Industrial Assembly & Maintenance
Dow Corning
®
brand Silicone Sealants and Foams
for Industrial Assembly and Maintenance
Selection Guide
PROTECT
ADHERE
SEAL
Stability over a wide temperature range
When properly cured, most of our products
can be used at temperatures ranging from
-70 to 350°F/-56 to 177°C (400°F/204°C
intermittent), with still others capable of
higher thermal stability up to and exceeding
500°F/260°C (600°F/315°C intermittent).
Weather resistance
High resistance to ultraviolet (UV) rays,
radiation and weather prevents our products
from hardening, cracking, crumbling, drying
and becoming brittle.
Chemical stability
Our sealants do not readily degrade, even
under long-term exposure to many chemicals
and atmospheric pollutants.
Good bond strength
Our products provide good adhesion to a
wide variety of industrial materials, including
glass, ceramics and wood masonry; painted
surfaces; and many metals and plastics.
Electrical properties
Designed for a variety of applications, our
products can be used in various electrical
and electronic applications, including devices
that are thermally cycled over a wide tem-
perature range.
Low flammability
In fire conditions, silicone adhesives/sealants
are reluctant to burn. Many products comply
with UL flammability standards.
Dow Corning
®
Silicone Sealants
Silicon-based
Dow Corning
®
sealants last longer and are more versatile than most organic
polymer sealants. They are durable RTV sealants; cure at room temperature to a tough,
rubbery solid with exceptional performance characteristics; and meet a wide variety of your
industrial bonding and sealing needs.
Benefits of
Dow Corning
silicone sealants include:
When you specify an assembly and maintenance product from Dow Corning, you receive a
solution backed by the world leader in silicone technology with more than 70 years of expertise
and innovations.
2
INDUSTRIAL ASSEMBLY
AND MAINTENANCE
SOLUTIONS FOR
Why Silicones?
For application versatility, durability, aesthetics and value, silicones outperform organics.
Silicone sealants from Dow Corning are unrivaled, delivering:
• Protection that typically lasts three times longer than organic materials in the same
applications, thus avoiding premature and costly renovations
• Proven performance with successful track records in a range of diverse applications
• Outstanding life-cycle value
• All-weather application and performance, with resistance to UV exposure, ozone, rain,
snow and extreme temperatures
• More durability than organic-based materials
• Continued flexibility and adhesion, even while being stretched or compressed
• Resistance to cracking, splits or tears
without hardening or fading
• Easy application over a wide
temperature range
Organics are prone to chemical reversion,
a phenomenon in which organic poly-
urethane loses its cured properties and
reverts to a substance with the softness
of chewing gum. The differences between
silicones and organics are the difference
between long-term value and premature
failure. Silicones prevail.
3
Which Silicone?
Silicone sealants from Dow Corning are offered in a wide range of formulation
options, including:
•
RTV (room-temperature-vulcanizing) sealants
These silicone polymers work with a condensation reaction in humidity at typical
room conditions, but the cure can be accelerated by increasing temperature and
humidity. RTV sealants are easy to install, and they offer relatively low cost and
good adhesion.
•
Heat cure sealants
Delivering much shorter cure times than RTV sealants, these materials can be
automatically dispensed to meet industrial equipment assembly requirements.
•
Hot-melt silicone sealants
Ideal for automated applications in the manufacturing of various components, these
reactive hot-melt materials provide instant green strength, which can increase
productivity, improve quality and reduce costs in industrial assembly applications.
•
One-part materials
Containing all the ingredients needed to produce a cured material, these sealants
use external factors – such as moisture in the air, heat or the presence of UV light
– to initiate, speed or complete the curing process. One-part sealant formulations are
easy to use and typically have a low- or room-temperature cure, but moisture-curing
materials may take 24 hours or more to fully cure.
•
Two-part materials
With the reactive ingredients separated to prevent premature initiation of the cure
process, these materials often use the addition of heat to facilitate or accelerate
cure. Two-part formulations typically offer longer shelf life, high-speed cure, and the
ability to carefully control working/open time and cure time by manipulating the
formulation, but they require mixing and may involve more sophisticated processes
and application expertise.
•
Silicone foams
Ideal as compression gaskets or as “environmental seals” to protect against ambient
air, splashed water, dust and moisture, these materials are a cost-effective sealing
solution compared to preformed gaskets and foam tapes for use sealing high-tolerance
gaps. Applied using automated robotic dispensing, these materials have a fast
room-temperature or low-temperature cure.
Sealant Chemistry
Silicone sealants typically consist of an inorganic siloxane (Si-O-Si-O-Si) polymer and
appropriate filler, crosslinker, catalyst, adhesion promoter, pigment and plasticizer.
To meet specific needs, silicone sealants are offered in a variety of chemistries
and cure types, each with their own benefits. The following tables will assist you
in selecting the right material to help meet your performance requirements.
4
TABLE I. SEALANT CHEMISTRIES
Chemistry
Surface Cure
Green Strength
Primerless
Adhesion
Shelf Life
Clear/T
ranslucent
Features
Limitations
Acid Cure
Acetoxy
(One-Part)
●●●
●
●
●●●
●●
• Competitively priced versus organics
• Fast cure
• No-catalyst versions available
• Good shelf life
• Clear
• Adhesion durability
• Acidic; potentially corrosive to
metals
• Strong odor
Neutral Cure
Alkoxy
(One-Part)
●
●
●●
●●
LA
1
• Neutral cure
• Robust adhesion
• Economical; chalk filled
• Low VOC
• Stability of silica system not robust,
so achieving clarity is difficult
• Slower cure speed
• 12-month shelf life
Oxime
(One-Part)
●●
●●
●
●
●●
• Fast cure
• Low-catalyst options possible
• Good silica versions with clear/translucent
offerings
• High-temperature (104°F/40°C)
storage causes discoloration
• Strong odor
• High VOC, typically due to large
leaving group
Alkoxy
(Two-Part)
●●
●●●
●
●
NA
• Fast cure/green strength; parts can be
moved in under 4 hours
• Total VOC low when mixed
• Tunable cure profile based on mix ratio
• Adhesion to many substrates
• Dispensing equipment and
maintenance
• Settling of components can be
an issue
• Catalyst is flammable
Hot Melt
(One-Part)
●●
●●●
●●●
●●
●●●
• Instant green strength for immediate hold
• Instant assembly – no “hold time” requirement
• Worker friendly – low odor,
nonhazardous
• Long pot life and long open time
• Proven neutral-cure 100% silicone chemistry
• Aggressive adhesion to a variety of substrates
• Not intended for use when in total
confinement (atmospheric moisture
required for cure)
• Not intended for continuous water
immersion
• Not intended for use on surfaces
that might bleed oils, plasticizers
or solvents
Platinum
(Two-Part)
“Silicone
Foams”
●
—
—
●
NA
• Fast-curing products available in heat cure
and room temperature cure options
• Ideal choice for compression gaskets
• Provides environmental sealing versus
elements
• Low sealing force/modulus
• Ideal for sealing enclosures requiring
serviceability
• Allows for flexibility in seal and bead design
• Not optimized for fluid sealing
• Does not offer high adhesion with-
out a primer or surface treatment
• Cure inhibition (“poisoning” of
platinum catalyst)
NA = Not available LA = Limited availability – = Poor • = Good •• = Better ••• = Best
