STS1

Temperature sensor

Applications

- Household appliances
- Electronics
- Engineering
- Automotive

Benefits

- Temperatures from -40°C up to +170°C
- Excellent long-term temperature stability
- High precision and reliability
- No reversal polarity (+/-) possible

Replacement

for

KTY84

Tel:   +49 (0)7231 787-0
Fax :  +49 (0)7231 787-155
info@microtherm.de
www.microtherm.de

Microtherm GmbH

Taeschenwaldstrasse 3
D-75181 Pforzheim

or

PO Box 1208
D-75112 Pforzheim

05.2016/HB   Technical subject to change without notice

technical data

ordering example

STS1 1000  3    L360  500 G918



Housing number



                                  Length of leads (+/- 10 mm)
                         Leads white, AWG24, ETFE
                Tolerance (%)
        R at 100°C
Type of sensor



type

ratings

STS1

typ. resistance at 100°C (+-3%)

1000

Ω

operating temperature range

-40°C ... +170 (190)°C

min. insulation resistance (100 Vdc)

100 M

Ω

operating current

1 mA

max. rated power

10 mW

standard types

type

execution

illustration

drawing

dimensions (mm)

technical

description

STS1 G918

housing PPS

leads ETFE, AWG24, white

STS1 U129

shrink sleeve Kynar

®

leads ETFE, AWG24, white

temperature vs. resistance

Remark:

Values of electric resistance correspond almost exactly to KTY84.

               Above 170°C the sensor may loose its linearity.

RoHS

compliant

product

T°C

-10

0

10

20

30

40

50

60

70

80

90

100

110

120

130

140

150

160

170

min.

411

454

495

536

578

620

668

720

776

836

902

970

1036

1105

1171

1234

1296

1354

1406

typ.

433

477

520

561

603

647

695

747

804

866

931

1000

1071

1142

1213

1282

1348

1410

1467

max.

455

500

544

586

628

674

722

774

832

895

961

1030

1105

1180

1255

1330

1400

1466

1529

0

500

1000

1500

2000

R [

Ω

]

T [°C]
