Structural Adhesives

Selector Guide

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

We’re Writing the Law

We’re Writing the Law

Loctite

®



Structural Adhesives

Selector Guide

2

We’re writing the law

on Structural Adhesives

Henkel would like to introduce
to you The Immutable Laws
of Structural Engagement

™

.

The laws were written to help
you understand why structural
adhesives are stronger,
tougher and more reliable
than traditional fasteners.
Loctite

®

 Structural Adhesives

can allow manufacturers to
eliminate or significantly
reduce the fasteners or welds,
while improving the strength
and durability of your assembly.
Put The Immutable Laws of
Structural Engagement

™

 to

work for you.

1

st

 Law of

Structural Engagement

Mechanical fasteners

can’t spread the load.

When forces are applied to a
mechanically-fastened assembly, the
stresses are concentrated at a single
point rather than distributed evenly
over a broader area. This may lead to
premature failure of the joint. When
forces are applied to an adhesive bonded
assembly, the stresses are distributed
across the entire area of the bonded
joint. This results in an overall stronger
assembly, which provides the opportunity
to reduce substrate thickness and thus
the cost and weight of the assembly.

From the

Leader



    in

Structural Adhesives

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

We’re Writing the Law

We’re Writing the Law

www.henkelna.com/loctitestructurals

Loctite

®

 Structural Adhesives are nearly



2x stronger than spot welds and



bolts and easier on the bottom line

Strength and Cost

Previous process. Note the through-bolts.

Loctite

®

 H8600

™

 Speedbonder

™

 Adhesive process.

Note the smooth finish.

Before

After

3

TABLE OF CONTENTS

  Magnet Bonding  . . . . . . . . . . . 4



For the fastest, most durable bond strengths





on magnets, including ferrite, alnico and





neodymium iron boron permanent magnets.

  Metal Bonding . . . . . . . . . . . . . 8





Optimized to meet the demands of today’s





metal fabricating requirements.

  Multiple Surface Bonding  . . 14





For excellent bond strengths on a wide





range of surfaces.

  Plastic / Composite /

  Polyolefin Bonding  . . . . . . . . 24





For the toughest, most durable bond





strength on plastics, composites and

  difficult-to-bond

polyolefins.

  Dispensing Equipment . . . . . 30





A full line of adhesive dispensing equipment





for manual, semi-automated or fully-automated

  assembly

processes.

 Index. . . . . . . . . . . . . . . . . . . . 34

?

Look for

Professor McGlue’s

Clues throughout this

brochure to learn

tips about Loctite

®



Structural Adhesives.

Loctite

®

 Structural Adhesives are available in a range

of formulations, including one-part epoxy, two-part
epoxy, acrylic and polyurethane, and two-step acrylic
adhesives. They have been specially formulated to meet
a variety of industrial bonding requirements and are
available in four application categories:

Magnet Bonding – for the fastest, most durable bond
strengths on ferrite, alnico and neodymium iron boron
permanent magnets.

Metal Bonding – optimized to meet the demands of
today’s metal fabricating requirements.

Multiple Surface Bonding – for excellent bond
strengths on a variety of surfaces.

Plastic and Composite Bonding – for the toughest,
most durable bond strength on composites and plastics,
including polyolefins.

Loctite

®

 Structural Adhesives are available in

easy-to-use packages for hand-held, manual and semi-
automated applications, including caulking cartridges,
syringes, soft-squeeze bottles and dual cartridges for
two-part formulations. Loctite

®

 Structural Adhesives

are also offered in larger packages, such as 5- or
55-gallon pails, for high volume and automated
assembly operations.

All Loctite

®

 Structural Adhesives are easily dispensed

through Loctite

®

 dispensing systems. Systems are

available in a full range of options, including manual
or pneumatic versions, portable or stationary systems,
small or large package systems, and pressure-time or
volumetric dispense systems.

Most importantly, you can rely on the industry’s most
trusted brand – Loctite

®

. A name synonymous with the

highest quality, superior technical support and the best
overall value.

TOP CHOICE

The Top Choice designation lets you know
that this Loctite

®

 product has demonstrated

proven performance and/or represents the
latest technology to handle a variety of
customer applications, and is most often
included in initial product testing and evaluation.

A Clue From Prof. McGlue

Magnet Bonding

4

Loctite

®

 Structural Adhesives for magnet bonding combine

the benefits of fast process speeds with tough, durable,
environmentally resistant bond strengths, making them ideal for
bonding ferrite, alnico and neodymium iron boron permanent
magnets used in electric motors, small engines, speakers,
transformers and other devices. Magnets assembled with
adhesives provide a wealth of benefits, including:



  •  Ability to use lower cost components



  •  Decreased inventory cost



  •  Easier to automate



  •  Will not chip magnets



  •  Prevent vibrational noise



  •  Prevent corrosion



  •  Acid-free



  •  Higher impact strength



  •  Higher temperature resistance



  •  Lower odor

2

nd

 Law of

Structural Engagement

If you want to prevent

rust and corrosion,

use an adhesive;

if not, suffer the

consequences.

Due to structural adhesives’ unique
combination of sealing and joining
properties, using an adhesive to
assemble your parts will prevent
moisture and contamination ingress
that can lead to the build-up of rust
and corrosion. And rust and corrosion
between your parts can only lead to
severe performance consequences and
ultimate failure. So use an adhesive
instead, and come out a winner!

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

We’re Writing the Law

We’re Writing the Law

www.henkelna.com/loctitestructurals

5

?

Loctite

®

 Magnet

Bonders are

available in

Noncorrosive,

Acid-Free

formulations.

A Clue From Prof. McGlue

* Made to Order Item

1

 Steel

6

Fast Fixture / No Mixing Required

Fast Fixture / No Mixing Required

General-

Purpose

High

Toughness

Severe Environment

Severe Environment

Acid-Free

Ultra-Fast

Fixture

Fast Fixture

High

Temperature



 Humidity

Resistant

Chemical
Resistant

Room Temperature Cure

Heat Cure

Fast Fixture

Large Gap

No-Gap

Gap Filling

Induction

Cure

Oven Cure

TOP CHOICE

TOP CHOICE

312

™

392

™

334

™

NEW

A-671

™

NEW

A-6750

™

325

™

331

™

3060

™

E-220IC

™

E-214HP

™

Chemistry

Two-Step

Acrylic

Two-Step

Acrylic

Two-Step

Acrylic

External Mix

Acrylic

External Mix

Acrylic

Two-Step

Acrylic

Two-Step

Acrylic

External Mix

Acrylic

One-Part Epoxy

One-Part Epoxy

Color

Clear to Amber

Amber

Yellow

Green

Green

Clear Brown

Cream

Green

Grey

Light Grey

Viscosity (cP)

1,000

6,500

80,000

30,000

30,000

20,000

20,000

15,000

Paste

Paste

Gap Fill (in.)

.003

.025

.02

.1

.2

.04

.04

>.05

—

—

Fixture Time (seconds)

30

60

90

30-60

12 minutes

300

20

55

N/A

N/A

Cure Time (hours)

24

24

24

1

3

24

24

24

0.03 (induction)

1 (oven)

2

Shear Strength

1

 (psi)

>2,490

2,500

2,800

2,500

2,500

2,200

3,100

3,800

5,900

4,820

Impact Strength

1

 (kJ/m

2

)

—

—

5.2

9

9

—

>13

>13

>13

—

Temperature Resistance

250ºF (121ºC)

250ºF (121ºC)

350ºF (177ºC)

311°F (155°C)

311°F (155°C)

300ºF (149ºC)

350ºF (177ºC)

300ºF (149ºC)

300ºF (149ºC)

300ºF (149ºC)

Suggested Activator

Loctite

®



736

™

 Primer NF

™

Loctite

®



7387

™

 Activator

Loctite

®



7387

™

 Activator

N/A

N/A

Loctite

®



7075

™

 Activator

Loctite

®



7387

™

 Activator

N/A

N/A

N/A

Loctite

®

 312

™

 Speedbonder

™



Structural Adhesive
Ultra-Fast Fixture

Single component, medium

viscosity, activator-cure acrylic.

Fixtures in 30 seconds with 75%

of full strength developed in 10

minutes. Ideal for bonding a variety

of close-fitting parts, including

metal, glass and ceramic.

P/N

Package Size

03333  10 ml kit (10 ml bottle of

Loctite

®

 312

™

 Speedbonder

™



and 40 g aerosol can of

Loctite

®

 736

™

 Primer NF

™

)

00144  50 ml kit (50 ml bottle of

Loctite

®

 312

™

 Speedbonder

™



and 6 oz. aerosol can of

Loctite

®

 736

™

 Primer NF

™

)

31231  50 ml bottle

31243  1 liter bottle

Loctite

®

 392

™



Structural Adhesive
Fast Fixture /

Toughened

Single component, dual-

cure acrylic. Provides

fast fixture speed and

tough, reliable bonds.

P/N

Package Size

39250  50 ml tube
39275  300 ml cartridge
39280  1 liter bottle

Loctite

®

 334

™



Structural Adhesive
High Temperature

Single component,

dual-cure acrylic. Forms

tough, flexible bonds on

gaps up to 0.02". Resists

up to 350°F.

P/N

Package Size

33403  25 ml syringe
33470  300 ml cartridge

Loctite

®

 A-671

™



Structural Adhesive

(formerly National Adhesives
Bondmaster

™

 671)

Gap Filling

Two-component external

mix acrylic requires no

static mixing or activators.

Excellent humidity

resistance and gap filling

capability. Fast fixturing.

P/N

  Package Size

1256489    40 ml kit

(adhesive/activator)

1256488   4,000 ml kit

 (adhesive/activator)

1256502   2 liter bottle, adhesive

1255708   2 liter bottle, activator

1256501   19 liter pail, adhesive

1255709   19 liter pail, activator

Loctite

®

 A-6750

™



Structural Adhesive

(formerly National Adhesives
Bondmaster

™

 675)

Extended Work Life

Two-component external

mix acrylic requires no static

mixing or activators. Excellent

humidity resistance and gap

filling capability. Extended

5-minute work life to

allow added time to position

parts.

P/N

Package Size

1256506   40 ml kit,

 (adhesive/activator)

1256503   2 liter bottle, adhesive

1255702   2 liter bottle, activator

Loctite

®

 325

™



Speedbonder

™



Structural Adhesive
Chemical Resistant

Solvent resistant, activator-

cured acrylic that fixtures

in minutes. Forms flexible

bonds on gaps up to

0.04". Designed for severe

environments and

temperatures to 300°F

(149°C).

P/N

Package Size

32530  50 ml bottle
32586  1 liter bottle

Loctite

®

 331

™



Structural Adhesive
Ultra-Fast Fixture

Single component, toughened,

activator-cure acrylic. Acid-

free, noncorrosive to sensitive

parts. Fixtures in 20 seconds

and develops full strength in

30 minutes. Excellent high

temperature resistance. Ideal

for bonding close-fitting

metals and magnets.

