6.2 Ton Lithium-Ion Dieless Hydraulic Crimper

Ilsco

TaskMaster

™

6 Ton Hydraulic Tool System

The innovative

TaskMaster Hydraulic Tool System

is a battery-powered hydraulic tool with three
interchangeable heads for three distinct operations—
it’s a 6-ton, 4-indent universal dieless crimper, cable
cutter, and knock-out punch tool.

Features

• Heavy duty steel crimp and cutter heads rotate 360°

• Ruggedly built high impact nylon inline tool body

• Automatic cycle and retract for continuous use

• 18 volt advanced lithium-ion battery

• Over molded rubber grip and large trigger

• LED diagnostics and work light

• Crimps 8 AWG to 750 kcmil copper and 8 AWG to

500 kcmil aluminum

• Cutter head features hardened steel alloy blades

• Cuts up to 750 kcmil copper/aluminum building wire

and up to 500 kcmil copper fine stranded wire

• Punch head provide precise, clean, quick holes

• Punch head kit includes punch head, 3/4" and 3/8" draw bolts,

long, medium, and short spacers, and 3/8" pilot bit

• 1/2" to 3-1/2" knock-out punch and cut dies sold separately

Part Number

TMT6

Crimp Head

Cutter Head

Punch Head Kit

Punch and cut dies

sold separately

System includes tool body, crimp
head, cutter head, punch head kit,
two batteries, charger, and impact
resistant molded carrying case

Uni-Die Dieless Hydraulic Crimping Tool

develops 6.2 tons

of force to crimp 4 AWG to 750 kcmil copper compression lugs
and splices, and crimps 25% faster than most comparable tools.
Includes two batteries, charger, shoulder strap, and tool bag.

Features

• Up to135% more crimps per charge than tools with NiCd or

NiMH batteries (up to 183 crimps with a Panduit 500 kcmil lug)

• Provides UL Listed and CSA Certified wire range-taking

capability with Panduit copper lugs and splices

• ~3.5 second crimp cycle time
• Ergonomically balanced and lightweight, only

11.75 lbs. with battery

• Aluminum alloy flip-top crimp head rotates 360°
• Audible “pop-off” valve indicates crimp completion
• 120 VAC (230 VAC model also available)

Part Number

CT-2980L

(907) 561-5955 Toll Free (888) 245-WIRE

CALL TO ORDER

The

Tri-Form Compression Crimper

distributes equal force on all three sides

of its unique dieless triangular crimp, eliminating pinching and fracturing and
producing a homogenous mass of copper. Crimps battery terminals,
connectors and heavy-duty lugs from 6 AWG through 4/0 AWG.

• Over 50 settings—two finger dial adjusts settings quickly and accurately

• Bench tool version has angle iron mounting brackets, good visibility

of crimp location, and provides added leverage

Correct Crimp

exerts 5 tons of force for fast, complete crimps. Its built-in

diamond shaped rotating dies quickly adjust to accommodate various terminals
and lugs. Produces a solid mass of copper every time, assuring a low-resistance
connection. Single screw adjustment provides for easy calibration to
compensate for die wear. Crimps battery terminals, lugs and connectors.
6 AWG to 250 MCM range.

Handheld 94285

includes a controlled cycle ratchet mechanism—

once a crimp is started, the tool will not release until the crimp cycle
is complete. Quick override lever for safety.

Ilsco

Tri-Form Compression Crimper

Ilsco

Correct Crimp Compound Crimper

Controlled Cycle

Handheld

(not pictured)

Part Number

94285

Length

25"

Weight

6.2 lbs

Same as 94284 with

controlled mechanism to

assure full closure of tool

Large Wire Gauge Handheld,

Bench, and Hammer Crimpers

Handheld

Part Number

CT-804

Length

25"

Weight

5 lbs

Bench Mount

Part Number

BT-904

Length

23"

Weight

6.2 lbs

Handheld

Part Number

94284

Length

25"

Weight

5.9 lbs

Bench Mount

Part Number

94284-BM

Length

20"

Weight

7.8 lbs

Pre-Measured Solder

17901

2 AWG

17902

1 AWG

17903

1/0

17904

2/0

17905

3/0

17906

4/0

Part Number

17999

Portable Butane Heat Tools

The

Shrink Jet

flameless heat

tool reaches temperatures up
to 1250°F. Ideal for indoor and
outdoor applications where open
flame is not recommended.