1
Dow Corning
®
3145 RTV MIL-A-46146 Adhesive Sealant is available in clear translucent.
5
TABLE II. ACETOXY SEALANTS
Acetoxy Sealants
Acetoxy Sealants
High-Temperature Acetoxy Sealants
Dow Corning
®
700
Industrial Grade Silicone Sealant
Dow Corning
®
730 FS
Solvent Resistant Sealant
Dow Corning
®
732
Multi-Purpose Sealant
Dow Corning
®
733
Glass & Metal Sealant
Dow Corning
®
734
Flowable Sealant
Dow Corning
®
786
Mildew Resistant Sealant
Dow Corning
®
1890
Protective Coating
Dow Corning
®
736
Heat Resistant Sealant
Dow Corning
®
Q3-1566
Heat Resistant Adhesive/Sealant
Special Features
Resistant to weathering;
withstands temperature
extremes
Solvent-resistant
Multipurpose; FDA; NSF
Good adhesion
Flowable; self-leveling
Mildew-resistant
Excellent moisture protection
and resistance to sand, dust
and dirt particles; easy-to-apply,
thin coating that will not run
or drip when applied to vertical
or overhead surfaces
High-temperature-resistant
High-temperature-resistant
Primary Uses
General industrial sealing and
adhesive applications
Bonding, sealing and caulking
where resistance to fuels, oils
and solvents is required
General-purpose bond-
ing and sealing; making
formed-in-place gaskets
Bonding and sealing
To fill voids, cracks and crevices;
conformal coating for connections
and battery terminals
Interior sealing applications
exposed to high moisture
General-purpose coating
for protecting motors and
electrical equipment;
maintenance coating
Sealing and bonding applica-
tions exposed to tempera-
tures as high as 600°F
(315°C)
Sealing and bonding
applications exposed to
temperatures as high as
662°F (350°C)
Applications
1
Adhering auto trim, appliance
trim and nameplates; formed-
in-place gaskets for compres-
sors, gearboxes and pumps;
bonding appliance parts and
signs; caulking doors and
windows; sealing out moisture
Assembling and repairing
fuel lines and tanks; bonding
components exposed to fuels,
oils and solvents; making
formed-in-place gaskets
for chemical compressors,
fluid-filled distributors and
transformers; repairing rubber
linings exposed to corrosive
conditions; sealing pipe joints
on lines carrying corrosive
chemicals
Sealing flashing, vents,
flues, gutters, marine cabins
and windows, and electrical
boxes; caulking joints in
sheet metal stacks and
ductwork; bonding appliance
parts, signs and sign letters;
adhering auto trim, appliance
trim and nameplates; making
formed-in-place gaskets for
compressors, gearboxes and
pumps
Bonding and sealing appliances,
heavy equipment, marine equip-
ment and recreational vehicles
Coating mechanical devices;
making formed-in-place gaskets
for compressors, gearboxes
and pumps; potting electrical
terminals; sealing ammunition
fuses, trailers and truck cabs
Sealing tubs, sinks,
plumbing fixtures and
interior walls
Coating motor windings, bus
bars, splines, connectors,
transformers, insulators,
trailers, truck cabs and
wooden pole tops
Sealing fired heaters,
flanged pipe joints, access
doors, moving oven belts,
industrial ovens and boilers,
plywood drying ovens, bag
filters on smokestacks, and
flues on gas appliances;
bonding appliance parts and
electrical and electronic
equipment; caulking joints
in sheet metal stacks and
ductwork
Can be used in ovens,
cookers and other heating
equipment; automotive oil
and other coolant sealing
applications
Temperature Range
2
, °F/°C,
continuous (intermittent)
-70 to 350 (400)/-57 to 177 (204)
-70 to 350 (400)/-57 to 177 (204)
-85 to 500 (600)/-65 to 260
(315)
-58 to 527 (662)/-50 to 275
(350)
Skin-Over Time, min
13
5
10
10
7
5
15
10
5
Tack-Free Time, min
25
25
20
15
13
20
25
17
18
Extrusion Rate, g/min
350
250
350
350
650
350
—
390
270
Durometer, Shore A
20
40
25
25
27
25
21
26
43
Tensile, PSI
225
300
325
335
222
325
—
350
522
Elongation
577
200
600
500
315
600
—
600
340
Specific Gravity
1.02
1.4
1.04
1.03
1.03
1.04
1.03
1.04
1.06
Listings/Specs
FDA 21
3
; NSF 51; UL 94 HB
—
FDA 21
3
, NSF 51, NSF 61,
UL 94 HB, MIL spec
NSF 51, UL 94 HB, FDA
FDA 21
3
, NSF 51, UL 94 HB,
MIL spec
FDA 21
4
, NSF 51
FDA 21
3
FDA 21
3
, NSF 51, UL 94 HB,
MIL spec
—
Color
Aluminum, clear translucent,
white, black
White
Aluminum, black,
clear translucent, white
Aluminum, black,
clear translucent, white
Clear translucent, white
Clear translucent, white
Gray
Red
Black
Sealant Type for Fluid
Resistance Table
5
MQ
FVMQ
MQ
MQ
MQ
MQ
MQ
MQ
MQ
Primerless Adhesion
Acrylic
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
Acrylonitrile Butadiene
Styrene (ABS)
No Adhesion
No Adhesion
Fair
No Adhesion
No Adhesion
No Adhesion
Not Tested
Fair
Not Tested
Low Density Polyethylene
(LDPE)
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
Nylon 6/6
Poor
No Adhesion
Fair
Fair
Poor
Poor
Not Tested
Fair
Not Tested
Polycarbonate
No Adhesion
Poor
No Adhesion
Poor
Poor
No Adhesion
Not Tested
No Adhesion
Not Tested
Polypropylene (PP)
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
Glass
Poor
Poor
Fair
Fair
Poor
Fair
Not Tested
Fair
Not Tested
Aluminum, Mill Finish
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
Poor
Not Tested
Copper
Poor
Poor
Poor
Poor
Poor
No Adhesion
Not Tested
Fair
Not Tested
Steel, Galvanized
No Adhesion
No Adhesion
No Adhesion
Poor
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
Steel, Low Carbon
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
Steel, Stainless
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
1
Most paints will not adhere to sealant; not for underwater structural or adhesive applications; requires atmospheric moisture to cure. May stress-crack some plastics;
test
before
use.
2
Estimated service temperatures based on product formulation and laboratory testing. Actual service temperature range is dependent on other factors, including the
specific application environment.
3
Meets
FDA
CFR
21.177.2600.
4
Meets FDA CFR 21.177.2600 and FDA CFR 21.175.105.
5
Refer to the “Performance Profiles for
Silastic
®
brand Silicone and Fluorosilicone Rubber and XIAMETER
®
brand Silicone Rubber” guide, Form No. 45-0113, for
assistance in determining fluid resistance capabilities of selected sealant types.