P/N

  Package Size

1057673  25 ml syringe
1057674*  1 liter bottle
1062124*  5 gallon pail

Loctite

®

 3060

™



Structural Adhesive
Gap Filling

Two-component, acid-free toughened,

external-mix acrylic requires no

static mixing or activators. Turns

green when mixed. Excellent high

temperature resistance. Ideal for

bonding large metal parts and ferrite

or rare earth magnets. Noncorrosive

to sensitive parts. Excellent gap filling

capability.

P/N

Package Size

1087985  60 ml kit

 (2 - 30 ml syringes)

1087986  1 liter, resin

1087987  1 liter, activator

1087988* 10 liter, resin

1088035* 10 liter, activator

Loctite

®

 E-220IC

™

 Hysol

®



Epoxy Adhesive
Induction Cure

A one-component, acid-free,

epoxy adhesive designed for

induction cure operations. A fast

curing paste that is formulated to

reduce the risk of localized heat-

ing. Well suited for metal and

magnet bonding. Noncorrosive to

sensitive parts.

P/N

  Package Size

1078250*  30 ml syringe

1078261*  1 liter bottle

1078499*  5 gallon pail

Loctite

®

 E-214HP

™



Hysol

®



Epoxy Adhesive
Oven Cure

A one-component, acid-

free, heat cure epoxy.

Light grey, temperature

resistant, high strength,

non-sag. Noncorrosive to

sensitive parts.

P/N

Package Size

29339  30 ml cartridge
29340  300 ml cartridge

Product Description

Your Application

Magnet Bonding

Solution

7

Fast Fixture / No Mixing Required

Fast Fixture / No Mixing Required

General-

Purpose

High

Toughness

Severe Environment

Severe Environment

Acid-Free

Ultra-Fast

Fixture

Fast Fixture

High

Temperature



 Humidity

Resistant

Chemical
Resistant

Room Temperature Cure

Heat Cure

Fast Fixture

Large Gap

No-Gap

Gap Filling

Induction

Cure

Oven Cure

TOP CHOICE

TOP CHOICE

312

™

392

™

334

™

NEW

A-671

™

NEW

A-6750

™

325

™

331

™

3060

™

E-220IC

™

E-214HP

™

Chemistry

Two-Step

Acrylic

Two-Step

Acrylic

Two-Step

Acrylic

External Mix

Acrylic

External Mix

Acrylic

Two-Step

Acrylic

Two-Step

Acrylic

External Mix

Acrylic

One-Part Epoxy

One-Part Epoxy

Color

Clear to Amber

Amber

Yellow

Green

Green

Clear Brown

Cream

Green

Grey

Light Grey

Viscosity (cP)

1,000

6,500

80,000

30,000

30,000

20,000

20,000

15,000

Paste

Paste

Gap Fill (in.)

.003

.025

.02

.1

.2

.04

.04

>.05

—

—

Fixture Time (seconds)

30

60

90

30-60

12 minutes

300

20

55

N/A

N/A

Cure Time (hours)

24

24

24

1

3

24

24

24

0.03 (induction)

1 (oven)

2

Shear Strength

1

 (psi)

>2,490

2,500

2,800

2,500

2,500

2,200

3,100

3,800

5,900

4,820

Impact Strength

1

 (kJ/m

2

)

—

—

5.2

9

9

—

>13

>13

>13

—

Temperature Resistance

250ºF (121ºC)

250ºF (121ºC)

350ºF (177ºC)

311°F (155°C)

311°F (155°C)

300ºF (149ºC)

350ºF (177ºC)

300ºF (149ºC)

300ºF (149ºC)

300ºF (149ºC)

Suggested Activator

Loctite

®



736

™

 Primer NF

™

Loctite

®



7387

™

 Activator

Loctite

®



7387

™

 Activator

N/A

N/A

Loctite

®



7075

™

 Activator

Loctite

®



7387

™

 Activator

N/A

N/A

N/A

Loctite

®

 312

™

 Speedbonder

™



Structural Adhesive
Ultra-Fast Fixture

Single component, medium

viscosity, activator-cure acrylic.

Fixtures in 30 seconds with 75%

of full strength developed in 10

minutes. Ideal for bonding a variety

of close-fitting parts, including

metal, glass and ceramic.

P/N

Package Size

03333  10 ml kit (10 ml bottle of

Loctite

®

 312

™

 Speedbonder

™



and 40 g aerosol can of

Loctite

®

 736

™

 Primer NF

™

)

00144  50 ml kit (50 ml bottle of

Loctite

®

 312

™

 Speedbonder

™



and 6 oz. aerosol can of

Loctite

®

 736

™

 Primer NF

™

)

31231  50 ml bottle

31243  1 liter bottle

Loctite

®

 392

™



Structural Adhesive
Fast Fixture /

Toughened

Single component, dual-

cure acrylic. Provides

fast fixture speed and

tough, reliable bonds.

P/N

Package Size

39250  50 ml tube
39275  300 ml cartridge
39280  1 liter bottle

Loctite

®

 334

™



Structural Adhesive
High Temperature

Single component,

dual-cure acrylic. Forms

tough, flexible bonds on

gaps up to 0.02". Resists

up to 350°F.

P/N

Package Size

33403  25 ml syringe
33470  300 ml cartridge

Loctite

®

 A-671

™



Structural Adhesive

(formerly National Adhesives
Bondmaster

™

 671)

Gap Filling

Two-component external

mix acrylic requires no

static mixing or activators.

Excellent humidity

resistance and gap filling

capability. Fast fixturing.

P/N

  Package Size

1256489    40 ml kit

(adhesive/activator)

1256488   4,000 ml kit

 (adhesive/activator)

1256502   2 liter bottle, adhesive

1255708   2 liter bottle, activator

1256501   19 liter pail, adhesive

1255709   19 liter pail, activator

Loctite

®

 A-6750

™



Structural Adhesive

(formerly National Adhesives
Bondmaster

™

 675)

Extended Work Life

Two-component external

mix acrylic requires no static

mixing or activators. Excellent

humidity resistance and gap

filling capability. Extended

5-minute work life to

allow added time to position

parts.

P/N

Package Size

1256506   40 ml kit,

 (adhesive/activator)

1256503   2 liter bottle, adhesive

1255702   2 liter bottle, activator

Loctite

®

 325

™



Speedbonder

™



Structural Adhesive
Chemical Resistant

Solvent resistant, activator-

cured acrylic that fixtures

in minutes. Forms flexible

bonds on gaps up to

0.04". Designed for severe

environments and

temperatures to 300°F

(149°C).

P/N

Package Size

32530  50 ml bottle
32586  1 liter bottle

Loctite

®

 331

™



Structural Adhesive
Ultra-Fast Fixture

Single component, toughened,

activator-cure acrylic. Acid-

free, noncorrosive to sensitive

parts. Fixtures in 20 seconds

and develops full strength in

30 minutes. Excellent high

temperature resistance. Ideal

for bonding close-fitting

metals and magnets.

P/N

  Package Size

1057673  25 ml syringe
1057674*  1 liter bottle
1062124*  5 gallon pail

Loctite

®

 3060

™



Structural Adhesive
Gap Filling

Two-component, acid-free toughened,

external-mix acrylic requires no

static mixing or activators. Turns

green when mixed. Excellent high

temperature resistance. Ideal for

bonding large metal parts and ferrite

or rare earth magnets. Noncorrosive

to sensitive parts. Excellent gap filling

capability.

P/N

Package Size

1087985  60 ml kit

 (2 - 30 ml syringes)

1087986  1 liter, resin

1087987  1 liter, activator

1087988* 10 liter, resin

1088035* 10 liter, activator

Loctite

®

 E-220IC

™

 Hysol

®



Epoxy Adhesive
Induction Cure

A one-component, acid-free,

epoxy adhesive designed for

induction cure operations. A fast

curing paste that is formulated to

reduce the risk of localized heat-

ing. Well suited for metal and

magnet bonding. Noncorrosive to

sensitive parts.

P/N

  Package Size

1078250*  30 ml syringe

1078261*  1 liter bottle

1078499*  5 gallon pail

Loctite

®

 E-214HP

™



Hysol

®



Epoxy Adhesive
Oven Cure

A one-component, acid-

free, heat cure epoxy.

Light grey, temperature

resistant, high strength,

non-sag. Noncorrosive to

sensitive parts.

P/N

Package Size

29339  30 ml cartridge
29340  300 ml cartridge

Metal Bonding

8

Loctite

®

 Structural Adhesives for metal bonding have been specially

formulated to provide tough, long-lasting bonds to metal surfaces,
such as steel, galvanized steel, aluminum, sheet metal and stainless
steel. These adhesives are capable of reducing or replacing the
need for threaded fasteners, welds or rivets, resulting in a higher
quality assembly. As a result, structural adhesives are ideal for
use in agriculture and construction equipment, specialty vehicles,
commercial furniture, appliances, signage, tub and spa, and
structural building components.

Loctite

®

 Structural Adhesives have been formulated to withstand

higher temperatures, provide excellent chemical resistance, survive
aggressive pre-treating and high performance paint processes,
and provide long-term corrosion resistance. Loctite

®

 Structural

Adhesives are available in a variety of cure speeds for any type
of job. Our two-part epoxies have strengths close to heat cure
epoxies, eliminating the need for an oven-cure process, thereby
reducing bottlenecks and lowering costs.

Overall, Loctite

®

 Structural Adhesives for metal bonding offer:



  •  High strength coupled with high impact and peel resistance



  •  Compatibility with oily/unclean metal surfaces



  •  Resistance to high temperatures, aggressive chemicals



  •  Squeeze-out prevention in clamped assemblies



  •  A variety of open times to meet processing needs



  •  Fast fixture time for handling strength in minimal



    amount of time



  •  Even stress distribution over bond line



  •  Cost benefits for replacement and/or reduction of welds,



    rivets and mechanical fasteners

3

rd

 Law of

Structural Engagement

Vibration is everywhere.

Vibrational loosening

is not.

Metal fabricators like the benefits of
pneumatic pins because of their fast
processing speeds. Unfortunately, the
pins can wallow out of their parts
during transportation due to vibrational
loosening. However, when used in
combination with structural adhesives,
not only are the assemblies able to
withstand stronger forces, but the pins
are bonded in place by the adhesive, thus
preventing them from wallowing out.

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

We’re Writing the Law

We’re Writing the Law

www.henkelna.com/loctitestructurals

9

?

Loctite

®

 3050

™

 and

Loctite

®

 H8700

™



Speedbonder

™

 can

be welded-through in

their liquid states and

still maintain their high

performance properties.

