Rev. No.

D

Revision Note

Web Site 2001

Date

1-2-01

Signature

RG

PART NUMBER

SPECIFICATION

Comus Group of Companies

PRODUCT DATA SHEET

CONTACT FORM/STYLE

SWITCHING VOLTAGE

SWITCHING CURRENT

SWITCHING CAPACITY

CONTACT RESISTANCE

OPERATING TEMPERATURE

STORAGE TEMPERATURE

CASE MATERIAL

CABLE/TERMINATION

FEATURES

Max. Vac

Max. A

Max. VA

Max.

Ω

Deg. ˚C

Deg. ˚C

See above

60

0.1

3

30

-37˚ + 100˚

-40˚ + 125˚

Steel-tin plated

Pin

Compact Mercury Free

MOVEMENT / VIBRATION SWITCH

Non Mercury Contacts

CW 1600-3

Drawings not to scale
All dimensions in mm (inches) nominal

FORM AE043 ISS1

As part of the company policy of continued product improvement, specifications may change without notice. Our sales
office will be pleased to help you with the latest information on this product range and details of our full design and
manufacturing service. All products are supplied to our standard conditions of sale otherwise agreed in writing.

©2001 Copyright Comus Group of Companies

8.7

(.343)

3.6ø (.141)

Pin 0.5ø (.020)

5.60

(.220)

Max.

5.6

(.220)

The Comus Group of Companies
consist of:
Assemtech Europe Limited
E. Bachem GmbH
Comus International
W. Gunther GmbH
Gunther Belgium
Gunther France
S.T.G.

Contact Form/Style: Switch types CW1600 may have
a normally open or closed contact depending on the
positioning of the switch. These switches have a
change in sensitivity depending on the switch posi-
tion.

NOTE: When cutting or bending switch leads it is important that the glass seal is not damaged. The cutting or bending point
should be no closer than 3mm to the glass to metal seal and the lead should be supported between the cutting or bending point
and the glass to metal seal.

CONTACT FORM / STYLE

Centre pin up

Contacts Open

Centre pin down

contacts Closed

Sensitive

position

Sensitive

position
