O
18
Quartz
ADX Series
Thru Hole
ADXUM1 (UM-1)
pg19
ADX49 (HC49/U)
pg19
ADXUM5 (UM-5)
pg19
ADX49S (HC49/S)
pg20
±100ppm
A
±50ppm
B
±45ppm
C
±40ppm
D
±35ppm
E
±30ppm
F
±25ppm
G
±20ppm
H
±15ppm
I
±10ppm
J
±5ppm
K
Fundamental
F
3rd Overtone
3
5th Overtone
5
7th Overtone
7
9th Overtone
9
Third Lead
L
Insulator Tab
I
Tape & Reel
T
Vinyl Sleeving
V
Package Type
Frequency Tolerance
@ 25ºC
Frequency Stability
Over Temperature
Operating
Temperature Range
Operating Mode
Load Capacitance
Options
MHz
M
KHz
K
Frequency
0ºC to +70ºC
1
-10ºC to +60ºC
2
-20ºC to +70ºC
3
-40ºC to +75ºC
4
-40ºC to +85ºC
5
-40ºC to +90ºC
6
0ºC to +55ºC
7
-40ºC to +125ºC
8
±100 ppm
P
±50 ppm
Q
±45 ppm
R
±40 ppm
S
±35 ppm
T
±30 ppm
U
±25 ppm
V
±20 ppm
W
±15 ppm
X
±10 ppm
Y
±5 ppm
Z
6 pF
6
10 pF
10
12 pF
12
18 pF
18
20 pF
20
22 pF
22
30 pF
30
32 pF
32
50 pF
50
Series
S
PACKAGE TYPE
FREQUENCY
FREQUENCY TOLERANCE @ 25ºC
OPTIONS
LOAD CAPACITANCE
OPERATING MODE
OPERATING TEMPERATURE RANGE
FREQUENCY STABILITY
OVER TEMPERATURE
EXAMPLE
- H
12.5
T -
❑
K
PACKAGE TYPE
FREQUENCY TOLERANCE @ 25ºC
FREQUENCY
OPTIONS
LOAD CAPACITANCE
EXAMPLE
Load Capacitance
6 pF
6
7 pF
7
12.5 pF
12.5
ADX26T
pg21
ADX38T
pg22
ADX310
pg23
Package Type
±100ppm
A
±50ppm
B
±45ppm
C
±40ppm
D
±35ppm
E
±30ppm
F
±25ppm
G
±20ppm
H
±15ppm
I
±10ppm
J
±5ppm
K
Frequency Tolerance
@ 25ºC
Bulk
Blank
Insulator Tab
I
Tape & Reel
T
Options
MHz
M
KHz
K
Frequency
-
❑
M -
A
P
1
F
18
I
Cylindrical