6
Acetoxy Sealants
Acetoxy Sealants
High-Temperature Acetoxy Sealants
Dow Corning
®
700
Industrial Grade Silicone Sealant
Dow Corning
®
730 FS
Solvent Resistant Sealant
Dow Corning
®
732
Multi-Purpose Sealant
Dow Corning
®
733
Glass & Metal Sealant
Dow Corning
®
734
Flowable Sealant
Dow Corning
®
786
Mildew Resistant Sealant
Dow Corning
®
1890
Protective Coating
Dow Corning
®
736
Heat Resistant Sealant
Dow Corning
®
Q3-1566
Heat Resistant Adhesive/Sealant
Special Features
Resistant to weathering;
withstands temperature
extremes
Solvent-resistant
Multipurpose; FDA; NSF
Good adhesion
Flowable; self-leveling
Mildew-resistant
Excellent moisture protection
and resistance to sand, dust
and dirt particles; easy-to-apply,
thin coating that will not run
or drip when applied to vertical
or overhead surfaces
High-temperature-resistant
High-temperature-resistant
Primary Uses
General industrial sealing and
adhesive applications
Bonding, sealing and caulking
where resistance to fuels, oils
and solvents is required
General-purpose bond-
ing and sealing; making
formed-in-place gaskets
Bonding and sealing
To fill voids, cracks and crevices;
conformal coating for connections
and battery terminals
Interior sealing applications
exposed to high moisture
General-purpose coating
for protecting motors and
electrical equipment;
maintenance coating
Sealing and bonding applica-
tions exposed to tempera-
tures as high as 600°F
(315°C)
Sealing and bonding
applications exposed to
temperatures as high as
662°F (350°C)
Applications
1
Adhering auto trim, appliance
trim and nameplates; formed-
in-place gaskets for compres-
sors, gearboxes and pumps;
bonding appliance parts and
signs; caulking doors and
windows; sealing out moisture
Assembling and repairing
fuel lines and tanks; bonding
components exposed to fuels,
oils and solvents; making
formed-in-place gaskets
for chemical compressors,
fluid-filled distributors and
transformers; repairing rubber
linings exposed to corrosive
conditions; sealing pipe joints
on lines carrying corrosive
chemicals
Sealing flashing, vents,
flues, gutters, marine cabins
and windows, and electrical
boxes; caulking joints in
sheet metal stacks and
ductwork; bonding appliance
parts, signs and sign letters;
adhering auto trim, appliance
trim and nameplates; making
formed-in-place gaskets for
compressors, gearboxes and
pumps
Bonding and sealing appliances,
heavy equipment, marine equip-
ment and recreational vehicles
Coating mechanical devices;
making formed-in-place gaskets
for compressors, gearboxes
and pumps; potting electrical
terminals; sealing ammunition
fuses, trailers and truck cabs
Sealing tubs, sinks,
plumbing fixtures and
interior walls
Coating motor windings, bus
bars, splines, connectors,
transformers, insulators,
trailers, truck cabs and
wooden pole tops
Sealing fired heaters,
flanged pipe joints, access
doors, moving oven belts,
industrial ovens and boilers,
plywood drying ovens, bag
filters on smokestacks, and
flues on gas appliances;
bonding appliance parts and
electrical and electronic
equipment; caulking joints
in sheet metal stacks and
ductwork
Can be used in ovens,
cookers and other heating
equipment; automotive oil
and other coolant sealing
applications
Temperature Range
2
, °F/°C,
continuous (intermittent)
-70 to 350 (400)/-57 to 177 (204)
-70 to 350 (400)/-57 to 177 (204)
-85 to 500 (600)/-65 to 260
(315)
-58 to 527 (662)/-50 to 275
(350)
Skin-Over Time, min
13
5
10
10
7
5
15
10
5
Tack-Free Time, min
25
25
20
15
13
20
25
17
18
Extrusion Rate, g/min
350
250
350
350
650
350
—
390
270
Durometer, Shore A
20
40
25
25
27
25
21
26
43
Tensile, PSI
225
300
325
335
222
325
—
350
522
Elongation
577
200
600
500
315
600
—
600
340
Specific Gravity
1.02
1.4
1.04
1.03
1.03
1.04
1.03
1.04
1.06
Listings/Specs
FDA 21
3
; NSF 51; UL 94 HB
—
FDA 21
3
, NSF 51, NSF 61,
UL 94 HB, MIL spec
NSF 51, UL 94 HB, FDA
FDA 21
3
, NSF 51, UL 94 HB,
MIL spec
FDA 21
4
, NSF 51
FDA 21
3
FDA 21
3
, NSF 51, UL 94 HB,
MIL spec
—
Color
Aluminum, clear translucent,
white, black
White
Aluminum, black,
clear translucent, white
Aluminum, black,
clear translucent, white
Clear translucent, white
Clear translucent, white
Gray
Red
Black
Sealant Type for Fluid
Resistance Table
5
MQ
FVMQ
MQ
MQ
MQ
MQ
MQ
MQ
MQ
Primerless Adhesion
Acrylic
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
Acrylonitrile Butadiene
Styrene (ABS)
No Adhesion
No Adhesion
Fair
No Adhesion
No Adhesion
No Adhesion
Not Tested
Fair
Not Tested
Low Density Polyethylene
(LDPE)
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
Nylon 6/6
Poor
No Adhesion
Fair
Fair
Poor
Poor
Not Tested
Fair
Not Tested
Polycarbonate
No Adhesion
Poor
No Adhesion
Poor
Poor
No Adhesion
Not Tested
No Adhesion
Not Tested
Polypropylene (PP)
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
Glass
Poor
Poor
Fair
Fair
Poor
Fair
Not Tested
Fair
Not Tested
Aluminum, Mill Finish
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
Poor
Not Tested
Copper
Poor
Poor
Poor
Poor
Poor
No Adhesion
Not Tested
Fair
Not Tested
Steel, Galvanized
No Adhesion
No Adhesion
No Adhesion
Poor
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
Steel, Low Carbon
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
Steel, Stainless
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
Not Tested
7
TABLE III. ALKOXY (NEUTRAL-CURE) SEALANTS
Dow Corning
®
739
Plastic Adhesive
Dow Corning
®
748
Noncorrosive Sealant
Dow Corning
®
832
Multi-Surface Adhesive/Sealant
Dow Corning
®
838
Silicone Adhesive/Sealant
Dow Corning
®
3145
RTV MIL-A-46146
Adhesive Sealant
Dow Corning
®
7091
Adhesive Sealant
Dow Corning
®
7092
High Green Strength Adhesive
and Sealant
Special Features
Plastic adhesive
FDA- and NSF-approved
Excellent adhesion
Nonflowing; high elongation for added
stress-relief; UL 94 HB; faster in-line
processing with optional heat acceler-
ation; added reliability can result from
lower cured stress
Nonflowing; high tensile/tear strength
and elongation; faster in-line process-
ing with optional heat acceleration;
can be considered for uses with Mil
Spec requirements
Non-sag; paste consistency; easy
to apply; cures to a tough, flexible
rubber; excellent adhesion to many
substrates
Instant green strength; easy to use;
excellent adhesion to a wide range of
substrates, such as glass, metals and
plastics; non-sag; paste consistency;
fast strength buildup supports
productivity enhancements due to
fast handling of bonded units; saves
time, as no buffer for strength buildup
required
Primary Uses
Adhering, bonding and sealing plastic
and metal; making formed-in-place
gaskets
Electrical sealing applications;
food-processing and transportation
applications
Bonding, sealing and assembly where a
noncorrosive sealant is required
General-purpose adhesive applica-
tions using automated or manual
needle dispensing systems
Sealing and assembly in applications
requiring Mil Spec standards
Applications that demand a strong but
flexible bond, such as when bonding
materials with differing thermal
expansion rates (e.g., glass to metal
or glass to plastic)
Applications that require immediate
handling and processing of the units
Applications
1
Adhering auto trim, appliance trim and
parts; assembling plastic toys; bonding
gaskets in refrigeration units, signs and
sign letters; caulking cement and
masonry; making formed-in-place
gaskets for compressors, gearboxes and
pumps; sealing flashing, vents, gutters,
marine cabins and windows; waterproofing
leakproof tractor cabs
Bonding and sealing electrical equip-
ment, power and control connections,
motors, cover plates, instrument lenses,
regulators, junction boxes, and control
panels; sealing refrigerator and freezer
liners
Sealing and repairing roof penetrations,
gutters, concrete floor seams, marine
equipment and windows, pipes, and
threaded connections; assembling
original equipment components
Sealing openings in modules and
housings; adding mechanical stability
to individual components; assembly of
components on printed wiring boards
(PWBs); sealing in and around wired
and electrical leads; yoke assembly
Sealing openings in modules and
housings; assembly of components
on printed wiring boards (PWBs);
sealing in and around wired and
electrical leads
Adhering commonly used materials,
including enameled and painted steel,
aluminum, ceramic and glass, as well
as to certain plastics used in engi-
neering applications; formed-in-place
gasket (FIPG) applications
Adhering commonly used materials,
including certain steels, aluminum and
glass, as well as certain plastics used
in engineering applications
Temperature Range
2
, °F/°C,
continuous (intermittent)
-65 to 300 (350)/-54 to 149 (177)
-65 to 350 (400)/-55 to 177 (204)
-67 to 300 (350)/-55 to 149 (177)
-49 to 392/-45 to 200
-49 to 392/-45 to 200
-40 to 356/-40 to 180
-58 to 302/-50 to 150
Skin-Over Time, min
25
15
20
—
—
15
15-25
Tack-Free Time, min
45
30
50
33
63.8
41
Extrusion Rate, g/min
110
150
133
199.2
78.6
185
217
Durometer, Shore A
37
25
35
31
45.6
32
55
Tensile, PSI
225
275
350
270
138
363
290
Elongation
640
350
420
—
626
680
435
Specific Gravity
1.52
1.33
1.33
1.02
1.10
1.4
1.55
Listings/Specs
UL 94 HB
FDA 21
3
, NSF 51, NSF 61, UL 94 HB
UL 94 HB
UL 94 HB
MIL-A-46146 Group II, TY I, UL 94 HB —
UL 94 HB
Color
Black, gray, white
Off-white
Black, gray, off-white
White
Clear translucent
Black, white, gray
Black, white
Sealant Type for Fluid
Resistance Table
4
MQ
MQ
MQ
MQ
MQ
MQ
MQ
Primerless Adhesion
Acrylic
Good
No Adhesion
Fair
Not Tested
No Adhesion
Excellent
Not Tested
Acrylonitrile Butadiene
Styrene (ABS)
Excellent
No Adhesion
Excellent
Not Tested
No Adhesion
Excellent
Not Tested
Low Density Polyethylene
(LDPE)
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
No Adhesion
Not Tested
Nylon 6/6
Excellent
Good
Excellent
Not Tested
Fair
Excellent
Not Tested
Polycarbonate
No Adhesion
No Adhesion
Excellent
Not Tested
No Adhesion
No Adhesion
Not Tested
Polypropylene (PP)
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
No Adhesion
Not Tested
Glass
Excellent
Excellent
Excellent
Not Tested
Good
Excellent
Not Tested
Aluminum, Mill Finish
Excellent
Excellent
Excellent
Not Tested
Poor
Excellent
Not Tested
Copper
Good
No Adhesion
Excellent
Not Tested
No Adhesion
Excellent
Not Tested
Steel, Galvanized
Excellent
Excellent
Excellent
Not Tested
No Adhesion
Excellent
Not Tested
Steel, Low Carbon
Fair
Excellent
Excellent
Not Tested
Poor
Excellent
Not Tested
Steel, Stainless
Poor
Fair
Excellent
Not Tested
No Adhesion
Good
Not Tested
1
Most paints will not adhere to sealant; not for underwater structural or adhesive applications; requires atmospheric moisture to cure. May stress-crack some plastics;
test
before
use.