A Clue From Prof. McGlue

10

* Made to Order Item

1

 Steel

2

220ºF (104ºC) Shear on Steel

3

Grit Blasted Mild Steel

4

Aluminum

5

Etched Aluminum

General Performance

High Temperature / Chemical Resistant

Corrosion Resistant

Low Odor

Paint Bake

Compatible

Low Sag

Chemical Resistant

Fast Room

Temperature

Fixture

Fast Room

Temperature

Fixture

Extended Room

Temperature

Fixture

Extended Room

Temperature

Fixture

Non-Sag

High

Performance

High Strength

High

Temperature

TOP CHOICE

TOP CHOICE

H4500

™

H4710

™

H4720

™

H3151

™

E-20NS

™

E-60HP

™

E-214HP

™

9432NA

™

H8700

™

Chemistry

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Epoxy

Two-Part Epoxy

One-Part Epoxy

One-Part Epoxy

Two-Part Acrylic

Color

Grey

Grey

Teal

Light Yellow

Tan

Off-White

Grey

Grey

Blue

Viscosity (cP)

45,000

70,000

70,000

70,000

60,000

47,000

Paste

225,000

40,000

Mix Ratio

10:1

10:1

10:1

1:1

2:1

2:1

N/A

N/A

2:1

Work Life (minutes)

6

5

65

60

20

60

N/A

N/A

25

Fixture Time (minutes)

15

15

105

120

150

4

180

4

N/A

N/A

40

1

Cure Time (hours)

24

48

48

24

24

24

40 min. @

218ºF (120ºC)

30 min. @

218ºF (120ºC)

24

Shear Strength

1

 (psi)

3,100

1,800

4,200

3,800

2,790

3

4,320

3

4,820

3

3,000

3

2,175

Impact Strength

1

 (kJ/m

2

)

11.5

>14

8.5

7.7

–

–

–

–

14

Peel Strength

4

 (pli)

10.7

16

25.3

15

–

–

–

–

7

Hot Strength

2

 (psi)

950

540

1,100

900

1,100

430

5

3,172

5

3,000

4

435

Loctite

®

 H4500

™



Speedbonder

™



Structural Adhesive
Fast Fixture

High strength structural

adhesive for metals.

Fixtures in 15 minutes.

Now with mix color

indication.

P/N

  Package Size

996512    50 ml dual

 cartridge

83041    490 ml dual

 cartridge

Loctite

®

 H4710

™



Speedbonder

™



Structural Adhesive
Corrosion Resistant

Thixotropic, two-component,

room temperature curing

methacrylate adhesive

designed for structural

bonding of galvanized and

galvaneal parts. Excellent

environmental resistance. Its

non-sag characteristics are

well suited for filling gaps up

to 0.375". Delivers excellent

peel and impact strength with

no surface preparation.

P/N

Package Size

1056941  50 ml dual cartridge

39317    490 ml dual cartridge

Loctite

®

 H4720

™



Speedbonder

™



Structural Adhesive
Corrosion Resistant

Maintains superior

strength in corrosive

environments. Excellent

general-purpose metal

bonder.

P/N

  Package Size

1296594  50 ml dual cartridge
913475    490 ml dual

 cartridge

Loctite

®

 H3151

™



Speedbonder

™



Structural Adhesive
Extended Open Time

Extended open time

allows for adjustment

of parts. Excellent bond

strength on aluminum

and steel. Impact and

peel resistant.

P/N

Package Size

83015  50 ml dual cartridge
83014  400 ml dual cartridge

Loctite

®

 E-20NS

™

 Hysol

®



Epoxy Adhesive
Non-Sag

A light tan, non-sag,

high peel, high shear

epoxy with a 20-minute

work life. Excellent on

stainless steel, copper and

bronze.

P/N

Package Size

29334  50 ml dual cartridge
29335  200 ml dual cartridge
29336  400 ml dual cartridge

Loctite

®



E-60HP

™

 Hysol

®



Epoxy Adhesive
Toughened

A high strength epoxy with

a 60-minute work

life. Off-white, high peel

and shear strength.

P/N

Package Size

29319  50 ml dual cartridge
29320  200 ml dual cartridge
29321  400 ml dual cartridge
29322*  5 gallon pail, resin
29323*  5 gallon pail, hardener

Loctite

®



E-214HP

™

 Hysol

®



Epoxy Adhesive
High Strength

A one-component,

heat cure epoxy.

Grey, temperature

resistant, non-sag.

P/N

Package Size

29339  30 ml cartridge
29340  300 ml cartridge

Loctite

®



9432NA

™

 Hysol

®



Epoxy Adhesive
High Temperature

A grey, one-component

paste, heat cure epoxy.

Excellent high temperature

performance, excellent

chemical resistance,

surface insensitive.

P/N

Package Size

83217*  2 lb. can
83216  55 lb. pail

Loctite

®

 H8700

™



Speedbonder

™



Structural Adhesive
Weld-Through Capable

A weld-through

capable, toughened,

two-component acrylic

adhesive designed for

weld/rivet reduction.

Exhibits high resistance to

paint bake temperatures.

P/N

  Package Size

1064166  50 ml dual cartridge
1064321  400 ml dual cartridge

New &



Improved



Formula!

Product Description

Your Application

Metal Bonding

Solution

11

General Performance

High Temperature / Chemical Resistant

Corrosion Resistant

Low Odor

Paint Bake

Compatible

Low Sag

Chemical Resistant

Fast Room

Temperature

Fixture

Fast Room

Temperature

Fixture

Extended Room

Temperature

Fixture

Extended Room

Temperature

Fixture

Non-Sag

High

Performance

High Strength

High

Temperature

TOP CHOICE

TOP CHOICE

H4500

™

H4710

™

H4720

™

H3151

™

E-20NS

™

E-60HP

™

E-214HP

™

9432NA

™

H8700

™

Chemistry

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Epoxy

Two-Part Epoxy

One-Part Epoxy

One-Part Epoxy

Two-Part Acrylic

Color

Grey

Grey

Teal

Light Yellow

Tan

Off-White

Grey

Grey

Blue

Viscosity (cP)

45,000

70,000

70,000

70,000

60,000

47,000

Paste

225,000

40,000

Mix Ratio

10:1

10:1

10:1

1:1

2:1

2:1

N/A

N/A

2:1

Work Life (minutes)

6

5

65

60

20

60

N/A

N/A

25

Fixture Time (minutes)

15

15

105

120

150

4

180

4

N/A

N/A

40

1

Cure Time (hours)

24

48

48

24

24

24

40 min. @

218ºF (120ºC)

30 min. @

218ºF (120ºC)

24

Shear Strength

1

 (psi)

3,100

1,800

4,200

3,800

2,790

3

4,320

3

4,820

3

3,000

3

2,175

Impact Strength

1

 (kJ/m

2

)

11.5

>14

8.5

7.7

–

–

–

–

14

Peel Strength

4

 (pli)

10.7

16

25.3

15

–

–

–

–

7

Hot Strength

2

 (psi)

950

540

1,100

900

1,100

430

5

3,172

5

3,000

4

435

Loctite

®

 H4500

™



Speedbonder

™



Structural Adhesive
Fast Fixture

High strength structural

adhesive for metals.

Fixtures in 15 minutes.

Now with mix color

indication.

P/N

  Package Size

996512    50 ml dual

 cartridge

83041    490 ml dual

 cartridge

Loctite

®

 H4710

™



Speedbonder

™



Structural Adhesive
Corrosion Resistant

Thixotropic, two-component,

room temperature curing

methacrylate adhesive

designed for structural

bonding of galvanized and

galvaneal parts. Excellent

environmental resistance. Its

non-sag characteristics are

well suited for filling gaps up

to 0.375". Delivers excellent

peel and impact strength with

no surface preparation.

P/N

Package Size

1056941  50 ml dual cartridge

39317    490 ml dual cartridge

Loctite

®

 H4720

™



Speedbonder

™



Structural Adhesive
Corrosion Resistant

Maintains superior

strength in corrosive

environments. Excellent

general-purpose metal

bonder.

P/N

  Package Size

1296594  50 ml dual cartridge
913475    490 ml dual

 cartridge

Loctite

®

 H3151

™



Speedbonder

™



Structural Adhesive
Extended Open Time

Extended open time

allows for adjustment

of parts. Excellent bond

strength on aluminum

and steel. Impact and

peel resistant.

P/N

Package Size

83015  50 ml dual cartridge
83014  400 ml dual cartridge

Loctite

®

 E-20NS

™

 Hysol

®



Epoxy Adhesive
Non-Sag

A light tan, non-sag,

high peel, high shear

epoxy with a 20-minute

work life. Excellent on

stainless steel, copper and

bronze.

P/N

Package Size

29334  50 ml dual cartridge
29335  200 ml dual cartridge
29336  400 ml dual cartridge

Loctite

®



E-60HP

™

 Hysol

®



Epoxy Adhesive
Toughened

A high strength epoxy with

a 60-minute work

life. Off-white, high peel

and shear strength.

P/N

Package Size

29319  50 ml dual cartridge
29320  200 ml dual cartridge
29321  400 ml dual cartridge
29322*  5 gallon pail, resin
29323*  5 gallon pail, hardener

Loctite

®



E-214HP

™

 Hysol

®



Epoxy Adhesive
High Strength

A one-component,

heat cure epoxy.

Grey, temperature

resistant, non-sag.

P/N

Package Size

29339  30 ml cartridge
29340  300 ml cartridge

Loctite

®



9432NA

™

 Hysol

®



Epoxy Adhesive
High Temperature

A grey, one-component

paste, heat cure epoxy.

Excellent high temperature

performance, excellent

chemical resistance,

surface insensitive.

P/N

Package Size

83217*  2 lb. can
83216  55 lb. pail

Loctite

®

 H8700

™



Speedbonder

™



Structural Adhesive
Weld-Through Capable

A weld-through

capable, toughened,

two-component acrylic

adhesive designed for

weld/rivet reduction.

Exhibits high resistance to

paint bake temperatures.

P/N

  Package Size

1064166  50 ml dual cartridge
1064321  400 ml dual cartridge

?

All Loctite

®

 Two-Part

Acrylic Metal Bonders

are formulated with

glass spacer beads to

prevent adhesive

squeeze-out

during clamping.

A Clue From Prof. McGlue

12

* Made to Order Item

1

 Steel

2

220ºF (104ºC) Shear on Steel

3

Grit Blasted Steel





4

Aluminum

5

Etched Aluminum

6

Galvanized Steel

7

Abraded and Etched Aluminum

Galvanized Bonding

High Toughness

Flexible

Heat Cure

Steel

Bonding

Aluminum Bonding

Fast Room

Temperature

Fixture

Medium Room

Temperature

Fixture

Extended Room

Temperature

Fixture

Medium Room

Temperature

Fixture

Extended Room

Temperature

Fixture

Medium Room

Temperature

Fixture

Contains

Spacer Beads

Fast Room

Temperature

Fixture

Ultra-Fast Room

Temperature

Fixture

TOP CHOICE

TOP CHOICE

TOP CHOICE

H8610

™

H8600

™

E-50GW

H8500

™

H8510

™

H8000

™

H8010

™

NEW

H8100

™

NEW

H8110

™

U-05FL

™

3984

™

Chemistry

Two-Part Acrylic

Two-Part Acrylic

Two-Part Epoxy

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part

Urethane

One-Part Epoxy

Color

White

Blue

Grey

Grey

Grey

Green

Grey

Green

Green

Off-White

Light Grey

Viscosity (cP)



105,000

86,000

37,000

60,000

45,000

190,000

200,000

185,000

200,000

100,000

25,000

Mix Ratio

2:1

2:1

4:1

10:1

10:1

10:1

10:1

10:1

10:1

1:2

One Part

Work Life (minutes)

5

25

50

20

30

15

35

15

2-3

5

N/A

Fixture Time (minutes)

20

1

55

6

75

17

30

30

40

20

5

180

N/A

Cure Time (hours)

48

48

24

72

72

24

24

24

24

24

25 min. @

212ºF (100ºC)

Shear Strength

1

 (psi)

1,800

3,355

1,900

6

2,899

2,175

3,250

2,175

2,880

1,360

930

3

>2,000

5

Impact Strength

1

 (kJ/m

2

)

>14

38

–

26.3

>14

17.4

29

11

8

636

7

–

Peel Strength

4

 (pli)

10

22.6

–

46.4

58

40

37

12

9

–

–

Hot Strength

2

 (psi)

500

460

1,273 (500 hours)

960

540

450

485

560

–

280

200

Loctite

®

 H8610

™



Speedbonder

™



Structural Adhesive
Galvanized Steel Bonder

A fast curing, two-

component acrylic

designed for bonding

galvanized steel, galvaneal

and galvalum. Excellent

shear strength on steel

and aluminum. Especially

designed for long-term

heat and humidity

resistance.

