Blocks – 250V

Data Sheet: H250 Series, 1112; R250 Series, 1110

H250 & R250 Series

Specifications

Descriptions:
H250 Series:

1-, 2- and 3-pole fuse

blocks for use with Class
H fuses.

R250 Series:

1-, 2- and 3-pole fuse

blocks for use with Class
R fuses (Bussmann LPN-
RK and FRN-R and KTN-R fuses).

Dimensions:

See Dimensions illustrations.

Ratings:

Volts: — 250Vac/dc (H250 & R250 Series)

Amps: —

⁄

-100A

SCCR: — H250 Series; 10kA RMS Sym.

— R250 Series; 200kA RMS Sym.

Agency Information:

CE, UL Listed UL 4248, Guide IZLT,

File E14853; CSA Certified, Class 6225-01, File 47235.

Flammability Rating:

UL 94V0.

Features and Benefits

• H250 fuse blocks provide one, two and three pole housing

for Class H, K and R fuses at 250Vac.

• H250 fuse blocks are listed with a Short-Circuit Current

Rating of 10kA RMS Sym.

• R250 fuse blocks provide 1-, 2- and 3-pole housing for Class

R fuses at 250Vac.

• R250 fuse blocks are listed with a Short-Circuit Current

Rating of 200kA RMS Sym.

Typical Applications

• 250Vac/dc or less Control Systems
• 250Vac/dc or less Industrial Control
• 250Vac/dc or less Industrial Control Circuits

Recommended DIN-Rail adapters for the

⁄

-30A series

• see page 509.

Class H Fuseblocks (250V) Catalog Data (for NON and REN Fuses)

Terminal Type (Suffix No.)

Screw

Box Lug w/

⁄

H25030-1

S SR

P PR

—

C, CR #2-14 Cu, #2-12 Al

H25030-2

S SR

P PR

C CR

—

P, PR #10-18 Cu Only

H25030-3

S SR

P PR

C CR

—

Q N/A

S, SR #10-18 Cu Only

H25060-1

—

C, CR #2-14 Cu, #2-8 Al

H25060-2

— —

—

CO #2-14 Cu Only

H25060-3

— —

—

H25100-1

— SR

— —

— CR

—

H25100-2

— SR

— —

—

CR #1/0-8 Cu/Al

100

H25100-3

— SR

— —

— CR

—

SR #8W/ Ring Terminal

Amps

Catalog

Number

Pressure

Plate

Pressure Plate

& Clip with

Reinforced Spring

Copper

Only

Wire

Range

0.25˝

Quick

Connect

Clip with

Reinforced

Spring

Clip with

Reinforced

Spring

—

Figure

Number

Poles

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

295

Fuse Holder

& Blocks

Fuse Holders and Blocks

Class H(K) and R Fuse Blocks – 250V

Data Sheet: H250 Series, 1112; R250 Series, 1110

1.41"

0.22"

1.09"

3.03"

0.5"

0.17"

0.75"

0.25"

1.25"

0.95"

0.22" DIAMETER

0.41"

2.05"

2 SPACES AT

0.95" - 1.91"

2.5"

0.55"

1.27"

1.52"

0.55"

Dimensions – in
250V

⁄

to 30A

FIGURE 1.

FIGURE 2.

FIGURE 3.

4.25

0.27

1.73

1.5

0.5

2.81

0.5

1.31

0.5

1.31

4.125

1.5

0.5

1.31

0.5

1.25

0.22 x 0.41

250V, 31A to 60A

FIGURE 4.

FIGURE 5.

FIGURE 6.

Class R Fuseblocks (250V) Catalog Data (for LPN-RK, FRN-R and KTN-R Fuses)

Terminal Type (Suffix No.)

Screw w/

Box Lug w/

0.25”

Catalog

Pres.

Clip

Quick-

Fig.

Wire

Number

—

Plate

—

Cu Only

Connect

No.

Range

⁄

R25030-1

COR

QR*

COR #6-14 Cu Only

R25030-2

COR

—

CR #2-14 Cu, #2-12 Al

R25030-3

COR

—

PR #10-18 Cu Only

QR N/A

SR #10-18 Cu Only

R25060-1

—

R25060-2

—

CR #2-14 Cu, #2-8 Al

R25060-3

—

R25100-1

—

R25100-2

—

CR 1/0-8 Cu/Al

100

R25100-3

—

Poles

Amps

250V, 61A to 100A

FIGURE 7.

FIGURE 8.

FIGURE 9.

7.36"

0.25"

2.06"

1.81"

0.62"

3.38"

0.59"

0.62"

4.94"

2.38"

2.125"

0.62"

0.28" DIA. x
0.5" C'BORE

0.59"

1.56"

3.125"

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

296

Fuse Holders and Blocks

Class H(K) and R Fuse Blocks – 600V

Data Sheet: H600 Series, 1113; R600 Series, 1111

H60030-2PR

H60030-3C

H600 & R600 Series

Specifications
Descriptions:
H600 Series:

fuse blocks for use with 1-, 2- and 3-pole

Class H fuses.

R600 Series:

fuse blocks for use with 1-, 2- and 3-pole

Class R fuses (Bussmann LPS-RK, FRS-R, PVS-R and

KTS-R fuses).

Dimensions:

See Dimensions illustrations.

Ratings:

Volts: — 600Vac/dc (H600 & R600 Series)

Amps: —

⁄

-100A

SCCR: — H600 Series; 10kA RMS Sym.

— R600 Series; 200kA RMS Sym.

Agency Information:

CE, UL Listed UL 4248, Guide IZLT,

File E14853; CSA Certified, Class 6225-01, File 47235.

Flammability Rating:

UL 94V0.

Features and Benefits

• H600 fuse blocks provide one-, two- and three-pole housing

for Class H, K and R fuses at 600Vac.

• H600 fuse blocks are listed with a Short-Circuit Current

Rating of 10kA RMS Sym.

• R600 fuse blocks provide one-, two- and three-pole housing

for Class R fuses at 600Vac.

• R600 fuse blocks are listed with a Short-Circuit Current

Rating of 200kA RMS Sym.

Typical Applications

• 600Vac/dc or less Control Systems
• 600Vac/dc or less Industrial Control
• 600Vac/dc or less Individual Control Circuits

Class H Fuseblocks (600V) Catalog Data (for NOS and RES Fuses)

Terminal Type (Suffix No.)

Screw

Box Lug w/

⁄

H60030-1

S SR

P PR

C, CR #2-14 Cu, #2-12 Al

H60030-2

S SR

P PR

C CR

P, PR, S, SR #10-18 Cu Only

H60030-3

S SR

P PR

C CR

H60060-1

—

H60060-2

— —

C, CR #2-14 Cu, #2-8 Al

H60060-3

— —

H60100-1

— —

— CR

H60100-2

— —

—

CR #1/0-8 Cu/Al

100

H60100-3

— —

— CR

Pressure

Plate

Pressure Plate

& Clip with

Reinforced Spring

Wire

Range

Clip with

Reinforced

Spring

—

Figure

Number

Amps

Catalog

Number

Clip with

Reinforced

Spring

—

Poles

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

297

Fuse Holder

& Blocks

Fuse Holders and Blocks

Class H(K) and R Fuse Blocks – 600V

Data Sheet: H600 Series, 1113; R600 Series, 1111

Class R Fuseblocks (600V) Catalog Data (for LPS-RK, FRS-R, PVS-R and KTS-R Fuses)

Terminal Type (Suffix No.)

Screw w/

Box Lug w/

Catalog

Pres.

Clip

Fig.

Wire

Number

—

Plate

—

Cu Only

No.

Range

⁄

R60030-1

—

COR #6-14 Cu Only

R60030-2

COR

CR #2-14 Cu, #2-12 Al

R60030-3

COR

PR, SR #10-18 Cu Only

R60060-1

—

R60060-2

—

CR #2-14 Cu, #2-8 Al

R60060-3

—

R60100-1

—

R60100-2

—

CR, 1/0-8 Cu/Al

100

R60100-3

—

6.25

0.26

1.73

1.54

0.62

2.90

0.25

1.56

0.62

1.56

4.25

3.13

1.56

0.62

1.56

0.25

0.28 x 0.5

7.36"

0.25"

2.06"

1.81"

0.62"

3.38"

0.59"

0.62"

4.94"

2.38"

2.125"

0.62"

0.28" DIA. x
0.5" C'BORE

0.59"

1.56"

3.125"

Dimensionals – in

600V,

⁄

to 30A

600V, 31 to 60A

FIGURE 1.

FIGURE 2.

FIGURE 3.

FIGURE 4.

FIGURE 5.

FIGURE 6.

Amps

Poles

0.88

0.67

1.81

4.03

2.22

0.28 x 0.5

0.88

0.67

1.81

0.28 x 0.5

5.84

9.5

0.34

2.38

4.25

2.63

600V, 61 to 100A

FIGURE 7.

FIGURE 8.

FIGURE 9.

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

298

Fuse Holders and Blocks

J600 Series

Specifications
Description:

1-, 2- or 3-pole fuse blocks for use with Class

J fuses (Bussmann LPJ, DFJ and JKS).

Dimensions:

See Dimensions illustrations.

Construction:

Thermoplastic.

Poles:

1 to 3

Ratings:

Volts: — 600Vac/dc

Amps: —

⁄

-100A

SCCR: — 200kA RMS Sym.

Agency Information:

CE, UL Listed, UL 4248, Guide IZLT,

File E14853, CSA Certified, C22.2 No. 4248, Class 6225-01,
File 47235.

Flammability Rating:

UL 94V0.

Mounting:

Accepts DIN-Rail adapter DRA-1. See page 507.

Class J Fuse Blocks

Data Sheet: 1114

⁄

- 60A

Dimensions - in (±0.015)

.30"

2.28"

6.28"

.94"

.22"
Dia.