The

Micro-Jet

refillable open-flame

butane heat tool is ideal for installing
heat shrink tubing and connectors,
making solder terminations, and
many other applications.

Heat Shrink Torch

screws directly onto 14 oz. and 16 oz. propane bottles with

1" connector. Cast aluminum body with durable, long lasting, baked-on epoxy
finish, heavy-duty stainless steel burn tube. Push “ON” ignite button for instant starts.
Air intake vent combines gas and air to provide the optimum flame setting. Regulator
pressure for constant propane gas flow in any position. 1" wide brass burn-tip.

Pre-Measured Solder

pieces provide the correct

amount of solder for each wire gauge. Color coded
for easy cable size identification.

Solder-It

™

Low Temperature Solder Paste

Solder-It

™

Solder Paste

is easy to use—no skill required, no flux required.

Joins 22 different combinations of metal and is five times stronger than
ordinary solder. Finished joint is bright silver, and won’t tarnish or blacken.

• Low melting point of 430° F—works with the heat of a match or lighter

• Can also be used with soldering iron, open flame, butane, propane, acetylene, or MAPP gas

Part Number

Size

Part Number

94800

Part Number

94700

Part Number

HST-T1

Dual-temperature Heat Gun

is ideal for

heat shrink, melting adhesives, curing epoxy,
stripping paint and more. 1000°F (538°C)
and 600°F (315°C) heat settings.

The included nozzle accessories concentrate
the heat where needed. Molded case.

Pro’sKit

Heat Gun and Accessories

Part Number

SS-611A

Scraper for

Stripping Paint

Solder Service Kit

available on

page 82

Length: 5"

Weight: 3.2 oz

Length: 6"

Weight: 3.4 oz

17900

4 AWG

Reflector for

Heat Shrink

Heat Concentrating

Reducers

(907) 561-5955 Toll Free (888) 245-WIRE

Heat Tools and Solder

Iroda

Automatic Ignition Butane Torch

Iroda

Turbo-lite Butane Lighter and Torch

The elegant, multi-purpose

Turbo-Lite Micro-Torch/Lighter

is designed for

high style and function. Turbo-Lites are as useful as fully adjustable precision
1300°C (2400°F) torches as they are as reliable windproof lighters. Perfect as gifts
or compact additions to the tool or emergency kit.

• 1300°C/2400°F pinpoint flame

• Piezo lifetime waterproof ignition system

• Simple twist flame adjustment

• Protective flip-open cap

• Stylish see-through fuel tank

• Five attractive colors

• Refills from standard butane fuel available everywhere

Length: 2.25"

Weight: 1.69 oz.

The heavy duty

Pro-Torch™ Butane Torch

provides a powerful and stable butane flame

for demanding jobs where the highest BTU output is required. Precision orifice and controls.
The ergonomic grip makes using the PT-500 comfortable at most any angle.

• State of the art waterproof Piezo Electronic Ignition system

• Large fuel tank provides up to 200 minutes use on each filling

• Powerful high-output wind-resistant flame

• Sturdy heavy duty ribbed aluminum body with comfort grip

• Easily refilled with any brand of butane gas

• Flame adjustment for the most demanding applications

Length: 4.73"

Height: 6.9"

Weight: 10.6 oz.

Iroda

Cordless Refillable Butane Heat Gun

The

Ultra-Therm Cordless Heat Gun

is designed for industrial use where high volume flameless heat is required.

Its wide nozzle and high-output long life catalyst provide infinitely adjustable heat levels in a completely portable
tool. Safe to use underhood where vapors may be present. Included deflector attachments make even heavy-wall
shrink tubing a breeze to install. Use almost anywhere you would use a corded heat gun but without the cord!

