HOOK-UP WIRE PRODUCT/APPLICATION INFORMATION

AUTOMOTIVE WIRE (WA SERIES) – 80



GAUGES:

18-16-14-12-10

VOLTAGE RATING:

120 Volts

INSULATION:

P.V.C

COLORS:

Black, Brown, Red, Orange, Yellow, Green, Blue, Violet, Gray, White

PACKAGES:

10, 15, 20, 30 & 40 Feet

SPOOLS:

100 Feet

18 is 16 strand, 16/14/12/10 is 19 strand

Bare copper conductor

APPLICATIONS:



Used in all automotive and truck applications



J1128 industry certification

PTFE (WT SERIES) – 200



GAUGES:

26-24-22-20-18

VOLTAGE RATING:

600 Volts

COLORS:

Black, Brown, Red, Orange, Yellow, Green, Blue, Violet, Gray, White

SPOOLS:

25 and 100 feet

Silver plated copper conductor: 26/24 is 7 strand, 22/20/18 is 19 strand

PTFE insulation

Resistance to oils, alkalies, acids, flame and moisture

Meets Mil 16878/4 and Mil 22759/11 specs

APPLICATIONS:



All hi-temp or hi-rel applications



Used in critical, high performance; military; commercial; racing

300V SOLID WIRE (WHS SERIES) – 90



GAUGES:

26-24-22-20-18

INSULATION:

P.V.C

COLORS:

Black, Brown, Red, Orange, Yellow, Green, Blue, Violet, Gray, White

SPOOLS:

25 and 100 feet

Tined plated copper conductor

Insulation thickness = 1/64”

UL Style 1007

CSA TR-64/1569

2 of 5

Passes UL VW-1.S vertical flame test

OSHA acceptable

APPLICATIONS:



Internal wiring of electrical and electronic equipment



Internal wiring of panels, meters, computers, business machines, appliances & control panels



Point to point wiring where 300V required

300V STRANDED WIRE (WH SERIES) – 90



GAUGES:

26-24-22-20-18

INSULATION:

P.V.C

COLORS:

Black, Brown, Red, Orange, Yellow, Green, Blue, Violet, Gray, White

SPOOLS:

25 and 100 feet

Tinned plated copper conductor: 22/24/26 is 7 strand, 20 is 10 strand, 18 is 16 strand

Insulation thickness = 1/64”

UL Style 1007

CSA TR-64/1569

Passes UL VW-1.S vertical flame test

OSHA acceptable

APPLICATIONS:



Internal wiring of electrical and electronic equipment



Internal wiring of panels, meters, computers, business machines, appliances & control panels



Point to point wiring where 300V required



6 Amp

600V STRANDED WIRE (WH6 SERIES) – 105



GAUGES:

18-16-14-12-10

INSULATION:

P.V.C

COLORS:

Black, Brown, Red, Orange, Yellow, Green, Blue, Violet, Gray, White

SPOOLS:

25 and 100 feet

Tinned plated copper conductor:

18 is 16 strand, 16 is 26 strand, 14 is 41 strand, 12 is 65 strand, 10 is 105 strand

UL Style 1015

CSA type TEW

Insulation thickness = 1/32”

UL VW-1.S Vertical Flame Test

OSHA acceptable

APPLICATIONS:



Internal wiring of electrical, electronic equipment and machinery



Internal wiring of panels and meters



Point to point wiring where 600V required



15 Amp max.

3 of 5

SPEAKER WIRE (CLEAR)

GAUGES:

22/2-20/2-18/2-16/2-14/2-12/2-10/2

INSULATION:

P.V.C

SPOOLS:

25 and 100 feet

OSHA acceptable

Type CL2 (16/2, 25’ spool

ONLY

)

Rated for 50V Max. (300V Max for 16/2, 25’ spool

ONLY

)

APPLICATIONS:



Lamps, radios, jukeboxes, HiFi & stereo

SPEAKER WIRE (CLEAR) HIGH PERFORMANCE

GAUGES:

18/2-16/2-14/2-12/2-10/2

INSULATION:

P.V.C

SPOOLS:

25 and 100 feet

Oxygen-free copper

Low capacitance, resistance, and inductance

OSHA acceptable

Rated for 50V Max.

APPLICATIONS:



High end audio, home theater

BLACK/RED BONDED SPEAKER WIRE

GAUGES:

18/2-16/2-14/2-12/2-10/2

INSULATION:

P.V.C

SPOOLS:

25 and 100 feet

Easy identification

OSHA acceptable

Rated for 50V Max.

APPLICATIONS:



Stereos, lamps, automotive, truck

MAGNET WIRE (WM SERIES)

GAUGES:

36-34-32-30-28-26-24-22-20-18

COATING:

Polyurethane/Polyamide(Nylon)

SPOOLS:

½ lb.

Solid bare copper conductor

4 of 5

(PE) Plain Enamel

Solderable: 18-24 AWG at 430



C /

26-36 AWG at 360



MIL JW-1177/9, MW28-C, Class 130 & MIL JW-1177/42, MW80-C, Class 155

RoHS Compliant

APPLICATIONS:



Coils, transformers, inductors, motors, headphones, loudspeakers, potentiometers, electromagnets

TEST LEAD WIRE (WTL Series)

GAUGES:

18 AWG (65 x 36) Tin Copper Wire

INSULATION:

EPDM Rubber (-30



to +90



SPOOLS:

100 feet

OSHA acceptable

Insulation thickness = 0.047”

Working voltage = 5000V

Breakdown voltage = 20000V

Resists oils, acids, alkalies, ozone and solvents

APPLICATIONS:



Flexible test probes



High voltage apparatus

300V MULTI-CONDUCTOR CABLE (WMC Series)

GAUGES:

18-22

INSULATION:

(PE) Polyethylene color coded (Shielded)

INSULATION:

Color coded plastic (PVC) (Unshielded)

SHIELD (where applicable):

Mylar aluminum foil plus stranded tinned copper drain wire

SHIELD (where applicable):

100% shielded coverage with 25% overlap on Mylar/aluminum foil shield

JACKET:

Chrome gray PVC

TEMPERATURE:

-20



to +75



SPOOLS:

100 feet

OSHA acceptable

UL approved

RoHS compliant

Working voltage = 300V

Tinned copper conductor provides excellent corrosive resistance

Also greatly improves soldering connections

Ease of termination handling due to extra-flexible stranding

APPLICATIONS:



Public address systems



Intercom systems



Remote control circuits



Actuator controls (Shielded ONLY)



Broadcast (Shielded ONLY)



Audio (Shielded ONLY)