.5"
C'Bore

1.583"

3.14"

1.75"

1.5"

FIGURE 4. FIGURE 5.

Catalog Numbers

Pressure

Box

Box Lug w/

Fig.

Wire

Screw†

Plate†

Lug

Retaining Clip

Amps

Poles

No.

Range

J60030-1S*

J60030-1P

J60030-1C

J60030-1CR††

C, CR #2-14 Cu, #2-8 Al

J60030-2S*

J60030-2P

J60030-2C

J60030-2CR††

⁄

-30

COR #2-14 Cu Only

J60030-3S*

J60030-3P

J60030-3C

J60030-3CR††

P, PR, S, SR #10-14 Cu Only

—

J60060-1C

J60060-1CR††

C, CR, #2-14 Cu/Al

—

J60060-2C

J60060-2CR††

31-60

COR #4-14 Cu Only

—

J60060-3C

J60060-3CR††

—

J60100-1CR

61-100

COR 1/0-8 Cu Only

—

J60100-3CR††

CR, CRQ 1/0-8 Cu/Al

†Clip reinforcing springs are standard on fuse blocks rated 100A and above. Available on 30A and 60A blocks by adding the letter “R” to the end of the part

number.

††Copper only connections available by changing “CR” suffix to “COR”.
*No UL, No CSA Certification

Features and Benefits

• J600 fuse blocks provide one-, two- and three-pole housing

for Class J fuses at 600Vac.

• J600 fuse blocks are listed with a Short-Circuit Current

Rating of 200kA RMS Sym.

Typical Applications

• 600Vac/dc or less Control Systems
• 600Vac/dc or less Industrial Control
• 600Vac/dc or less Individual Control Circuits

Catalog Numbers

61-100A

2.415"

.750

1.702

2.250

3.202

.750

4.702

2.250

1.500

4.005

FIGURE 1. FIGURE 2. FIGURE 3.

61-100

31-60

⁄

-30

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

300

Fuse Holders and Blocks

Class T Fuse Blocks – 300V

Data Sheet: 1115

T30030-S
SECTION X-X

0.91"

1.63"

0.72"

0.16"

Full
Radius

0.44"

0.20"

1.20"

0.69"

2.5"

2.75"

T30060-C
SECTION Z-Z

0.91"

1.63"

0.72"

0.16"

Dimensions - in

Figure 1.

⁄

-60A

T300

Specifications
Description:

T300 (300V) fuse blocks for use with Class T

fuses (Bussmann JJN).

Dimensions:

See Dimensions illustrations.

Poles:

1 to 4

Ratings:

Volts: — 300Vac/dc

Amps: —

⁄

- 600A

SCCR:— 200kA RMS Sym.

Agency Information:

CE, UL Listed UL 4248, Guide IZLT,

File E14853, CSA Certified, Class 6225-01, File 47235.

Flammability Rating:

UL 94V0.

Features and Benefits

• Provide 1-, 2- and 3-pole housing for 300Vac Class T fuses.
• Short-Circuit Current Rating of 200kA RMS Sym.
• Class T fuse blocks have a small foot print, providing

substantial space savings in equipment

Typical Applications

• 300Vac/dc or less Control Systems

• 300Vac/dc or less Individual Control Circuits

Catalog Numbers

T30100-1CR

T30030-2CR

T30600-1C

Catalog

Dimensions - in

Number

T30030-2

2.41

—

1.03

T30060-2

2.41

—

1.03

T30030-3

3.44

1.03

2.06

T30060-3

3.44

1.03

2.06

T30030-4

4.47

2.06

3.09

T30060-4

4.47

2.06

3.09

Catalog Numbers

Fig.

Screw

Box Lug

Amps

Poles No.

Wire Range

T30030-2SR T30030-2CR

1/2-30

SR #10-18 Cu

T30030-3SR T30030-3CR

CR #6-14 Cu/Al

T30030-4SR T30030-4CR

T30060-2SR T30060-2CR

31-60

CR #2-14 Cu/Al

T30060-3SR T30060-3CR

SR #10-18 Cu Only

T30060-4SR T30060-4CR

—

T30100-1CR

61-100

—

T30100-2CR

1/0-8 Cu/Al

—

T30100-3CR

—

T30200-1C

101-200

250kcmil-6 Cu/Al

—

T30200-3C

—

T30400-1C

201-400

600kcmil-2/0 Cu/Al

—

T30600-1C

401-600

(2) 600kcmil-4/0 Cu/Al

⁄

-30

31-60

61-100

101-200

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

302

Fuse Holders and Blocks

Class T Fuse Blocks – 600V

Data Sheet: 1116

Figure 1.

⁄

to 30A

3.19"

1.44"

1.563"

0.33"

1.42"

0.5"

1.44"

0.55"

0.33" 0.55"

2.59"

1.16"

0.33"

0.55"

3.75"

2.31"

0.33"

0.22" DIAMETER

0.5" C'BORE

2.94"

1.75"

1.63"

1.47"

0.5"

1.81"

0.59"

0.63" 0.59"

3.34"

1.53"

0.63"

0.59"

4.86"

3.06"

0.63"

0.22" DIAMETER

0.5" C'BORE

Figure 2. 31 to 60A

T600

Specifications
Description:

T600 (600V) fuse blocks for use with Class T

fuses (Bussmann JJS).

Dimensions:

See Dimensions illustrations.

Poles:

1 to 3

Ratings:

Volts: — 600Vac/dc

Amps: —

⁄

- 600A

SCCR:— 200kA RMS Sym.

Agency Information:

CE, UL Listed UL 4248, Guide IZLT,

File E14853, CSA Certified, Class 6225-01, File 47235.

Flammability Rating:

UL 94V0.

Features and Benefits

• Provide 1-, 2- and 3-pole housing for 600Vac Class T fuses.
• Short-Circuit Current Rating of 200kA RMS Sym.
• Class T fuse blocks have a small foot print, providing

substantial space savings in equipment

Typical Applications

• 600Vac/dc or less Control Systems

• 600Vac/dc or less Individual Control Circuits

T30030-2CR

T60600-1C

Fig.

Screw

Box Lug

Amps

Poles No.

Wire Range

T60030-1SR

T60030-1CR

SR #10-18 Cu

T60030-2SR

T60030-2CR

1/2-30

T60030-3SR

T60030-3CR

CR #2-14 Cu/Al

T60060-1SR

T60060-1CR

CR #2-14 Cu/Al

T60060-2SR

T60060-2CR

31-60

T60060-3SR

T60060-3CR

SR #10-18 Cu Only

—

T60100-1C

—

T60100-2C

61-100

2/0-14 Cu/Al

—

T60100-3C

—

T60200-1C

101-200

250kcmil-6 Cu/Al

—

1B0089*

—

T60400-1C

201-400

600kcmil-2/0 Cu/Al

—

T60600-1C

401-600

(2) 600kcmil-4/0 Cu/Al

* UL Listed, Guide IZLT, File E14853, CSA Certified Class 6225-01, File 21455M18

Catalog Numbers

⁄

-30

31-60

61-100

101-200

Dimensions - in

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

304

Fuse Holders and Blocks

BCA Series - Class CC fuses
BMA Series -

⁄

" X 1

⁄

" fuses

Specifications
Description:

1-, 2 and 3-pole fuse

blocks for use with Class CC fuses
(BCA Series use Bussmann
LP-CC, KTK-R, and FNQ-R), or with
standard

⁄

" x 1

⁄

" fuses (BMA Series

use Bussmann KTK, FNQ, PVN, FNM,
BAF, PV and AGU) Both Series use an
"adder block" to form multi-pole seg-
mented blocks to achieve the desired
number of poles.

Dimensions:

See Dimensions

illustration.

Poles:

1 to 3.

Wire Range:

#10-#18 Cu only.

Terminals:

Screw/quick connect*

or pressure plate/quick connect*.

Ratings:

Volts: — 600Vac/dc

Amps: —

⁄

-30A

SCCR: — BCA Series:

200kA RMS Sym.
BMA Series:
10kA RMS Sym.

Agency Information:

BCA Series:

CE, UL Listed, UL

4248, Guide IZLT, File E14853.
CSA Certified, C22.2 No. 4248, Class 6225-01, File 47235.

BMA Series:

CE, UL Recognized, UL 4248, Guide IZLT2,

File E14853. CSA Certified, C22.2 No. 4248, Class 6225-01,
File 47235.

Flammability Rating:

UL 94V0

*Quick connect rated for 20A maximum.

Catalog Numbers

BCA Series

Catalog Numbers

Poles

Terminal Type

BCA603ASQ

Adder Block

Screw w/ quick connect

BCA6031SQ

Screw w/ quick connect

BCA6032SQ

Screw w/ quick connect

BCA6033SQ

Screw w/ quick connect

BCA603APQ

Adder Block

Pressure plate w/ quick connect

BCA6031PQ

Pressure plate w/ quick connect

BCA6032PQ

Pressure plate w/ quick connect

BCA6033PQ

Pressure plate w/ quick connect

Add-a-pole Fuse Blocks

Data Sheets: BCA Series 1154, BMA Series 1155

Dimensions in ± 0.015" (0.38mm)

Adder Block

1-Pole

2-Pole

3-Pole

BMA Series

Catalog Numbers

Poles

Terminal Type

BMA603ASQ

Adder Block

Screw w/ quick connect

BMA6031SQ

Screw w/ quick connect

BMA6032SQ

Screw w/ quick connect

BMA6033SQ

Screw w/ quick connect

BMA603APQ

Adder Block

Pressure plate w/ quick connect

BMA6031PQ

Pressure plate w/ quick connect

BMA6032PQ

Pressure plate w/ quick connect

BMA6033PQ

Pressure plate w/ quick connect

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

305

Fuse Holder

& Blocks

Fuse Holders and Blocks

Class CC, Type M and Class G Fuse Blocks

Data Sheet: 1106

Data Sheet: 1104

Data Sheet: 1105

Specifications

Description:

Class CC fuse blocks for

use with Class CC fuses ( Bussmann
LP-CC, KTK-R, and FNQ-R).

