110
Molded Chokes
ADMC Series
Axial Leaded Thru Hole
ADMC
FEATURES
• Low cost.
• High Q and SRF, Low RDC.
• Permanent Color Band.
STANDARD SPECIFICATIONS
COLOR CODE
FIRST
SECOND
MULTIPLIER
INDUCTANCE
SIGNIFICANT
SIGNIFICANT
TOLERANCE
FIGURE
FIGURE
(%)
Black
0
0
1
-
Brown
1
1
10
-
Red
2
2
100
-
Orange
3
3
1000
-
Yellow
4
4
-
-
Green
5
5
-
-
Blue
6
6
-
-
Violet
7
7
-
-
Gray
8
8
-
-
White
9
9
-
-
Black (M)
-
-
-
±20
Gold (J)
-
-
0.1
±5
Silver (K)
-
-
0.01
±10
ADMC -
❑ ❑ ❑ ❑
-
❑ ❑ ❑
❑
-
❑
PACKAGE TYPE
ADMC: MOLDED CHOKE
SIZE
INDUCTANCE:
OPTIONS
B Bulk
TA
Tapping with Ammo Box
T
TAPE & REEL
INDUCTANCE TOLERANCE:
M ±20%
K ±10%
J ±5%
PART NUMBERING GUIDE
INDUCTANCE VALUES ARE INDICATED WITH COLOR CODE AS SHOWN BELOW.
FIRST SILVER COLOR CODE MEANS AMERICAN MILITARY SPECIFICATION TYPE.
ADMC SERIES
O
INDUCT
ORS
111
Molded Chokes
ADMC Series — Continued
XTAL
OSC
VCXO
VCO
TCXO
VCTCXO
FLTR
RES
IND
Axial Leaded Thru Hole
ADMC SERIES
STANDARD SPECIFICATIONS
PACKAGE TYPE
Ø A (mm)
B (mm)
C (mm)
Ø D (mm)
ADMC-4812
4.83 ±0.25
11.18 ±0.25
25.91 (min.)
0.635 ±0.05
ADMC-2434
2.41 ±0.25
3.35 ±0.25
25.91 (min.)
0.500 ±0.05
ADMC-4095
3.96 ±0.25
9.53 ±0.25
25.91 (min.)
0.600 ±0.05
ADMC-6515
6.50 ±0.10
14.50 ±0.25
25.91 (min.)
0.800 ±0.05
ADMC-2051
1.98 ±0.25
5.08 ±0.25
25.91 (min.)
0.410 ±0.05
ADMC-4110
4.11 ±0.25
10.41 ±0.25
25.91 (min.)
0.600 ±0.05
INDUCTANCE & RATED CURRENT RANGES
PACKAGE TYPE
INDUCTANCE
RATED CURRENT
ADMC-4812
0.15
1000 uH
3050
78 mA (max.)
ADMC-2434
0.10
1000 uH
1380
28 mA (max.)
ADMC-4095
0.15
1000 uH
2740
82 mA (max.)
ADMC-6515
0.10
1000 uH
1900
80 mA (max.)
ADMC-2051
0.10
270 uH
895
39 mA (max.)
ADMC-4110
0.10
10000 uH
1790
24 mA (max.)
ADMC
O
INDUCT
ORS
113
XTAL
OSC
VCXO
VCO
TCXO
VCTCXO
FLTR
RES
IND
Molded Chokes
ADMC-4812 Series — Continued
Axial Leaded Thru Hole
STANDARD SPECIFICATIONS
ORDERING CODE
INDUCTANCE
Q
FREQUENCY
SELF-RESONANT
RDC
IDC
(L)
min.
(MHz)
FREQUENCY (MHz)
(
Ω
)
(mA)
min.
max.
max.
ADMC-4812-560
❑❑
56.00 uH
45
2.5
14
4.100
225
ADMC-4812-620
❑❑
62.00 uH
45
2.5
12
4.200
220
ADMC-4812-680
❑❑
68.00 uH
45
2.5
11
4.200
220
ADMC-4812-750
❑❑
75.00 uH
45
2.5
10
4.200
220
ADMC-4812-820
❑❑
82.00 uH
45
2.5
9.3
4.400
215
ADMC-4812-910
❑❑
91.00 uH
45
2.5
9.1
4.700
210
ADMC-4812-101
❑❑
100.00 uH
45
2.5
8.5
4.900
205
ADMC-4812-111
❑❑
110.00 uH
60
0.79
7.5
5.100
200
ADMC-4812-121
❑❑
120.00 uH
60
0.79
7.3
5.400
195
ADMC-4812-131
❑❑
130.00 uH
60
0.79
.5
5.700
190
ADMC-4812-151
❑❑
150.00 uH
60
0.79
6.2
6.200
180
ADMC-4812-161
❑❑
160.00 uH
60
0.79
6.0
6.600
175
ADMC-4812-181
❑❑
180.00 uH
60
0.79
5.7
7.100
170
ADMC-4812-201
❑❑
200.00 uH
60
0.79
5.5
7.500
165
ADMC-4812-221
❑❑
220.00 uH
60
0.79
5.2
7.900
160
ADMC-4812-241
❑❑
240.00 uH
60
0.79
5.0
8.300
155
ADMC-4812-271
❑❑
270.00 uH
65
0.79
5.6
8.200
110
ADMC-4812-301
❑❑
300.00 uH
65
0.79
5.3
8.700
107
ADMC-4812-331
❑❑
330.00 uH
65
0.79
5.0
9.100
105
ADMC-4812-361
❑❑
360.00 uH
65
0.79
4.7
9.600
102
ADMC-4812-391
❑❑
390.00 uH
65
0.79
4.5
10.000
100
ADMC-4812-431
❑❑
430.00 uH
65
0.79
4.3
10.600
97
ADMC-4812-471
❑❑
470.00 uH
65
0.79
4.0
11.100
95
ADMC-4812-501
❑❑
500.00 uH
65
0.79
3.9
11.400
94
ADMC-4812-511
❑❑
510.00 uH
65
0.79
3.8
11.600
93
ADMC-4812-561
❑❑
560.00 uH
65
0.79
3.6
12.300
91
ADMC-4812-621
❑❑
620.00 uH
60
0.79
3.5
13.000
88
ADMC-4812-681
❑❑
680.00 uH
60
0.79
3.4
13.700
85
ADMC-4812-751
❑❑
750.00 uH
60
0.79
3.3
14.400
83
ADMC-4812-821
❑❑
820.00 uH
60
0.79
3.1
15.100
81
ADMC-4812-911
❑❑
910.00 uH
60
0.79
2.9
15.800
79
ADMC-4812-102
❑❑
1.00 mH
60
0.79
2.8
16.500
78
