Secure connectionS. World-Wide.

EDITION 2020

1901

Founding of Messrs. Stock & Co.
in Wuppertal-Elberfeld. The
button factory has five employees.
Hugo Henkels becomes a partner
and later the sole proprietor.

1911

The subsidiary at Hellenthal/
Eifel is set up. Stock & Co.
employ already 110 workers
at that time

1929

At the end of the twenties,
start of the production
of special parts for the
electro-technical and radio
industries

1950

Steady growth
of
the company

From the beginnings .....

STOCKO is a company with a tradition going back for more than one hundred years. The foundation stone was laid by Alfred Aders,
Heinrich Pfeiffer, and Johann August Stock 1901 at Wuppertal under the name of Stock & Co. - as button manufacturers. Amongst
other items, they produced hollow rivets, eyelets, and press fasteners that, during the Wilhelmian boom era, were in great demand and
were even shipped to South America. When Stock & Co. developed the eyelet tag from a shoe eyelet with a solder tag added, the
future direction of the company’s activities was set: electrical technologies. Very soon there followed additional pressed, drawn, and
seamed metal parts all of which could be manufactured with the same machines as the button parts up until now.

..... to the present

During the Weimar period that is during the twenties of the last century, the living habits of the people changed drama-
tically; modern electrical devices such as the radio, telephone, or even the electric shaver found entry into the households
in large scale. The new direction of the company proved to be a particularly lucky move, 500 people were employed 1935;
two years later there were already 1000. Now under the sole company name STOCKO. With the new factory at Malmedy
in Belgium 1940, the company grew to a concern employing 1800 people. However, the war was not without consequen-
ces, and the number sank down to 300. There followed the years of the so-called “economic miracle”, and STOCKO, too,
gained by the new boom. Subsidiaries were founded like in England, France, Switzerland, and overseas. With the expertise, which
STOCKO had gained in the manufacture of plastic parts, the product range was extended by film spools, tape cassettes, slide frames
etc.. During these years, the expansions abroad continued steadily until far-reaching re-structuring measures took place during the
nineties. In 1994, STOCKO divorced themselves from the division Fasteners. In 1998 a merger with the Bamberg Wieland Group took
place and since then the company’s name is STOCKO Contact GmbH. & Co. KG. Today STOCKO employ about 600 people at three
locations: Sales and Marketing are at Wuppertal, production is distributed among the plants at Hellenthal (Germany) and Andlau/France.

THE STOCKO SUCCESS STORY

1960

Dr. Dirk Henkels,
grandson of
Hugo Henkels and
son of Kurt Henkels
(with the company
since 1930) joins
the firm

1998

Wieland Holding GmbH. take
over Stocko Metallwaren-
fabriken, Henkels und Sohn
GmbH & Co..
New name : STOCKO Contact
GmbH & Co. KG.

2001

STOCKO celebrate
their centenary at
Wuppertal.

stocko-broschuere-en-html.html

2007

STOCKO France
celebrate their
50th anniversary
at Andlau.

2011

STOCKO Hellenthal
celebrate their
100th anniversary.

2009

The Malmedy factory,
one of four production
facilities to date, will be
closed in spring 2009
and the production
will be relocated to
Hellenthal.

2012/2013

A high volume of
investment in all factories
and divisions. Significant
improvement in
infrastructure, machinery
and large parts of
production.

2014

Production area
extension by 1,000m²
in Hellenthal
Construction work in the
order of 3,000m² is being
completed in Andlau.

STOCKO has met the great ruptures and frequent changes of the industry in masterly fashion.

Today the company is well prepared to continue with the 100 year old tradition also in the future.

2017

As part of its growth strategy,
STOCKO is once again investing
in the Hellenthal location and is
expanding its production and
administration areas by around
3,000 m

with the construction

of a new hall.

2016/2017

In order to ensure the continued
growth of STOCKO France, land
in the order of 20,000 m

was

acquired in 2016 and a property on
it with a building area of 3,500 m

has been core redeveloped.

stocko-broschuere-en-html.html

Secure Connections. World-wide.

Today, STOCKO is one of the leading European manufacturers of electro-mechanical components; for
very good reasons, because, for more than one hundred years, we are focussed in our daily work on
the most important object, to satisfy our customers.
Of course, it is not easy to meet these expectations over such a long period of time
Electronic component manufacturing is a key industry that does not tolerate mistakes,
and customers’ requirements are very complex and challenging. Again and again,
they demand our full efforts beginning with research and development and finally in
logistics and marketing. Hence we invite our customers’ involvement in numerous
stages of production processes but above all with regard to quality assurance, right
from the beginning, and thus make sure that we continue to offer our products at a
high quality level. Products that can be found equally in heating controls, drink
dispensing machines, dish washers or motor cars.
If, at STOCKO, we talk of secure connections then for this reason that in every one of
our connectors an element of conviction reverberates that good connections are always
a matter of trust.

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical alterations and changes reserved. WEEE Reg. No. DE 14484959

Seite

The Company

...............................................................................................................................

4 - 23

Connector Systems

Pitch

2,5 mm ..................................................................................................................... 24 - 26

Pitch

2,54 mm ...................................................................................................................

Pitch

3,5 mm ....................................................................................................................

Pitch

4,2 mm ....................................................................................................................

Pitch

5 mm ....................................................................................................................... 30 - 35

Pitch

5,08 / 7,62 mm ...................................................................................................... 36 - 37

Pitch

6,35 mm ..................................................................................................................

Pitch

6,5 mm ....................................................................................................................

Pitch

8 mm .......................................................................................................................

Cirtcular Connector.............................................................................................................

Pin Strips

..........................................................................................................................

Insulation housings

..................................................................................................................

Crimp contacts,

loose and in bandolier form

............................................................................. 44 - 45

Automotive

............................................................................................................................... 46 - 50

Customers’ special products

....................................................................................................

Solderless terminals

..................................................................................................................

Terminating systems

.................................................................................................................

index

stocko-broschuere-en-html.html

STOCKO CONTACT

Assured QuAlity

certified integrAted mAnAgement systems

Certified according to

ISO 9001

ISO 50001

ISO 14001

IATF 16949

STOCKO CONTACT Germany

STOCKO CONTACT Germany, France

stocko-broschuere-en-html.html

STOCKO CONTACT

Our mArkets

Domestic appliances industry

Industry

Automotive

Heating industry

Distribution

Our PrOducts

Multi-way connector systems with terminations

for insulation displacement crimping or soldering

Solderless terminals

Crimp contacts

Customers‘ special products

Terminating systems for all STOCKO products:

Hand tools, semi- and fully automated machines

fActOries

Wuppertal / Germany

Hellenthal / Germany

Andlau / France

Sokolov / Czech Republic

Shanghai / China

fOunded

1901 in Wuppertal

emPlOyees WOrld-Wide

700

company profile

stocko-broschuere-en-html.html

STOCKO CONTACT

development

Toolmaking

Absolutely essential and a decisive component in our successful connector technolo-
gy, is our toolmaking capability and that takes place inhouse at STOCKO. The produc-
tion tools with which amongst other things the negative forms of housings are pro-
duced are of paramount importance that quality is assured, and our design teams for
electro-technical components have to adhere to strict guidelines with regard to the
mechanical design of such components. All press and moulding tools are built
by STOCKO according to the latest state of the art. They are central in a value
producing chain that ultimately is to the benefi t of our customers.

Design and Development

STOCKO products are renowned and held in high estimation. They represent
solid solutions and a multitude of applications as connectors and terminals. The
growing functionality and complexity in this sector, however, limits the usage
of volume-produced standard components; more and more customers demand
individual applications or new designs. Such processes need know-how, ideas,
and adjustment to technical and economical philosophies in a sensible manner.
Together with our customers, we are concentrating our energy on the expected
performance of the new product and, step by step, work out the details – the
material, the surface fi nish, the physical properties and fi nally the design. For
design and development, we have the most modern, computer aided systems
at our disposal. With the stereolithography method for example, we are in a
position to check the precision of future products with the aid of prototypes, or
manufacture prototype samples for testing purposes. Before reaching marketing
stages, all STOCKO products are subjected to rigorous test procedures in our
laboratories to check the mechanical and electrical properties as well as the
infl uence they may have on the environment.

stocko-broschuere-en-html.html

STOCKO CONTACT

Our laboratories test all components of their suitability for volume production.