2
Estimated service temperatures based on product formulation and laboratory testing. Actual service temperature range is dependent on other factors,
including the specific application environment.
3
Meets FDA CFR 21.177.2600 and FDA CFR 21.175.105.
4
Refer to the “Performance Profiles for
Silastic
®
brand Silicone and Fluorosilicone Rubber and XIAMETER
®
brand Silicone Rubber” guide,
Form No. 45-0113, for assistance in determining fluid resistance capabilities of selected sealant types.
8
Dow Corning
®
739
Plastic Adhesive
Dow Corning
®
748
Noncorrosive Sealant
Dow Corning
®
832
Multi-Surface Adhesive/Sealant
Dow Corning
®
838
Silicone Adhesive/Sealant
Dow Corning
®
3145
RTV MIL-A-46146
Adhesive Sealant
Dow Corning
®
7091
Adhesive Sealant
Dow Corning
®
7092
High Green Strength Adhesive
and Sealant
Special Features
Plastic adhesive
FDA- and NSF-approved
Excellent adhesion
Nonflowing; high elongation for added
stress-relief; UL 94 HB; faster in-line
processing with optional heat acceler-
ation; added reliability can result from
lower cured stress
Nonflowing; high tensile/tear strength
and elongation; faster in-line process-
ing with optional heat acceleration;
can be considered for uses with Mil
Spec requirements
Non-sag; paste consistency; easy
to apply; cures to a tough, flexible
rubber; excellent adhesion to many
substrates
Instant green strength; easy to use;
excellent adhesion to a wide range of
substrates, such as glass, metals and
plastics; non-sag; paste consistency;
fast strength buildup supports
productivity enhancements due to
fast handling of bonded units; saves
time, as no buffer for strength buildup
required
Primary Uses
Adhering, bonding and sealing plastic
and metal; making formed-in-place
gaskets
Electrical sealing applications;
food-processing and transportation
applications
Bonding, sealing and assembly where a
noncorrosive sealant is required
General-purpose adhesive applica-
tions using automated or manual
needle dispensing systems
Sealing and assembly in applications
requiring Mil Spec standards
Applications that demand a strong but
flexible bond, such as when bonding
materials with differing thermal
expansion rates (e.g., glass to metal
or glass to plastic)
Applications that require immediate
handling and processing of the units
Applications
1
Adhering auto trim, appliance trim and
parts; assembling plastic toys; bonding
gaskets in refrigeration units, signs and
sign letters; caulking cement and
masonry; making formed-in-place
gaskets for compressors, gearboxes and
pumps; sealing flashing, vents, gutters,
marine cabins and windows; waterproofing
leakproof tractor cabs
Bonding and sealing electrical equip-
ment, power and control connections,
motors, cover plates, instrument lenses,
regulators, junction boxes, and control
panels; sealing refrigerator and freezer
liners
Sealing and repairing roof penetrations,
gutters, concrete floor seams, marine
equipment and windows, pipes, and
threaded connections; assembling
original equipment components
Sealing openings in modules and
housings; adding mechanical stability
to individual components; assembly of
components on printed wiring boards
(PWBs); sealing in and around wired
and electrical leads; yoke assembly
Sealing openings in modules and
housings; assembly of components
on printed wiring boards (PWBs);
sealing in and around wired and
electrical leads
Adhering commonly used materials,
including enameled and painted steel,
aluminum, ceramic and glass, as well
as to certain plastics used in engi-
neering applications; formed-in-place
gasket (FIPG) applications
Adhering commonly used materials,
including certain steels, aluminum and
glass, as well as certain plastics used
in engineering applications
Temperature Range
2
, °F/°C,
continuous (intermittent)
-65 to 300 (350)/-54 to 149 (177)
-65 to 350 (400)/-55 to 177 (204)
-67 to 300 (350)/-55 to 149 (177)
-49 to 392/-45 to 200
-49 to 392/-45 to 200
-40 to 356/-40 to 180
-58 to 302/-50 to 150
Skin-Over Time, min
25
15
20
—
—
15
15-25
Tack-Free Time, min
45
30
50
33
63.8
41
Extrusion Rate, g/min
110
150
133
199.2
78.6
185
217
Durometer, Shore A
37
25
35
31
45.6
32
55
Tensile, PSI
225
275
350
270
138
363
290
Elongation
640
350
420
—
626
680
435
Specific Gravity
1.52
1.33
1.33
1.02
1.10
1.4
1.55
Listings/Specs
UL 94 HB
FDA 21
3
, NSF 51, NSF 61, UL 94 HB
UL 94 HB
UL 94 HB
MIL-A-46146 Group II, TY I, UL 94 HB —
UL 94 HB
Color
Black, gray, white
Off-white
Black, gray, off-white
White
Clear translucent
Black, white, gray
Black, white
Sealant Type for Fluid
Resistance Table
4
MQ
MQ
MQ
MQ
MQ
MQ
MQ
Primerless Adhesion
Acrylic
Good
No Adhesion
Fair
Not Tested
No Adhesion
Excellent
Not Tested
Acrylonitrile Butadiene
Styrene (ABS)
Excellent
No Adhesion
Excellent
Not Tested
No Adhesion
Excellent
Not Tested
Low Density Polyethylene
(LDPE)
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
No Adhesion
Not Tested
Nylon 6/6
Excellent
Good
Excellent
Not Tested
Fair
Excellent
Not Tested
Polycarbonate
No Adhesion
No Adhesion
Excellent
Not Tested
No Adhesion
No Adhesion
Not Tested
Polypropylene (PP)
No Adhesion
No Adhesion
No Adhesion
Not Tested
No Adhesion
No Adhesion
Not Tested
Glass
Excellent
Excellent
Excellent
Not Tested
Good
Excellent
Not Tested
Aluminum, Mill Finish
Excellent
Excellent
Excellent
Not Tested
Poor
Excellent
Not Tested
Copper
Good
No Adhesion
Excellent
Not Tested
No Adhesion
Excellent
Not Tested
Steel, Galvanized
Excellent
Excellent
Excellent
Not Tested
No Adhesion
Excellent
Not Tested
Steel, Low Carbon
Fair
Excellent
Excellent
Not Tested
Poor
Excellent
Not Tested
Steel, Stainless
Poor
Fair
Excellent
Not Tested
No Adhesion
Good
Not Tested
9
TABLE IV. TWO-PART ALKOXY AND ONE-PART OXIME (NEUTRAL-CURE) SEALANTS
Neutral, Two-Component
Neutral, Oxime
Dow Corning
®
Q3-3636
Adhesive
Dow Corning
®
236
Dispersion
Dow Corning
®
737
Neutral Cure Sealant
Dow Corning
®
750
Plastic-Surface Adhesive/Sealant
Dow Corning
®
1437
Industrial Sealant and Adhesive
Special Features
Fast cure at room temperature; good, durable adhesion; reduced weight loss (fogging) at high
operating temperatures; fast assembly process; adhesion to a wide variety of substrates;
through cure and not an outside-inward cure like typical moisture-cure adhesives; not
humidity-cure-sensitive
Excellent release; weather resistance;
excellent electrical insulator; coating;
675 cps viscosity
Fast cure
Excellent adhesion to a wide range
of substrates, including polymeric
surfaces that are traditionally difficult
to adhere to, such as anodized
aluminum, vinyl, PVC, polypropylene,
polyethylene, powder coat, paint and
fluoropolymer coatings; priming not
required on most surfaces; usable
over wide temperature range
Fast cure; adheres to glass, metals
and many plastics; wide temperature
range
Primary Uses
Durable adhesive sealing of components that must perform in difficult environments
Release coating for surfaces that offer
protection from weathering, corrosion
and dirt
General manufacturing assembly
operations where quick cure and good
adhesion are important
Adhering, bonding and sealing
a wide range of low-energy
metallic and thermoplastic surfaces
Industrial assembly and maintenance
applications
Applications
1
Bonding of polycarbonate or glass lenses to the reflector housing of headlamps and fog lamps; in
