Rev. No.

B

Revision Note

Web Site 2001

Date

1-2-01

Signature

RG

PART NUMBER

Comus Group of Companies

PRODUCT DATA SHEET

MOVEMENT / VIBRATION SENSOR - Mercury Contacts

CM1344-0

FORM AE043 ISS1

As part of the company policy of continued product improvement, specifications may change without notice. Our sales
office will be pleased to help you with the latest information on this product range and details of our full design and
manufacturing service. All products are supplied to our standard conditions of sale otherwise agreed in writing.

©2001 Copyright Comus Group of Companies

The Comus Group of Companies
consist of:
Assemtech Europe Limited
E. Bachem GmbH
Comus International
W. Gunther GmbH
Gunther Belgium
Gunther France
S.T.G.

SPECIFICATION

Drawings not to scale
All dimensions in mm (inches)

5.46 (.214)

Contact Style

Switching Voltage

Switching Current

Switching Capacity

Contact Resistance

Operating Temperature

Storage Temperature

Case Material

Cable / Termination

See above

120

0.25

-

5

-37 to +100

-40 +125

Steel/tin plated

Pin

Max Vac

Max A

Max. VA

Max.

Ω

Deg

°

C

Deg

°

C

When stationary in any position the contacts
are open. Upon vibration or movement the
contacts will intermittently close.

0.51 (.020)

15.75 (.620)

5.08 (.200)

4.7 (.185)

CONTACT FORM / STYLE

Switch open in

all positions

CM1344 switch is non-position  sensitive.