The quality and equipment of our laboratories are of such high level that the VDE approvals and certifi cation institute uses them
to carry out their own independent tests. These include VDE and even the stringent CSA and UL tests for the inter national markets.

ideaS With a future

Milling machine with automation

Wire cutting machine

stocko-broschuere-en-html.html

STOCKO CONTACT

highly flexiBle automation

stocko-broschuere-en-html.html

STOCKO CONTACT

Production of Plastic Mouldings

Production at STOCKO is concentrated in manufacturing centres to se-
cure the highest quality even with growing output rates. Thus the whole
production of plastic parts is at our Hellenthal plant.

With this location specializing on this sector, they can fully concentrate on to the highly
technical requirements of those parts such as the production of a maximum
number of pin count with a minimum contact spacing and the closest possi-
ble tolerances, processing special flame retarding plastic materials, usage of
a wide range of materials, and a high machine output rate. For this, we rely
on the most modern machines available. We compliment our fully automated
moulding presses with intelligent ancillary devices and tooling from our own
in-house production.

With regard to production techniques and the development of new possibilities
for plastic materials, we are constantly aiming for the best possible solutions.
This is hard cast quality.

manufacturing
technology

stocko-broschuere-en-html.html

STOCKO CONTACT

Stamping

Stamping technology at STOCKO stands for the highest level of economy and
quality. At our production centres in Hellenthal and Andlau we produce the
precision stamped parts for our various product groups both in bands and
loose. For this we have the latest high-performance stamping machines with
speeds of between 100 and 1400 strokes per minute and a compression
force range of up to 160 tonnes. All the presses are equipped with the latest
peripherals.

Rationalised production stages, a high level of automation and well designed
integrated process monitoring systems guarantee year-on-year increased
productivity that we ensure with the latest electronic quality control. Here we
produce our stamped, drawn and formed parts with downstream composite
tools made in-house and precisely tailored to the process architecture. This
creates further cost benefits that we can pass on to our customers.

manufacturing
technology

stocko-broschuere-en-html.html

STOCKO CONTACT

highly flexiBle automation

stocko-broschuere-en-html.html

STOCKO CONTACT

highly flexiBle automation

stocko-broschuere-en-html.html

STOCKO CONTACT

Assembly

Our connector systems are assembled by STOCKO in Hellenthal (Germany)
and Sokolov (Czech Republic) using fully automated processes.

Here, too, we apply the STOCKO philosophy of developing and producing most of
the machinery, tooling and auxiliary devices in-house.

The result is a highly flexible degree of automation leading to our high qua-
lity standards, which are assured with control systems that have also been
developed in-house.

manufacturing
technology

stocko-broschuere-en-html.html

STOCKO CONTACT

machine Building

We give high priority to our STOCKO terminating systems, because the quality
and reliability of an electrical connection is largely determined by the high
levels of the terminating technology. That is why we allocate considerable
financial resources to the development and production of such systems. In
addition to quality, innovation and economies play important parts. Our aim
is to improve the productivity of our customers by integrating our termina-
ting machines smoothly into their production processes. Thus once more,
STOCKO solutions act as catalysts and enable profitable competition. And
to make sure everything runs smoothly, training is given to your staff for the
various production processes, and our team of service engineers is always at
your disposal with help and advice to ensure productivity all along the line.

stocko-broschuere-en-html.html

STOCKO CONTACT

STOCKO Terminating Technology - for every type of application, from simple
hand tools, to semi-automated machines, and ultimately to fully automated
modular machines with “Just in Time” functions, computer controlled, auto-
mated quality control functions, modem connections for outside diagnostic
centres and the option to programme sequences of cable forms.

productivity all the Way

stocko-broschuere-en-html.html

STOCKO CONTACT

Environmental protection

We take it as our social responsibility to integrate environmental protection in our manufacturing processes. For this reason, the plating
shop at our manufacturing centre at Andlau was only recently modernized and converted taking account of the latest environmental and
ecological developments. In an elaborate process, all effluents are returned to nature, purified and completely free of harmful substances.

stocko-broschuere-en-html.html

STOCKO CONTACT

Quality is our highest premise

For it is the best argument for customers’ satisfaction and a solid position in a hard
fought market. This quality approach at STOCKO does not simply begin at the
manufacturing stage.

From the first initial contact, we wish our customers to know they are in safe
hands and can rely on this also during the planning and development stages:
with an application oriented design, the uncompromising selection of the
most suitable materials, and strict observation of the customers’ requirements
profile. International standards can only act as guidelines for us. We exceed
their demands by setting our own additional standards: with our own desig-
ned testing programs, in-house laboratories, a continued striving for optimal
organisational processes during all phases and a close exchange of experiences
and know-how with our customers and users.

In addition to this, our quality offensive goes even further in that our environ-
mental responsibilities are firmly imbedded in our manufacturing processes.
Right from the development stage of our products, we aim for the conscientious
use of our raw material resources. All our plastics and metal materials are
recyclable and our state-of-the-art production processes completely eliminate
the use of chlorinated hydrocarbons and chlorofluorocarbons. Moreover and
to avoid waste, STOCKO are using re-usable packaging systems such as blister
packs, reels, and magazines.

StocKo Quality

stocko-broschuere-en-html.html

STOCKO CONTACT

DIN EN ISO 9001 and IATF 16949

Having been awarded certifi cation to ISO 9001, we have received approval that a quality management system is in operation throughout all areas of
activity that assures a uniform high level of quality. Likewise, this is also the basis for specifi cation IATF16949. This certifi cation is a prerequisite to qualify as
supplier to the automotive industry. It acknowledges that the company has set up special procedures in all areas of activity and, therefore, complies with cus-
tomers’ specifi c demands in the automotive sector. Thus and in the long-term, STOCKO increase the effi ciency and safety for their customers and themselves.

DIN EN ISO 14001

In recent years we have with great commitment incorporated numerous improvement processes into our company environmental policy and constantly
expanded them. Since 2011 our factory in Andlau has met the strict requirements of environmental management standard ISO 14001 and since
2012 our factory in Hellenthal has done so too. By doing so, we commit ourselves to a far greater extent than normal to the voluntary reduction of
environmental risks such as waste, waste water and emissions. We are constantly planning, implementing and monitoring our goals in this regard.
For us they are a major factor in our value system.

DIN EN ISO 50001

It has long been one of our corporate goals to keep increasing the energy effi ciency in our plants while at the same time reducing energy consumption
as well as CO

emissions.

For sustainable control and optimisation, STOCKO has developed an intelligent energy management system with which we can precisely detect any
energy losses and initiate countermeasures at an early stage. ISO 50001 certifi cation for this is for us the worthwhile supplement to ISO 14001.
Whereas there energy is only a partial aspect, the focus in ISO 50001 lies on the energy effi ciency of a company. With our energy management system
we are, in the best-case scenario, even going beyond the strict requirements of this ISO because we can among other things increase our effi ciency
even without increasing our energy consumption.

Environmental Protection

Preserving our environment and natural resources for future generations is an integral part of the company policy and is enshrined in the management
principles of STOCKO CONTACT.

StocKo Quality

stocko-broschuere-en-html.html

STOCKO CONTACT

stocko-broschuere-en-html.html

STOCKO CONTACT

preciSely adJuSted for you

stocko-broschuere-en-html.html

STOCKO CONTACT

Service and close proximity with our customers has always been a
top priority and form an integral part of the STOCKO philosophy.

Of course, to discuss with our customers their specific requirements and to meet
their expectations in the best possible way is part of our flexibility. We wish to
offer our customers superior performance characteristics and to support them
in their business activities by anticipating future requirements.

Our customers shall be able to rely upon us so that they become true partners
eventually. Partners, who we can assist with our know-how and comprehensive
knowledge of the markets. Particularly our sales engineers and our service
engineers carry this part of our philosophy outside. Moreover, an extensive
network of subsidiaries, sales offices, and agencies around the world assist in
bringing this principle close to our customers wherever they are. This network
will be expanded still further during the next few years so that our customers
can benefit from close on-site support even more efficiently.

And should one of our customers ever ask if we are the right partners then
something must have gone wrong from our part.