appliance manufacturing, especially for oven and ceramic hob assembly or for bonding glass to
metal, glass to painted metal or glass to plastic
Easing cleanup of latex-manufacturing
equipment and paint-spraying opera-
tions and removal of flash in urethane
and polyester molding; preventing
adhesion and buildup on conveyor
belts, paper and fabric rolls; reducing
buildup on waste-handling equipment
OEM and assembly applications;
substitute for mechanical fasteners on
appliances; adhering plastic moldings
to plastic substrates; waterproofing
components; sealing coaxial connectors;
protecting instrumentation; may be
used on concrete and masonry
Interior air sealing between a sheet-
or liquid-applied weather-resistant
barrier and fenestration element; edge
lap seal for weather-resistant barriers;
sealing penetrations in weather-
resistant barriers such as plumbing
or ductwork; sealing other difficult-to-
adhere surfaces, such as mill finishes
and plastics
Automated application systems for
OEM applications
Temperature Range
2
, °F/°C, continuous (intermittent)
—
-40 to 300/-40 to 150
-85 to 350/-65 to 177
—
-60 to 300/-51 to 149
Skin-Over Time, min
2.5-10 min working time
85
5
15
Tack-Free Time, min
5-20
120
14
—
9
Extrusion Rate, g/min
—
n/a
395
252
300-400
Durometer, Shore A
32-35
20
33
28
21
Tensile, PSI
>261
325
175
190
130
Elongation
>300
500
300
785
300
Specific Gravity
1.31 (base)/1.00-1.04 (catalyst)
1.64
1.04
1.38
1.04
Listings/Specs
—
—
UL 94 HB
—
UL 94 HB
Color
Gray, black, special black
White
Black, clear translucent, white
White
Clear translucent
Sealant Type for Fluid Resistance Table
3
MQ
MQ
MQ
MQ
MQ
Primerless Adhesion
Acrylic
Excellent
Not Tested
No Adhesion
Excellent
Excellent
Acrylonitrile Butadiene Styrene (ABS)
Fair
Not Tested
Poor
Excellent
Good
Low Density Polyethylene (LDPE)
No Adhesion
Not Tested
No Adhesion
Poor
No Adhesion
Nylon 6/6
Poor
Not Tested
No Adhesion
Excellent
Good
Polycarbonate
Excellent
Not Tested
Fair
Excellent
Excellent
Polypropylene (PP)
No Adhesion
Not Tested
No Adhesion
Excellent
No Adhesion
Glass
Fair
Not Tested
Excellent
Excellent
Excellent
Aluminum, Mill Finish
Fair
Not Tested
Excellent
Excellent
Excellent
Copper
Excellent
Not Tested
Fair
Excellent
Excellent
Steel, Galvanized
Excellent
Not Tested
Fair
Excellent
Excellent
Steel, Low Carbon
Excellent
Not Tested
Excellent
Excellent
Excellent
Steel, Stainless
Fair
Not Tested
Excellent
Fair
Excellent
1
Most paints will not adhere to sealant; not for underwater structural or adhesive applications; requires atmospheric moisture to cure. May stress-crack some plastics;
test
before
use.
2
Estimated service temperatures based on product formulation and laboratory testing. Actual service temperature range is dependent on other factors,
including the specific application environment.
3
Refer to the “Performance Profiles for
Silastic
®
brand Silicone and Fluorosilicone Rubber and XIAMETER
®
brand Silicone Rubber” guide,
Form No. 45-0113, for assistance in determining fluid resistance capabilities of selected sealant types.
10
Neutral, Two-Component
Neutral, Oxime
Dow Corning
®
Q3-3636
Adhesive
Dow Corning
®
236
Dispersion
Dow Corning
®
737
Neutral Cure Sealant
Dow Corning
®
750
Plastic-Surface Adhesive/Sealant
Dow Corning
®
1437
Industrial Sealant and Adhesive
Special Features
Fast cure at room temperature; good, durable adhesion; reduced weight loss (fogging) at high
operating temperatures; fast assembly process; adhesion to a wide variety of substrates;
through cure and not an outside-inward cure like typical moisture-cure adhesives; not
humidity-cure-sensitive
Excellent release; weather resistance;
excellent electrical insulator; coating;
675 cps viscosity
Fast cure
Excellent adhesion to a wide range
of substrates, including polymeric
surfaces that are traditionally difficult
to adhere to, such as anodized
aluminum, vinyl, PVC, polypropylene,
polyethylene, powder coat, paint and
fluoropolymer coatings; priming not
required on most surfaces; usable
over wide temperature range
Fast cure; adheres to glass, metals
and many plastics; wide temperature
range
Primary Uses
Durable adhesive sealing of components that must perform in difficult environments
Release coating for surfaces that offer
protection from weathering, corrosion
and dirt
General manufacturing assembly
operations where quick cure and good
adhesion are important
Adhering, bonding and sealing
a wide range of low-energy
metallic and thermoplastic surfaces
Industrial assembly and maintenance
applications
Applications
1
Bonding of polycarbonate or glass lenses to the reflector housing of headlamps and fog lamps; in
appliance manufacturing, especially for oven and ceramic hob assembly or for bonding glass to
metal, glass to painted metal or glass to plastic
Easing cleanup of latex-manufacturing
equipment and paint-spraying opera-
tions and removal of flash in urethane
and polyester molding; preventing
adhesion and buildup on conveyor
belts, paper and fabric rolls; reducing
buildup on waste-handling equipment
OEM and assembly applications;
substitute for mechanical fasteners on
appliances; adhering plastic moldings
to plastic substrates; waterproofing
components; sealing coaxial connectors;
protecting instrumentation; may be
used on concrete and masonry
Interior air sealing between a sheet-
or liquid-applied weather-resistant
barrier and fenestration element; edge
lap seal for weather-resistant barriers;
sealing penetrations in weather-
resistant barriers such as plumbing
or ductwork; sealing other difficult-to-
adhere surfaces, such as mill finishes
and plastics
Automated application systems for
OEM applications
Temperature Range
2
, °F/°C, continuous (intermittent)
—
-40 to 300/-40 to 150
-85 to 350/-65 to 177
—
-60 to 300/-51 to 149
Skin-Over Time, min
2.5-10 min working time
85
5
15
Tack-Free Time, min
5-20
120
14
—
9
Extrusion Rate, g/min
—
n/a
395
252
300-400
Durometer, Shore A
32-35
20
33
28
21
Tensile, PSI
>261
325
175
190
130
Elongation
>300
500
300
785
300
Specific Gravity
1.31 (base)/1.00-1.04 (catalyst)
1.64
1.04
1.38
1.04
Listings/Specs
—
—
UL 94 HB
—
UL 94 HB
Color
Gray, black, special black
White
Black, clear translucent, white
White
Clear translucent
Sealant Type for Fluid Resistance Table
3
MQ
MQ
MQ
MQ
MQ
Primerless Adhesion
Acrylic
Excellent
Not Tested
No Adhesion
Excellent
Excellent
Acrylonitrile Butadiene Styrene (ABS)
Fair
Not Tested
Poor
Excellent
Good
Low Density Polyethylene (LDPE)
No Adhesion
Not Tested
No Adhesion
Poor
No Adhesion
Nylon 6/6
Poor
Not Tested
No Adhesion
Excellent
Good
Polycarbonate
Excellent
Not Tested
Fair
Excellent
Excellent
Polypropylene (PP)
No Adhesion
Not Tested
No Adhesion
Excellent
No Adhesion
Glass
Fair
Not Tested
Excellent
Excellent
Excellent
Aluminum, Mill Finish
Fair
Not Tested
Excellent
Excellent
Excellent
Copper
Excellent
Not Tested
Fair
Excellent
Excellent
Steel, Galvanized
Excellent
Not Tested
Fair
Excellent
Excellent
Steel, Low Carbon
Excellent
Not Tested
Excellent
Excellent
Excellent
Steel, Stainless
Fair
Not Tested
Excellent
Fair
Excellent
11
12
Hot-melt, neutral-cure sealants are
intended for assembly, bonding, sealing,
gasketing and other OEM applications
that require instant adhesion and high
green strength.