Dimensions:

See Data Sheet 1105

Poles:

1 to 3

Ratings:

Volts: — 600V

Amps: —

⁄

-30A

SCCR:— 200kA RMS Sym.

Agency Information:

CE, UL Listed

(Guide IZLT, File E14853), CSA (Class
6225-01, File 47235)

Flammability Rating:

UL 94V0

DIN-Rail Adapters:

See page 413 for

DRA-1 & DRA-2

Catalog Numbers

Terminal Type

Screw

Pressure

with

Plate w/

Quick

Pressure

Quick

Box

Screw

Connect*

Plate

Connect*

Lug

Poles

BC6031S

BC6031SQ

BC6031P

BC6031PQ

BC6031B

BC6032S

BC6032SQ

BC6032P

BC6032PQ

BC6032B

BC6033S

BC6033SQ

BC6033P

BC6033PQ BC6033B

BCCM Series

Description:

3-pole fuse block for use

with (2) Class CC fuses and (1)

⁄

” x 1

⁄

”

fuse

Catalog Numbers

Catalog

Terminal

Numbers

Type

BCCM6033SQ

Screw with Quick-Connect*

BCCM6033PQ

Pressure Plate w/Quick-Connect*

*Quick-connect terminal rated for 20A max.

Specifications

Description:

Supplementary fuse

blocks for use with any

⁄

” x 1

⁄

” fuses

(Bussmann KTK, PVM, FNQ, FNM,
BAF, PV, and AGU).

Dimensions:

See Data Sheet 1104

Poles:

1 to 3

DIN-Rail Adapters:

See page 413

for DRA-1 & DRA-2

Ratings:

Volts: — 600Vac/dc

Amps: —

⁄

-30A

SCCR:— 10kA RMS Sym.

Agency Information:

CE, UL

Recognized (Guide IZLT2, File
E14853), CSA (Class 6225-01, File
47235).

Flammability Rating:

UL 94V0.

Catalog Numbers

Terminal Type

Screw

Pressure

with

Plate w/

Quick

Box

Connect*

Lug

Poles

BM6031SQ

BM6031PQ

BM6031B

BM6032SQ

BM6032PQ

BM6032B

BM6033SQ

BM6033PQ

BM6033B

Specifications

Description:

Class G fuse blocks for use

with Class G fuses (Bussmann SC).

Dimensions:

See Data Sheet 1106

Poles:

1 to 3

Ratings:

Volts: — 600Vac/dc (0-20A)

— 480Vac/dc (25-60A)

Amps: — 1-60A (See Catalog Numbers

table)

SCCR: — 100kA RMS Sym.

Agency Information:

CE, UL Listed

35-60A (Guide IZLT, File E14853), UL
Recognized 1-30A, (Guide IZLT2, File
E14853), CSA (Class 6225-01, File 47235).

DIN-Rail Adapters:

See page 413 for

DRA-1 & DRA-2.

Catalog Numbers

Terminal Type

Screw

Pressure

with

Plate w/

Box Lug

Quick

Box

w/retaining

Connect*

Lug

clip

Amps

Poles

BG3011SQ BG3011PQ

BG3011B

—

BG3012SQ BG3012PQ BG3012B

—

BG3013SQ BG3013PQ BG3013B

—

BG3021SQ BG3021PQ BG3021B

—

BG3022SQ BG3022PQ BG3022B

—

BG3023SQ BG3023PQ BG3023B

—

BG3031S

BG3031P

BG3031B

—

BG3032S

BG3032P

BG3032B

—

BG3033S

BG3033P

BG3033B

—

G30060-1CR

—

G30060-2CR

—

G30060-3C G30060-3CR

BC Series

BM Series Type M

BG & G Series

1-15

25-30

35-60

Recommended Cover Puller

• PF1-WH (White)
• PF1-BK (Black)

Recommended Cover Puller

• PF1-WH (White)
• PF1-BK (Black)

Recommended Cover Puller

• PF1-WH (White)
• PF1-BK (Black)

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

306

Fuse Holders and Blocks

Modular Fuse Blocks

Specifications

Description:

For use with Bussmann high speed fuses.

Ratings:

SCCR: — 200kA RMS Sym. or fuse IR, whichever

is lower.

Agency Information:

CE, UL Recognized, Guide EZLT2,

File No. E14853 up to 700V, CSA Certified, Class 6225-01,
File No. 47235 up to 700V.

BH Series Features and Benefits

• BH fuse blocks provide a wide range of mounting

configurations for Bussmann high speed fuses.

• BH fuse blocks have a Short-Circuit Current Rating of any

installed fuse up to 200kA RMS Sym.

Typical Applications

• Solid State Control Circuits
• VFDs
• UPS Systems

Catalog Numbers

BH-0001

BH-0122

BH-2001

BH-3004

BH-0002

BH-1001

BH-2002

BH-3033

BH-0003

BH-1002

BH-2003

BH-3144

BH-0111

BH-1003

BH-2031

BH-3145

BH-0112

BH-1131

BH-2032

BH-0113

BH-1132

BH-2033

BH-0121

BH-1133

BH-3003

Data Sheet: (BH-0) 1200; (BH-1) 1201; (BH-2) 1202;
(BH-3) 1203

Refer to the data sheet numbers below for the catalog code
description information.

Figure 1

Figure 2

BH Series

Modular Type Fuse blocks for Class H &
J Fuses

Specifications

Description:

3-Pole only, modular type fuse blocks for

Class H & J fuses with standard reinforced retaining clips.

Ratings:

Volts: — 250V (0-60A See Catalog Numbers table)

— 600V (35-60A See Catalog Numbers table)

Amps: — 0-60A @ 250Vac/dc (See Catalog Numbers table)

— 35-60A@600V (See Catalog Numbers table)

SCCR: — Class J 200kA, Class H 10kA

Agency Information:

CE, UL Recognized, Guide IZLT2,

File E14853, CSA Certified, Class 6225-01, File 47235.

Class H & J Features and Benefits

• H & J modular fuse blocks provide three pole 30 and 60

amp ratings for specific client requirements for separate line
and load fuse clip configurations.

Typical Applications

• Up to 60A, space confined, control circuits

Catalog Numbers
Fuse

Fig.

Screw

Pressure Plate Class

Volts

Amps

No.

11241-3SR*

11241-3PR*

250

11242-3SR

11242-3PR

11241-3SR

11241-3PR

600

11242-3SR** 11242-3PR**

11239-3SR

11239-3PR

11240-3SR** 11240-3PR**

11241-3SR

11241-3PR

600

11239-3SR*

11239-3PR*

Note: Order two blocks per fuse (matched or mixed.)

*11239 and 11241 have wire terminals and mounting holes located under fuse. (Figure 1)
**11240 and 11242 have wire terminals and mounting holes located at end of fuse. (Figure 2)

250

600

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

307

Fuse Holder

& Blocks

Fuse Holders and Blocks

SOU, SRU, SSN, SSU, SOW, SRW, SSW,
SOX, SRX, SSX, SOY, SRY, SSY, SSY-RL,
SSY-L, STY, SCY & SOY-B

Specifications

Description:

Box covers for standard electrical boxes that

provide fused outlet, fused switch or circuit fuse protection.

Ratings:

Volts: — 125V/250V (See Catalog Numbers table)

Amps: — 0-15A (See Catalog Numbers table)

Agency Information:

CE, See Catalog Numbers table.

Features/Benefits

• Bussmann Box Cover Units provide a low-cost method of

controlling and protecting small motors when used with
Bussmann Type T, Fusetron

™

, dual-element fuses.

• Provide low-cost supplementary protection and

disconnection of 125V or less, single phase circuits.

Typical Applications

• Fractional Horsepower, 125 Volt Single-Phase Motor Circuits
• General 125 Volt Supplemental Circuits

Box Cover Units for Plug Fuses

Data Sheet: 1129

Catalog Numbers

Receptacle

Motor

Agency4

Catalog

Fuse holder3

Outlet to Load

Switch

Size

Listing/

Numbers

Type Box

Single Double

125V

250V

Control1

Light2

(Max)

General Data

Certification

SOU

⁄

125V, 15A

UL, CSA

SRU

⁄

" Handy

⁄

125V, 15A

SSU

⁄

125Vac, (do not use on dc), 15A

UL, CSA

SOW

⁄

125V, 15A

UL, CSA

SRW

⁄

" Switch

⁄

125V, 15A

SSW

⁄

125Vac, (do not use on dc), 15A

UL, CSA

SOX

⁄

125V, 15A

UL, CSA

SRX

4" Octagon

⁄

125V, 15A

SSX

⁄

125Vac, (do not use on dc), 15A

UL, CSA

SOY

⁄

125V, 15A

UL, CSA

SRY

⁄

125V, 15A

SSY

⁄

125Vac, (do not use on dc), 15A

UL, CSA

SSY-RL

4" Square

⁄

125Vac, (do not use on dc), 15A

—

STY3

⁄

125Vac, (do not use on dc), 15A

SCY

X(2)

⁄

hp (2)

125Vac, (do not use on dc),
can protect two motors, 15A

SOY-B

⁄

125V, protects two motors, 15A

SSN

Single Gang

⁄

Weatherproof model, 15A

1 Switch turns power to fused load OFF or ON.
2 Switch light indicates power to load (dark when switch OFF or fuse open).
3 Double pole switch opens both sides of circuit. Can be used for two separate motors with common switch or a single motor (

⁄

Hp, 250Vac max.).