Service

stocko-broschuere-en-html.html

STOCKO CONTACT

Safely connected to progreSS

stocko-broschuere-en-html.html

STOCKO CONTACT

Our markets

Developments in the electro-technical market are short-lived and permanently exposed to innovative
pressures; again and again the limits are newly defined. How gratifying, there is a safe con-
stancy on which one can rely. STOCKO offer such constancy. Our name stands synonymous
for connector systems in crimp and ID form, crimp contacts, solderless terminals, and special
parts. Millions of all these elements perform their tasks unnoticed and reliably day in, day
out. STOCKO components ensure secure and advanced connections and progress in a wide
range of industries and areas of application. A range as wide as household appliances, the
heating industry, automotives, industrial and entertainment electronics, control equipment
and machine building, as well as the sectors multi-media and telecommunication. Maintai-
ning the well-proven STOCKO quality, we are continuously upgrading the performance of
our products to changing market conditions enabling us to set standards for customers of
the highest levels of expectation.

Our Products

Connector systems in insulation displacement, crimp or solder form
Crimp contacts
Solderless terminals
Customers’ special products
Terminating systems for all STOCKO products: hand tools,
semi-automated and fully automated machines.

marKetS & productS

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Pitch

2.5 mm

Positions

2 - 20

Termination

IDC

Wire size

0.12-0.14mm² / 0.22 - 0.35 mm

Insulation Ø

max. 1.6 mm

Hardness of insulation

Shore A 90° ± 5

Type of wire

solid, stranded

Temperature range

-40 °C ...+ 120 °C

Board thickness

1.55 ± 0.19 mm

Electrical

Rated current

2 A

Rated voltage

Pitch 2.5 mm: 32 V

Pitch 5 mm: 250 V

Dielectric strength

Fully assembled 2.5 mm: 1.4 kV

Partially assembled 5 mm: 2.8 kV

Insulation resistance

> 10

Contact resistance

< 10 m

Air gap and creeping distances Pitch 2.5 mm: > 1 mm

Pitch 5 mm: > 3 mm

Creeping strength

CTI 400

Approved IDC connector

UL / ULC E96569

DIN EN 61984 (IEC 61984)

according to

- LV 214: 2010-03

- USCAR-2

Approved Pin connectors

UL/ ULC E96569

DIN EN 61984 (IEC 61984)

Materials

Contact

Socket: CuSn, Cu-alloy / Pin: CuZn

Contact finishing

Socket: Sn, NiAu / Pin: Sn

Housing

PA, glow wire resistant, GWT 750 °C acc. to IEC 60335-1

SMT pin connector

PA, glow wire resistant, GWT 750 °C acc. to IEC 60335-1

Colour of housing

natural, SMT pin connector black

Polarizing

to RAST 2.5

cOnnecTOR SYSTeM | PiTch 2.5 MM

ecO-TROnic

deScRiPTiOn Of SYSTeM

IDC housings

Direct and indirect connectors with IDC termination in accordance with the RAST 2.5 standard specification

for domestic appliances

Trimming polarizing pegs to individual requirements produces a large number of clearly defined

connector combinations

With direct edge versions, polarizing and locking feature for PCB

Pin connectors

In vertical and horizontal versions facilitate 90° and 180° cable angles
SMT version for vertical PC board assembly

Pin connector panel mount

Pin connector with IDC termination for entry through back panel
Lockable in metal thickness 0.8 ± 0.1 mm

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Pitch

2.5 mm

Positions

2 – 12 (up to 20 on request)

Termination

crimp technology

Wire size

0.22 and 0.35 mm

Insulation Ø

max. 1.4 mm

Hardness of insulation

Shore A 90° ± 5

Type of wire

stranded

Temperature range

-40 °C ...+ 120 °C (Sn)

Board thickness

1.55 ± 0.19 mm

Electrical

Rated current

2 A

Rated voltage

Pitch 2.5 mm: 32 V

Pitch 5 mm: 250 V

Dielectrical strength

Fully assembled 2.5 mm: 1.4 kV

Partially assembled 5 mm: 2.8 kV

Insulation resistance

> 10

Contact resistance

< 10 m

Air gap and creeping distances

Pitch 2.5 mm: > 1 mm

Pitch 5 mm: > 3 mm

Creeping strength

CTI

≥

400

Approved Crimp connector

DIN EN 61984 (IEC 61984)

according to

- VW 60330

- LV 214: 2010-03

- USCAR 2

Approved Pin connectors

UL / ULC E96569

DIN EN 61984 (IEC 61984)

Materials

Contact Socket:

CuSn, Cu-alloy

Contact finishing

Sn, NiAu

Housing

PA, glow wire resistant,

GWT 750°C acc. to IEC 60335-1

Colour of housing

natural

Polarizing

to RAST 2.5

cOnnecTOR SYSTeM | PiTch 2.5 MM

ecO-TROnic cRiMP

deScRiPTiOn Of SYSTeM

Crimp housings

  Direct and indirect connectors with crimp termination
  Codings in accordance with the RAST 2.5 standard specification for domestic appliances
  Closed cable entries ensure long air and creepage distances
  Trimming polarizing pegs to individual requirements produces a large number of clearly defined

connector combinations

With direct edge versions, polarizing and locking feature for PCB
Primary and secondary lock

Pin connectors

In vertical and horizontal versions facilitate 90° and 180° cable angles
SMT version for vertical PC board assembly

Pin connector panel mount

Compatible with pin connector of ECO-TRONIC with IDC termination
Lockable in metal thickness 0.8 ± 0.1 mm

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Pitch

2.5 mm

Positions

up to 20

Termination

IDC, crimp,

soldering

Temperature range

-40 °C + 115 °C

Electrical

Rated current

5 A / 30 °C

2.5 A / 70 °C

Insulation resistance

>10

Contact resistance

<10 m

Test voltage

1 kV

Rated voltage

32 V

Approved by

UL E96569

Materials

Housing

PC, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Contact

CuSn

Finishing

cOnnecTOR SYSTeM | PiTch 2.5 MM

RfK 2

deScRiPTiOn Of SYSTeM

Socket connectors

Crimp version for indirect connections, wire range 0.12 - 0.5 mm

IDC version for direct and indirect connections, wire range 0.14 - 0.25 mm

Suitable for terminating ribbon cables and discrete wires

Pin connectors

With or without snap-in locking device, for vertical or horizontal connections
The tandem pin connectors can be used as flying lead connection

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Housing

SMD Socket connector

Mechanical

Positions

3 / 6

4-80

Pitch

2.54 mm

Termination

Crimp

SMD soldering

Wire size

0.14 - 0.34 mm²

AWG 26-22

Temperature range

- 20 °C ... + 110 °C

- 40 °C ... + 105 °C

Electrical

Rated current

max. 3 A at T

amb

80 °C

max. 1 A at T

amb

95 °C

(max. 3 A at T

amb

47 °C)

Rated voltage

250 V

Dielectrical strength

2.5 kV

1.39 kV

Insulation resistance

> 10

Contact resistance

< 10 m

< 40 m

Air gap

1.5 mm

Creeping distances

1.8 mm

1.25 mm

Creeping strength

CTI 425

CTI 600

Materials

Housing

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1 GWT 750 °C acc. to IEC 60335-1

Colour of housing

various colors

black

Associated contact

RVB 8231.001 Z 0.64-0.35

Contact

CuSn

Contact finishing

Contact area: gold flash,

Soldering area: Sn

cOnnecTOR SYSTeM | PiTch 2.54 MM

S-GRid 2.54

deScRiPTiOn Of SYSTeM

Suitable for the connection to HVAC periphery devices, e. g. stepping/servo motors or linear actuators
Housing variants

- In-line

3-positions or

- dual-line

6-positions

Three different coding variants
Cable exit 180°

SMD Socket Connector

  4 to 80 poles socket connector doublerow
  Board to board connection (bottom entry) with 0.64 x 0.64 mm pins
  Surface Mount Technology
  Contact area flash gold, soldering area tin plated

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Positions

Pitch

3.5 mm

Termination

Crimp

Temperature range

-40 ºC ... +120 ºC

Wire size

0.12 - 0.5 mm²

Electrical

Rated current

max. 5 A

Rated voltage

250 V

Insulation resistance

> 10

Contact resistance

< 10 m

Materials

Housing

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Colour of housing

black

Associated contact

RFB 7808 V 0.6-0.5

Contact

CuSn

Contact finishing

cOnnecTOR SYSTeM | PiTch 3.5 MM

hlK 3500

deScRiPTiOn Of SYSTeM

  Suitable for the connection to HVAC periphery devices, e. g. stepping/servo motors or linear actuators
  Pitch 3.5 mm
  Pluggable connector with external locking feature
  Crimped wires are from the rear insertable
  Cable exit 180°
  Remarks with or without seal
  With seal IP 44
  Clear positioning

