USTF 6030Series

Size:

  2.36 in sq. x 1.18 in. thk

(60mm sq. x 30mm thk.)

Airflow:

 11 CFM

Acoustical Noise:

  29 dB (A)

USTF6030 Series AC / Ball Bearing Fans

MATERIAL:

Frame - Aluminum Alloy, Painted Black Finish
Bearings - Sealed Ball
Impeller - UL94V-0 Plastic

WEIGHT:

5.0 oz. (140g)

TERMINATION:

Lead wires standard

OPERATION TEMPERATURE:

-40

0

 to +70

0

C

INSULATION RESISTANCE:

100,000 Ohms min @ 500 VDC

DIELECTRIC STRENGTH:

500 VAC for 1 min.

INSULATION:

Class A

SAFTEY:

Impedance Protected

SAFTEY APPROVALS:

UL No. E1065227, CSA No.
073720, VDE No. 16599

ROT

A

TION

.017 DIA
8HOLES
(4-

0

4.3)

2.36 +/- 0.02 (60 +/-0.5)

1.97 +/- 0.01 (50 +/- 0.3)

0.14
(3.5)

AIR

0.14

(3.5)

SPECIFICATIONS:

(Based on 60 Hz Frequency)

NOTE: Standard models with Terminals. Lead Wires available on request.

Airflow - CFM

Static Pressure - In. of W

ater

1.18 +/- 0.02
(30 +/- 0.5)

0

2

4

6

8

10

12

.02

.04

.06

.08

.10

.12

.14

.16

PERFORMANCE CURVES:

 (Obtained with test chamber and methods in accordance with AMCA Std. 210-74)

Inches
(mm)

11.8 +/- .79
(300 +/- 20)

LEADWIRE
#22 AWG per UL 3266

0.79
(20)

.39 +/- .04
(10 +/- 1)

14

16

11

R

E

B

M

U

N

T

R