4 UL Guide JAMZ, File IE6491; CSA Class 6225-01, File 47235.

⁄

" Handy

⁄

" Switch

4" Octagon

4" Square

SSU

SSN

SRU

SOU

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

308

Fuse Holders and Blocks

Specifications

Description:

Water-resistant in-line

fuse holder for

⁄

" x 1

⁄

" fuses.

Dimensions:

See Dimensions

illustration.

Construction:

Thermoplastic rubber

body with tin-plated, copper contacts.

Ratings:

Volts: — 32V

Amps: — 30A max

Catalog Numbers

Catalog
Numbers

Description

HFB*

Standard Pack (10-in)

BK/HFB

Bulk Pack (100-in)

BK/1A2294

HFB Replacement Contact Clip

1A2294-01

HFB-10** Replacement Contact Clip

*HFB accepts #12 to #18 wire leads (not provided). See
Data Sheet for recommended crimp tools.
**HFB-10 accepts #10 wire leads (not provided). See Data
Sheet for recommended crimp tools.

Features/Benefits

• Simple assembly with one-piece

thermoplastic (important information
molded into body)

• High visibility yellow color for easy

identification in dark or hard-to-access
locations

• Ideal for shock and vibration

environments; withstands many
organic solvents; temperature range -
40/+150°C

Typical Applications

• Supplemental, Low Voltage, Low

Amperage Control Circuits

Dimensions - in (mm)

In-line Fuse Holders for

⁄

" x

⁄

" to 1

⁄

" Fuses

0.75"

(19.1mm)

(76.2mm)

Data Sheet: 2102

Data Sheet: 2111

Data Sheet: 2103

Specifications

Description:

Universal in-line fuse

holder for

⁄

" x

⁄

" to 1

⁄

" fuses.

Dimensions:

See Dimensions

illustration.

Construction:

8" (203mm) #14 lead

wires.

Ratings:

Volts: — 32V

Amps: — 15A max

Features and Benefits

• HRK Universal in-line fuse holder for

⁄

" x

⁄

", 1" and 1

⁄

" fuses with #14

lead wires.

• RoHS compliant

Typical Applications

• Supplemental, Low Voltage, Low

Amperage Control Circuits

Catalog Number

Catalog

Amp

Number

Rating Volts

Fuse Description

HRK-R*

⁄

" diameter fuses of

different lengths.

*Three springs furnished with fuse holder to accommodate
different length

⁄

" fuses.

Dimensions - in (mm)

Specifications

Description:

Universal in-line fuse

holder for

⁄

" x

⁄

", 1" and 1

⁄

" fuses.

Dimensions:

See Dimensions

illustration.

Construction:

Nylon body with tin-

plated, copper contacts.

Ratings:

Volts: — 32V

Amps: — 30A max

Flammability Rating:

UL 94V2.

Pull Force:

5lbs minimum to separate

fuse holder housing with fuse installed.

Features and Benefits

• HHB Universal in-line fuse holder for

⁄

" x

⁄

", 1" and 1

⁄

" fuses.

Typical Applications

• Supplemental, Low Voltage, Low

Amperage Control Circuits

Catalog Numbers

Holder — without leads* - RoHS compliant

Catalog Numbers

Description

HHB-R

Standard Pack (10-in)

BK/HHB-R

Bulk Pack (100-in)

*Accepts #12 to #16 wire leads (not provided with basic fuse
holder). See Data Sheet for recommended crimp tools.

Holder — with pre-attached #14 Insulated
lead wires - Not RoHS compliant unless
noted

Catalog Numbers

Wire

19" Length

8" Length

Color

BK/HHB-Y419

BK/HHB-Y408

Yellow

BK/HHB-R419

BK/HHB-R408**

Red

BK/HHB-B419

BK/HHB-B408

Black

**RoHS compliant.

Dimensions - in (mm)

Fuse Length

Fuse Holder Length “L”

⁄

" (AGW)

2.100 Max

1" (AGX)

2.250 Max

⁄

" (AGC, MDL)

2.420 Max

0.53"

(13.5mm)

0.75"

(19.1mm)

2.19"

(55.6mm)

1.56"

(39.7mm)

0.69"

(17.5mm)

0.38"

(9.5mm)

HFB & HFB-10

HHB

HRK

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

309

Fuse Holder

& Blocks

Fuse Holders and Blocks

HR and HM Series

Specifications

Description:

In-line

fuse holders for SFE
and

⁄

" dia. x various

length fuses.

Dimensions:

See

Dimensions
illustration.

Ratings:

Volts: — 32V

Amps: — 20A

Features and Benefits

• HR and HM Universal in-line fuse

holder for SFE and various length

⁄

diameter fuses with #14 lead wires.

Typical Applications

• Supplemental, Low Voltage, Low

Amperage Control Circuits

Catalog Numbers

Catalog

Includes

Wire Length

Numbers

Fuse

& Size

HRJ*

SFE-20

HRI

SFE-14

HRH

SFE-9

19” of #14

HRE

SFE-7

⁄

HRG

SFE-6

HRF

SFE-4

HMJ**

SFE-20

HMI

SFE-14

HMH

SFE-9

8” of #14

HME

SFE-7

⁄

HMG

SFE-6

HMF

SFE-4

* Also available as in-line fuse holder only with lead wire
contacts, HRJ-LESS-Fuse.
** Also available as in-line fuse holder only with lead wire
contacts, HMJ-LESS-Fuse.

HHJ-A

For

⁄

" x 1

⁄

" fuse, no wire or fuse

included, accepts #18 - #22 wire.

HHJ-B

For

⁄

" x 1

⁄

" fuse, no wire or fuse

included, accepts #12 - #16 wire.

HHI-B

For

⁄

" x 1

⁄

" fuse, no wire or fuse

included, accepts #12 - #16 wire.

Replacement Contacts

Catalog
Number

Symbol

9838

HHJ-A

9841

HHJ-B

Dimensions - in (mm)

In-line Fuse Holders

0.75"

(19.1mm)

2.19"

(55.6mm)

1.56"

(39.7mm)

0.69"

(17.5mm)

0.38"

(9.5mm)

Data Sheet: 2122

Specifications

Description:

In-line water-resistent

fuse holders for

⁄

" x 1

⁄

" fuses.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 250V

Amps: — 20A

Refer to data sheet for recommend
crimp tools

Catalog Numbers

Catalog
Numbers

Terminals

HFA

Crimp #12 - #16

HFA-HH*

⁄

" Quick Connect

*No UL Recognition.

Specifications

Description:

In-line fuse holders for

5 x 15mm or 5 x 20mm fuses.

Dimensions:

See Dimensions

illustration.

Construction:

Black thermoplastic

body with brass contacts, wire: 16
AWG, red.

Ratings:

Volts: — 32V

Amps: — 5A (5 x 15mm)

— 10A (5 x 20mm)

Catalog Numbers

Catalog Number

Fuse Size

HHT

5 x 15mm & 5 x 20mm

HFA Series

HHT Series

Data Sheet: 2115

Data Sheet: 2138

Specifications

Description:

Single-pole, non-break-

away, in-line fuse holders for Type SC
fuses, 480V (or less).

Ratings:

Volts: — 600V

Amps: — 0-15A

Fuse Size:

⁄

" x 1.31"

Catalog Number

HEG-AA

Optional Boots:

2A0660 Single Conductor
2A0661 Two Conductor

Specifications

Description:

Single-pole, non-

breakaway, in-line fuse holders for
Type SC fuses (Also fuse types BBS
& KTQ, nominal size

⁄

" x 1

⁄

").

Ratings:

Volts: — 600V

Amps: — 0-20A

Agency Information:

CSA - 15A.

Catalog Numbers

HEH-AA, HEH-AD

Optional Boots:

2A0660 Single Conductor
2A0661 Two Conductor

HEG Series

HEH Series

Data Sheet: 2124

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

310

Fuse Holders and Blocks

Tron

™

In-line Fuse Holders

Specifications

Description:

Single-pole,

non-breakaway,

in-line fuse

holders for Type SC-25, &
SC-30 fuses,

size

⁄

" x 1

⁄

Ratings:

Volts: — 480V

Amps: — 0-30A

Catalog Numbers

HEC-AA, HEC-RW-RLB-R

Optional Boots:

2A0660 Single Conductor
2A0661 Two Conductor

Specifications

Description:

Single-pole,

non-breakaway, in-line fuse
holders for Type SC and Type
HVW fuses, size

⁄

" x 2

⁄

Ratings:

Volts: — 480V

Amps: — 35-60A Type SC

—

⁄

-6A Type HVW

Catalog Numbers

HEJ-AA, HEJ-AB, HEJ-AC, HEJ-BB,
HEJ-JJ, HEJ-JK, HEJ-LL, HEJ-LLB,
HEJ-CC, HEJ-DD, HEJ-WW, HEJ-PP,
HEJ-QQ

Optional Boots:

2A0660 Single Conductor
2A0661 Two Conductor

Specifications

Description:

Single-pole

in-line fuse holders for any

⁄

" x 1

⁄

" fuses (typically

fuse types: BAF, FNM, FNQ,
and KTK

⁄

- 30A).

Ratings:

Volts: — 600V

Amps: — 0-30A

Catalog Numbers

See Page 311

Optional Boots:

2A0660 Single Conductor

2A0661 Two Conductor

Specifications

Description:

Single-pole

in-line fuse holders for

⁄

" x 1

⁄

" fuses with a

permanently solid neutral
identified by white plastic
coupling nut.