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Positions

Single-row

2 - 6

Dual-row

2 - 24

Pitch

4.20 mm

Termination

Connector, Counter part Crimp

Headers

Solder

Wire size

0.22 - 0.48 mm² / AWG 24-22

0.50 - 1.00 mm² / AWG 20-18

Degree of pollution

Temperature range

-40 °C ... +110 °C

Electrical

Rated current

7 A

Rated voltage

250 V

Insulation resistance

> 10

Contact resistance

< 10 m

Air gap and creeping distances

3 mm

Creeping strength

CTI 325*

Surge category

Insulation group

III a*

Dielectric strength

3 kV

Approved by

UL / ULC E96569

Materials

Housing

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Colour of housing

natural, other colours

on request

Contact

CuZn

Contact finishing

* Depending on material

cOnnecTOR SYSTeM | PiTch 4.2 MM

S-fiT 4.20

deScRiPTiOn Of SYSTeM

  Universal connector system for internal equipment wiring
  Applicable as flying lead coupling, for panel mounting or for printed circuit board contacting
  Available in a range of versions and materials
  Crimp contacts are touch-protected into the housing located
  Cable exit 180°

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Pitch

5 mm

Positions

2 - 10

Termination

IDC

Wire size

0.35 - 0.75 mm

Insulation Ø

max. 2.4 mm

Hardness of insulation

Shore A 90° ± 5

Type of wire

stranded

Temperature range

-40 °C ...+ 120 °C

Board thickness

1.55 ± 0.19 mm

Electrical

Rated current

Direct connector 6 A

Indirect connector 10 A / 2 - 4 way

Rated voltage

250 V

Dielectric strength

2.8 kV

Insulation resistance

> 10

Contact resistance

< 10 m

Air gap and creeping distances

> 3.2 mm

Creeping strength

CTI 400

Approved by

DIN EN 61984 (IEC 61984)

UL / ULC E96569

Materials

Contact

Socket: CuSn

Cu-alloy

Pin: CuZn

Contact finishing

Socket: Sn

Pin: Sn

Housing

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Colour of housing

natural

Polarizing

to RAST 2.5

cOnnecTOR SYSTeM | PiTch 5 MM

ecO-TROnic pro

deScRiPTiOn Of SYSTeM

IDC housings

Direct and indirect connectors with IDC termination in according to the RAST 2.5 standard

specification for domestic appliances

Trimming polarizing pegs to individual requirements produces a large number of clearly defined

connector combinations

With direct edge versions, polarizing and locking feature for PCB

Pin connectors

Versions for vertical or horizontal PC board assembly

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Pitch

5 mm

Positions

Direct connector

2 - 12

Indirect connector

1 - 12

Locking features

Direct connector

PCB

Indirect connector

inside and outside

Termination

IDC

Wire size

Direct connector

0.5 - 0.75 mm

Indirect connector

0.35 - 1.5 mm²

Insulation diameter

3.0 mm

Cable exit 180°

max. 2.4 mm

Type of wire

stranded

Temperature range

- 40 °C ...+ 110 °C

Electrical

Rated current

Direct connector

6 A

Indirect connector

16 A

Rated voltage

250 V

Delectrical strength

3.0 kV

Insulation resistance

Contact resistance

5 m

Air gap

3 mm

Creeping distance

3.6 mm

Creeping strength

CTI 400

Approved by

DIN EN 61984 (IEC 61984)

UL / ULC E96569

Materials

Contakt

Socket: CuSn

Contact finishing

Socket: Sn

Housing

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Colour of housing

natural

cOnnecTOR SYSTeM | PiTch 5 MM

ecO-dOMO nf

deScRiPTiOn Of SYSTeM

IDC housings

Direct and indirect connector with IDC termination in accordance with the RAST 5 standard

specifications for domestic appliances, with locking features inside or outside

Direct connector with central polarizing and polarizing pegs at sides, locking features for PCB
Cable exit 90° and 180° according to RAST 5

Tab connectors

Versions for vertical or horizontal PC board assembly see series ECO-FLEX M

stocko-broschuere-en-html.html

STOCKO CONTACT

EH 688

EH 699

Technical daTa

Mechanical

Pitch

5 mm

Positions

EH 699

2 – 8

EH 688

1 – 8

EH 788

2 – 6

Locking features

inside

6.3 FSH

Termination

Crimp technology

Wire size

0.5 – 1.5 mm²

Insulation-Ø

max. 3.3 mm

Temperature range

EH 688 / EH 699

-40 ºC ... +120 ºC

EH 788

-40 ºC ... +135 / 140 ºC

Electrical

Rated current

16 A

Rated voltage

250 / 400 V

Dielectrical strength



3.0 kV

Air gap



3 mm

Creeping distance



3 mm

Approved by

EH 688 / EH 699

DIN EN 61984 (IEC 61984)

EH 688

UL / ULC E96569

EH 699

UL E306640

EH 788

UL E306845

Materials

Housing

PA, glow wire resistant,

GWT 750°C acc. to IEC 60335-1

Colour of housing

natural

other colours on request

cOnnecTOR SYSTeM | PiTch 5 MM

ecO-dOMO crimp

deScRiPTiOn Of SYSTeM

Housings

Housing with crimp connection
Dimensions of housing in accordance with RAST 5

standard specification for domestic appliance

  Different polarizing features
  Indirect connector with inside locking device
  Cable exit 90° / 180°

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Positions

2 - 10

Pitch

5 mm

Temperature range

-40 °C ... +130 °C

Panel thickness

0.8 - 1.0 mm

Electrical

Current rating

max. 16 A

Nom. voltage

max. 400 V

Approved by

DIN EN 61984 (IEC 61984)

Materials

Housing

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Contactx

CuZn, Sn

cOnnecTOR SYSTeM | PiTch 5 MM

ecO-dOMO PM

deScRiPTiOn Of SYSTeM

Tab connector

For flying lead or panel mounting
Dimensions of housing in accordance with RAST 5

standard specification for domestic appliance

  Mating connector for series ECO-DOMO NF and ECO-DOMO Crimp
  The connection is made on 6.3 x 0.8 mm tab
  Different codings

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Pitch

5 mm

Positions

2 - 10

Termination

IDC

Wire size

0.5 - 0.75 mm

/ 0.5 + 0.5 mm²

Insulation diameter

2.3 mm

Type of wire

stranded wire

Temperature range

- 40 °C ...+ 110 °C

Electrical

Rated current

10 A

Rated voltage

250 V

Dielectrical strength

2,5 kV

Creeping strength

CTI 400

Air gap and creeping distance

4 mm

Insulation resistance

> 10

Contact resistance

< 10 m

Approved by

DIN EN 61984 (IEC 61984)

Materials

Contact

tabs 6.3 x 0.8 mm

Contact material

CuSn

Contact finishing

Housings

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Colour of housing

natural

cOnnecTOR SYSTeM | PiTch 5 MM

ecO-dOMO Ti

deScRiPTiOn Of SYSTeM

  Tab connector for IDC termination as flying lead coupling or for panel mounting application
  Versions with / without back panel clips
  Cable exits 90°, 180° (optional 270°)



Single and / or twin terminations depending on wire size



Codings in accordance with the RAST 5 standard specifications for domestic appliance



Label optional

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Pitch

5 mm

Positions

- ECO-FLEX M

without inserts

2 - 12

with inserts

2 - 20

- ECO-FLEX ML, BL, MBL;

with inserts or empty spaces

2 - 30*

Pitch

7.5 mm, 10 mm

Termination

soldering

Temperature range

40 ºC … +120 ºC

Electrical

Rated current

- Tab contacts 16 A

- Socket contacts 10 A

- Bridging contacts over IDC 10 A

Rated voltage

250 V

Approved

DIN EN 61984 (IEC 61984)

UL/ULC E96569 (only series MS 941x)