• Instant-On Piezo Ignition with long life catalyst

• Rapid heat-up for immediate use

• High output element for demanding applications

• No cords to limit use

• Comfortable ergonomic grip

• Up to 120 minutes use on each fill

• Deflector circulates heat and protects nearby work

• Adjustable heat output

Part Number

PTB-500

Part Number

MT-500

Length: 7.5"

Weight: 4.8 oz.

Part Number

UT-500

Greenlee

Paladin

GripP 10 Stripper

Pressmaster

Embla 16 Stripper/ Cutter

The self-adjusting

Embla 16 Stripping and Cutting Tool

has the

widest stripping capacity of any tool of its type and integrated wire
cutting capability. Strong, durable, and comfortable ergonomic design.

• Tool-less interchangeable cassettes for wide, diverse stripping capacity
• Cutting capacity: Flexible wires, 8 AWG. Rigid wires, 16 AWG
• Fine adjustability for thin or thick insulation
• Blades open and remain open to facilitate easy and snag free wire removal
• Frame and mechanism life span exceeds 150,000 cycles (tested with 16 AWG PVC cable)

Part Number

EMBLA-16

Rotary Cable Stripper/Slitters

strip and slit round cable. Adjustable cutting depths. Swivel blade for circular,

longitudinal and spiral cuts. Cable-holding clip can also separate slit insulation.

Eclipse® Precision Wire Stripper

strips and cuts 10 AWG to 20 AWG wire.

Precision-crafted and ruggedly constructed of durable materials.
• Plier nose, cutter jaw, PVC handles, spring return
• Processed by CNC lathe for accurate size of notches
• Safety lock design for convenient storage

Eclipse

Precision Wire Stripper

Part Number

1821

Slits and strips round

cable from 1.0" to

1.4" in diameter

Greenlee Paladin Rotary Cable Stripper/Slitters

Part Number

200-009

Slits and strips round

cable from .18" up to

1.0" in diameter

Part Number

200-048

Slits and strips round

cable from 1.0" up to

1.4" in diameter

Eclipse Rotary Cable Stripper/Slitters

Spare blade in handle. Lifetime tool warranty.

Part Number

1820

Slits and strips round

cable from .18" to

1.0" in diameter

The

GripP Wire Strippe

r features an optimum 22º angle design to prevent awkward wrist bends. Strips most

common wire and cable, 22-10 AWG electrical wire, hook-up wire, multi-conductor cable and flat cable. Not for
use on steel or armored wire and cable. One-year warranty.

• Contoured wire stripping areas precision ground for accuracy
• Non-scoring strip and smooth wire cutting
• Features screw cutter and wire loops embedded in frames
• Gripping jaws on front of tool, spring-loaded closure

Part Number

1117

Part Number

200-010

(907) 561-5955 Toll Free (888) 245-WIRE

Cutting, Stripping, Slitting Tools

Eclipse

Economy Heavy Duty Cable Cutter

Heavy Duty Cable Cutter

handles aluminum

and soft copper cables up to 500 MCM.

• Rubberized cushioning in handles

• Heavy duty construction

• Jaw and handle designed for easy cutting

Ilsco

Heavy Duty Cable Cutter

cuts up to 500 MCM

copper or aluminum cable.

• Sharp, precision-ground Moly steel blades make

clean, distortion-free cuts and stay sharper longer

• Durable 20 3/4" fiberglass handles

Ilsco

Manual Cutter

cuts up to 2/0 AWG copper or aluminum cable—a great cutting range for a pouch tool.

• 7 1/2" overall length gives better leverage for easier cutting
• Sharp, precision-ground blades make clean, distortion-free cuts
• Blades are heat treated for long, dependable and durable operation
• Narrow head design for easy access to confined areas

Ilsco

Ratchet Cable Cutter

Lightweight

Cable Cutter

with ratchet mechanism

and open/close lever cuts up to 750 MCM copper or
aluminum cable. 16" length.