P/N

  Package Size

1055263   50 ml dual cartridge

1055839   400 ml dual cartridge

Loctite

®

 H8600

™



Speedbonder

™



Structural Adhesive
Galvanized Steel Bonder

Excellent shear strength

on steel and aluminum.

Especially designed for

severe environments.

P/N

Package Size

40875  50 ml dual cartridge
38762  400 ml dual cartridge
38760*  5 gallon pail, adhesive
38761*  5 gallon pail, activator

Loctite

®



E-50GW

™

 Hysol

®



Epoxy Adhesive
Galvanized Steel

to Wood Bonder

A grey, two-component

epoxy designed to

bond galvanized steel

to wooden surfaces.

Extended, 50-minute

work life makes for

easy adjustment of larger

parts.

P/N

  Package Size

1078249  50 ml dual cartridge
1077864*  400 ml dual

  cartridge

Loctite

®

 H8500

™



Speedbonder

™



Structural Adhesive
Ultra-Tough

Excellent peel strength

on steel and aluminum.

Contains 30 mil spacer

beads to prevent

excessive squeeze-out

of adhesive due to over-

clamping. Provides fast

fixturing.

P/N

  Package Size

996514  50 ml dual cartridge
827608  490 ml dual cartridge
40888*  5 gallon pail, activator
40889*  5 gallon pail, adhesive

Loctite

®

 H8510

™



Speedbonder

™



Structural Adhesive
Ultra-Tough

Offers superior peel and

impact strength on steel

and aluminum. This grey,

ultra-fracture toughened,

two-component acrylic

adhesive has an extended

open time, making it ideal

for the assembly and

adjustment of larger parts.

Contains 30 mil spacer

beads to prevent excessive

squeeze-out of adhesive

due to over-clamping.

P/N

  Package Size

996513    50 ml dual cartridge
1107651  490 ml dual cartridge

Loctite

®

 H8000

™



Speedbonder

™



Structural Adhesive
Tough Aluminum

Bonder

Exhibits excellent peel

strength on multiple

substrates, especially

aluminum.

P/N

  Package Size

996453  50 ml dual

cartridge

36160  490 ml dual

cartridge

35939*  35 lb. pail,

adhesive

35940*  45 lb. pail,

activator

Loctite

®

 H8010

™



Speedbonder

™



Structural Adhesive
Tough Aluminum Bonder

Non-sag, two-component,

room temperature curing,

methacrylate adhesive,

exhibits superior peel

strength on multiple

substrates, especially

aluminum. Contains 5 mil

spacer beads to prevent

excessive squeeze-out

of adhesive due to over-

clamping.

P/N

  Package Size

1056929  50 ml dual cartridge
40594    490 ml dual cartridge

Loctite

®

 H8100

™



Speedbonder
Structural Adhesive
Fast Fixture

Exhibits excellent peel

and shear strength on

aluminum.

P/N

  Package Size

1056942  50 ml dual

 cartridge

1056943  490 ml dual

 cartridge

Loctite

®

 H8110

™



Speedbonder
Structural Adhesive
Ultra-Fast Fixture

Aluminum bonder

fixtures in five

minutes.

P/N

  Package Size

1371355  50 ml dual

 cartridge

1371361  490 ml dual

 cartridge

Loctite

®

 U-05FL

™

 Hysol

®



Urethane Adhesive
High Strength

A two-part, high

performance urethane

adhesive for metal bonding

with a 5-minute work life.

Off-white, highly flexible,

impact and moisture

resistant, high peel, high

shear.

P/N

Package Size

29348  50 ml dual cartridge
29349  200 ml dual cartridge
29350  400 ml dual cartridge
29351  5 gallon pail, resin
29352  5 gallon pail, hardener

Loctite

®

 3984

™



Hysol

®



Epoxy Adhesive
High Performance /

Various Substrates

Highly fluorescent,

one-part, heat

cure epoxy

adhesive offering

superior physical,

environmental

and performance

properties.

P/N

Package Size

36768  30 ml syringe
37299*  1 liter bottle

Metal Bonding

Product Description

Your Application

Solution

13

Galvanized Bonding

High Toughness

Flexible

Heat Cure

Steel

Bonding

Aluminum Bonding

Fast Room

Temperature

Fixture

Medium Room

Temperature

Fixture

Extended Room

Temperature

Fixture

Medium Room

Temperature

Fixture

Extended Room

Temperature

Fixture

Medium Room

Temperature

Fixture

Contains

Spacer Beads

Fast Room

Temperature

Fixture

Ultra-Fast Room

Temperature

Fixture

TOP CHOICE

TOP CHOICE

TOP CHOICE

H8610

™

H8600

™

E-50GW

H8500

™

H8510

™

H8000

™

H8010

™

NEW

H8100

™

NEW

H8110

™

U-05FL

™

3984

™

Chemistry

Two-Part Acrylic

Two-Part Acrylic

Two-Part Epoxy

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part

Urethane

One-Part Epoxy

Color

White

Blue

Grey

Grey

Grey

Green

Grey

Green

Green

Off-White

Light Grey

Viscosity (cP)



105,000

86,000

37,000

60,000

45,000

190,000

200,000

185,000

200,000

100,000

25,000

Mix Ratio

2:1

2:1

4:1

10:1

10:1

10:1

10:1

10:1

10:1

1:2

One Part

Work Life (minutes)

5

25

50

20

30

15

35

15

2-3

5

N/A

Fixture Time (minutes)

20

1

55

6

75

17

30

30

40

20

5

180

N/A

Cure Time (hours)

48

48

24

72

72

24

24

24

24

24

25 min. @

212ºF (100ºC)

Shear Strength

1

 (psi)

1,800

3,355

1,900

6

2,899

2,175

3,250

2,175

2,880

1,360

930

3

>2,000

5

Impact Strength

1

 (kJ/m

2

)

>14

38

–

26.3

>14

17.4

29

11

8

636

7

–

Peel Strength

4

 (pli)

10

22.6

–

46.4

58

40

37

12

9

–

–

Hot Strength

2

 (psi)

500

460

1,273 (500 hours)

960

540

450

485

560

–

280

200

Loctite

®

 H8610

™



Speedbonder

™



Structural Adhesive
Galvanized Steel Bonder

A fast curing, two-

component acrylic

designed for bonding

galvanized steel, galvaneal

and galvalum. Excellent

shear strength on steel

and aluminum. Especially

designed for long-term

heat and humidity

resistance.

P/N

  Package Size

1055263   50 ml dual cartridge

1055839   400 ml dual cartridge

Loctite

®

 H8600

™



Speedbonder

™



Structural Adhesive
Galvanized Steel Bonder

Excellent shear strength

on steel and aluminum.

Especially designed for

severe environments.

P/N

Package Size

40875  50 ml dual cartridge
38762  400 ml dual cartridge
38760*  5 gallon pail, adhesive
38761*  5 gallon pail, activator

Loctite

®



E-50GW

™

 Hysol

®



Epoxy Adhesive
Galvanized Steel

to Wood Bonder

A grey, two-component

epoxy designed to

bond galvanized steel

to wooden surfaces.

Extended, 50-minute

work life makes for

easy adjustment of larger

parts.

P/N

  Package Size

1078249  50 ml dual cartridge
1077864*  400 ml dual

  cartridge

Loctite

®

 H8500

™



Speedbonder

™



Structural Adhesive
Ultra-Tough

Excellent peel strength

on steel and aluminum.

Contains 30 mil spacer

beads to prevent

excessive squeeze-out

of adhesive due to over-

clamping. Provides fast

fixturing.

P/N

  Package Size

996514  50 ml dual cartridge
827608  490 ml dual cartridge
40888*  5 gallon pail, activator
40889*  5 gallon pail, adhesive

Loctite

®

 H8510

™



Speedbonder

™



Structural Adhesive
Ultra-Tough

Offers superior peel and

impact strength on steel

and aluminum. This grey,

ultra-fracture toughened,

two-component acrylic

adhesive has an extended

open time, making it ideal

for the assembly and

adjustment of larger parts.

Contains 30 mil spacer

beads to prevent excessive

squeeze-out of adhesive

due to over-clamping.

P/N

  Package Size

996513    50 ml dual cartridge
1107651  490 ml dual cartridge

Loctite

®

 H8000

™



Speedbonder

™



Structural Adhesive
Tough Aluminum

Bonder

Exhibits excellent peel

strength on multiple

substrates, especially

aluminum.

P/N

  Package Size

996453  50 ml dual

cartridge

36160  490 ml dual

cartridge

35939*  35 lb. pail,

adhesive

35940*  45 lb. pail,

activator

Loctite

®

 H8010

™



Speedbonder

™



Structural Adhesive
Tough Aluminum Bonder

Non-sag, two-component,

room temperature curing,

methacrylate adhesive,

exhibits superior peel

strength on multiple

substrates, especially

aluminum. Contains 5 mil

spacer beads to prevent

excessive squeeze-out

of adhesive due to over-

clamping.

P/N

  Package Size

1056929  50 ml dual cartridge
40594    490 ml dual cartridge

Loctite

®

 H8100

™



Speedbonder
Structural Adhesive
Fast Fixture

Exhibits excellent peel

and shear strength on

aluminum.

P/N

  Package Size

1056942  50 ml dual

 cartridge

1056943  490 ml dual

 cartridge

Loctite

®

 H8110

™



Speedbonder
Structural Adhesive
Ultra-Fast Fixture

Aluminum bonder

fixtures in five

minutes.

P/N

  Package Size

1371355  50 ml dual

 cartridge

1371361  490 ml dual

 cartridge

Loctite

®

 U-05FL

™

 Hysol

®



Urethane Adhesive
High Strength

A two-part, high

performance urethane

adhesive for metal bonding

with a 5-minute work life.

Off-white, highly flexible,

impact and moisture

resistant, high peel, high

shear.

P/N

Package Size

29348  50 ml dual cartridge
29349  200 ml dual cartridge
29350  400 ml dual cartridge
29351  5 gallon pail, resin
29352  5 gallon pail, hardener

Loctite

®

 3984

™



Hysol

®



Epoxy Adhesive
High Performance /

Various Substrates

Highly fluorescent,

one-part, heat

cure epoxy

adhesive offering

superior physical,

environmental

and performance

properties.