Catalog Numbers

HET-AA, HET-AB, HET-AW, HET-
AW-RLC-A, HET-AW-RLC-B, HET-
AW-RLC-C, HET-AW-RLC-J, HET-
AW-RYC, HET-BB, HET-BW-RLC-B,
HET-BW-RYC, HET-JJ, HET-JK,
HET-JW, HET-JW-RLC-J, HET-JW-
RYC, HET-KK

Specifications

Description:

Waterproof

(IPX7), single-pole Class
CC in-line fuse holders.
Holds Bussmann fuse
types: LP-CC, FNQ-R and
KTK-R.

Ratings:

Volts: — 600V (or less)

Amps: — Up to 30A*

Conductors: Lineside &
Loadside**

#12 to #8 Crimp terminal
#12 to #3 Setscrew terminal

*Amp rating limited by conductor size and fuse sizing

when used with insulating boots

**See details in non-breakaway and breakaway

specifications

Data Sheet: 2130

Specifications

Description:

Double-pole in-

line fuse holders for

⁄

" x 1

⁄

fuses (typically fuse types
BAF, FNM, FNQ, and KTK

⁄

- 30A).

Ratings:

Volts: — 600V

Amps: — 0-30A

Catalog Numbers

HEX-AA, HEX-AB, HEX-AC, HEX-AD,
HEX-AE, HEX-AW, HEX-AW-DRLC-A,
HEX-AW-DRYC, HEX-AW-RLC-A,
HEX-AW-RYC, HEX-AY, HEX-BB,
HEX-CC, HEX-JJ, HEX-JK,
HEX-JW-DRYC, HEX-KK

HEB Series

HET Series

HEZ Series

Specifications

Description:

Double-pole

in-line fuse holders for KTK-
R fuses with optional break-
away receptacle, polarized,
and accepting Class CC
branch circuit fuses
(Bussmann KTK-R, FNQ-R
& LP-CC; 600V or less,
200kA IR).

Ratings:

Volts: — 600V

Amps: — 0-30A

Catalog Numbers

HEY-AA, HEY-AB, HEY-AC, HEY-
AD, HEY-AE, HEY-AL, HEY-AW-
DRLC-A, HEY-AW-DRLC-B, HEY-
AW-DRYC, HEY-BB, HEY-JJ

Data Sheet: 2126

HEY Series

HEX Series

HEC Series

HEJ Series

Data Sheet: 2127

Data Sheet: 2125

Data Sheet: 2126

Data Sheet: 2124

Data Sheet: 2123

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

311

Fuse Holder

& Blocks

Fuse Holders and Blocks

For HEB Holders Only

Data Sheet: 2127

Copper #12 to #8

Crimp

#12

Copper

#12 to #8

Crimp

#12

Copper

#12 to #8

Crimp

#12

Copper

#12 to #8

Crimp

#12

Copper

#12 to #8

Crimp

#12

Copper

#12 to #8

Crimp

#12

Copper

#12 to #8

Crimp

#12

Copper

#12 to #8

Crimp

#12

Copper

#12 to #8

Crimp

#12

Copper

#12 to #8

Crimp

#12

Copper

Crimp

#10

Copper

Crimp

#10

Copper

Crimp

#10

Copper

Crimp

#10

Copper

Crimp

Copper

Crimp

Copper

#20, #18

Crimp
Copper

#12 to #3

Setscrew
Copper

#12 to #3

Setscrew
Copper

#12 to #3

Setscrew
Copper

#12 to #3

Setscrew
Aluminum

#12 to #2

Setscrew
Aluminum

Crimp

Aluminum

Crimp

Aluminum

#3, #4

Crimp

Aluminum

#1, #2

Crimp
Aluminum

1/0

Crimp

SolidTerminal

#8 to #12

for aluminum
connector

#10 to #14

Copper #12 to #8

Crimp

#12

Copper

Crimp

#10

Copper #4

Crimp

Copper

Crimp

Copper

2/0

Crimp

Copper

#12 to #3

Setscrew
Copper

#12 to #3

Setscrew
Aluminum

#12 to #2

Setscrew
Aluminum

#12 to #2

Setscrew
Aluminum

#1, #2

Crimp
Copper

#12 to #8

Crimp

#12

Copper

Crimp

#10

Copper

Crimp

Copper

Crimp

Copper

Crimp

Copper

Crimp

Copper

#12 to #8

Crimp

#12

Copper

#12 to #3

Setscrew
Copper

#12 to #3

Setscrew
Aluminum

#12 to #2

Setscrew
Aluminum

#12 to #2

Setscrew
Aluminum

#12 to #2

Setscrew
Aluminum

Crimp

Aluminum

Crimp

Aluminum

#3, #4

Crimp

Aluminum

#1, #2

Crimp
Aluminum

1/0

Crimp

SolidTerminal

#8 to #12

for aluminum
connector

#10 to #14

Terminal

No. of

Wire Size Wires per

Solid Stranded

Type

Terminal

Wire

Loadside Terminal

Directions: To select complete holder P/N, work from left to right starting with loadside terminal options and then lineside terminal options. Then determine breakaway or non-breakaway style.

Terminal

No. of

Wire Size Wires per

Solid Stranded

Type

Terminal

Wire

Lineside Terminal

Available P/N’s

Non-Breakaway Breakaway

P/N

(Boots not included)

(Boots included)

HEB-AA(1)(2) HEB-AW-RLC-A(1)(2)

HEB-AB(2)

HEB-AW-RLC-B

HEB-AC(2)

HEB-AW-RLC-C(4)

HEB-AD(2)

N/A

HEB-AE(2)

N/A

HEB-AJ

HEB-AW-RLC-J

HEB-AK

HEB-AW-RYC

HEB-AL

HEB-AW-RLA

HEB-AY

HEB-AW-RYA

HEB-AR

N/A

HEB-BA(2)

HEB-BW-RLC-A

HEB-BB(2)

HEB-BW-RLC-B

HEB-BC(2)

N/A

HEB-BD(2)

N/A

HEB-CC(2)

N/A

HEB-DD(2)

N/A

HEB-ZA

N/A

HEB-JJ

HEB-JW-RLC-J

HEB-JK

HEB-JW-RYC

HEB-JL

N/A

HEB-JY

N/A

HEB-LL

HEB-LW-RLA

HEB-NN

N/A

HEB-PP(2)

N/A

HEB-QQ(2)

N/A

HEB-RR(2)

N/A

HEB-TT(2)

N/A

HEB-SS

N/A

(3)

(1)UL Recognized, Guide IZLT2, File E14853

(2)CSA Certified, Class 6225-01, File 47235

(3)CE

(4)HEB-AW-RLC-C is for (1) #4 stranded wire only.

Contact your local Bussmann representative for other possible
terminations not listed.

Insulating boots for single conductor-2A0660
Dual conductor-2A0661

(4)

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

312

Fuse Holders and Blocks

Panel Mounted Fuse Holders for 5 x 20mm Fuses

Specifications

Terminals:

Tin-plated brass.

Molded Materials:

High temperature thermoplastic that meets the flammability ratings of UL 94V0; Glow Wire Test:
960°C per IEC 60695-2-1.

Solderability:

In accordance with IEC 68-2-20.

Agency Information:

cURus, VDE

Electrical:

Contact Resistance: ≤ 10 megohm; Insulation Resistance: ≥ 10MΩ; Dielectric Strength ≥
2000Vac.

Shock Safety:

PC2 (fuse holders).

Packaging:

Standard Qty 10 (No Prefix), Bulk Qty 100 (Prefix Catalog Number with BK/).

3.0x0.51mm

12.00mm

+0.0
–0.1

12.70mm

+0.0

–0.1

12.00mm

+0.0
–0.1

12.70mm

+0.0

–0.1

12.00mm

+0.0
–0.1

12.70mm

+0.0

–0.1

12.00mm

+0.0
–0.1

12.70mm

+0.0

–0.1

3.0x0.51mm

4.8x0.51mm

37.5mm

4mm

Ø15mm

Ø16mm

11mm

5.5mm

Ø22mm

6.5mm

Ø15mm

37.5mm

36mm

4mm

Ø15mm

Ø16mm

11mm

5.5mm

0.5mm

35.5mm

4mm

Ø15mm

Ø16mm

11mm

5.5mm

0.5mm

10.2mm

Data Sheet: 2110

HTC-35M

Ratings:

Volts: — 250Vac

Amps: — 10A UL, 6.3A VDE

Fuse Access:

Threaded cap

HTC-55M

Ratings:

Volts: — 250Vac

Amps: — 10A UL, 6.3A VDE

Fuse Carrier:

Bayonet type

HTC-40M

Ratings:

Volts: — 250Vac

Amps: — 10A UL, 6.3A VDE

Fuse Access:

Screwdriver slot

HTC-70M

Ratings:

Volts: — 250Vac

Amps: — 10A UL, 6.3A VDE

Fuse Carrier:

Bayonet type

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

313

Fuse Holder

& Blocks

Fuse Holders and Blocks

Panel Mounted Fuse Holders for

⁄

" x 1

⁄

" Fuses

Specifications

Terminals:

Bayonet-type knob.
Vibration resistant.
For panels up to

⁄

" (7.9mm) thick.

Agency Information:

CE (HKP, HKP-L, HKP-W, HKP-OO), UL Recognized — Guide IZLT2, File E14853, CSA
Certified — Class 6225-01, File 47235

Replacement Parts:

Cap: 9435-1/2
Plastic Nut: BK/1A4287 (100 pieces minimum)
Metal Nut: BK/1A4806-2 (100 pieces minimum)
Washer: 9732

.800"

(20.3mm)

Punched Mounting Hole

.811"

(20.6mm)

.890"

(22.6mm)

1.56"

(39.7mm)

.75"

(19.1mm)

.855"

(21.7mm)

1.17"

Data Sheet: 2106

Specifications
Description:

Standard fuse holders.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 250V

Amps: — 30A

Catalog Numbers

Catalog

Fuse

Numbers Description

HKP

—

HKP-L

HKP w/ 2250V stand-off barrier

HKP-W

HKP w/ drip-proof knob

Dimensions - in (mm)

Specifications
Description:

Fuse holders with

⁄

quick-connects.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 250V

Amps: — 15A

Catalog Numbers

Catalog

Fuse

Numbers

Description

HKP-BBHH

HKP w/

⁄

" quick-connects, nut and washer

assembled.