Materials

Housings

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Colour

housing

natural

Tab connector SMT

black

Contacts Tabs

6.3 x 0.8 mm

Contact materials

CuZn / CuSn

Contact surface

* depending on number of inserts or empty spaces, higher pole versions on request

cOnnecTOR SYSTeM | PiTch 5 MM

ecO-fleX

deScRiPTiOn Of SYSTeM

Connector system allowing individual, free contact combinations in accordance with the

RAST 5-standard specification for domestic appliances

  SMT version for vertical PC board assembly
  Versions for vertical or horizontal PC board assembly
  For dual-in-line or in-line hole patterns
  Individual polarizing and positioning possible
  Clear grouping of connecting positions using movable inserts or empty spaces
  Neutral and/or grounded bridging contacts
  Polarizing pegs optional
  Advancing tab contacts as grounded conductor optional

Mating connectors

  Suitable for RAST 5 indirect connectors in screw, crimp, or IDC technology
  8105B / 8105FU (screw type)
  EH 688 / EH 699 (crimp type)
  ECO-DOMO NF (IDC type)

Variants

ECO-FLEX M Tab connector
ECO-FLEX ML Tab connector with bridging contacts
ECO-FLEX BL Socket connector with bridging contacts
ECO-FLEX MBL Connectors in tab/socket combinations with bridging contacts
ECO-FLEX SMT Tab connector SMT

stocko-broschuere-en-html.html

STOCKO CONTACT

deScRiPTiOn Of SYSTeM



Tab connector for IDC termination as

flying lead coupling or for panel mounting application



Different coding variants on request



Cable exit 90°, 270°



Label optional



Mating counterpart e. g. Wiecon 8213 B

Technical daTa

Mechanical

Positions

2 - 13

Pitch

5.08 mm

Termination

IDC

Wire size

0.35 - 0.5 mm²

Temperature range

-40 °C ... +110 °C

Electrical

Rated current

max. 6 A

Rated voltage

250 V

Dielectrical strength

≥

2.5 kV

Insulation resistance

> 10

Contact resistance

< 10 m

Air gap

≥

4 mm

Creeping distances

≥

2.5 mm

Tracking resistance

CTI

≥

250

Materials

Housing

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Colour of housing

natural

Associated contacts

RSB 8199

Contact

CuSn

Contact finishing

cOnnecTOR SYSTeM | PiTch 5,08 MM

S-cOn 5.08

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Pitch

5.08 / 7.62 mm

Positions

1-8 / 11

Termination

crimp

Temperature range

-40 °C...+100 °C, PBT: +125 °C

Wire size crimp contact

0.22-1 mm²

Electrical

Max. current load per contact

4 A

Rated current

3 A

Rated voltage

250 V

Insulation resistance

> 10

Contact resistance

< 10 m

Materials

Housings

PC, 2-way: PBT

Crimp contact

RFB 7851 CuSn tin plated

cOnnecTOR SYSTeM | Pitch 5.08 / 7.62 mm

MKh 2800

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Pitch

6.35 mm

Positions

In-line

2 - 5

Multi-row

6 - 15

Termination

Connector / Counter Part

Crimp

Headers

Solder

Wire size

0.34 - 0.82 mm² / AWG 22-18

0.75 - 2.03 mm² / AWG 18-14

Locking feature

yes

Degree of pollution

Temperature range

-40 °C ... +110 / +120 °C *

Electrical

Rated current

max. 16 A

Rated voltage

400 V

Dielectric strength

2.21 kV

Insulation resistance

Contact resistance

< 10 m

Air gap and creeping distances

4 mm

Creeping strength

CTI 600 / 300 *

Surge category

Insulation group

I / III a *

Approved by

UL E306640 and UL/ULC E96569

VDE tested

Materials

Contact

CuZn, CuSn

Contact finishing

Housing

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Colour of housing

natural

Polarizing

yes

* Depending on material

VDE tested

cOnnecTOR SYSTeM | PiTch 6.35 MM

S-lOcK 6.35

deScRiPTiOn Of SYSTeM

Universal connector system for white goods,

industrial electronics and commercial building
equipment appliances.

Application as flying lead assemblies, panel mounting

and for PCB connections.

2 to 15 positions with crimp contacts and locking

feature outside

  Suitable for power connections up to 16 A
  Headers pre-loaded for PCB assembly
  Cable exit 180°
  Coding via contact types
  Clear positioning

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Positions

Pitch

6.5 mm

Termination

Crimp

Wire size

0.5 - 1.5 mm² (AWG 20-16)

Insulation Ø max.

2.8 mm

Stripping length

4.5 ± 0.5 mm

Locking feature

Locking cap

Temperature range

-40 °C ... +110 °C

Mechanical

Rated current

16 A

Rated voltage

250 V

Overvoltage category

III

Test voltage

1.39 kV / 60 s

Dielectric strength

at housing material

5 kV

Insulation group

III a

Degree of pollution

Creeping strength

CTI

≥

325

Air gap

≥

1.5 mm

Creeping distances

≥

2.5 mm

Insulation resistance

> 10

Ω

Contact resistance

< 10 m

Ω

Materials

Contact material

CuZn

Contact finishing

Housing

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Colour of housing

Different colours

cOnnecTOR SYSTeM | PiTch 6.5 MM

SenSOR PlUG

deScRiPTiOn Of SYSTeM

  2-pole sensor plug
  Pitch 6.5 mm
  Loadable with flag receptacles 4.8 mm RSB 8186
  Cable exit 90°
  Locking cap
  Different colours

stocko-broschuere-en-html.html

STOCKO CONTACT

deScRiPTiOn Of SYSTeM

This connector range, which consists of housings EH 700/4-2 HT and receptacle RSB 8180.1158, is designed to inter-
connect with tabs 6.3 x 0.8 mm to DIN spec. 46244. The housings have a connector spacing of 8 mm and are ideally
suitable to mate with interconnections of electric kitchen hobs.
Temperature range max. 270° C.

cOnnecTOR SYSTeM | PiTch 8 MM

SeRieS Tl 3 hT

Technical daTa

Mechanical

Pitch

8 mm

Positions

1- 4, up to 6-way on request

Termination

Crimp

Wire size

0.5 – 1.5 mm²

Insulation Ø max.

3.3 mm

Coding

yes

Positioning

yes

Locking

possible

Temperature range

-40 °C ... + 270 °C

Mechanical

Rated current

16 A at Tu 240 °C

15 A at Tu 250 °C

Rated voltage

400 V

Contact resistance

< 5 m Ω

Creeping strength

CTI > 175

Approved by

VDE DIN EN 61984 (IEC61984), ÜG130926

UL 1977 / ULC CAN/CSA C22.2, File E96569

Materials

Contacts

RSB 8180.1158 F6,3-1,5

RSB 8220.1158 F6,3-1,5

Contact material

Housing

PPS-V0, glow wire resistant,

GWT 750 °C acc. to IEC 60335

Colour of housing

black

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Poles

1 - 4

Termination

Crimp

Applicable terminals

Socket

RBB 8210

RTB 8211

Split pin, low insertion force

RTB 8212

Wire size

0.35 - 2.03 mm

Temperature range

-40 °C ... + 120 °C

Panel thickness

0.8 mm

Elektrical

Rated current

16 A

Rated voltage

250 V

Dielectrically strength

> 2.21 kV

Insulation resistance

> 10

Contact resistance

< 10 m

Creeping distance

≥ 2.2 mm

Creeping strength

CTI ≥ 400

Materials

Housing

PA, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

Colour of housing

natural

Contact material

CuZn or CuSn

Contact finishing

ciRcUlaR cOnnecTOR

Mh 2490 / MV 2490

deScRiPTiOn Of SYSTeM

  1 to 4 poles circular connector
  Round contacts for crimp termination
  Sealed according to IP44
  Two-sided external locking latches
  Possibility of coding
  Single or hose cable
  Cable exit 180°
  Clamping possibility for lateral plate cut out
  Housing rip

stocko-broschuere-en-html.html

STOCKO CONTACT

Technical daTa

Mechanical

Positions

up to 40

Termination

soldering

Temperature range

-40 °C...+100 °C

Electrical

Max. current load per contact

Rated current

Rated voltage

Insulation resistance

Contact resistance

Materials

Contact

CuZn

Contact finishing

Housings

PBT

PC, glow wire resistant,

GWT 750 °C acc. to IEC 60335-1

* Electrical data are dependent on the application.

Information is available on request.