P/N

Package Size

36768  30 ml syringe
37299*  1 liter bottle

Multiple

Surface Bonding

14

4

th

 Law of

Structural Engagement

You can’t weld plastic to

glass, or metal to wood,

no matter how hard

you try.

Unlike welding, soldering and brazing,
adhesives are able to bond two
dissimilar materials, whether it be
steel to wood, plastic to glass, or
composites to aluminum.

Loctite

®

 Structural Adhesives for multiple surfaces bond a wide

variety of materials, such as metal, ceramic and plastic.
They are available in a variety of formulations and performance
capabilities, including fast cure, superior water/humidity resistance,
ease of dispense, excellent hot strength and resistance to a wide
range of chemicals.

Overall benefits of Loctite

®

 Structural Adhesives for multiple

surfaces include:



  •  Range of cure profiles



  •  Range of viscosities



  •  High-impact strength



  •  Peel strength



  •  Variety of colors



  •  Toughness on a wide variety of substrates



  •  Durability on a wide variety of substrates

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

We’re Writing the Law

We’re Writing the Law

www.henkelna.com/loctitestructurals

15

?

Loctite

®

 E-30UT

™



contains Kevlar

®

 to

provide ultra-tough

performance properties.

As a result, special

Loctite

®

 mix

nozzles are required

for dispensing.

A Clue From Prof. McGlue

16

* Made to Order Item

1

 Steel

General Performance

General Performance

No-Mix / No-Gap

Clear Bonding

Fast Fixture

General-Purpose

Ultra-Fast Fixture

Fast Fixture

Medium Fixture

Extended Fixture

Flowable

Non-Sag

Chemical Resistant

TOP CHOICE

TOP CHOICE

326

™

330

™

NEW

A-533

™

E-00CL

™

608

™

E-30CL

™

0151

™

Chemistry

Two-Step Acrylic

Two-Step Acrylic

Two-Step Acrylic

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Color

Light Amber

Pale Yellow

Grey

Clear

Clear

Clear

Clear

Viscosity (cP)

17,000

67,500

15,000

10,000

100,000

10,000

60,000

Mix Ratio

N/A

N/A

N/A

1:1

1:1

2:1

2.7:1

Work Life (minutes)

N/A

N/A

N/A

5

5

30

60

Fixture Time (minutes)

1

5

0.5

15

15

>180

>180

Cure Time (hours)

24

24

1

24

24

24

24

Shear Strength

1

 (psi)

3,500

3,300

3,500

2,160

2,080

3,100

2,675

Temperature Resistance

250ºF (121ºC)

250ºF (121ºC)

325°F (163°C)

180ºF (82ºC)

180ºF (82ºC)

350ºF (177ºC)

350ºF (177ºC)

Loctite

®

 326

™

 Speedbonder

™



Structural Adhesive
Fast Fixture

An all-purpose bonder. Offers

the strength of an epoxy and the

speed of an instant adhesive.

Solvent resistant. Cures in

minutes. Ideal for applications

requiring fast fixturing. Use with

Loctite

®

 7649

™

 Primer N

™

.

P/N

Package Size

32629  50 ml bottle
32685  1 liter bottle

Loctite

®

 330

™

 Depend

®

 Adhesive

General-Purpose

A general-purpose, high viscosity

adhesive for a wide range of

materials, including metal, wood,

ferrite, ceramic and plastic. Use with

Loctite

®

 7387

™

 Depend

®

 Activator.

P/N

Package Size

20253  3 ml kit (2.5 ml tube of Loctite

®

 330

™



Depend

®

 Adhesive and .6 ml ampule

of Loctite

®

 7387

™

 Depend

®

 Activator)

20251  25 ml kit (25 ml syringe of Loctite

®



330

™

 Depend

®

 Adhesive and 25

g aerosol can of Loctite

®

 7387

™



Depend

®

 Activator)

20252  250 ml kit (250 ml tube of Loctite

®

 330

™

 Depend

®

 Adhesive and 128 g

of Loctite

®

 7387

™

 Depend

®

 Activator)

33058  250 ml tube
33064  300 ml cartridge
33081  1 liter bottle



Loctite

®

 A-533

™



Structural Adhesive

(formerly National Adhesives
Bondmaster

™

 533)

Ultra-Fast Fixture

A general-purpose adhesive for

bonding magnets, metals and

glass. Fixtures in seconds. Use

with Loctite

®

 A-534R

™

 Activator.

P/N

  Package Size

1254145  50 ml bottle
1254144  1 liter bottle
1254143  14 liter pail

Loctite

®

 E-00CL

™

 Hysol

®



Epoxy Adhesive
Flowable

A clear, flowable, fast setting

epoxy with a 5-minute work life.

P/N

Package Size

29289  50 ml dual cartridge
29290  200 ml dual cartridge
29291  400 ml dual cartridge

Loctite

®

 608

™

 Hysol

®



Epoxy Adhesive

(Alternative: Loctite

®

 E-00NS

™

Hysol

®

 Epoxy Adhesive)

Non-Sag

A fast-setting, low odor

epoxy with a 5-minute work life.

Cures at room temperature to

form a clear bond line.

P/N

Package Size

83086  4 g foil pack
83075  50 ml dual cartridge
83082  EPK 2.8 oz. kit

Loctite

®

 E-30CL

™

 Hysol

®



Epoxy Adhesive
Chemical Resistant

An ultra clear, low viscosity,

impact resistant epoxy with a

30-minute work life. An

excellent glass bonder. Exhibits

exceptional chemical resistance.

P/N

Package Size

29329  50 ml dual cartridge
29330  200 ml dual cartridge
29331  400 ml dual cartridge

Loctite

®

 0151

™

 Hysol

®



Epoxy Adhesive
Ultra Clear

A general-purpose, thixotropic

paste epoxy with a 60-minute

work life. Allows for extended

adjustment time.

P/N

Package Size

83069  50 ml dual cartridge
83176  EPK 3.3 oz. kit
83179  2.6 lb. kit
83178  10.7 lb. kit

Your Application

Multiple

Surface Bonding

Product Description

Solution

17

General Performance

General Performance

No-Mix / No-Gap

Clear Bonding

Fast Fixture

General-Purpose

Ultra-Fast Fixture

Fast Fixture

Medium Fixture

Extended Fixture

Flowable

Non-Sag

Chemical Resistant

TOP CHOICE

TOP CHOICE

326

™

330

™

NEW

A-533

™

E-00CL

™

608

™

E-30CL

™

0151

™

Chemistry

Two-Step Acrylic

Two-Step Acrylic

Two-Step Acrylic

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Color

Light Amber

Pale Yellow

Grey

Clear

Clear

Clear

Clear

Viscosity (cP)

17,000

67,500

15,000

10,000

100,000

10,000

60,000

Mix Ratio

N/A

N/A

N/A

1:1

1:1

2:1

2.7:1

Work Life (minutes)

N/A

N/A

N/A

5

5

30

60

Fixture Time (minutes)

1

5

0.5

15

15

>180

>180

Cure Time (hours)

24

24

1

24

24

24

24

Shear Strength

1

 (psi)

3,500

3,300

3,500

2,160

2,080

3,100

2,675

Temperature Resistance

250ºF (121ºC)

250ºF (121ºC)

325°F (163°C)

180ºF (82ºC)

180ºF (82ºC)

350ºF (177ºC)

350ºF (177ºC)

Loctite

®

 326

™

 Speedbonder

™



Structural Adhesive
Fast Fixture

An all-purpose bonder. Offers

the strength of an epoxy and the

speed of an instant adhesive.

Solvent resistant. Cures in

minutes. Ideal for applications

requiring fast fixturing. Use with

Loctite

®

 7649

™

 Primer N

™

.

P/N

Package Size

32629  50 ml bottle
32685  1 liter bottle

Loctite

®

 330

™

 Depend

®

 Adhesive

General-Purpose

A general-purpose, high viscosity

adhesive for a wide range of

materials, including metal, wood,

ferrite, ceramic and plastic. Use with

Loctite

®

 7387

™

 Depend

®

 Activator.

P/N

Package Size

20253  3 ml kit (2.5 ml tube of Loctite

®

 330

™



Depend

®

 Adhesive and .6 ml ampule

of Loctite

®

 7387

™

 Depend

®

 Activator)

20251  25 ml kit (25 ml syringe of Loctite

®



330

™

 Depend

®

 Adhesive and 25

g aerosol can of Loctite

®

 7387

™



Depend

®

 Activator)

20252  250 ml kit (250 ml tube of Loctite

®

 330

™

 Depend

®

 Adhesive and 128 g

of Loctite

®

 7387

™

 Depend

®

 Activator)

33058  250 ml tube
33064  300 ml cartridge
33081  1 liter bottle



Loctite

®

 A-533

™



Structural Adhesive

(formerly National Adhesives
Bondmaster

™

 533)

Ultra-Fast Fixture

A general-purpose adhesive for

bonding magnets, metals and

glass. Fixtures in seconds. Use

with Loctite

®

 A-534R

™

 Activator.

P/N

  Package Size

1254145  50 ml bottle
1254144  1 liter bottle
1254143  14 liter pail

Loctite

®

 E-00CL

™

 Hysol

®



Epoxy Adhesive
Flowable

A clear, flowable, fast setting

epoxy with a 5-minute work life.

P/N

Package Size

29289  50 ml dual cartridge
29290  200 ml dual cartridge
29291  400 ml dual cartridge

Loctite

®

 608

™

 Hysol

®



Epoxy Adhesive

(Alternative: Loctite

®

 E-00NS

™

Hysol

®

 Epoxy Adhesive)

Non-Sag

A fast-setting, low odor

epoxy with a 5-minute work life.

Cures at room temperature to

form a clear bond line.

P/N

Package Size

83086  4 g foil pack
83075  50 ml dual cartridge
83082  EPK 2.8 oz. kit

Loctite

®

 E-30CL

™

 Hysol

®



Epoxy Adhesive
Chemical Resistant

An ultra clear, low viscosity,

impact resistant epoxy with a

30-minute work life. An

excellent glass bonder. Exhibits

exceptional chemical resistance.

P/N

Package Size

29329  50 ml dual cartridge
29330  200 ml dual cartridge
29331  400 ml dual cartridge

Loctite

®

 0151

™

 Hysol

®



Epoxy Adhesive
Ultra Clear

A general-purpose, thixotropic

paste epoxy with a 60-minute

work life. Allows for extended

adjustment time.

P/N

Package Size

83069  50 ml dual cartridge
83176  EPK 3.3 oz. kit
83179  2.6 lb. kit
83178  10.7 lb. kit

18

* Made to Order Item

1

 Steel

2

Grit Blasted Mild Steel

General Performance (Cont.)

General Performance (Cont.)