• Alloy steel precision-ground replaceable blades

Heavy Duty Cable Cutter

cuts aluminum and

soft copper cables up to 1 1/4" or 500 MCM.

• Ratcheted with safety release

• Comfortable handles

Part Number

200-043

Part Number

94012

Part Number

CTR-500

Part Number

200-006

Part Number

CTR-750

Eclipse

Economy Heavy Duty Ratchet Cutter

EK50ML Micro Crimping Tool

The new EK50ML battery powered

Micro Crimping Tool

combines the benefits of manual crimping tools with

the convenience of battery-powered hydraulic tools. This lightweight tool can deliver 3,400 pounds of crimping
force and crimps 65 percent faster with 90 percent less hand force compared to ratcheting tools, making it the
ideal crimper for high volume, time critical jobs.

The EK50ML is designed to crimp 28 – 4 AWG wire using PowerSense™
Technology, a patented trigger which allows you to hold your work
in the jaws of the tool before crimping. Powered by a compact 10.8V
Lithium-Ion battery, the EK50ML Micro Crimping Tool can perform 250
crimps to 10 AWG wire on a single battery charge.

Intelligent Crimping System Technology monitors amp draw for each
crimp and provides a visual alert if a crimp does not complete a full cycle.

Features

• Includes 2 die sets to crimp 22-10 AWG heat shrink terminals

and nylon insulated terminals; other die sets sold separately

• Patented jaw actuation for crimping cycle

• Crimps three times faster and with 90% less force

• Reduces hand force from 53 pounds to 6 pounds

• 1.2 seconds to perform crimp using one finger

• 65% faster crimping than ratcheting tools (1.2 seconds vs 3.5 seconds)

• Innovative PowerSense™ trigger holds work to be crimped

• When crimping is complete, simply release the trigger

to open the jaws for the next crimp

• Overmolded tacky grip for maximum comfort and security

• Multifunction LED for maintenance display and data

transfer via optional interface and USB adapter

• LED work light for use in dark areas

• LED battery level indicator monitors charge

• 10.8V Li-ion battery can perform

up to 250 crimps to 10 AWG
wire on one battery charge

• Weighs just 2.2 lbs

with battery

• 12mm Jaw

Part Number

EK50ML

Includes micro crimper,

10.8V Li-ion battery,

110V battery charger,

two die sets,

and case

Crimps 22-10 AWG

heat shrink terminals

Crimps 22-10 AWG nylon

insulated terminals

Many more dies

available soon.

Contact us!

(907) 561-5955 Toll Free (888) 245-WIRE

Small Wire Gauge Handheld

Crimpers, Crimp Frames and Dies

Pro’sKit®

Crimping Tools

use

interchangeable die sets to crimp
a wide variety of connectors for
electrical and industrial wire,
twisted pair and flat phone cable,
fiber optic cable, coaxial cable, etc.
All metal parts are oil-hardened
tempered steel. Precision dies and
integral ratcheting mechanism
ensure high crimp quality.

• Choose frames and die sets

individually for maximum
versatility and cost efficiency

• Dies are changed easily with thumbscrews
• Crimping pressure adjustment wheel
• Ratcheting action for perfect crimps
• Lever action, ergonomic,