1
These sealants feature:
• Excellent adhesion to most substrates
without the need for a primer
• Instant adhesion, enabling parts to be
shipped out quickly
• Long open time
• Long pot life
• Low VOC
• Safe handling with nonhazardous
composition and by-products
• Long life once cured
Dow Corning
®
HM-2500
Assembly Sealant
Dow Corning
®
HM-2510
Assembly Sealant
Dow Corning
®
HM-2515
Assembly Sealant
Dow Corning
®
HM-2520
Assembly Sealant
Dow Corning
®
HM-2600
Assembly Sealant
Special Features
Offers the fastest build of green strength;
100% silicone sealant; high viscosity at
room temperature resists flow of material,
which reduces material squeeze-out;
excellent clarity
Offers high robustness; multipurpose
100% silicone sealant; high viscosity
at room temperature resists flow of
material, which reduces material
squeeze-out; excellent clarity
Lowest viscosity; 100% silicone
sealant; can be used in assembly
and lamination; dispensed in fine
beads, fibers or spiral patterns; low
durometer
Offers highest mechanical properties;
100% silicone; high viscosity at room
temperature resists flow of material,
which reduces material squeeze-out;
translucent clear
Offers highest degree of mechanical
adhesion and overall performance;
100% silicone; high durometer;
excellent clarity
Specific Gravity
1.08
1.08
1.07
1.11
1.08
Viscosity at 120°C, Pa·s
200
110
27
110
70
15-Min Green Strength, MPa
0.06
0.04
0.004
0.03
0.03
Durometer, Shore A
49
38
14
31
60
Ultimate Tensile Strength, MPa
4.8
4.6
2.3
6
4.4
Ultimate Elongation, %
1,900
1,900
1,500
1,500
1,300
Tear Strength – Type B, pli
80
78
67
89
70
Peel Strength
2
, pli
>45
>41
>33
>30
>30
SAFT
3
, °C
250
250
248
280
310
NSF/ANSI Standard 51 and 61
Yes
Yes
Yes
Yes
N/A
4
FDA 21 CFR 177.2600
3
Yes
Yes
Yes
Yes
N/A
4
UL 94 (Relative Thermal Index)
HB (105)
HB (105)
HB (105)
5
N/A
HB (105)
5
Color
Clear
Clear
Clear
Clear
Clear
Primerless Adhesion
Acrylic
Excellent
Excellent
Not Tested
Fair
Excellent
Acrylonitrile Butadiene Styrene (ABS)
Excellent
Excellent
Not Tested
Fair
Excellent
Low Density Polyethylene (LDPE)
Excellent
Excellent
Not Tested
Fair
Excellent
Nylon 6/6
Excellent
Good
Not Tested
Good
Excellent
Polycarbonate
Excellent
Good
Not Tested
Fair
Excellent
Polypropylene (PP)
Excellent
Excellent
Not Tested
Good
Excellent
Glass
Excellent
Excellent
Not Tested
Excellent
Excellent
Aluminum, Mill Finish
Excellent
Excellent
Not Tested
Excellent
Good
Copper
Excellent
Excellent
Not Tested
Good
Good
Steel, Galvanized
Excellent
Excellent
Not Tested
Excellent
Excellent
Steel, Low Carbon
Excellent
Excellent
Not Tested
Good
Excellent
Steel, Stainless
Excellent
Excellent
Not Tested
Excellent
Excellent
Duranar
®
, Black
Excellent
Excellent
Not Tested
Excellent
Excellent
Fluropon
®
, White
Excellent
Excellent
Not Tested
Excellent
Good
Polyethylene Powder Coatings (PEPC), Black Excellent
Excellent
Not Tested
Excellent
Excellent
1
Most paints will not adhere to sealant; not for underwater structural or adhesive applications;
requires atmospheric moisture to cure. May stress-crack some plastics; test before use.
2
180° peel from various substrates based on ASTM C794: 21-day cure
(24 ±2°C; 50 ±5% RH) + 7-day H
2
O
immersion.
3
Shear adhesion failure temperature based on ASTM 4498.
4
Not available; has not been submitted for testing and certification.
5
Qualified only under electronics or lighting industry label.
TABLE V. HOT-MELT (NEUTRAL-CURE) SEALANTS
13
Dow Corning
®
HM-2500
Assembly Sealant
Dow Corning
®
HM-2510
Assembly Sealant
Dow Corning
®
HM-2515
Assembly Sealant
Dow Corning
®
HM-2520
Assembly Sealant
Dow Corning
®
HM-2600
Assembly Sealant
Special Features
Offers the fastest build of green strength;
100% silicone sealant; high viscosity at
room temperature resists flow of material,
which reduces material squeeze-out;
excellent clarity
Offers high robustness; multipurpose
100% silicone sealant; high viscosity
at room temperature resists flow of
material, which reduces material
squeeze-out; excellent clarity
Lowest viscosity; 100% silicone
sealant; can be used in assembly
and lamination; dispensed in fine
beads, fibers or spiral patterns; low
durometer
Offers highest mechanical properties;
100% silicone; high viscosity at room
temperature resists flow of material,
which reduces material squeeze-out;
translucent clear
Offers highest degree of mechanical
adhesion and overall performance;
100% silicone; high durometer;
excellent clarity
Specific Gravity
1.08
1.08
1.07
1.11
1.08
Viscosity at 120°C, Pa·s
200
110
27
110
70
15-Min Green Strength, MPa
0.06
0.04
0.004
0.03
0.03
Durometer, Shore A
49
38
14
31
60
Ultimate Tensile Strength, MPa
4.8
4.6
2.3
6
4.4
Ultimate Elongation, %
1,900
1,900
1,500
1,500
1,300
Tear Strength – Type B, pli
80
78
67
89
70
Peel Strength
2
, pli
>45
>41
>33
>30
>30
SAFT
3
, °C
250
250
248
280
310
NSF/ANSI Standard 51 and 61
Yes
Yes
Yes
Yes
N/A
4
FDA 21 CFR 177.2600
3
Yes
Yes
Yes
Yes
N/A
4
UL 94 (Relative Thermal Index)
HB (105)
HB (105)
HB (105)
5
N/A
HB (105)
5
Color
Clear
Clear
Clear
Clear
Clear
Primerless Adhesion
Acrylic
Excellent
Excellent
Not Tested
Fair
Excellent
Acrylonitrile Butadiene Styrene (ABS)
Excellent
Excellent
Not Tested
Fair
Excellent
Low Density Polyethylene (LDPE)
Excellent
Excellent
Not Tested
Fair
Excellent
Nylon 6/6
Excellent
Good
Not Tested
Good
Excellent
Polycarbonate
Excellent
Good
Not Tested
Fair
Excellent
Polypropylene (PP)
Excellent
Excellent
Not Tested
Good
Excellent
Glass
Excellent
Excellent
Not Tested
Excellent
Excellent
Aluminum, Mill Finish
Excellent
Excellent
Not Tested
Excellent
Good
Copper
Excellent
Excellent
Not Tested
Good
Good
Steel, Galvanized
Excellent
Excellent
Not Tested
Excellent
Excellent
Steel, Low Carbon
Excellent
Excellent
Not Tested
Good
Excellent
Steel, Stainless
Excellent
Excellent
Not Tested
Excellent
Excellent
Duranar
®
, Black
Excellent
Excellent
Not Tested
Excellent
Excellent
Fluropon
®
, White
Excellent
Excellent
Not Tested
Excellent
Good
Polyethylene Powder Coatings (PEPC), Black Excellent
Excellent
Not Tested
Excellent
Excellent
14
TABLE VI. SILICONE FOAMS (TWO-PART, ADDITION-CURE)
Dow Corning
®
8257
Silicone Foam
Dow Corning
®
3-8209
Silicone Foam
Dow Corning
®
3-8219 RF
Silicone Foam
Dow Corning
®
3-8259 RF
Silicone Foam
White
Black
Gray
Dark Gray
Special
Features
Low hardness (Shore
00); available in
white and black; low
density
Low to medium
hardness
(Shore 00);
medium
density
Medium hard-
ness (Shore
00); medium to
high density;
reduced flow
aids applica-
tion to vertical
surfaces
Medium hardness
(Shore 00); available
in gray and dark gray;
high density; reduced
flow aids application to
vertical surfaces
Viscosity, mPas A: 21,000
B: 12,000
A: 20,000
B: 12,000
A: 14,000
B: 15,000
A: 21,000
B: 40,000
A:
68,000
B:
63,000
A: 64,000
B: 62,000
Snap Time, sec 230
240
220
200
200
200
Tack-Free
Time, min
8
8
7
6
7
6
Density, kg/m
3
140
150
250
300
330
330
Flowability, cm Flowable Flowable Flowable
17
15
16
Cell Structure,
Zellen/3 cm
35
30
Fine
Fine
Fine
Fine
Hardness,
Shore 00
25
25
45
45
50
50
Two-part, addition-cure silicone foams
designed to be dispensed and cured
directly on parts to form an integrated
compression gasket. They typically
are used in automotive parts, including
seals for vibration and noise damping,
housings for electronic devices, exterior
lighting, and domestic appliance
components.