HKP-HH

HKP w/

⁄

" quick-connect.

HKP-LW-HH

HKP w/ drip-proof knob, 2250V stand-off
barrier and

⁄

" quick-connects.

Dimensions - in (mm)

Specifications
Description:

Snap-lock fuse holders.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 250V

Amps: — 30A

Catalog Numbers

Catalog

Fuse

Number

Description

HKP-OO

HKP with snap-lock

Dimensions - in (mm)

HKP, HKP-L, HKP-W

HKP-OO

HKP-BBHH, HKP-HH and
HKP-LW-HH

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

314

Fuse Holders and Blocks

Panel Mounted Fuse Holders for 5 x 20mm
and

⁄

" x 1

⁄

" Fuses

HTB Series

Specifications
Description:

Fuse holders with knob-type carriers.

Dimensions:

See Dimensions illustrations.

Construction:

High temperature, flame retardant

thermoplastic; UL Component Recognized; UL 94V0;
mounting nut, spacer-black polycarbonate. Terminals:
tin-plated brass.

Electrical Data:

Insulation resistance (per IEC #257) —

10,000 ohms @ 500Vdc; contact resistance (per IEC #257)
— 0.005 ohms Max @ 1A; standoff voltage (per IEC #257)
— 480V/Mil @ 0.125” thickness.

Agency Information:

CE, UL Recognized — Guide IZLT2,

File E14853,

⁄

˝ dia fuse @ 20A, 5mm dia fuse @16A @

250V, CSA — 16A @ 250V Class 6225-01 File 47235; VDE
Certified: 136128, HTB-XXM, SEMKO Certification: Ref.
#0146149/01, HTB-XXM.

Mounting:

Withstands 15 to 20 Lb-In torque to mounting

nut when mounting fuse holder to panel.

Environmental:

Operating temperature range -55°C to

85°C.

Dimensional Data - in (mm)

Data Sheet: 2119

0.30”

HTB-22I-R

HTB-24I-R

HTB-26I-R

HTB-28I-R

7.62mm

HTB-22M-R

HTB-24M-R HTB-26M-R HTB-28M-R

0.125”

HTB-42I-R

HTB-44I-R

HTB-46I-R

HTB-48I-R

3.18mm

HTB-42M-R

HTB-44M-R HTB-46M-R HTB-48M-R

0.30”

HTB-62I-R

HTB-64I-R

HTB-66I-R

HTB-68I-R

7.62mm

HTB-62M-R

HTB-64M-R HTB-66M-R HTB-68M-R

0.125”

HTB-82I-R

HTB-84I-R

HTB-86I-R

HTB-88I-R

3.18mm

HTB-82M-R

HTB-84M-R HTB-86M-R HTB-88M-R

Fuse holders and fuse carriers may be ordered separately.

1.125"

(28.6mm)

0.47"

(11.9mm)

0.09" NOM.

(2.4mm)

1.125"

(28.6mm)

0.47"

(11.9mm)

0.92"

(23.4mm)

0.67"

(17.1mm)

0.91"

(23.0mm)

0.69"

(17.5mm)

Knob Type Carrier

Common Dimensions:
Length (Knob Type) - 1.69"
(42.9mm) Plus In-Line Terminal
NOTE: Plus In-Line Terminal

Maximum

Panel

Thickness

Solder/

⁄

" Quick-Connect

⁄

" Quick-Connect

Carrier Options

⁄

" x 1

⁄

" 5 x 20mm

(“I” Equals Inches) (“M” Equals Metric)

Knob Knob

In-Line

Rt. Angle

In-Line

Rt. Angle

0.34"

(8.7mm)

0.33"

(8.3mm)

0.47"

(11.9mm)

0.45"

(11.5mm)

Terminal Options

Replacement Parts

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

315

Fuse Holder

& Blocks

Fuse Holders and Blocks

Panel Mounted Fuse Holders for 5 x 20mm
and

⁄

" x 1

⁄

" Fuses

0.30”

HTB-32I-R

HTB-34I-R

HTB-36I-R

HTB-38I-R

7.62mm

HTB-32M-R

HTB-34M-R HTB-36M-R HTB-38M-R

0.125”

HTB-52I-R

HTB-54I-R

HTB-56I-R

HTB-58I-R

3.18mm

HTB-52M-R

HTB-54M-R HTB-56M-R HTB-58M-R

0.125”

HTB-92I-R

HTB-94I-R

HTB-96I-R

HTB-98I-R

3.18mm

HTB-92M-R

HTB-94M-R HTB-96M-R HTB-98M-R

0.17"

(4.37mm)

1.58"

(40.03mm)

0.17"

(4.37mm)

1.59"

(40.08mm)

0.41"

(10.31mm)

1.34"

(34.13mm)

Packing
Blank (Std.)

– 10 fuse holders

in a carton

– 100 fuse holders in a
cardboard shelf package

Rear Terminal Configuration
2 —

Solder /

Quick-Connect

Solder /

Quick-Connect

(In-Line)

4 —

(Right Angle)

6 —

Quick-Connect (In-Line)

8 —

Quick-Connect (Right Angle)

Fuse Carrier
I —

x 1

M —

5 x 20mm

Splash Proof

(Optional on Knob

Holders Only)

Body Configuration and Mounting
Knob Holders
2 —

Low Profile (Rear Panel Hex-Nut)

4 —

High Profile

6 —

(Front Panel Hex-Nut)

8 —

Low Profile (Snap-In)

Screwdriver Slotted Holders
3 —

Low Profile

5 —

High Profile

9 —

Low Profile (Snap-In)

Product
Symbol

HTB-

Packaging
(Blank)

– Std.

BK/

– Bulk

Fuse Carrier
I —
M —

5 x 20mm

Product
Symbol
FT —

Knob Type

(For 20, 40, 60,
and 80 Series
Only)

ST —

Screwdriver

Slotted (For 30,
50, and 90 Series
Only)

-R

*Profile varies with panel thickness. Holder installs through rear of panel.

FUSE CARRIER ONLY

Cap with O-Ring

x 1

RoHS
Compliant

Data Sheet: 2119

Catalog Number Build-A-Code

HTB Series

HTB-3

HTB-5

HTB-9

Screwdriver Type Carrier

Common Dimensions:
(Screwdriver Slotted)
1.75" (44.5mm)
NOTE: Plus In-Line Terminal

Maximum

Panel

Thickness

Solder/

⁄

" Quick-Connect

⁄

" Quick-Connect

Carrier Options

⁄

" x 1

⁄

" 5 x 20mm

(“I” Equals Inches) (“M” Equals Metric)

Screwdriver Screwdriver

In-Line

Rt. Angle

In-Line

Rt. Angle

0.34"

(8.7mm)

0.33"

(8.3mm)

0.47"

(11.9mm)

0.45"

(11.5mm)

Terminal Options

Dimensional Data - in (mm)

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

316

Fuse Holders and Blocks

Panel Mounted Fuse Holders for Indicating Type Fuses

.630" + .005"

(16.0mm + .13mm)

.573" + .003"

(14.6mm + .08mm)

Punched Mounting Hole

Octagonal Sides

0.81"

(20.6mm)

1.19"

(30.2mm)

2.81"

(71.4mm)

Flat-Sides

Data Sheet: 2120

Data Sheet: 2121

Data Sheet: 2105

Specifications
Description:

Pin indicating for

⁄

" x 1

⁄

" fuses.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 250V

Amps: — 15A

Agency Information:

CE, UL

Recognized, File E14853, Guide IZLT2.

Catalog Numbers

Catalog
Numbers*

Terminals

HLD

Solder terminals

HLD-HH

⁄

" quick-connect terminals

*Use w/GBA, GLD Fuses.

Dimensions - in (mm)

Specifications
Description:

Neon lamp indicating for

⁄

" x 1" fuses.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 250V

Amps: — 15A

Agency Information:

None

Catalog Number

Catalog

Lamp

Knob

Number*

Volts

Color

Type

HJL

90 to 250 Clear

Oct

*Use with AGX or MKB fuses, for panels up to

⁄

" thick.

Dimensions - in (mm)

Specifications
Description:

Neon and incandescent

lamp indicating for

⁄

" x 1

⁄

" fuses

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 250V

Amps: —15A (HKL, HKL-X)

— 20A (HKR, HKT, HKU, HKX)

Agency Information:

CE, UL

Recognized, (Guide IZLT2, File
E14853), CSA Certified
(Class 6225-01, File 47235).

Catalog Numbers

Catalog

Lamp

Numbers

Volts

Knob Color/Type

HKL*

90-250

Clear/Oct

HKL-X*

90-250

Clear/FS

HKR**

22-30

Amber/Oct

HKT**

13-22

Amber/Oct

HKU**

4-6

Red/Oct

HKX**

22-33

Amber/FS

* Neon lamp — UL Recognized and CSA Certified.
** Incandescent lamp.

HLD

HK Series

HJL

Octagonal Sides

0.505" ± 0.005”

(16.0mm ± 0.13mm)

0.473" ± 0.005”

(12.0mm ± 0.13mm)

Punched Mounting Hole

0.69"

(17.5mm)

2.5" Ma

. (HLD)

(63.5mm Ma

2.75" Ma

. (HLD-HH)

(69.9mm Ma

0.86"

(21.8mm)

Washer

.630" + .005"

(16.0mm + .13mm)

.590" + .003"

(14.6mm + .08mm)

Punched Mounting Hole

Octagonal Sides

0.81"

(20.6mm)

1.19"

(30.2mm)

2.81"

(71.4mm)

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

317

Fuse Holder

& Blocks

Fuse Holders and Blocks

Panel Mounted Fuse Holders for

⁄

" x 1

⁄

" to 1

⁄

" Fuses

Data Sheet: 2114

Data Sheet: 2113

Data Sheet: 2108

0.180" DIA.

