PART NUMBERING GUIDE
FEATURES
• Wide band choke has a higher impedance character-
istic. It supplies several kinds of models for cus-
tomers’ requirement.
• Applications: Computer Products (Motherboards,
Printers, Monitors, Power Suppliers, etc.),
Communication Products (Telephone Switchboards,
etc.), Modems, OA Products, etc., Counter measures
for complying with CE, FCC VDE or VCCI radiated
emissions.
ADWBCA Series
Wide Band Chokes
Axial Leaded Thru Hole
ADWBCA
PACKAGE TYPE
PACKAGE TYPE
Ø A (mm)
B (mm)
C (mm)
Ø D (mm)
R6H 6x10
6.0 ±0.25
10.0 ±0.30
0.9 ±0.15
0.5 ±0.05
