FAST RECOVERY RECTIFIER

VOLTAGE RANGE  50 to 1000 Volts   CURRENT 1.0 Ampere

RECTRON

SEMICONDUCTOR

TECHNICAL  SPECIFICATION

FEATURES

* Fast switching
* Low leakage
* Low forward voltage drop
* High current capability
* High surge capability
* High reliability

MECHANICAL DATA

* Case: Molded plastic
* Epoxy: Device has UL flammability classification 94V-O
* Lead: MIL-STD-202E method 208C guaranteed
* Mounting position: Any
* Weight: 0.33 gram

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

o

C ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

ELECTRICAL CHARACTERISTICS (At T

A

 = 25

o

C unless otherwise noted)

FR101

THRU

FR107

DO-41

MAXIMUM RATINGS (At T

A

 = 25

o

C unless otherwise noted)

NOTES : 1. Test Conditions: I

F

 = 0.5A, I

R

 = -1.0A, I

RR

 = -0.25A

2. Measured at 1 MH

Z

 and applied reverse voltage of 4.0 volts

Dimensions in inches and (millimeters)

2002-11

RATINGS

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Current
at T

A

 = 75

o

C

Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)

Typical Junction Capacitance (Note 2)

Operating and Storage Temperature Range

SYMBOL

V

RRM

V

DC

I

O

I

FSM

C

J

T

J

, T

STG

V

RMS

Volts

Volts

Volts

Amps

1.0

30

15

-55 to + 150

Amps

pF

0

C

50

35

50

100

200

140

70

100

200

400

280

400

600

420

600

600

400

600

800

560

800

1000

700

1000

1000

700

1000

UNITS

FR101 FR102 FR103 FR104 FR105 FR105P FR106 FR107 FR107P

at Rated DC Blocking Voltage T

A

 = 25

o

C

CHARACTERISTICS

Maximum Full Load Reverse Current Full Cycle
Average, .375” (9.5mm) lead length at T

L

 = 55

o

C

Maximum Reverse Recovery Time (Note 1)

V

F

SYMBOL

I

R

trr

UNITS

1.3

5.0

100

150

250

500

uAmps

uAmps

nSec

Maximum DC Reverse Current

Maximum Instantaneous Forward Voltage at 1.0A DC

Volts

FR101 FR102 FR103 FR104 FR105 FR105P FR106 FR107 FR107P

150

250

1.0 (25.4)

MIN.

.166 (4.2)

.205 (5.2)

1.0 (25.4)

MIN.

.107 (2.7)

.080 (2.0)

DIA.

.034 (0.9)

.028 (0.7)

DIA.

RECTRON

RATING AND CHARACTERISTIC CURVES ( FR101 THRU FR107 )

JUNCTION CAPACITANCE, (pF)

FIG. 5 - TYPICAL JUNCTION CAPACITANCE

REVERSE VOLTAGE, ( V )

200

100

60
40

20

10

6

4

2

1

.1

.2

.4

1.0

2

4

10

20 40

100

TJ = 25

trr

+0.5A

0

-0.25A

-1.0A

1cm

SET TIME BASE FOR
50/100 ns/cm

FIG. 6 - TEST CIRCUIT DIAGRAM  AND REVERSE

50
NONINDUCTIVE

10
NONINDUCTIVE

D.U.T

25 Vdc
(approx)

( - )

( - )

( + )

( + )

1
NON-
INDUCTIVE

OSCILLOSCOPE

(NOTE 1)

PULSE

GENERATOR

(NOTE 2)

NOTES:

1  Rise Time = 7ns max. Input Impedance =
    1 megohm. 22pF.
2. Rise Time = 10ns max. Souce Impedance =
    50 ohms.

RECOVERY TIME CHARACTERISTIC

FIG. 1 - TYPICAL FORWARD CURRENT

AVERAGE FORWARD CURRENT, (A)

AMBIENT TEMPERATURE, (     )

DERATING CURVE

1.0

.8

.6

.4

.2

0

0

25

50

75

100

125

150

175

Single Phase
Half Wave 60Hz
Resistive or
Inductive Load

FIG. 3 - TYPICAL INSTANTANEOUS

FORWARD CHARACTERISTICS

INSTANTANEOUS FORWARD CURRENT, (A)

INSTANTANEOUS FORWARD VOLTAGE, (V)

TJ = 25
Pulse Width=300uS
1% Duty Cycle

20

10

3.0

1.0

0.3

0.1

.03

.01

0.4

0.6

0.8

1.0

1.2

1.4

1.6

1.8

FIG. 4 - TYPICAL REVERSE CHARACTERISTICS

INSTANTANEOUS REVERSE CURRENT, (uA)

PERCENT OF RATED PEAK REVERSE VOLTAGE, (%)

TJ = 25

10

.01

.02

.04

.06

.1

.2

.4

.6

1.0

2

4

6

0

20

40

60

80

100

120

140

FIG. 2 - MAXIMUM NON-REPETITIVE FORWARD

PEAK FORWARD SURGE

NUMBER OF CYCLES AT 60Hz

CURRENT, (A)

SURGE CURRENT

1

2

4

6 8 10

20

40

60 80 100

50

40

30

20

10

0

8.3ms Single Half Sine-Wave
(JEDED Method)