(4.6mm)

1.125"

(28.6mm)

1.00"

(25.4mm)

Without Fuse

2.69" Max.

(68.3mm)

0.88"

(22.2mm)

1.78"

(45.2mm)

1.31"

(33.3mm)

2.81" Max.

(71.4mm)

With Fuse

0.250"

.003"

(6.35

.08mm)

(Typ.2)

0.88"

(22.2mm)

2.81"

(71.4mm)

With Fuse

Without Fuse

2.41"

(64.3mm)

0.80"

(20.2mm)

1.78"

(45.2mm)

0.180"

(4.6mm)

1.125"

(28.6mm)

0.250"

0.003"

(6.35

.08mm)

(Typ.2)

1.125"

(28.6mm)

0.88"

(22.2mm)

2.81"

(71.4mm)

Specifications
Description:

Standard fuse holders

with

screw-type knob

for

⁄

" x 1

⁄

" to

⁄

" Fuses.

Dimensions:

See Dimensions

illustration.

Agency Information:

CE, UL

Recognized, Guide IZLT2, File E14853;
CSA Certified, Class 6225-01, File
47235.

Flammability Rating:

UL 94HB.

Terminals:

Combination

⁄

quick-connect/solder terminals.

Catalog Numbers

Catalog

Amp

Numbers Ratings Volts AC Fuse Description

HPF

600

⁄

" (38.1mm)

HPF-C

600

⁄

" (38.1mm) clear knob.

HPF-L

600

BBS,

⁄

" x 1

⁄

" fuses.

HPF-EE

600

SC 0-15,

⁄

" x 1

⁄

" fuses.

HPF-JJ

600

SC 20,

⁄

" x 1

⁄

" fuses.

HPF-FF

480

SC 25 & 30,

⁄

" x 1

⁄

" fuses.

HPF-RR

600

KTK-R, LP-CC & FNQ-R
Class CC fuses.

HPF-WT

600

Splash-proof knob.

⁄

" x 1

⁄

(38.1mm)

No CSA Certification

20A max when used with quick-connect terminals.

HPF-C ratings for CSA-15A, 250V

Dimensions - in (mm)

Specifications
Description:

Standard fuse holders

with

bayonet-type knob

for

⁄

" x 1

⁄

to 1

⁄

" fuses.

Dimensions:

See Dimensions

illustration.

Agency Information:

CE, UL

Recognized, Guide IZLT2, File E14853;
CSA Certified, Class 6225-01, File
47235.

Flammability Rating:

UL 94HB.

Terminals:

Combination

⁄

" quick-

connect/solder terminals.

Catalog Numbers

Catalog

Amp

Symbol

Ratings Volts AC Fuse Description

HPS

2 3

600

⁄

" x 1

⁄

HPS-L

600

BBS,

⁄

" x 1

⁄

" fuses.

HPS-EE*

600

SC 0-15,

⁄

" x 1

⁄

" fuses.

HPS-JJ*

600

SC 20,

⁄

" x 1

⁄

" fuses.

HPS-F-EE

600

Sleeve on body, leaded for

⁄

" x 1

⁄

" fuses.

HPS-FF*

480

SC 25 & 30,

⁄

" x 1

⁄

" fuses.

HPS-RR*

600

KTK-R, LP-CC, FNQ-R Class
CC fuses.

*-EE, -JJ, -FF and -RR versions are UL Recognized for
applications requiring branch circuit protection.

No CSA Certification

20A max when used with quick-connect terminals.

HPS rated at 250V for CSA

Dimensions - in (mm)

Specifications
Description:

Standard fuse holders

with

bayonet-type knob

for

⁄

" x 1

⁄

fuses.

Dimensions:

See Dimensions

illustrations.

Agency Information:

CE, UL

Recognized, (Guide IZLT2, File
E14853).

Flammability Rating:

UL 94V0 - fuse

holder body UL 94HB - Knob.

Catalog Numbers

Catalog

Amp

Numbers Ratings Volts AC Fuse Description

HPG*

600

⁄

" x 1

⁄

" fuses

HPG-EE* 15

600

SC 0-15,

⁄

" x 1

⁄

" fuses.

HPD**

600

⁄

" x 1

⁄

" fuses

20A max when used with quick-connect terminals.

*HPG and HPG-EE has combination

⁄

" quick-connect/solder

terminals on both side (load) and rear (line) terminals.
**HPD has combination

⁄

" quick-connect/solder terminal on

side (load) terminal only. Rear (line) terminal is

⁄

" shorter

than HPG. Rear terminal solder only.

Dimensions - in (mm)

HPG, HPG-EE

HPD

HPF

HPD

HPG

HPS

#10 wire max

for solder connection

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

318

Fuse Holders and Blocks

Panel Mounted Fuse Holders for

⁄

" x 1

⁄

" Fuses

Data Sheet: 2112

Data Sheet: 2109

Data Sheet: 2140

Panel Mount Hole Dimensions

1.41"

(30.6mm)

0.94"

(23.8mm)

With Fuse

Without Fuse

2.73"

(69.5mm)

2.594"

(65.89mm)

0.250"

0.003"

(6.35

0.08mm)

1.031" + 0.003"

(26.2mm + 0.08mm)

0.187" + 0.002"

(4.75mm + 0.05mm)

Mounting Hole
Flange Rear of Panel

Mounting Hole
Flange Front of Panel

0.890" + 0.003"

(22.6mm + 0.08mm)

1.312" + 0.003"

(33.3mm + 0.08mm)

1.312" + 0.003"

(33.3mm + 0.08mm)

1.775"

(45.1mm)

0.180"

(4.6mm)

1.120"

(30.5mm)

0.88"

(22.2mm)

2.48"

(63.1mm)

With Fuse

Specifications
Description:

Standard fuse holder

with

screw-type knob

for

⁄

" x 1

⁄

fuses.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 600Vac/dc

Amps: — 30A

20A max when used with quick-connect terminals.

Agency Information:

CE, UL

Recognized, Guide IZLT2, File E14853;
CSA Certified, Class 6225-01, File
47235.

Flammability Rating:

UL 94HB.

Catalog Numbers

Catalog
Numbers

Description

HPM

⁄

" quick-connect/solder

HPM-D

Splash-resistant knob

HPM-D has

⁄

quick-connect/solder terminal on rear (load)

terminal only. The side (line) terminal is

⁄

" quick-

connect only.

Dimensions - in (mm)

Specifications
Description:

Fuse holder with

screw-type knob

for

⁄

" x 1

⁄

" fuses.

Supplied with O-ring and panel gasket.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 600Vac/dc

Amps: — 30A

20A max when used with quick-connect terminals.

Agency Information:

CE, UL

Recognized, Guide IZLT2, File E14853.

Flammability Rating:

UL 94HB.

Catalog Numbers

Catalog
Number

Description

HPC-D

Mount in panels up to

⁄

" thick.

Replacement knob - BK/9987SA

Dimensions - in (mm)

Specifications
Description:

For fuse size

⁄

" x 1

⁄

meeting UL 1598 requirement that both
poles be removed simultaneously.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 600V@30A

Amps: — 0-30A

20A max when used with quick-connect terminals.

Agency Information:

UL 4248

recognized, (Guide IZLT2, File
E14853), CSA certified:
(Class 6225-01, File 47235).

Flammability Rating:

UL 94V0.

Terminals:

⁄

” quick-connect/solder.

Catalog Numbers

Catalog
Numbers

HPS2

Standard 10-in carton

BK/HPS2

Bulk 100-in carton

Dimensions - in (mm)

HPM

HPC-D

HPS2

#10 wire max

for solder connection

Nut Torque:

30 lb-in.

Replacement Knob:

Catalog Number: BK/9789-Y2
(50 pieces)

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

319

Fuse Holder

& Blocks

Fuse Holders and Blocks

Fuse Blocks for

⁄

" x 1

⁄

" Fuses

4405 -

0° Solder terminals

with integral terminal and clip

Dimensions - in (mm)

Note: Mounting screw hole diameter is 0.147" (3.7mm).
Counterbore diameter, 0.636" (8.0mm). Max Mounting
Screw No. 6.

Specifications

Description:

Bolt-in and snap-in mounting for

⁄

" x 1

⁄

fuses.

Construction:

Blocks are molded flame retarded

thermoplastic. Clips are spring-bronze.

Ratings:

Volts: — 300V

Amps: — 25A (See Catalog Numbers table)

Agency Information:

CE, UL Recognized ; File E14853,

Guide IZLT2, CSA Certified Class 6225-01, File 47235.

Anti-Rotation Pin:

Single-pole blocks may be ordered

without the anti-rotational pin simply by adding an “X” to the
number of poles (Example: BK/S-8000-1X).

Carton Quantity:

10; shelf package: 100.

Bulk Carton:

Single-pole and 2-pole fuse blocks – 1,000;

Multiple-pole fuse blocks – 3- to 8-pole: 200; 9- to 12-pole:
50. When ordering bulk quantities, prefix “BK/” to catalog
number: (Example: BK/S-8001-1-SNP).

