Ametherm, Inc

. 3111 N. Deer Run Road #4 Carson City, NV 89701

Telephone: (800) 808-2434 (775) 884-2434 Fax: (775) 884-0670

www.ametherm.com



DATA SHEET

Part Number: SL32 4R023



Ordering Different Lead Types:



Inside Kinked Leads

Not available

Outside Kinked Leads  Use

–B

 after Ametherm’s Part #

For example: to order an outside kinked lead use part number SL32 4R023-

B
















Resistance @ 25

°

C

4.0

Ω

 ± 20%

Max Steady State Current Up to 65

°

C

23.0 A

Max Recommended Energy Rating

200.0 J

Actual Failure Point of Instantaneous Energy

448.0 J

Resistance @ 100 % of Maximum Current

0.020

Ω



Resistance @ 50% of Maximum Current

0.065

Ω



Body Temperature at Maximum Current

236

°

C

Dissipation Constant

65.4 mW/

°

C

Thermal Time Constant

208 seconds

Material Type

“G”

Maximum Capacitance @ 240/440 VAC

3400 µ

F/

1000

µ

F








D

30.0 ± 2.5 mm

T

6.35 ± 0.4 mm

Lead Diameter

1.3 ± 0.1 mm

S

7.8 ± 2.0 mm

L

38.0 ± 9.0 mm

Coating Run Down
Straight Leads

5.0 ± 1.0 mm

B

9.35 ± 0.85 mm

C

 3.82 ± 1.0 mm











Revision Date 3/16/2004

L



OUTSIDE

KINKED LEADS

S



STRAIGHT



LEADS



B



INSIDE

KINKED LEADS

S

S

D



D

D

C



T