PiTch 2.54 MM

Pin STRiPS

VeRSiOnS

  vertical
  horizontal
  single row

stocko-broschuere-en-html.html

STOCKO CONTACT

VeRSiOnS

Single or multi-way housings for receptacles and tabs,
available in following versions

  Glow wire resistant, GWT 750 °C acc. to IEC 60335-1
  Flammability class UL 94 V2 or V0
  Natural or in different colours

STOCKO products are fully tested at our laboratories. VDE, UL / ULC and other approvals for the main STOCKO
items are regularly updated.

Technical data sheets are available on request.

inSUlaTiOn hOUSinGS

stocko-broschuere-en-html.html

STOCKO CONTACT

STOCKO products are fully tested at our laboratories. VDE, UL / ULC and other approvals for the main STOCKO
items are regularly updated.

Technical data sheets are available on request.

Receptacles for tab width 2.8 mm, in versions permanently engaged, with low insertion force,
as timer contact, inserted into housing3,5

Material:

brass, phosphor bronze or steel, other materials on request

Finishing:

natural, tin plated or nickel plated

Wire size:

0.14 -1.5 mm² / AWG 26 –16

Tab thickness:

0.5 - 0.8 mm in accordance with DIN or IEC specifications

Temperature range: - 40 °C to +300 °C

Receptacles for tab width 6.3 mm, in versions self locking, permanently engaged, with low
insertion force, as timer contact, inserted into housing, suitable for RAST 5 connector housings

Material:

brass, phosphor bronze or steel, other materials on request

Finishing:

natural, tin plated or nickel plated

Wire size:

0.2 - 6 mm² / AWG 24 - 10

Tab thickness:

0.8 mm in accordance with DIN or IEC specifications

Temperature range: - 40 °C to +300 °C

Receptacles for tab width 4.8 mm, in versions self-locking, permanently engaged, with low
insertion force, inserted into housing

Material:

brass, phosphor bronze or steel, other materials on request

Finishing:

natural, tin plated or nickel plated

Wire size:

0.14 - 2.5 mm² / AWG 26 - 14

Tab thickness:

0.5 - 0.8 mm in accordance with DIN or IEC specifications

Temperature range: - 40 °C to +300 °C

cRiMP cOnTacTS in BandOlieR fORM

stocko-broschuere-en-html.html

STOCKO CONTACT

STOCKO products are fully tested at our laboratories. VDE, UL / ULC and other approvals for the main STOCKO
items are regularly updated.
Technical data sheets are available on reques

Open barrel terminals in ring or c-type version, with or without insulation crimp

Drill hole diameter: 2.3 - 10 mm
Wire size: 0.25 - 20 mm² / AWG 22 - 4

Complementary to our product range “Crimp Contacts”, STOCKO offers

  Circular sockets
  Circular pins
  PC board contacts
  Miscellaneous special types

End splices with or without insulation crimp

  For longitudinal or transverse transport
  For stranded or enamel wires
  Wire size: 0.2 - 16 mm² / AWG 24 - 6

Tabs 2.8 / 4.8 or 6.3 mm wide for STOCKO receptacles

  For crimping
  For PC Board assembly
  Weld tabs

cRiMP cOnTacTS in BandOlieR fORM

stocko-broschuere-en-html.html

STOCKO CONTACT

SPaRK PlUG cOnnecTORS

iGniTiOn lOcK

ScRUBBeR BRacKeT

SPaRK PlUG cOnnecTORS

STANDARD PROGRAM AND CUSTOM DESIGN SOLUTIONS

aUTOMOTiVe

stocko-broschuere-en-html.html

STOCKO CONTACT

ncc PlUG-in

Bulb holder HiperVision New Cap Concept i. a. for turn indicator or daytime running light

  crimp acc. to VW 60330
  unsealed
  plug-in-Interface
  various hand grips and covers are available

ncc BajOneT

Bulb holder HiperVision New Cap Concept i. a. for turn indicator or fog lamp

  connector socket
  sealed
  bayonet-Interface

Bulb holder for headlight H7
Different contours and grips

Bulb holder for turn indicator and parklight
Customized parts on request

EXAMPLES FOR CUSTOM DESIGN SOLUTIONS

aUTOMOTiVe

stocko-broschuere-en-html.html

STOCKO CONTACT

STaMPinG PaRTS

Precision in big dimension

We have transferred our well-known and usual high precision in the fine blanking range also to big stamping parts. By
request, we develop, validate and produce stamping/bending parts with smallest shape and position tolerances, e.g.
with regard to solderless terminals and current bridges, in order to meet at any time the increasing precision and quality
requirements in the automotive sector.

Features

  Press capacity up to 160 tons
  Sheet thicknesses up to 5 mm
  Band widths up to 300 mm
  Part size up to 120 x 250 mm
  Copper metals, aluminium and steels

EXAMPLES FOR CUSTOM DESIGN SOLUTIONS

aUTOMOTiVe

88 mm

72 mm

max 250 mm

125 mm

stocko-broschuere-en-html.html

STOCKO CONTACT

cUSTOMeR-SPecific clinch fRaMeS

  Direct-Connector as an option
  With or without overmoulding
  Contour-forming, also 3D
  Part size up to 12O x 25O mm
  Full-, selective-, or special-finishing
  Various metals and plastics,

standard to high temperature

EXAMPLES FOR CUSTOM DESIGN SOLUTIONS

aUTOMOTiVe

stocko-broschuere-en-html.html

STOCKO CONTACT

BUSBaR

  Sheet thickness up to 5 mm
  Part size up to 12O x 25O mm
  With or without overmoulding
  Usage:

Fuse Box

Power distribution

Customer specific applications

Combinable with fuse- and

relay-contacts

Specific materials and surfaces

EXAMPLES FOR CUSTOM DESIGN SOLUTIONS

aUTOMOTiVe

stocko-broschuere-en-html.html

STOCKO CONTACT

lOUdSPeaKeR MOdUle

Centre disc and contact unit for miniature loudspeakers 13 mm dia.

Application

Mobile telephones

chaRGe cOnTacTS fOR BaTTeRY ShaVeRS

RinG TeRMinalS wiTh aSSeMBled nUT

eXaMPleS fOR cUSTOM deSiGn SOlUTiOnS

stocko-broschuere-en-html.html

STOCKO CONTACT

  Solderless terminals with and without insulation
  Pin terminals
  Parallel splices
  Butt splices
  Tabs
  Terminating technology:

Cable stripper, hand tools, electrical and hydraulic crimping tools

SOldeRleSS TeRMinalS

stocko-broschuere-en-html.html

STOCKO CONTACT

The quality and reliability of an electrical connection depend largely on the terminating technology.
Consequently, STOCKO offers an economical and efficient terminating technique for every product.
Whatever the particular requirements and production quantities are, we offer state-of-the art tools and machinery.
From a simple hand tool to semi-automated machines and to fully automated machines of modular construction
incorporating ”Just-in-Time” functions, Computer controlled machine operation, automated quality control, modem
connection for remote diagnostics, and the option to program sequences in cableform output.
With the object in mind improving our customers’ productivity through optimum production rationalization.
A qualified STOCKO team of service engineers is always at your disposal for advice and practical assistance. In an
emergency, they attend to prompt machine maintenance and carry out preventative servicing tasks.

1 Service hand tool for IDC connector systems
2 STOCKOMAT ECO-DOMO professional line

Semi-automated terminating machine for connector ECO-DOMO according to RAST 5 specification

3 STOCKOMAT CRIMP professional line

Semi-automatic terminating machine for crimp contacts in bandolier form

4 ECO-MASTER

Fully automated terminating machine for connector series ECO-TRONIC, ECO-TRONIC pro and
crimp contacts.

TeRMinaTinG TechnOlOGY

stocko-broschuere-en-html.html

STOCKO CONTACT

contact adreSSeS

Great Britain

Cablectrix Ltd.

9/10 James Watt Close
Drayton Field Industrial Estate
Daventry, Northants NN11 8QU, UK
Phone: +44 1327 876769
Fax:

+44 1327 300130

E-Mail: sales@cablectrix.co.uk

J-Tronics Ltd

1 Granger Avenue
Acomb
York, YO26 5LF, UK
Phone: +44 1904 795690
Fax:

+44 1904 790887

E-Mail: julie@j-tronics.co.uk

If you need a design partner
for harnesses contact:
gareth@j-tronics.co.uk

New Force Ltd

Fair Crest
Conghurst Lane
Hawkhurst
Cranbrook
Kent
TN18 5DZ
TPhone: 01580 752014
E-Mail: sales@new-force.co.uk

Hungary

CZINEGE és FIAI Kft.

