www.genteqcapacitors.com

AC Capacitors for

Motor Run Applications

AC Capacitors for

HID Lighting Applications

Product Range:

Capacitance: 2uF to 120uF
Tolerance:

-6%, +6%

Voltage:

240 to 660 VAC

Op. Temp:

-40°C to +70°C

Case:

Aluminum

Applications:

•

HVAC Equipment

•

Appliances

•

Office Equipment

Features:

•

Proven EIA-456 Compliant 60,000 Hour Reliability

•

Pressure Sensitive Interrupter (PSI)

Product Range:

Capacitance: 5uF to 60uF
Tolerance:

-3%, +3%

Voltage:

280 to 580 VAC

Op. Temp:

-40°C to +90°C
-40°C to +100°C

Case:

Aluminum

Applications:

•

Mercury Vapor

•

Metal Halide

•

High Pressure Sodium

Features:

•

Proven EIA-456 Compliant 60,000 Hour Reliability

•

Pressure Sensitive Interrupter (PSI)

www.genteqcapacitors.com

Dry Capacitors for

Motor Run Applications

Capacitors for AC and DC

General Purpose Applications

Product Range:

Capacitance: 2uF to 120uF
Tolerance:

-6%, +6%

Voltage:

240 to 660 VAC

Op. Temp:

-40°C to +70°C

Case:

Aluminum

Features:

•

Proven EIA-456 Compliant 60,000 Hour Reliability

•

Pressure Sensitive Interrupter (PSI)

Applications:

•

Electronic Power Conversion

•

Filtering

•

Power Supply

Product Range:

Capacitance: 1uF to 50uF
Tolerance:

-10%, +10%

Voltage:

120 to 370 VAC

Op. Temp:

-40°C to +70°C

Case:

Plastic

Features:

•

Proven EIA-456 Compliant 60,000 Hour Reliability

•

UL Recognized Construction

Applications:

•

HVAC Equipment

•

Appliances

•

Office Equipment

www.genteqcapacitors.com

Dry Capacitors for

HID Lighting Applications

Snubber, High Current DC,

and Switching Capacitors

Product Range:

Capacitance: 1uF to 50uF
Tolerance:

-3%, +3%

Voltage:

120 to 370 VAC

Op. Temp:

-40°C to +90°C

Case:

Plastic

Applications:

•

Mercury Vapor

•

Metal Halide

•

High Pressure Sodium

Features:

•

Proven EIA-456 Compliant 60,000 Hour Reliability

•

UL Recognized Construction

Product Range:

Capacitance: 0.01uF to 30uF
Tolerance:

±5%, ±10%

Voltage:

250 to 3,000 VAC

Op. Temp:

-40°C to +85°C
-55°C to +105°C

Case:

Potting Compound

Applications:

•

Input/Output Filters

•

Switch-Mode Power Supplies

•

Un-Interruptible Power Systems

Features:

•

Fire Retardant Tape

www.genteqcapacitors.com

Snap-In

Electrolytic Capacitors

Screw Terminal

Electrolytic Capacitors

Product Range:

Capacitance: 100uF to 100,000uF
Tolerance:

±20%

Voltage:

10 to 450 VAC

Op. Temp:

-40°C to +85°C
-40°C to +105°C

Case:

Aluminum

Features:

•

High-Gain Aluminum Foil

Applications:

•

Drives

•

Power Conditioning

•

Photoflash Lighting

Product Range:

Capacitance: 250uF to 230,000uF
Tolerance:

-10%, +50%

Voltage:

50 to 450 VAC

Op. Temp:

-40°C to +85°C
-55°C to +105°C

Case:

Aluminum

Features:

•

High-Gain Aluminum Foil and Reliable Safety Vent

Applications:

•

Drives

•

Power Conditioning

•

Photoflash Lighting

www.genteqcapacitors.com

Life-Line Capacitor Kit

for Motor Run Applications

Mounting Accessories for

Oil-Filled Capacitors

Included in Kit:

•

6 best in class Genteq Motor Run Capacitors

•

2 Life-Line “Spider” Devices

•

1 Capacitor Mounting Hardware Kit

•

1 Device Mounting Hardware Kit

•

1 Robust Carrying Case

Features:

•

UL Listed Life-Line “Spider” Device

•

Replace 48 Different Ratings (Over 85% of models)

•

Lowest Total Cost Replacement Solution

•

Solves Truck Inventory Hassles

Universal Wrap Around Brackets:

•

Oval Capacitors - 1.25”, 1.50”, 1.75”, or 2.00” base size

•

Round Capacitors – 1.75”, 2.00”, 2.50”, or 3.00” base size

Wrap Around Brackets:

•

Oval Capacitors - 1.25”, 1.50”, 1.75”, or 2.00” base size

•

Round Capacitors – 1.75”, 2.00”, or 2.50” base size

Footed Brackets:

•

Oval Capacitors - 2.12”, 2.88”, 3.88”, 4.75”, or 5.75” in height

•

Round Capacitors - 2.12”, 2.88”, 3.88”, 4.75”, or 5.75” in height