2.31"

(58.7mm)

1.63"

(41.3mm)

0.27"

(6.7mm)

0.69"

(17.5mm)

Catalog Numbers

Bolt-in Mounting

Basic
Catalog

Agency

Poles

Numbers

Series

Terminal

Angle

Maximums

(Suffix)

S-8001-

8000

Solder

0°

UL 25A

1 - 12

S-8002-

40°

CSA 21A

S-8101-

8100

⁄

" Quick

0°

UL 20A

S-8102-

Connect

40°

CSA 13A

S-8201-

8200

⁄

" Quick

0°

UL 20A

S-8202-

Connect

40°

CSA 16A

S-8203-

Side

S-8301-

8300

Screw

—

UL 30A
CSA 25A

Snap-in Mounting

Catalog

Agency

Poles

Numbers

Series

Terminal

Angle

Maximums

(Suffix)

S-8001-1-SNP

8000

Solder

0°

UL 25A

Available

S-8002-1-SNP

40°

CSA 21A

only in

S-8101-1-SNP

8100

⁄

" Quick

0°

UL 20A

single

S-8102-1-SNP

Connect

40°

CSA 13A

pole

S-8201-1-SNP

8200

⁄

" Quick

0°

UL 20A

S-8203-1-SNP

Connect

Side

CSA 16A

Catalog Number Build-A-Code

4406 -

Side solder terminal

4574 -

Spare fuse block

Dimensions - in (mm)

2499 -

Side quick-connect

Agency Information:

Recognized, Guide IZLT2, File
E14853

Terminals:

⁄

" (6.4mm); 15A, 250V

Dimensions - in (mm)

Series 8000

Data Sheet: 2101

1.63"

(41.3mm)

0.27"

(6.7mm)

0.69"

(17.5mm)

0.27"

(6.7mm)

0.75"

(19.1mm)

0.5"

(12.7mm)

0.72"

(18.3mm)

1.63"

(41.3mm)

Single-Pole Fuse Blocks

Specifications

Description:

Single-pole fuse block for

⁄

" x 1

⁄

(6.4 x 31.8mm) size fuses.

Dimensions:

See Dimensions illustrations.

Construction:

Bakelite base width

⁄

" (12.7mm); spring-

bronze, bright tin-lead plate clips.

Ratings:

Volts: — 250V

Amps: — 30A

8000

Available

only in

single

pole

1 - 12

8100

8300

8200

Catalog Code

BK/

S-8 0

-00

Prefix

for

ulk

Packing

Series

8000

Product

Line

Terminal

Angle

“01”

straight

(0,)

“02”-

“03”

side*

Type

Terminal

“0”-Solder
“1”-

‹

¡§∑

Quick

Connect

“2”

⁄

¢∑

Quick

Connect

“3”

Screw

Number

Poles

(1-12)

*Available

only

single

pole

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

320

Fuse Holders and Blocks

No. 4520 -

Integral clip and straight solder

terminals

Fuse Blocks for

⁄

" x 1" Fuses

0.19"

(4.8mm)

0.63"

(15.9mm)

1.88"

(47.6mm)

1.38"

(34.9mm)

1.94"

(49.2mm)

1.38"

(34.9mm)

.188"

(4.8mm)

.598"

(15.2mm)

1.38"

(34.9mm)

0.188"

(4.8mm)

0.598"

(15.2mm)

No. 4393 -

Spare fuse block

3828 Series

4520 and 4393

Specifications
Description:

Fuse block for

⁄

" x 1" (6.4 x 25.4mm) fuses

with solder terminals.

Dimensions:

See Dimensions illustration.

Ratings:

Volts: — 250V

Amps: — 30A

Mounting:

Mounting screw hole diameter is 0.147"

(3.7mm), diameter. Max mounting screw No. 6.

Catalog Numbers

Poles

*Base Length - in (mm)

3828-1

⁄

(12.7)

3828-2

⁄

(28.6)

3828-3

⁄

(44.5)

3828-4

⁄

(60.3)

3828-5

3 (76.2)

3828-6

⁄

(92.1)

3828-7

⁄

(108.0)

3828-8

⁄

(123.8)

3828-10

⁄

(155.6)

3828-12

⁄

(187.3)

*Small phenolic base, base width 1

⁄

" (34.9mm)

Dimensions - in (mm)

Specifications
Description:

Single-pole fuse block for

⁄

" x 1" fuses.

Dimensions:

See Dimensions illustrations.

Construction:

Bakelite with

⁄

" (12.7mm) width base.

Spring-bronze, bright tin-lead plated clips.

Ratings:

Volts: — 250V

Amps: — 30A

Mounting:

Mounting screw hole diameter is 0.147"

(3.7mm), counterbore 0.636" (8.0mm) diameter. Max
mounting screw No. 6.

Catalog Numbers

Catalog
Numbers

Description

4520

Integral clip and straight solder terminals

4393

Spare fuse block

Dimensions - in (mm)

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

321

Fuse Holder

& Blocks

Fuse Holders and Blocks

Blocks for

⁄

" X 1

⁄

" Fuses

Specifications

Description:

Add-on fuse blocks for

⁄

" X 1

⁄

" (10.3 X 38.1mm) fuses.

Single pole blocks lock into each other
and can be added at any time. Each
has a single end barrier.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 600Vac/dc

Amps: — 30A

Agency Information:

CE, UL

Recognized Guide IZLT2, File E14853.

3742—End Barrier Only

3723—Block and end barrier

marking strip. Length is 9

⁄

(23.8cm).

Note: Mounting screw hole is 0.147"
(3.7mm) dia. Counterbore, 0.636"
(8mm) dia. Max. mounting screw No. 6.

Specifications

Description:

Single pole fuse blocks

for

⁄

" X 1

⁄

" (10.3 X 38.1mm) fuses.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 250Vac/dc (or less)

Amps: — 30A

Agency Information:

4421—Solder Terminals

Base width

⁄

" (15.9mm)

4515—Screw Terminals

Base width

⁄

" (19mm)

Note: Mounting screw hole diameter is
0.147" (3.7mm). Countersink, 0.312"
(7.9mm). Max. mounting screw No. 6.

Specifications

Description:

Multiple pole fuse blocks

for

⁄

" X 1

⁄

" (10.3 X 38.1mm) fuses.

Dimensions:

See Dimensions

illustration.

Ratings:

Volts: — 250Vac/dc

Amps: — 30A

Agency Information:

Catalog Numbers

Catalog

Base* Width

Numbers

Poles

In (mm)

3835-1

⁄

(21.4)

3835-2

⁄

(46.0)

3835-3

⁄

(70.6)

3835-4

⁄

(95.2)

3835-5

⁄

(119.9)

3835-6

⁄

(144.5)

3835-7

⁄

(169.0)

3835-8

⁄

(193.7)

3835-9

⁄

(218.8)

3835-10

⁄

(242.9)

3835-12

⁄

(292.1)

*Base length: 2

⁄

" (69.9mm)

Dimensions - in (mm)

Note: Mounting screw hole diameter is
0.148" (3.7mm). Countersink, 0.313"
(7.9mm). Max. mounting screw No. 6.

3 7 4 2

0.25"

2.56"

1.125"

1.29"

0.84"

0.500"

1.125"

(28.6mm)

2.56"

(65.1mm)

0.78"

(19.8mm)

1.34"

(34.1mm)

0.25"

(6.4mm)

0.323"

(8.2mm)

0.144"

0.19"

(4.8mm)

0.897"

(22.78mm)

2.5"

(63.5mm)

1.63"

(41.3mm)

2.56"

(65.1mm)

0.19"

(4.8mm)

0.897"

(22.78mm)

2.75"

(69.9mm)

0.25"

(6.4mm)

1.0"

(25.4mm)

3743

4421 and 4515

3835 Series

Data Sheet: 2104

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com

For product data sheets, visit www.cooperbussmann.com/DatasheetsEle

322

Fuse Holders and Blocks

NDNF1-WH

Specifications

Description:

Fuse holding rail

mount terminal block.

Circuit Jumper:

JF1,

2 circuits

Fuse Size:

⁄

" X 1

⁄

(KTK, FNQ, PVM).

Poles:

Wire Range:

AWG #8-22 Cu.

Ratings:

Volts: — 600V

Amps: — 30A

Mounting Options

: 35mm DIN-Rail, C-rail

Fuse Pullers

: • PF1 (standard)

• neon or incandescent bulb

*LPF1 (lighted neon or incandescent bulb).

Torque Rating

: 18 lb-in

Operating Temperature

: 105°C

Catalog Numbers

Catalog

Number

Color

NDNF1-WH

White

Fuse Pullers (Optional):

PF1

Lighted neon or incandescent lamp:

Catalog

Numbers

Voltage

LPF1-24

LPF1-120

120

LPF1-120-C

120

LPF1-220

220

LPF1-440

440

NDNLFD1-WH

Specifications

Description:

Rail mount

fuse holder.

Circuit Jumper:

JF1,

2 circuits.

Fuse Size:

⁄

" X 1

⁄

(Bussmann AGC, MDL or
equivalent).

Poles:

Wire Range:

AWG #8-22 Cu.

Ratings:

Volts: — 600V

Amps: — 30A (NDND1 non-fused)

— 15A (NDNFD1, 600V/CSA, fused)

— 15A (NDNLFD1*fused, indicating)

*WH24 - 24V White, WH-90Vdc-600Vdc, 115Vac-600Vac White

Agency Information:

Mounting Options

: 35mm DIN-Rail, C-rail

Marking Tape

: MT12-1-2

Torque Rating

: 18 lb-in

Operating Temperature

: 105°C

Agency Information

: CSA File 15364

Catalog Numbers

Catalog

Number

Color

Indicator

NDND1-WH

White

NDNFD1-WH

White

NDNLFD1-WH

White

90Vdc-600Vdc
115Vac-600Vac

NDNLFD1-WH 24

White

24V

Rail Mount Fuse Blocks and Holders

Courtesy of Steven Engineering, Inc. - (800) 258-9200 - sales@steveneng.com - www.stevenengineering.com