Sandable

Potting

Flexible

Fast Fixture

Medium Fixture

Extended Fixture

Fast Fixture

Medium Fixture

Extended Fixture

TOP CHOICE

615

™

U-09LV

™

E-60NC

™

E-05CL

™

E-40FL

™

E-90FL

™

Chemistry

Two-Part Epoxy

Two-Part Urethane

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Color

Light Blue

Clear

Black

Clear

Opaque Grey

Opaque Grey

Viscosity (cP)

200,000

1,000

8,000

2,500

70,000

40,000

Mix Ratio

1:1

1:1

1:1

1:1

1:1

1:1

Work Life (minutes)

10

10

60

5

40

90

Fixture Time (minutes)

25

150

360

30

180

180

Cure Time (hours)

24

24

24

24

24

24

Shear Strength

1

 (psi)

3,825

2

1,146

2

2,630

2

1,430

2

640

2

810

2

Temperature Resistance

350ºF (177ºC)

350°F (177°C)

250ºF (121ºC)

300ºF (148ºC)

350ºF (177ºC)

350ºF (177ºC)

Loctite

®

 615

™

 Hysol

®



Epoxy Adhesive
Sandable / Machinable

A high strength, low odor epoxy

with a 10-minute work life. Blue,

fast cure, gap filling.

P/N

Package Size

83094  EPK 3.2 oz. kit
83095*  12 lb. kit

Loctite

®

 U-09LV

™

 Hysol

®



Urethane Adhesive
Low Viscosity

A two-part, high performance

urethane adhesive for plastic

bonding with a 10-minute work

life.

P/N

Package Size

38588  50 ml dual cartridge
38589  200 ml dual cartridge

Loctite

®

 E-60NC

™

 Hysol

®



Epoxy Adhesive
Noncorrosive / Potting

An electronics-grade potting

compound with a 60-minute

work life. Black, opaque, low

viscosity with excellent cure-

through depth.

P/N

Package Size

29324  50 ml dual cartridge
29325  200 ml dual cartridge
29326  400 ml dual cartridge

Loctite

®

 E-05CL

™

 Hysol

®



Epoxy Adhesive
Toughened

An ultra-clear, high peel, low odor

epoxy with a 5-minute work life.

P/N

Package Size

29299  50 ml dual cartridge
29300  200 ml dual cartridge
29301  400 ml dual cartridge
29302*  5 gallon pail, resin
29303*  5 gallon pail, hardener

Loctite

®

 E-40FL

™

 Hysol

®



Epoxy Adhesive
Flexible

A grey, impact resistant, toughened

epoxy with a 40-minute work life.

P/N

Package Size

29304  50 ml dual cartridge
29305  200 ml dual cartridge
29306  400 ml dual cartridge

Loctite

®

 E-90FL

™

 Hysol

®



Epoxy Adhesive
Impact Resistant

A grey, impact resistant, toughened

epoxy with a 90-minute work life.

P/N

Package Size

29309  50 ml dual cartridge
29310  200 ml dual cartridge
29311  400 ml dual cartridge
29312*  5 gallon pail, resin
29313*  5 gallon pail, hardener

Multiple

Surface Bonding

Your Application

Product Description

5

th

 Law of

Structural Engagement

There are no pretty

bolt heads.



While fit and function are important,
style is often the difference in a successful
product in today’s marketplace. Fasteners
protrude from the surface and can detract
from the aesthetic styling of the assembly.
Since adhesives are applied inside the
joint, they are invisible within the
assembly, resulting in a more cosmetically
appealing product.

Solution

19

General Performance (Cont.)

General Performance (Cont.)

Sandable

Potting

Flexible

Fast Fixture

Medium Fixture

Extended Fixture

Fast Fixture

Medium Fixture

Extended Fixture

TOP CHOICE

615

™

U-09LV

™

E-60NC

™

E-05CL

™

E-40FL

™

E-90FL

™

Chemistry

Two-Part Epoxy

Two-Part Urethane

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Color

Light Blue

Clear

Black

Clear

Opaque Grey

Opaque Grey

Viscosity (cP)

200,000

1,000

8,000

2,500

70,000

40,000

Mix Ratio

1:1

1:1

1:1

1:1

1:1

1:1

Work Life (minutes)

10

10

60

5

40

90

Fixture Time (minutes)

25

150

360

30

180

180

Cure Time (hours)

24

24

24

24

24

24

Shear Strength

1

 (psi)

3,825

2

1,146

2

2,630

2

1,430

2

640

2

810

2

Temperature Resistance

350ºF (177ºC)

350°F (177°C)

250ºF (121ºC)

300ºF (148ºC)

350ºF (177ºC)

350ºF (177ºC)

Loctite

®

 615

™

 Hysol

®



Epoxy Adhesive
Sandable / Machinable

A high strength, low odor epoxy

with a 10-minute work life. Blue,

fast cure, gap filling.

P/N

Package Size

83094  EPK 3.2 oz. kit
83095*  12 lb. kit

Loctite

®

 U-09LV

™

 Hysol

®



Urethane Adhesive
Low Viscosity

A two-part, high performance

urethane adhesive for plastic

bonding with a 10-minute work

life.

P/N

Package Size

38588  50 ml dual cartridge
38589  200 ml dual cartridge

Loctite

®

 E-60NC

™

 Hysol

®



Epoxy Adhesive
Noncorrosive / Potting

An electronics-grade potting

compound with a 60-minute

work life. Black, opaque, low

viscosity with excellent cure-

through depth.

P/N

Package Size

29324  50 ml dual cartridge
29325  200 ml dual cartridge
29326  400 ml dual cartridge

Loctite

®

 E-05CL

™

 Hysol

®



Epoxy Adhesive
Toughened

An ultra-clear, high peel, low odor

epoxy with a 5-minute work life.

P/N

Package Size

29299  50 ml dual cartridge
29300  200 ml dual cartridge
29301  400 ml dual cartridge
29302*  5 gallon pail, resin
29303*  5 gallon pail, hardener

Loctite

®

 E-40FL

™

 Hysol

®



Epoxy Adhesive
Flexible

A grey, impact resistant, toughened

epoxy with a 40-minute work life.

P/N

Package Size

29304  50 ml dual cartridge
29305  200 ml dual cartridge
29306  400 ml dual cartridge

Loctite

®

 E-90FL

™

 Hysol

®



Epoxy Adhesive
Impact Resistant

A grey, impact resistant, toughened

epoxy with a 90-minute work life.

P/N

Package Size

29309  50 ml dual cartridge
29310  200 ml dual cartridge
29311  400 ml dual cartridge
29312*  5 gallon pail, resin
29313*  5 gallon pail, hardener

?

Unlike most

5-minute epoxies,

Loctite

®

 E-05MR

™



Hysol

®

 has

non-skinning

properties, making

it process friendly

for bulk dispensing.

20

A Clue From Prof. McGlue

* Made to Order Item

1

Steel

2

Grit Blasted Mild Steel

3

Grit Blasted Steel

4

Block Grit Blasted Mild Steel

High Toughness

High Toughness

Fast Room

Temperature Fixture

Medium Room

 Temperature Fixture

Extended Room Temperature Fixture

Heat Cure - One Part

Moisture

Resistant

No-Mix /

No-Gap

Ultra-Tough

Easy Mix

Non-Sag

Impact

Resistant

High

Performance

Non-Sag

Flowable

Non-Sag

Low Temp.

Impact Resistant

TOP CHOICE

TOP CHOICE

TOP CHOICE

TOP CHOICE

E-05MR

™

324

™

E-30UT

™

E-20HP

™

9460

™

9430

™

E-60HP

™

9462

™

3981

™

3985

™

NEW

E-757

™

Chemistry

Two-Part Epoxy

Two-Step Acrylic

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

One-Part Epoxy

One-Part Epoxy

One-Part Epoxy

Color

Ultra Clear

Amber

Purple

Off-White

Grey

Off-White

Off-White

Beige

Transparent

Yellow

Black

Grey

Viscosity (cP)

25,000

17,000

12,200

30,000

200,000

12,000

45,000

70,000

5,000

50,000

Paste

Mix Ratio

1:1

N/A

2:1

2:1

1:1

3.78:1

2:1

1:1

N/A

N/A

N/A

Work Life (minutes)

5

N/A

35

20

50

50

60

50

N/A

N/A

N/A

Fixture Time (minutes)

15

5

180

120

>180

>180

7,180

>180

N/A

N/A

N/A

Cure Time (hours)

24

24

24

24

24

24

24

24

30 min. @

257ºF (125ºC)

30 min. @

272ºF (150ºC)

40 min. @

275°F (135°C)

Shear Strength

1

 (psi)

3,200

3,600

4,200

3,270

2

3,500

4

4,230

4,320

4,180

4,930

3

–

1,500

Temperature Resistance

250ºF (121ºC)

300ºF (148ºC)

350°F (177°C)

350ºF (177ºC)

350ºF (177ºC)

180ºF (82ºC)

350ºF (177ºC)

350ºF (177ºC)

250ºF (121ºC)

–

300°F (149°C)

Loctite

®

 E-05MR

™

 Hysol

®



Epoxy Adhesive
Moisture Resistant

Clear, two-component,

fast room temperature

curing epoxy adhesive

provides excellent moisture

resistance and exceptional

toughness for a 5-minute

epoxy. Its low odor and non-

skinning properties make

bulk dispensing possible.

P/N

  Package Size

1087601  25 ml dual cartridge
1086598  50 ml dual cartridge
1086600  200 ml dual cartridge
1086599*  400 ml dual cartridge
1087602*  5 gallon pail, resin
1087603*  5 gallon pail, hardener

Loctite

®

 324

™



Speedbonder

™



Structural Adhesive
High Impact

Ideal for larger gap

applications. Offers the

strength of an epoxy

and the speed of an

instant adhesive. Solvent

resistant. Fixtures in

minutes. Specially

formulated for toughness

and impact strength.

Use with Loctite

®

 7075

™



Activator.

P/N

Package Size

32430  50 ml bottle
32490  1 liter bottle

Loctite

®



E-30UT

™

 Hysol

®



Epoxy Adhesive
Ultra-Tough

A two-component room

temperature curing

epoxy adhesive that

contains Kevlar

®

 to

provide exceptional

fracture toughness

characteristics for

the most demanding

structural bonding

requirements.

35-minute work life.

P/N

  Package Size

1078234  50 ml dual cartridge
1078235  400 ml dual cartridge

Loctite

®

 E-20HP

™



Hysol

®

 Epoxy Adhesive

High Performance

A high strength epoxy

with a 20-minute

work life. Off-white,

toughened, high peel,

high shear.

P/N

Package Size

29314  50 ml dual cartridge
29315  200 ml dual cartridge
29316  400 ml dual cartridge
29317  5 gallon pail, resin
29318  5 gallon pail,

hardener

Loctite

®

 9460

™

 Hysol

®



Epoxy Adhesive
Non-Sag

A grey, impact

resistant, high

viscosity, high peel,

high shear epoxy with

a 50-minute work life.

P/N

Package Size

83129  50 ml dual cartridge
83128  200 ml dual cartridge
83127*  400 ml dual cartridge
83131  5 lb. kit
83130  20 lb. kit
83133  50 lb. pail, hardener
83134  50 lb. pail, resin

Loctite

®



9430

™

 Hysol

®



Epoxy Adhesive
Impact Resistant

An off-white,

toughened, light

paste, high peel, high

shear strength epoxy

with a 50-minute

work life.