These sealants feature:
• Room temperature cure (RTV)
• 1:1 mix ratio
• CFC-free content
• Low post-cure compression set
• Stability and flexibility across a wide
range of temperatures
Surface Preparation
Although
Dow Corning
silicone sealants possess excellent bond strength,
maximum adhesion is only attained on surfaces that are clean and dry.
Contaminants – such as dirt, grease, water, tar or rust – act as release
agents and prevent the formation of durable bonds. Use of a primer does
not negate the necessity for proper surface cleaning.
Wet or dirty surfaces should be properly prepared before sealants are applied.
• Wipe contaminated surface with a clean, oil-free cloth.
• Rewipe surface with a suitable cleaner or industrial solvent, such as
isopropyl alcohol (IPA), mineral spirits, naphtha or ketones. Note: Do not
clean surface with detergent or soap. (Soap residue may act as release
agent.)
• Rough rubber surfaces with sandpaper. Make a spot-check to determine
the adhesion of sealants for each application. Bond strength will increase
as the sealant cures.
The active ingredients must thoroughly wet-out and coat the bonding surfac-
es. Mild abrasion, solvent cleaning, plasma, corona discharge and other
pretreatments have been used to clean and enhance surface reactivity
to bonding. In general, light surface abrasion is recommended whenever
possible, because it promotes good cleaning and increases the surface
area for bonding. Clean and/or degrease surfaces with
Dow Corning
®
OS Fluids, naphtha, mineral spirits, methyl ethyl ketone (MEK), or other
suitable solvents that will remove oils and other contaminants that may be
present. A final surface wipe with acetone or IPA also may be helpful.
Some cleaning techniques may give better results than others; determine
the best technique for your application. For especially difficult-to-bond-to
surfaces, it may be necessary to increase the surface reactivity by using
chemical etchants or oxidizers or by exposing the surface to UV, corona,
plasma or flame sources. Allow solvents to completely evaporate before
applying the primer.
15
Primers and Adhesion Promoters
For maximum adhesion,
Dow Corning
®
primer is
recommended. After solvent-cleaning, apply a thin
coat of Dow Corning primer in a very light, even
coat by wiping, dipping or spraying. Wipe off excess
material to avoid overapplication, which generally
appears as a white, chalky surface. When dip- or
spray-coating, diluting by a factor of 2 to 4 with
additional solvent may avoid excessive buildup.
TABLE VII. CLEANERS AND PRIMERS
Cleaners
Primers
Dow Corning
®
OS-2
Silicone Cleaner and Surface Prep
Solvent
Dow Corning
®
DS-1000
Aqueous Silicone Cleaner
Dow Corning
®
DS-2025
Silicone Cleaning Solvent
Dow Corning
®
PR-1200 RTV
Prime Coat
Dow Corning
®
P5200
Adhesion Promoter
Dow Corning
®
1200 OS
Primer Clear
Dow Corning
®
Primer-C OS
Special
Features
VOC exempt (VOC = 0 g/L); certified
as a Clean Air Solvent by the
California South Coast Air Quality
Management District; easy to use;
low in toxicity; essentially odorless;
safe on plastics and noncorrosive to
metals; ideal for diluting and tailoring
the viscosity of silicones
Cleaner for use on uncured silicone;
effectively emulsifies silicone oils,
greases and uncured elastomers;
effective degreaser on a wide range
of applications; aqueous solution;
complies with EU detergent regulation
on biodegradability of surfactants;
nonflammable
Cleaner for use on cured silicone;
rapid digestion of cured silicone; leaves
silicone-free surface; nonflammable;
high flash point; does not contain
aromatic solvent; nonhalogenated
solvent; low viscosity; multiple use
and recyclable
Significantly improves the adhesion
of silicone sealants to a wide
variety of challenging substrates;
available in clear and red
Significantly improves the
adhesion of silicone sealants
with low VOC to a wide variety
of challenging substrates;
available in clear and red
Useful for both
moisture-curing-RTV
and heat-curing silicones;
diluted in low-molecular-weight
silicone fluid; meets many
international regulations for
low VOC content (including
European Union); similar to
Dow Corning
®
P5200
Adhesion Promoter
Improves adhesion of silicone
sealants to many substrates,
including plastics; accelerates
adhesion build of two-part
structural sealants; conforms to
South Coast and Bay Air Quality
Management District Regulations
for Architectural Sealant Primers;
user-friendly with low VOC; im-
proves quality control processes
by offering a visual confirmation
of primer presence; quick cure
time; nonstaining
Applications Cleaning plastics, metals and other
surfaces or preparing these surfaces
for painting, bonding or sealing
Cleaning surfaces, equipment and
manufacturing units contaminated
with nonsubstantive uncured silicone
residues
Cleaning surfaces, equipment and
manufacturing units contaminated with
substantive cured silicone residues
Improves the adhesion of silicone
sealants, coatings and rubber to
masonry, wood, granite, metals,
glass, ceramics, plastics, rubbers
and coatings
Improves the adhesion of
silicone sealants, coatings
and rubber to masonry, wood,
granite, plastics, rubbers and
coatings
Enhances bonding/adhesion
of RTV and heat-cure silicones
to ceramics, glass, wood,
masonry, structural plastics
(including FR-4) and many
metals
In-shop or field use with one-
and two-part Dow Corning
®
brand sealants; accelerating
adhesion to coated aluminum
substrates, such as polyvinylidene
fluoride (PVDF) or
Kynar
®
based
paints
16
Primer Cure
At normal room temperatures and 50% relative humidity conditions, allow the primer to air-dry from
five to 30 minutes. Low-humidity and/or low-temperature conditions require longer cure times. Mild
heat acceleration of the cure rate may be possible, but temperatures above 140°F (60°C) are not
recommended. During application, the carrier solvent typically evaporates quickly, allowing the
active ingredients to begin to react with atmospheric moisture and bonding surfaces. For optimal
bonding, different cure times may be required for different temperature and humidity conditions;
determine the best cure schedule and conditions for your application. Apply the desired silicone
sealant after the primer, prime coat or adhesion promoter has fully cured.