non-slip handles

Interchangeable Die Sets

Part Number Application

Crimp Size

300-039

Open Barrel Contacts

AWG 22-18/16-14/12-10
DIN 0.5-1.0/1.5-2.5/4.0-6.0mm

300-058

Red, Yellow, Blue Nylon and AWG 22-18/16-14/12-10
Vinyl Insulated Terminals

DIN 0.5-1.0/1.5-2.5/4.0-6.0mm

300-070

Insulated Flag Terminals

AWG 22-18/16-14
DIN 0.5-1.0/1.5-2.5mm

300-071

Uninsulated Flag Terminals

AWG 22-18/16-14
DIN 0.5-1.0/1.5-2.5mm

300-077D

Insulated and Non-Insulated AWG 6/4/2
Wire Ferrules

DIN 16/25/35mm

300-095

Uninsulated Terminals

AWG 20-18/16-14/12-10/8
DIN 0.5-1.0/1.5-2.5/4.0-6.0mm

300-097

Insulated and Non-Insulated AWG 22/20/18/16/14/12
Wire Ferrules

DIN 0.5/0.75/1.0/1.5/2.5/4.0mm

300-101

Red, Yellow, Blue Nylon/Vinyl AWG 22-18/16-14/12-10
Thinstyle Insulated Terminals DIN 0.5-1.0/1.5-2.5/4.0-6.0/10.0mm

300-103

Insulated and Non-Insulated AWG 10/8/6
Wire Ferrules

DIN 6/10/16mm

300-104

Nylon and Vinyl Miniature

AWG 26-16

Insulated Terminals

DIN 0.2-1.5mm

9PK-3003D27 Insulated Terminals

AWG 22-18/16-14/12-10/8
DIN 0.5-1.0/1.5-2.5/ 4.0-6.0mm

10.0mm

9PK-3003D42 Yellow and Blue Insulated

AWG 16-14/12-10

Flag Terminals

DIN 1.5-2.5/4.0-6.0mm

CP-5S2D

Multi-Contact (MC4)

AWG 14/12/10

04mm Solar Contacts

DIN 2.5/4.0/6.0mm

CrimPro

Crimp Frame

Die set sold

separately

Part Number

902-085

Crimp Frames

and Die Sets

sold individually

Lunar

Crimp Frame

Part Number

300-054

Ergo-Lunar

Crimp Frame

Part Number

300-096

Pro’sKit

Crimp Frames and Die Sets

Die Profile

Molex

ServiceGrade

™

Ratchet Hand Crimper

crimps heat shrink terminals 22 to

10 AWG (rings, spades, hooks, 3 and 4 ways, and splices).

• Full cycling ensures complete crimps

• Small handle spread is ideal for all users

• Crimp release for operator safety

Compound Action Controlled Crimper

is specifically

designed for heat shrink style terminals. Elliptical nest for
crimping insulated terminals.

• Wire range 22 to 10 AWG

• Weight: 12.4 oz. Length: 9 1/8"

Part Number

RHT-5770

Part Number

94130

Ilsco

Compound Action Crimper

The

Contour Crimp

controlled cycle ratchet

crimping tool crimps 8 to 1 AWG copper lugs and
splices, 6 to 4 AWG aluminum lugs and splices, and
8 to 2 AWG non-insulated S Series tubular terminals.
The rotary die-wheel locks easily into position with
a push-button mechanism. Each die is embossed with
die-code color. Nest includes red, blue, gray, brown, and green.

Part Number

CT-1700

Molex Selectakrimp

Hammer Crimp

is a heavy duty, compact tool for lower-volume

production and regular maintenance use. Crimps non-insulated 6 to 4/0 AWG wire.
Great performance for the lowest cost.

• Crimps with a hammer

• Small, portable, easy to use

Part Number

SKT-840

Selectakrimp

™

Compact Hammer Crimp Tool

Ilsco

Heavy Duty Crimper

features a dieless single indent compressor; there are no separate dies to buy or lose.

• Broad wire range—

crimps 8 AWG to 4/0 AWG
aluminum, and 8 AWG
to 250 MCM copper

• Steel adjusting knob

provides fast and easy
setting—simply align the wire size gauge to the die nest

• Ilsco’s standard line of connectors are UL Listed when crimped with this tool

Eclipse

Economy Heavy Duty Crimper

terminates insulated and non-insulated cable lugs from 8 AWG to 250 MCM

copper and 8 AWG to 4/0 aluminum with dual capacity plates.

• Easy-to-use knob adjustment

on top of tool

• Non-ratcheted

Part Number

MT-25

Part Number

300-107

Panduit

Contour Crimp

(907) 561-5955 Toll Free (888) 245-WIRE