P/N

Package Size

83114  2 lb. kit
83113  10 lb. kit

Loctite

®



E-60HP

™

 Hysol

®



Epoxy Adhesive
Flowable

A high strength epoxy

with a 60-minute work

life. Off-white, high

peel, high shear.

P/N

Package Size

29319  50 ml dual cartridge
29320  200 ml dual

cartridge

29321  400 ml dual

cartridge

29322*  5 gallon pail, resin
29323*  5 gallon pail,

hardener

Loctite

®

 9462

™

 Hysol

®



Epoxy Adhesive
Non-Sag

A beige, toughened

two-component room

temperature cure

epoxy with a 50-minute

work life. Its medium

viscosity, 1-to-1 mix

ratio, and non-sag

features make it very

easy to apply. Excellent

impact resistance for

bonding a variety of

surfaces, including

metal, plastic and wood.

P/N

Package Size

83142  50 ml dual cartridge
83135*  200 ml dual cartridge

Loctite

®



3981

™

 Hysol

®



Epoxy Adhesive
High Performance /

Various Substrates

Highly fluorescent,

one-component,

heat cure epoxy

adhesive offers

superior physical,

environmental

and performance

properties.

P/N

Package Size

36766  30 ml cartridge
37297  1 liter bottle

Loctite

®



3985

™

 Hysol

®



Epoxy Adhesive
Non-Sag

A one-component,

heat cure epoxy. Ideal

for bonding wires to

motor armatures.

P/N

Package Size

40870  1 liter bottle
34731*  5 gallon pail

Loctite

®

 E-757

™



Epoxy Adhesive

(formerly National
Adhesives EccoBond

®



G-757)

Low Temperature

Resistant

A one-component,

heat cure epoxy,

exhibiting excellent

low temperature

impact resistance.

P/N

  Package Size

1386228  25 ml syringe
1215379  1 gallon pail
1215380  5 gallon pail

Multiple

Surface Bonding

Your Application

Product Description

Solution

21

High Toughness

High Toughness

Fast Room

Temperature Fixture

Medium Room

 Temperature Fixture

Extended Room Temperature Fixture

Heat Cure - One Part

Moisture

Resistant

No-Mix /

No-Gap

Ultra-Tough

Easy Mix

Non-Sag

Impact

Resistant

High

Performance

Non-Sag

Flowable

Non-Sag

Low Temp.

Impact Resistant

TOP CHOICE

TOP CHOICE

TOP CHOICE

TOP CHOICE

E-05MR

™

324

™

E-30UT

™

E-20HP

™

9460

™

9430

™

E-60HP

™

9462

™

3981

™

3985

™

NEW

E-757

™

Chemistry

Two-Part Epoxy

Two-Step Acrylic

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

One-Part Epoxy

One-Part Epoxy

One-Part Epoxy

Color

Ultra Clear

Amber

Purple

Off-White

Grey

Off-White

Off-White

Beige

Transparent

Yellow

Black

Grey

Viscosity (cP)

25,000

17,000

12,200

30,000

200,000

12,000

45,000

70,000

5,000

50,000

Paste

Mix Ratio

1:1

N/A

2:1

2:1

1:1

3.78:1

2:1

1:1

N/A

N/A

N/A

Work Life (minutes)

5

N/A

35

20

50

50

60

50

N/A

N/A

N/A

Fixture Time (minutes)

15

5

180

120

>180

>180

7,180

>180

N/A

N/A

N/A

Cure Time (hours)

24

24

24

24

24

24

24

24

30 min. @

257ºF (125ºC)

30 min. @

272ºF (150ºC)

40 min. @

275°F (135°C)

Shear Strength

1

 (psi)

3,200

3,600

4,200

3,270

2

3,500

4

4,230

4,320

4,180

4,930

3

–

1,500

Temperature Resistance

250ºF (121ºC)

300ºF (148ºC)

350°F (177°C)

350ºF (177ºC)

350ºF (177ºC)

180ºF (82ºC)

350ºF (177ºC)

350ºF (177ºC)

250ºF (121ºC)

–

300°F (149°C)

Loctite

®

 E-05MR

™

 Hysol

®



Epoxy Adhesive
Moisture Resistant

Clear, two-component,

fast room temperature

curing epoxy adhesive

provides excellent moisture

resistance and exceptional

toughness for a 5-minute

epoxy. Its low odor and non-

skinning properties make

bulk dispensing possible.

P/N

  Package Size

1087601  25 ml dual cartridge
1086598  50 ml dual cartridge
1086600  200 ml dual cartridge
1086599*  400 ml dual cartridge
1087602*  5 gallon pail, resin
1087603*  5 gallon pail, hardener

Loctite

®

 324

™



Speedbonder

™



Structural Adhesive
High Impact

Ideal for larger gap

applications. Offers the

strength of an epoxy

and the speed of an

instant adhesive. Solvent

resistant. Fixtures in

minutes. Specially

formulated for toughness

and impact strength.

Use with Loctite

®

 7075

™



Activator.

P/N

Package Size

32430  50 ml bottle
32490  1 liter bottle

Loctite

®



E-30UT

™

 Hysol

®



Epoxy Adhesive
Ultra-Tough

A two-component room

temperature curing

epoxy adhesive that

contains Kevlar

®

 to

provide exceptional

fracture toughness

characteristics for

the most demanding

structural bonding

requirements.

35-minute work life.

P/N

  Package Size

1078234  50 ml dual cartridge
1078235  400 ml dual cartridge

Loctite

®

 E-20HP

™



Hysol

®

 Epoxy Adhesive

High Performance

A high strength epoxy

with a 20-minute

work life. Off-white,

toughened, high peel,

high shear.

P/N

Package Size

29314  50 ml dual cartridge
29315  200 ml dual cartridge
29316  400 ml dual cartridge
29317  5 gallon pail, resin
29318  5 gallon pail,

hardener

Loctite

®

 9460

™

 Hysol

®



Epoxy Adhesive
Non-Sag

A grey, impact

resistant, high

viscosity, high peel,

high shear epoxy with

a 50-minute work life.

P/N

Package Size

83129  50 ml dual cartridge
83128  200 ml dual cartridge
83127*  400 ml dual cartridge
83131  5 lb. kit
83130  20 lb. kit
83133  50 lb. pail, hardener
83134  50 lb. pail, resin

Loctite

®



9430

™

 Hysol

®



Epoxy Adhesive
Impact Resistant

An off-white,

toughened, light

paste, high peel, high

shear strength epoxy

with a 50-minute

work life.

P/N

Package Size

83114  2 lb. kit
83113  10 lb. kit

Loctite

®



E-60HP

™

 Hysol

®



Epoxy Adhesive
Flowable

A high strength epoxy

with a 60-minute work

life. Off-white, high

peel, high shear.

P/N

Package Size

29319  50 ml dual cartridge
29320  200 ml dual

cartridge

29321  400 ml dual

cartridge

29322*  5 gallon pail, resin
29323*  5 gallon pail,

hardener

Loctite

®

 9462

™

 Hysol

®



Epoxy Adhesive
Non-Sag

A beige, toughened

two-component room

temperature cure

epoxy with a 50-minute

work life. Its medium

viscosity, 1-to-1 mix

ratio, and non-sag

features make it very

easy to apply. Excellent

impact resistance for

bonding a variety of

surfaces, including

metal, plastic and wood.

P/N

Package Size

83142  50 ml dual cartridge
83135*  200 ml dual cartridge

Loctite

®



3981

™

 Hysol

®



Epoxy Adhesive
High Performance /

Various Substrates

Highly fluorescent,

one-component,

heat cure epoxy

adhesive offers

superior physical,

environmental

and performance

properties.

P/N

Package Size

36766  30 ml cartridge
37297  1 liter bottle

Loctite

®



3985

™

 Hysol

®



Epoxy Adhesive
Non-Sag

A one-component,

heat cure epoxy. Ideal

for bonding wires to

motor armatures.

P/N

Package Size

40870  1 liter bottle
34731*  5 gallon pail

Loctite

®

 E-757

™



Epoxy Adhesive

(formerly National
Adhesives EccoBond

®



G-757)

Low Temperature

Resistant

A one-component,

heat cure epoxy,

exhibiting excellent

low temperature

impact resistance.

P/N

  Package Size

1386228  25 ml syringe
1215379  1 gallon pail
1215380  5 gallon pail

22

* Made to Order Item

1

Steel

2

Grit Blasted Mild Steel

3

Etched Aluminum

High Temperature / Chemically Resistant

High Temperature / Chemically Resistant

Fast Room

Temperature

Medium Room

Temperature

Extended Room Temperature Fixture

Heat Cure - One-Part

No-Mix / No-Gap

Gap Filling

High Strength

Flowable

Non-Sag

Self-Leveling

TOP CHOICE

332

™

1C

™

E-40HT

™

E-50CR

™

9340

™

9459

™

Chemistry

Two-Step Acrylic

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

One-Part Epoxy

Color

Amber

White

Off-White

Black

Grey

Light Grey

Viscosity (cP)

100,000

350,000

16,000

5,000

Paste

40,000

Mix Ratio

N/A

2.5:1

2:1

2:1

1:1

N/A

Work Life (minutes)

N/A

25

45

50

90

N/A

Fixture Time (minutes)

3

210

180

300

>360

N/A

Cure Time (hours)

24

24

24

24

24

1 @ 250ºF (121ºC)

Shear Strength

1

 (psi)

3,000

1,750

3

4,030

2,500

2

2,300

3

3,000

3

Temperature Resistance

400ºF (204ºC)

350ºF (177ºC)

350ºF (177ºC)

350ºF (177ºC)

 >180°F (82°C)

 >300°F (148°C)

Loctite

®

 332

™



Structural Adhesive
Severe Environment

An activator-cured, no-mix

adhesive that provides high

temperature capability with

thermal durability up to

400°F (204°C). Use with Loctite

®



7387

™

 Depend

®

 Activator.

P/N

Package Size

33201  25 ml syringe
33275  300 ml cartridge
33290  1 liter bottle

Loctite

®

 1C

™

 Hysol

®



Epoxy Adhesive
Gap Filling

A high viscosity paste with a

25-minute work life. Excellent

gap-filling capability and

performance properties.

P/N

Package Size

83200  EPK 4 oz. kit
83202  4 lb. kit
83201  17 lb. kit
83206*  60 lb. pail, resin
83183*  43 lb. pail, hardener

Loctite

®

 E-40HT

™

 Hysol

®



Epoxy Adhesive
High Temperature

A two-component toughened

adhesive, which combines

high peel strength at room

temperature with tensile lap

shear strength at elevated

temperatures. An off-white

paste exhibiting exceptional high

temperature performance.

P/N

  Package Size

1086065  50 ml dual syringe
1086081  400 ml dual cartridge

Loctite

®

 E-50CR

™

 Hysol

®



Epoxy Adhesive
Chemically Resistant

A flowable, two-component,

extended room temperature curing

epoxy with excellent chemical

resistance properties. Black,

50-minute work life.