Pesti ucta 36,

H-5100 - Jászberény
Phone: +36 057 500190
Fax:

+36 057 500191

E-Mail: czinege@czinege.hu

India, Sri Lanka, UAE

AURO CONTROLS PRIVATE LIMITED

Florina Apartment, 6th Floor,
Survey No. 2/1/7, Erandwane,
Pune 411004 INDIA
Phone: +912025465915
E-Mail: sales@aurocontrols.com

Indonesia

PT. Esecodharma Permai

Green Sedayu Biz Park Daan Mogot
JL. Raya Daan Mogot KM.18
Blok DM-2 No.18, Jakarta Barat, 11840
Phone: +62 21 5696 8822
Fax: +62 21 5696 8811
E-Mail: eseco-mkt@eseco.co.id

Irland, Republik of

Cablectrix Ltd.

9/10 James Watt Close
Drayton Field Industrial Estate
Daventry, Northants NN11 8QU, UK
Phone: +44 1327 876769
Fax:

+44 1327 300130

E-Mail: sales@cablectrix.co.uk

Italy

KLEMI Contact Srl

via Monferrato, 43

20098 San Giuliano Milanese (MI)
Italy
Phone:  39-02-5560.6101
Fax:   +39-02-5560.7134
E-Mail:  klemi@klemi-contact.com

Germany

Head Office

STOCKO Contact GmbH & Co. KG
Simonshöfchen 31
42327 Wuppertal
Phone: +49 202 9733 - 2
Fax:

+49 202 9733 - 411

E-Mail: info@stocko-contact.com

STOCKO Contact GmbH & Co. KG

Oleftalstr. 26
53940 Hellenthal
Phone: +49 2482 84 - 0
Fax:

+49 2482 84 - 240

E-Mail: hellenthal@stocko-contact.com
E-Mail: service-idc@stocko-contact.com

Lorenzgroup Electronic

Distribution und Vertriebsgesellschaft mbH
Schieferstein 6
65439 Flörsheim
Phone: +49 6145 9599-0
Fax:

+49 6145 9599-40

E-Mail: info@lorenzgroup.com

HZ GmbH

Technische Kunststoffe & Elektrische
Verbindungstechnik
Johannes-Giesser-Straße 11
71364 Winnenden-Hertmannsweiler
Phone: +49 7195 59069 - 22
Fax:

+49 7195 59069 - 29

E-Mail: mail@hz-gmbh.com

Hoppe & Co. Electronic

Inhaber Hans Zeltner e.K.
Thomas-Mann-Straße 50
90471 Nürnberg

Phone: +49 911 327175
Fax:

+49 911 327141

E-Mail: info@hoppe-electronic.de

zeb elektroTECHNIK GmbH

Thomas-Mann-Straße 50
90471 Nürnberg
Phone: +49 911 323957-0
Fax:

+49 911 327141

E-Mail: info@zeb-gmbh.de

ETB Electronic Team

Beratungs- und Vertriebs GmbH
Wundramweg 1
31303 Burgdorf
Phone: +49 5136 97229-0
Fax:

+49 5136 972 9-39

E-Mail: info@etb-electronic.de

Australia

Braemac Pty Ltd

1/59-61 Burrows Road, Alexandria
Sydney, NSW 2015 Australia
Phone: +61 2 95506600
Fax:

+61 2 95506377

E-Mail: info@braemac.com.au

Austria

CODICO GmbH

Zwingenstraße 6-8
A-2380 Perchtoldsdorf
Phone: +43 01 86305-0
Fax:

+43 01 86305-5000

E-Mail: office@codico.com

Croatia, Slovakia, Slovenia, Czech Rep.

(via Codico Partner)

CODICO GmbH

Zwingenstraße 6-8
A-2380 Perchtoldsdorf
Phone: +43 01 86305-0
Fax:

+43 01 86305-5000

E-Mail: office@codico.com

Denmark

MATECH SYSTEMS A/S
Ankelbovej 6

7190 Billund
Denmark
Phone: +45 75 338949
Fax:

+45 75 338946

E-Mail: info@matechsystems.dk

Estonia, Latvia, Lithuenia

Adcontact/Gammeter

Paldiski mnt 31
EE - 76606 Keila, Harjumaa
Phone: +372 671 2251
Fax:

+372 671 2253

Mobile: +372 50 89343
E-Mail: info@gammeter.ee

Finland

Adcontact AB Filial I Finland

GAMMETER
Vehnämyllynkatu 6
FIN-33560 Tammerfors
Finland
Phone: +358 3 3802211
Fax:

+358 3 3802244

E-Mail: info@gammeter.fi

France

STOCKO CONTACT Eurl

7, Route d’Eichhoffen
CS 40017 Andlau
67145 - BARR Cedex
Phone: +33 388 585858
Fax:

+33 388 585888

E-Mail: andlau@stocko-contact.com

M. Roland DOTIGNY

4 Rue Rougette
60240 Liancourt St Pierre

Phone: +33 3 44479168
Fax:

+33 3 44479168

E-Mail: roland.dotigny@stocko-contact.com

(Parisienne, Ouest, Normandie, Nord)

CONNECT-SYSTEMES

31, Impasse de la Balme

69800 Saint-Priest
Phone: +33 4 78901315
Fax:

+33 4 78906332

E-Mail: commercial@connect-systemes.fr

(Rôhne-Alpes, Sud, Centre, Est)

Greece

S. SAKELLIOU & CO O.E.

Manufacturer’s Agents
15B Konstantinidou str.
K. Patissia 104 45 - Athens
Phone: +30 2 108322611
Fax:

+30 2 108325444

E-Mail: info@sasta.grr

Belgium, Luxembourg

ATEM N.V./S.A.

Bedrijvenpark De Veert 4
B-2830 Willebroek
Phone: +32 03 8661800
Fax:

+32 03 8661828

E-Mail: info@atem.be

Brazil, South America

STOCKO CONTACT Brasil Ltda.

Av. Paulista, 1439 – 1°andar Cj12
01311-200 São Paulo / SP / Brasil
Phone:   +55 11 4890 2223
Mobile:  +55 11 94251 2450
E-Mail:  brazil@stocko-contact.com

Canada

WIELAND Electric Inc.

2889 Brighton Rd.
Oakville, ON L6H 6C9
Phone: (905) 829-8414 or 1-800-Wieland
Fax:

(905) 829-8413

E-Mail: technical.support@

wieland.electric.com

China

STOCKO Contact GmbH & Co. KG

c/o Wieland Electric
Trading (Shanghai) Co. Ltd.
7F, East Huaihai Int‘l Mansion,
No 49 Huaihai Road (E),
Huang Pu District, Shanghai
200010, PRC
Phone:  +86 21  63555772-126
   63555772-127
Fax:

+86 21 6355 0090

Mobile: +86 136 36435222
E-Mail: china@stocko-contact.com

STOCKO Contact GmbH & Co. KG

#3-601, No.42 Dongshan 4th Road,
Qingdao 266100, P.R.China
Mobile: +86 139 69760609
Fax:

+86 532 / 66870622

E-Mail: china@stocko-contact.com

STOCKO Contact GmbH & Co. KG

No 147-149, Changping Avenue,
Lian Guan Plaza, Room 1520,
Guangdong Province, Dongguan City,
Changping Town 523560,
P.R.China
Mobile: +86 137 1278 7427
E-Mail: china@stocko-contact.com

STOCKO Contact GmbH & Co. KG

Unit 08-1-302, No.184 Taishan Road
New district Changzhou 213022,
P.R.China
Mobil:   +86 136 85216240
E-Mail:  china@stocko-contact.com

WG Industrial Control Equipment

Suit. 22, No. 328, Hengyong RD
Jiading District
201806 Shanghai, P.R.China

Phone: +86 21 34533671

Fax:

