www.adivatech.com

(888) 30-ADIVA (23482)

O

64

STANDARD SPECIFICATIONS

IMPEDANCE

IMPEDANCE

SIZE

PACKAGE TYPE

(

Ω

)

(

Ω

)

LENGTH

WIDTH

THICKNESS

TERMINAL

at 25 MHz

at 100 MHz

(A) mm

(B) mm

(C) mm

(D) mm

ADSMB2-252030

20 ± 20%

30 ± 20%

3.0 ± 0.15

2.5 ± 0.1

2.0 ± 0.1

1.15 ± 0.15

ADSMB2-312640A

30 -0

47 ± 20%

4.0 ± 0.15

3.1 ± 0.1

2.6 ± 0.1

1.35 ± 0.20

ADSMB2

-312685A

60 -0

90 ± 20%

8.5 ± 0.15

3.1 ± 0.1

2.6 ± 0.1

2.00 ± 0.20

ADSMB2-312640B

30

30

4.0 ± 0.15

3.1 ± 0.1

2.6 ± 0.1

1.35 ± 0.20

ADSMB2

-312685B

60

60

8.5 ± 0.15

3.1 ± 0.1

2.6 ± 0.1

2.00 ± 0.20

Wound Chip Beads

ADSMB2 Series

Surface Mount

ADSMB2 -

252030

PACKAGE TYPE
SIZE

PART NUMBERING GUIDE

ADSMB2-312685A & ADSMB2-312640A

ADSMB2-312685B & ADSMB2-312640B

ELECTRICAL CHARACTERISTIC

TAPE DIMENSIONS

SIZE

QUANTITY/ REEL

ADSMB2-252030

1,000

ADSMB2-312640A

500

ADSMB2

-312685A

3,000

ADSMB2-312640B

500

ADSMB2

-312685B

3,000

FEATURES

• High resistance to heat and humidity
• Accurate dimensions for automatically mounted
• Applications: celllular phones, telecommunications systems,

wireless communications equipment, and computer products

100

10

1

1

10

100

1000

100

10

1

1

10

100

1000

ADSMB2