P/N

  Package Size

1079594  50 ml dual syringe
1079593  400 ml dual cartridge

Loctite

®

 9340

™

 Hysol

®



Epoxy Adhesive
Environmental Resistance

A grey, high viscosity epoxy with

a 90-minute work life. Excellent

high temperature and chemical

resistance.

P/N

Package Size

83104  EPK 2.7 oz. kit
83105  5 lb. kit

Loctite

®

 9459

™

 Hysol

®



Epoxy Adhesive
High Temperature Resistance

A one-component, heat cure epoxy.

Low viscosity, self-leveling. Light

grey, excellent high temperature

performance, excellent chemical

resistance.

P/N

Package Size

83126  10 lb. can

Multiple

Surface Bonding

Your Application

Product Description

6

th

 Law of

Structural Engagement

When was the last time

you heard a structural

adhesive rattling around?

Many assemblies fastened together
using screws and bolts can loosen over
time, resulting in rattling noises as your
assemblies go through their paces. Using
an adhesive instead of fasteners not only
can prevent loosening, but the adhesive’s
ability to absorb noise and damp vibrations
also makes it an excellent sound deadener.

Solution

23

High Temperature / Chemically Resistant

High Temperature / Chemically Resistant

Fast Room

Temperature

Medium Room

Temperature

Extended Room Temperature Fixture

Heat Cure - One-Part

No-Mix / No-Gap

Gap Filling

High Strength

Flowable

Non-Sag

Self-Leveling

TOP CHOICE

332

™

1C

™

E-40HT

™

E-50CR

™

9340

™

9459

™

Chemistry

Two-Step Acrylic

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

Two-Part Epoxy

One-Part Epoxy

Color

Amber

White

Off-White

Black

Grey

Light Grey

Viscosity (cP)

100,000

350,000

16,000

5,000

Paste

40,000

Mix Ratio

N/A

2.5:1

2:1

2:1

1:1

N/A

Work Life (minutes)

N/A

25

45

50

90

N/A

Fixture Time (minutes)

3

210

180

300

>360

N/A

Cure Time (hours)

24

24

24

24

24

1 @ 250ºF (121ºC)

Shear Strength

1

 (psi)

3,000

1,750

3

4,030

2,500

2

2,300

3

3,000

3

Temperature Resistance

400ºF (204ºC)

350ºF (177ºC)

350ºF (177ºC)

350ºF (177ºC)

 >180°F (82°C)

 >300°F (148°C)

Loctite

®

 332

™



Structural Adhesive
Severe Environment

An activator-cured, no-mix

adhesive that provides high

temperature capability with

thermal durability up to

400°F (204°C). Use with Loctite

®



7387

™

 Depend

®

 Activator.

P/N

Package Size

33201  25 ml syringe
33275  300 ml cartridge
33290  1 liter bottle

Loctite

®

 1C

™

 Hysol

®



Epoxy Adhesive
Gap Filling

A high viscosity paste with a

25-minute work life. Excellent

gap-filling capability and

performance properties.

P/N

Package Size

83200  EPK 4 oz. kit
83202  4 lb. kit
83201  17 lb. kit
83206*  60 lb. pail, resin
83183*  43 lb. pail, hardener

Loctite

®

 E-40HT

™

 Hysol

®



Epoxy Adhesive
High Temperature

A two-component toughened

adhesive, which combines

high peel strength at room

temperature with tensile lap

shear strength at elevated

temperatures. An off-white

paste exhibiting exceptional high

temperature performance.

P/N

  Package Size

1086065  50 ml dual syringe
1086081  400 ml dual cartridge

Loctite

®

 E-50CR

™

 Hysol

®



Epoxy Adhesive
Chemically Resistant

A flowable, two-component,

extended room temperature curing

epoxy with excellent chemical

resistance properties. Black,

50-minute work life.

P/N

  Package Size

1079594  50 ml dual syringe
1079593  400 ml dual cartridge

Loctite

®

 9340

™

 Hysol

®



Epoxy Adhesive
Environmental Resistance

A grey, high viscosity epoxy with

a 90-minute work life. Excellent

high temperature and chemical

resistance.

P/N

Package Size

83104  EPK 2.7 oz. kit
83105  5 lb. kit

Loctite

®

 9459

™

 Hysol

®



Epoxy Adhesive
High Temperature Resistance

A one-component, heat cure epoxy.

Low viscosity, self-leveling. Light

grey, excellent high temperature

performance, excellent chemical

resistance.

P/N

Package Size

83126  10 lb. can

Loctite

®

 Structural Adhesives for plastic, composite and

polyolefin surfaces are capable of bonding a variety of materials,
including fiberglass, gel coat, thermoplastics, polycarbonate,
ABS, PVC, polyethylene and polypropylene. They have been
specially formulated to provide UV resistance, high impact
resistance and peel resistance.

Loctite

®

 Structural Adhesives for plastic, composite and

polyolefin materials are available with a variety of benefits,
including the following:



  •  Non-sag



  •  High temperature resistance



  •  Flexible bond strengths



  •  Toughened bond strengths to polyolefins



  •   Fast fixture time



  •  Substrate failure on many composite materials



  •  Varying cure times

Plastic / Composite /

Polyolefin Bonding

24

7

th

 Law of

Structural Engagement

Less is more.

Assemblies bonded with adhesives
often provide higher bond strength
versus those assembled with mechanical
fasteners. However, some manufacturers
cannot completely eliminate the use of
mechanical fasteners, sometimes due to
fast processing speed requirements and
the cure time needed for adhesives.
In these cases, manufacturers are able
to significantly reduce the number
of mechanical fasteners by using just
enough to help “fixture” the part during
assembly while the adhesive cures.
The adhesive still absorbs the brunt
of the force once cured, but allows the
manufacturer to reduce the number of
fasteners, thus reducing material costs.

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

THE IMMUTABLE LAWS OF

STRUCTURAL

ENGAGEMENT

We’re Writing the Law

We’re Writing the Law

www.henkelna.com/loctitestructurals

25

?

Loctite

®

 E-910

™



low cure

temperature

makes it ideal

for bonding

most plastics.

A Clue From Prof. McGlue

26

* Made to Order Item

1

Steel

2

Aluminum

3

Abraded Aluminum

4

Etched Aluminum

5

Block Shear Grit Blasted Steel

High Toughness

High Toughness

Fast Room Temperature Fixture

Medium Room Temperature Fixture

Extended Room

Temperature

Fixture

Heat Cure

Ultra-Fast Fixture

Impact Resistant

Non-Sag

UV Resistant

Impact Resistant

High Temperature /

Chemical Resistant

Fluorescent

Carbon Fiber

Composite Bonder

Low Cure

Temperature

TOP CHOICE

TOP CHOICE

H4100

™

H4200

™

H4000

™

H6051

™

H4800

™

E-120HP

™

3982

™

E-119HP

™

NEW

E-910

™

Chemistry

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Acrylic

Two-Part Epoxy

One-Part Epoxy

One-Part Epoxy

One-Part Epoxy

Color

Pale Yellow

Pale Yellow

Pale Yellow

White

Light Yellow

Amber

Off-White

Beige

Green

Viscosity (cP)

100,000

90,000

130,000

100,000

50,000

30,000

8,000

Thixotropic

40,000

Mix Ratio

10 : 1

10 : 1

10 : 1

10 : 1

10 : 1

2 : 1

N/A

N/A

N/A

Work Life (minutes)

2

5

8

35

25

120

N/A

N/A

N/A

Fixture Time (minutes)

5

15

14

50

35

180

N/A

N/A

N/A

Cure Time (hours)

24

24

24

24

24

24

30 min.

 @

257ºF (125ºC)

30 min.

 @

252ºF (122ºC)

1 @ 176°F

(80°C)

Shear Strength

1

 (psi)

3,140

4,020

3,500

2,400

3,930

4,300

5,830

5

4,930

3

2,000

2

Impact Strength

1

 (kJ/m

2

)

8

>42

20

–

>42

–

–

—

–

Peel Strength

2

 (pli)

13

55

45

35

4

50

20 to 50

–

—

–

Loctite

®

 H4100

™



Speedbonder

™



Structural Adhesive
Ultra-Fast Fixture

A non-sagging, two-component

methacrylate adhesive ideal

for bonding PVC, polycarbonate,

acrylic, ABS and FRP. Ultra-fast

adhesive develops handling

strength in 3 to 5 minutes. Forms

resilient bonds and maintains its

strength over a wide range of

temperatures.

P/N

Package Size

83032  490 ml dual cartridge

Loctite

®

 H4200

™

 Speedbonder

™



Structural Adhesive
Toughened

A plastic and composite bonder

with high peel and impact

resistance. Fixtures in 15 minutes.

P/N

Package Size

83038  490 ml dual cartridge

Loctite

®

 H4000

™

 Speedbonder

™



Structural Adhesive
Non-Sag

A medium fixturing structural

adhesive for bonding various

plastic and composite substrates,

including epoxy coat and glass

fiber reinforced polyester.

P/N

Package Size

83025  490 dual cartridge

Loctite

®

 H6051

™



Speedbonder

™



Structural Adhesive
UV Resistant

A white UV resistant

adhesive ideal for bonding

gel-coated surfaces.

Excellent non-sagging

properties.

P/N

Package Size

83062*  490 dual cartridge
83065*  38 lb. pail, adhesive
83063*  60 lb. pail, activator

Loctite

®

 H4800

™



Speedbonder

™



Structural Adhesive
Toughened

Excellent peel and impact

resistance. Provides

high bond strengths on

composites.

P/N

  Package Size

83045    490 ml dual cartridge
83047*    40 lb. pail, adhesive
83046*    36 lb. pail, activator

Loctite

®

 E-120HP

™

 Hysol

®



Epoxy Adhesive
Ultra Strength

An amber, non-sag,

aerospace grade epoxy

with an extended open

time to allow for the

adjustment of large parts.

P/N

Package Size

29353  50 ml dual cartridge
29354  200 ml dual cartridge
29355  400 ml dual cartridge
29356*  5 gallon pail, resin
29357*  5 gallon pail, hardener

Loctite

®

 3982

™

 Hysol

®



Epoxy Adhesive
High Performance /

Various Substrates

Highly fluorescent,

one-component, heat

cure epoxy adhesive

offering superior physical,

environmental and

performance properties.

P/N

Package Size

36767  30 ml syringe

Loctite

®

 E-119HP

™

 Hysol

®



Epoxy Adhesive
Non-Wicking

One-component, heat-cure

epoxy adhesive exhibits very

low wicking during cure

when exposed to elevated

cure temperatures. A

thixotropic, non-sag, beige

paste that bonds extremely

well to carbon composite

and aluminum materials.

P/N

  Package Size

1078992  30 ml syringe
1080008*  300 ml cartridge

Loctite

®

 E-910

™

 Epoxy

Adhesive

(formerly National Adhesives
EccoBond

®

 910-22)

Low Cure Temperature

One-component, heat-cure

epoxy can be cured at low

temperatures, making it

ideal for bonding most

plastics.

P/N

  Package Size

1215342  5 gallon pail

Your Application

Plastic / Composite /

Polyolefin Bonding

Product Description

Solution
