CERAMIC CAPACITORS KIT

GENERAL PURPOSE: C SERIES

KIT DATASHEET

(800) 950-8365

venkel.com

Email:

sales@venkel.com

   |



Phone:

512.794.0081

   |



Toll Free:

800.950.8365

   |



Web:

www.venkel.com

1

Part Number Structure

Hi-CAPC0GKIT   - 25



          Qty per value



        25



        50



        100

All values and sizes listed above are in this kit.

High Value COG Kit

Values in this Kit

Features:

•  Capacitance range: 330pF to 0.10uF
•  Suitable for Polyester Film Capacitor replacements
•  All Caps are C0G Dielectric
•  Sizes: 0402 to 1206
•  Composed of our Standard Ceramic Capacitors (C Series)

Size

Value

Voltage

Tolerance

0402

330pF

50V

±5%

470pF

50V

±5%

560pF

50V

±5%

680pF

50V

±5%

820pF

50V

±5%

1000pF

50V

5%

0603

1500pF

50V

±5%

1800pF

50V

±5%

2200pF

50V

±5%

2700pF

50V

±5%

0.01uF

25V

±5%

0805

3900pF

50V

±5%

4700pF

50V

±5%

5600pF

50V

±5%

8200pF

50V

±5%

0.01uF

50V

±5%

0.022uF

50V

±5%

1206

0.018uF

50V

±5%

0.022uF

50V

±5%

0.027uF

50V

±5%

0.033uF

50V

±5%

0.047uF

50V

±5%

0.056uF

50V

±5%

0.068uF

50V

±5%

0.082uF

50V

±5%

0.10uF

25V

±5%