+86 21 34311361

E-Mail: sales@wg-ind.com

stocko-broschuere-en-html.html

STOCKO CONTACT

Distribution

Plant

Representation

Subsidiary

Sales Office

Japan

STOCKO CONTACT GmbH & Co.KG

c/o Wieland Electric Co., Ltd.
Nisso No. 16 Bldg. 3-8-8
Shin-Yokohama Kohoku-ku Yokohama
222-0033 Japan
Phone:  +81-45-473-5085
Fax:   +81-45-470-5408
E-Mail:  japan@stocko-contact.com

Korea

Sam Tra International

Hoseo Venture Tower 609 Ho
319 Gasan-dong
Geumcheon-gu, Seoul 153-711
Korea
Phone: +82 2 26275625
Fax:

+82 2 26275629

E-Mail: sales@samtra.co.kr

Stocko Contact GmbH & Co. KG

Korea Office
Level 41, Gangnam Finance Center
152 Teheran-ro, Gangnam-gu,
Seoul 06236
Korea
Phone:   +82 2 2008 4580
Mobile:  +82 10 5809 5970
Fax:

+82 2 2008 4555

E-Mail: korea@stocko-contact.com

Malaysia

C.T.M. Industries Sdn. Bhd

(Penang Office)
14 & 16 Lorong Nagasari 4,
Kawasan Perusahaan Prai,
13600 Prai, Malaysia.
Phone: +60 4 397 9202
Fax: +60 4 397 9155
E-Mail: pg-ctm@ese-group.com

C.T.M. Industries Sdn. Bhd

(Kuala Lumpur Office)
Suite 719, Blk B2,
Leisure Commerce Square,
No. 9, Jalan PJS 8/9,
46150 Petaling Jaya,
Selangor Darul Ehsan, Malaysia.
Phone:  +60 3 7875 3212
Fax:   +60 3 7875 3302
Email:   pg-ctm@ese-group.com

Mexico

STOCKO CONTACT GmbH & Co. KG

Sales Offfice Texas
El Paso
Phone: +1 915 309 5363
E-Mail: Mexico@stocko-contact.com

Netherlands

AVT Industrial Components

Freddy van Riemsdijkweg 7
5657 EE Eindhoven
Phone: +31 40 2088088
Fax.: +31-40-2088099
E-Mail: sales@avtic.com

Norway

Adcontact/Gammeter
P.O. Box 246 Skøyen

N-0213 Oslo
Phone: +47 22417700
Fax:

+47 22417701

E-Mail: info@adcontakt.se

Philippines

C.T.P. Industries, Inc

Unit # 1001 Primeland Tower,
2218 Market Street,
Madrigal Business Park, Ayala Alabang,
Muntinlupa City, Philippines 1771
Phone:  +63 2 245 0632 / 245 0639
Fax:   +63 2 836 7968
E-Mail: admin@ctp.com.ph

Poland

EVOLTEC Tomasz Pawlowski

ul. Bekasóv 63/65
02-803 Warszawa
TPhone:+48 22 550 27 40-44
Tel.: +48 22 550 27 47
Fax:

+48 22 550 27 45

E-Mail: info@evoltec.pl

Portugal

STOCKO CONTACT GmbH & Co. KG

Sales Office Spain / Portugal
F. Rius i Taulet, 19-3°
E-08850 Gavà (Barcelona)

Phone: +34 936 627188
Fax:

+34 936 627188

Mobile: +34 676 490974
E-Mail: spain@stocko-contact.com

Russia

CE Engineering

Krasnokazarmennaya 3 build 5
Moscow 111250
Russia
Tel.: +7 495 2563541
Fax:

+7 495 9671561

E-Mail: info@faston.ru

ELCO Group LLC

13A, Building 4, Structure 4
Varshavskoye Shosse
Moscow 115230
Phone: +7 495 9818516
Fax:

+7 495 7750255

E-Mail: info@elcogroup.ru

Belarus

FEK Company

Pushkina 29-B
220016 MINSK
Belarus
Phone:  +375 17 2102189
Fax:   +375 17 2102189
E-Mail:  info@fek.by

Singapore

STOCKO Contact GmbH & Co. KG

Liaison Office Singapur
Blk 5, Rivervale Crescent
# 08-05 Singapore 545084

Mobile: +65 91 832131
E-Mail: singapore@stocko-contact.com

C.T.S. Industries Pte Ltd

47 Kaki Bukit Place,
Eunos Techpark,
Singapore 416225
Phone: +65 6276 3328
Fax: +65 6276 3336
E-Mail: sales_cts@ese.com.sg

Sweden

Adcontact/Gammeter
Ursviksv. 127B

P.O. Box 7044
S-17407 Sundbyberg
Phone: +46 8 4453600
Fax:

+46 8 4453610

E-Mail: info@adcontact.se

Switzerland

AWAG Elektrotechnik AG

Sandbüelstrasse 2

CH-8604 Volketswil
Phone: +41 044 9081919
Fax:

+41 044 9081999

E-Mail: info@awag.ch

Spain

STOCKO CONTACT GmbH & Co. KG

Sales Office Spain / Portugal
F. Rius i Taulet, 19-3°
E-08850 Gavà (Barcelona)

Phone: +34 936 627188
Fax:

+34 936 627188

Mobile: +34 676 490974
E-Mail: spain@stocko-contact.com

TC Componentes, S.L.

Cami de Can Calders,6 12-G
E-08173 Sant Cugat del Vallès
Barcelona

Phone: +34 93 590 28 30
Fax:

+34 93 590 02 67

E-Mail: info@tc-componentes.es

South Africa

APT Advanced Product Technology (PTY) LTD.

Corner Remblok and Langwa street
Strijdom Park
Randburg
South Africa1 7926010
Fax:

+27 11 7929879

E-Mail: craig@aptsa.co.za

Taiwan

Cian Shin Industrial Co.,LTD

4F., No.33, Ren’ai St. Tamsui Dist.,
New Taipei City 25168 Taiwan (R.O.C.)
Phone:  +886 2 26230681
Fax:   +886 2 26231920
E-Mail: sales@cianshin.com.tw

Thailand

ST Global Industries Co., Ltd.

36 Moo 4, Tambon Pimpha
Amphur Bangpakong
Chachoengsao, 24130
Thailand
Phone: +66 38 595983
Fax: +66 38 595363
E-Mail: stglobal@st-global.co.th

Turkey

STOCKO CONTACT GmbH & Co. KG

Istanbul Liaison Office
Atakoy 11. Kisim, Cigdem D Blok, D:33
34158 Istanbul / TURKIYE
Phone: +90 212 6618710
Fax:

+90 212 6618720

E-Mail: info@stockotr.com

USA

STOCKO CONTACT GmbH & Co. KG

Sales Office Michigan
Detroit
Cell: +1 248 5719596
E-Mail: usa@stocko-contact.com

STOCKO CONTACT GmbH & Co. KG

Sales Office Illinois
Chicago
913 N Neva Ave
Addison, IL 60101
Cell: +1 630 5185089

E-Mail: usa@stocko-contact.com

STOCKO CONTACT GmbH & Co. KG

Sales Offfice Texas
El Paso
Cell: +1 915 309 5363
E-Mail: usa@stocko-contact.com

STOCKO CONTACT GmbH & Co. KG

Sales Office Kentucky
Morehead
Cell.: +1 606 356 3499
E-Mail: usa@stocko-contact.com

Vietnam

C.T.S. Industries (Indochina) Co., Ltd

(Hanoi Head Office)
165 Thai Ha Street, Lang Ha Ward,
Song Hong Land Office Building,
Unit 2, 5th Floor,
Dong Da District, Hanoi, Vietnam
Phone:  +84 4 3203 2999
Fax:   +84 4 3201 2999
E-Mail:  sales@ctsindochina.com.vn

C.T.S. Industries (Indochina) Co., Ltd

(Ho Chi Minh Branch Office)
5th Floor, Mekong Tower,
235 - 241 Cong Hoa Street.,
Tan Binh District,
Ho Chi Minh City, Vietnam
Tel:   +84 8 3600 0826
Fax:   +84 8 6281 6568

E-Mail: sales@ctsindochina.com.vn

stocko-broschuere-en-html.html

Ref. Nr. 378422
Printed in Germany 07 / 20

STOCKO CONTACT

GmbH & Co. KG

Simonshöfchen 31
D-42327 Wuppertal

Phone

+49 202 9733 - 2

Fax +49 202 9733 - 411

E-Mail

info@stocko-contact.com

Internet www.stocko-contact.com

A Member of the Wieland Group