TABLE VII. CLEANERS AND PRIMERS
Cleaners
Primers
Dow Corning
®
OS-2
Silicone Cleaner and Surface Prep
Solvent
Dow Corning
®
DS-1000
Aqueous Silicone Cleaner
Dow Corning
®
DS-2025
Silicone Cleaning Solvent
Dow Corning
®
PR-1200 RTV
Prime Coat
Dow Corning
®
P5200
Adhesion Promoter
Dow Corning
®
1200 OS
Primer Clear
Dow Corning
®
Primer-C OS
Special
Features
VOC exempt (VOC = 0 g/L); certified
as a Clean Air Solvent by the
California South Coast Air Quality
Management District; easy to use;
low in toxicity; essentially odorless;
safe on plastics and noncorrosive to
metals; ideal for diluting and tailoring
the viscosity of silicones
Cleaner for use on uncured silicone;
effectively emulsifies silicone oils,
greases and uncured elastomers;
effective degreaser on a wide range
of applications; aqueous solution;
complies with EU detergent regulation
on biodegradability of surfactants;
nonflammable
Cleaner for use on cured silicone;
rapid digestion of cured silicone; leaves
silicone-free surface; nonflammable;
high flash point; does not contain
aromatic solvent; nonhalogenated
solvent; low viscosity; multiple use
and recyclable
Significantly improves the adhesion
of silicone sealants to a wide
variety of challenging substrates;
available in clear and red
Significantly improves the
adhesion of silicone sealants
with low VOC to a wide variety
of challenging substrates;
available in clear and red
Useful for both
moisture-curing-RTV
and heat-curing silicones;
diluted in low-molecular-weight
silicone fluid; meets many
international regulations for
low VOC content (including
European Union); similar to
Dow Corning
®
P5200
Adhesion Promoter
Improves adhesion of silicone
sealants to many substrates,
including plastics; accelerates
adhesion build of two-part
structural sealants; conforms to
South Coast and Bay Air Quality
Management District Regulations
for Architectural Sealant Primers;
user-friendly with low VOC; im-
proves quality control processes
by offering a visual confirmation
of primer presence; quick cure
time; nonstaining
Applications Cleaning plastics, metals and other
surfaces or preparing these surfaces
for painting, bonding or sealing
Cleaning surfaces, equipment and
manufacturing units contaminated
with nonsubstantive uncured silicone
residues
Cleaning surfaces, equipment and
manufacturing units contaminated with
substantive cured silicone residues
Improves the adhesion of silicone
sealants, coatings and rubber to
masonry, wood, granite, metals,
glass, ceramics, plastics, rubbers
and coatings
Improves the adhesion of
silicone sealants, coatings
and rubber to masonry, wood,
granite, plastics, rubbers and
coatings
Enhances bonding/adhesion
of RTV and heat-cure silicones
to ceramics, glass, wood,
masonry, structural plastics
(including FR-4) and many
metals
In-shop or field use with one-
and two-part Dow Corning
®
brand sealants; accelerating
adhesion to coated aluminum
substrates, such as polyvinylidene
fluoride (PVDF) or
Kynar
®
based
paints
17
Sealant Application
Apply
Dow Corning
®
adhesives/sealants to one of the prepared surfaces, then
quickly cover with the other substrate to be bonded. On exposure to moisture, the
freshly applied material will “skin over” in about 5 to 10 minutes (depending on the
product) at room temperature and 50% relative humidity.
Tool the sealant to coat or wet the substrate surface for maximum bonding. This
typically is done by properly filling the joint first and then dry-tooling the sealant
by pressing and pulling a round-tipped spatula or similar tool across the sealant
surface. This step forces sealant into joint surfaces and helps remove air pockets
or voids at the bond line. Tooling should be completed before the skin forms.
Keeping the primed surface clean may allow application of the silicone elastomer
to be delayed – but in some cases, if too much time elapses, lower adhesion can
result. Users are encouraged to determine the optimal cure conditions for their spe-
cific applications and the effects of any hold times imposed between applications of
the primer and sealant. In some cases, it may be recommended to reprime surfaces
if 8 to 24 hours elapse before the silicone sealant can be applied.
Cure Time
After skin formation, cure continues inward from the surface. In 24 hours (at room
temperature and 50% relative humidity),
Dow Corning
adhesive/sealant will cure to
a depth of about 1/8". Very deep sections, especially when access to atmospheric
moisture is restricted, will take longer to cure completely. Cure time is extended at
lower humidity levels.
Because the sealants cure by reaction with moisture in the air, keep the container
tightly sealed when not in use. A plug of used material may form in the tip of a tube
or cartridge during storage. This is easily removed and does not affect the remaining
contents.
18
Compatibility
Some
Dow Corning
adhesives/sealants release a small amount of acetic acid
during cure. This may cause corrosion on some metallic parts or substrates,
especially in direct contact or when the cure is carried out in a totally enclosed
environment that does not allow cure by-products to escape.
Platinum catalysts used in addition-cure silicone sealants – including silicone
foams – are sensitive to contamination by certain compounds that have the
power to stop or inhibit cure. For more information, refer to “Guarding against
potential inhibitors/poisons of platinum-catalyzed addition-cure release coatings,”
Form No. 30-1053-01, available in the Technical Library on
dowcorning.com
or
upon request from Dow Corning customer service.
Cleanup/Sealant Removal
Cured silicone can be removed from a surface with a sharp blade if the cured
silicone material is accessible. If it is difficult to cut through, solvents – such
as IPA, toluene, xylene, naphtha or mineral spirits – may be used to soften the
cured sealant.
Dow Corning
OS Fluids also can be used to help soften cured
silicone and/or remove silicone residue after it has been removed mechanically
from a surface.
Dow Corning
OS Fluids will generally be a lower-VOC alternative
to standard solvents.
Limitations
Refer to individual product data sheets for use limitations.
Health and Environmental Information
To support customers in their product safety needs, Dow Corning has an
extensive Product Stewardship organization and a team of Product Safety
and Regulatory Compliance (PS&RC) specialists available in each area.
For more information, please see our website,
dowcorning.com
, or consult
your local Dow Corning representative.
19
Images: Cover - AV25030, AV18647, AV25027, AV25028, AV25031, AV16029, AV25029; Page 2 -
AV15217; Page 3 - AV25032, AV08170, AV14174; Page 4 - AV12315; Page 12 - AV23389; Page 15
- AV18647; Page 16 - AV13896; Page 18 - AV25202; Page 20 – AV18278
HANDLING PRECAUTIONS
PRODUCT SAFETY INFORMATION REQUIRED FOR SAFE USE IS NOT INCLUDED IN THIS
DOCUMENT. BEFORE HANDLING, READ PRODUCT AND MATERIAL SAFETY DATA SHEETS
AND CONTAINER LABELS FOR SAFE USE, PHYSICAL AND HEALTH HAZARD INFOR-
MATION. THE MATERIAL SAFETY DATA SHEET IS AVAILABLE ON THE DOW CORNING
WEBSITE AT DOWCORNING.COM, OR FROM YOUR DOW CORNING SALES APPLICATION
ENGINEER, OR DISTRIBUTOR, OR BY CALLING DOW CORNING CUSTOMER SERVICE.
LIMITED WARRANTY INFORMATION – PLEASE READ CAREFULLY
The information contained herein is offered in good faith and is believed to be accurate. However, because
conditions and methods of use of our products are beyond our control, this information should not be used
in substitution for customer’s tests to ensure that our products are safe, effective and fully satisfactory for
the intended end use. Suggestions of use shall not be taken as inducements to infringe any patent.
Dow Corning’s sole warranty is that our products will meet the sales specifications in effect at the time of
shipment.
Your exclusive remedy for breach of such warranty is limited to refund of purchase price or replace-
ment of any product shown to be other than as warranted.
TO THE FULLEST EXTENT PERMITTED BY APPLICABLE LAW, DOW CORNING SPECIFI-
CALLY DISCLAIMS ANY OTHER EXPRESS OR IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE OR MERCHANTABILITY.
DOW CORNING DISCLAIMS LIABILITY FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Dow Corning, Silastic
and XIAMETER are registered trademarks of Dow Corning Corporation.
We help you invent the future
is a trademark of Dow Corning Corporation.
Duranar
is a registered trademark of PPG Industries Ohio, Inc.
Fluropon
is a registered trademark of The Valspar Corporation.
Kynar
is a registered trademark of Arkema or one of its affiliates.
©2016 Dow Corning Corporation. All rights reserved.
AGP14232
Form No. 80-8104-01
CONTACT US
For more than 60 years, OEM designers and
maintenance and materials engineers around the
world have trusted the
Dow Corning
®
brand for
performance and expertise to solve or prevent
sealant challenges. Dow Corning has sales offices,
manufacturing sites, and science and technology
laboratories – and a network of more than 3,000
distributors – around the world.
To learn more about our extensive product and
service offerings, order samples, or find a local
distributor, visit
dowcorning.com/IAM
industrial@dowcorning.com
or call Dow Corning
Technical Customer Service at 1 800 248 2481.
