ADO32/45

www.adivatech.com

(888) 30-ADIVA (23482)

O

144

Power Inductors

ADO32 and ADO45

Surface Mount

STANDARD SPECIFICATIONS

PACKAGE TYPE

Dimension (mm)

(A)

(B)

(C)

ADO-32

3.2 ±0.30

2.5 ±0.20

2.3 MAX

ADO-45

4.7 ±0.30

3.2 ±0.20

2.9 MAX

PACKAGE DATA

SIZE

ADO32

ADO45

Quantity / Reel

1,500

500

FEATURES

• High Q-value at high frequencies
• Low DC resistance permits high

current flow

• Excellent solder heat resistance

• Both flow and reflow soldering resistance

methods can be employed

• Applications: MP3 or walkman equipment,

communications, and audio equipment

ADO -

45 -

101 -

❑

PRODUCT TYPE
SIZE

TOLERANCE

K = ±10%
M = ±20%

INDUCTANCE

PART NUMBERING GUIDE

O

INDUCT

ORS

145

Power Inductors

ADO32 and ADO45 — Continued

XTAL

OSC

VCXO

VCO

TCXO

VCTCXO

FLTR

RES

IND

Surface Mount

STANDARD SPECIFICATIONS

Part

Inductance

Q

Frequency

ADO32

Q

Frequency

ADO45

CORD

(*H)

Hz

DCR (*)

IDC (mA)

Hz

DCR (*)

IDC (mA)

1R0

1

20

1M

0.5

445

35

1M

1R4

1.4

20

1M

0.6

425

35

1M

1R8

1.8

20

1M

0.6

400

35

1M

2R2

2.2

20

1M

0.7

390

35

1M

2R7

2.7

20

1M

0.8

370

35

1M

3R3

3.3

20

1M

0.9

320

35

1M

3R9

3.9

20

1M

1.1

300

35

1M

4R7

4.7

20

1M

1.2

290

35

1M

5R6

5.6

20

1M

1.3

270

35

1M

6R8

6.8

20

1M

1.5

250

35

1M

8R2

8.2

20

1M

1.6

240

35

1M

100

10

35

796K

1.8

225

40

796K

0.56

400

120

12

35

796K

2

190

40

796K

0.62

380

150

15

35

796K

2.2

180

40

796K

0.73

360

180

18

35

796K

2.5

170

40

796K

0.82

340

220

22

35

796K

2.8

165

40

796K

0.94

320

270

27

35

796K

3.1

150

40

796K

1.1

300

330

33

40

796K

3.5

125

40

796K

1.2

270

390

39

40

796K

3.9

115

40

796K

1.4

240

470

47

40

796K

4.3

110

40

796K

1.5

220

560

56

40

796K

4.9

100

40

796K

1.7

200

680

68

40

796K

5.1

85

40

796K

1.9

180

820

82

40

796K

6.2

80

40

796K

2.2

170

101

100

40

796K

7

80

40

796K

2.5

160

121

120

40

796K

8

80

40

796K

3

150

151

150

40

796K

9.3

75

40

796K

3.7

130

181

180

40

796K

10.2

70

40

796K

4.5

120

221

220

40

796K

11.8

65

40

796K

5.4

110

271

270

40

796K

12.5

65

40

796K

6.8

100

331

330

40

796K

13

65

40

796K

8.2

95

391

390

40

796K

9.7

90

471

470

40

796K

11.8

80

561

560

40

796K

14.5

70

681

680

40

796K

17

65

821

820

40

796K

20.5

60

102

1000

40

252K

25

50

122

1200

40

252K

30

45

DCR & IDC is all MAX. value.Tolerance: K±20% K is standard.

Note:Testing inductance at 1M Hz, but ADO45-471 to ADO45-1222 are 1KHz.

Other specifications are available.
