PEM

®

 Type MSO4

™

Self-clinching microPEM

®

 Standoffs

PEM Type MSO4 self-clinching microPEM
standoffs are used to space internal
components and provide strong, permanent,
and reusable load-bearing threads in metal
sheets as thin as .016” / 0.4mm.  Smallest
standoff size includes 2mm length with M1
threads. Other metric and unified sizes are also
offered.

www.pemnet.com

MSO4-912

•

Become integral parts of an assembly by clinching
permanently in place.

•

Will not loosen or fall out.

•

Can be installed into stainless steel sheets.

•

Can be installed automatically.

•

RoHS compliant.

Features and Benefits

NEW!

Fastener Material:

 400 series stainless steel

Threads:



(1)

 Unified ASME B1.1, 2B



(2)

 Miniature ISO 1501, 4H6



(3)

 Metric ASME B1.13M

Finish:

 Passivated and/or tested per ASTM A380

For Use In Sheet Hardness:

 HRB 88 / HB 176 or less

(4)

(4)  HRB - Hardness Rockwell “B” Scale.  HB - Hardness Brinell.

UNIFIED



Type



Min.

Hole

Size



Min. Dist.



Thread



Thread

Length

Sheet

In Sheet

C

H

L

Hole

C/

 Size  Stainless Steel

Code

Code

Thickness*

+.002 -.000

Max.

Nom.

+.002 –.003

To Edge



.060-80

MSO4 080 3 .016  .095 .094 .125 .094

.090

  (#0-80)

(1)



   4

.125



.086-56

MSO4 256 3 .016  .125 .124 .156 .094 .120

 (#2-56)

(1)





4

.125

All dimensions are in inches.

All dimensions are in millimeters.

MSO

4 – 080 –  3

PART NUMBER DESIGNATION

Type

Thread

Code

Length

Code

Material

Code

METRIC



Type



Min.

Hole

Size



Min. Dist.



Thread  Thread

Length

Sheet

In

Sheet C  H  L Hole

C/

 Size  Stainless Steel

Code

Code

Thickness*

+0.05

Max.

Nom.

+0.05 – 0.08

To Edge



S1

(2)

 MSO4  M1 2 0.4  2.41  2.39 3.18 2

2.3





   3      3



S1.2

(2)

 MSO4  M1.2 2  0.4  2.41  2.39 3.18 2  2.3



   3      3



S1.4

(2)

 MSO4  M1.4 2  0.4  2.41  2.39 3.18 2  2.3



   3      3

 M1.6 x 0.35

(3)

 MSO4

M1.6 2  0.4  2.41  2.39 3.18 2  2.3



   3      3

  M2 x 0.4

(3)

 MSO4

M2 2 0.4  3.18  3.16 3.96 2  3



   3      3

MATERIAL AND FINISH SPECIFICATIONS

H

L

C

* For installation into thinner sheets, contact Tech Support at techsupport@pemnet.com.

(1)  The values reported are averages when all installation specifications and procedures are followed.  Variations in mounting hole

size, sheet material and installation procedure will affect results.  Performance testing of this product in your application is
recommended.  We will be happy to provide samples for this purpose.

(2)  Performance in torque out and pull thru will depend on the strength and type of screw being used. In most cases the failure will be in the

screw and not in the self clinching standoff. Please contact our Applications Engineering group with any questions.

PEM

®

 Type MSO4

™

Self-clinching microPEM

®

 Standoffs

MSO4-2

PERFORMANCE DATA

(1)

UNIFIED





Max. Rec.

                    Test Sheet Material

  Thread

Tightening

          .017” 300 Series Stainless Steel



Code

Torque For





Mating Screw

Installation

Pushout

Torque-out

Pull-thru





(in. lbs.)

(lbs.)

(lbs.)

(in. lbs.) (2)

(lbs.) (2)

 080

.65

2500

64

3

170

 256

1.9

2500

67

7

265

METRIC





Max. Rec.

                   Test Sheet Material



Thread

Tightening

         0.43mm 300 Series Stainless Steel



Code

Torque For





Mating Screw

Installation

Pushout

Torque-out

Pull-thru





(N•m)

(kN)

(N)

(N•m) (2)

(N) (2)



M1  .019  11.1 285 0.34 755



M1.2  .036  11.1 285 0.34 755



M1.4  .057  11.1 285 0.34 755



M1.6  .084  11.1 285 0.34 755



M2  .28  11.1 300 0.79 1175

1.

  Prepare properly sized mounting

hole in sheet.



Do not perform any

secondary operations such as
deburring.

2.

  Insert fastener through mounting

hole (preferably the punch side) and
into anvil as shown in drawing.

3.

  With punch and anvil surfaces

parallel, apply only enough
squeezing force to embed the
standoff’s head flush in the sheet.

INSTALLATION

To be sure that you are getting
genuine PEM

®

 brand MSO4

standoffs, look for the “one
groove” trademark. On actual
parts, location of groove on
barrel may be different than
shown in photos.

PUNCH

ANVIL

BEFORE

AFTER

Recommended Installation Anvil

A

C

45˚

Nom.

L +.125” /

3.18mm

UNIFIED

  Thread      Anvil Dimensions (inches)

Anvil Punch

  Code A

C

Part Number

Part Number



080

.112 - .114

.097 - .099

8015796

975200997



256

.142 - .144

.127 - .129

8015797

975200997

METRIC

  Thread     Anvil Dimensions (millimeters)

Anvil Punch

  Code A

C

Part Number

Part Number



M1

2.84 - 2.89

2.46 - 2.51

8015796

975200997

  M1.2

2.84 - 2.89

2.46 - 2.51

8015796

975200997

  M1.4

2.84 - 2.89

2.46 - 2.51

8015796

975200997

  M1.6

2.84 - 2.89

2.46 - 2.51

8015796

975200997



M2

3.6 - 3.65

3.22 - 3.27

8015797

975200997

Specifications subject to change without notice.
See our website for the most current version of this bulletin.

RoHS compliance information can be found on our website.
© 2012 PennEngineering.

Technical support e-mail: techsupport@pemnet.com
