CROSS REFERENCE GUIDE

GENERAL PURPOSE

CERAMIC CAPACITORS

C SERIES

Ceramic Capacitors are made up of a
monolithic structure which provides
excellent long term reliability, and come in a
wide variety of case sizes and dielectrics.

PRODUCT CROSSES TO:

Manufacturer Series

AVX

Ceramic Capacitors

Cal-Chip GMC

Johanson Dielectronics

201

Kemet

Murata

GRM

Nic NMC

Novacap

0805

Panasonic

ECJ

Samsung CL

Taiyo Yuden

TDK C

Vishay / Vitramon

Walsin 0805

Yageo CC

CONTENTS

CROSS REFERENCE GUIDE

AVX

CAL-CHIP - GMC SERIES

JOHANSON DIELECTRICS

KEMET - C SERIES

MURATA - GRM SERIES

NIC - NMC SERIES

NOVACAP - 0805 SERIES

PANASONIC - ECJ SERIES

SAMSUNG - CL SERIES

TAIYO YUDEN - M SERIES

TDK - C SERIES

VISHAY / VITRAMON - VJ SERIES

WALSIN - 0805 SERIES

YAGEO - CC SERIES

CROSS REFERENCE GUIDE

Venkel Part Number Structure

0603
0805
1206
1210
1808
1812
1825
2220
2225

6 = 6.3V
Z = 10V
Y = 16V
3 = 25V
5 = 50V
1 = 100V

A = C0G/NP0
C = X7R

1st two digits are significant;
third digit denotes number
of zeros,
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

B = ±0.1pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
N = ± 30%

AVX Part Number Structure

AVX

0805

5 C 103

K A T 2 A

SIZE (EIA)

VOLTAGE

DIELECTRIC

CAPACITANCE

TOLERANCE

FAILURE RATE TERMINATION PACKAGING & MARKING

SPECIAL CODE

A = N/A

T = 100%
matte Tin
(Sn) over
Nickel
1 =
Palladium
Silver

1 = 7” Reel Embossed/Unmarked
2 = 7” Reel Paper/Unmarked
3 = 13” Reel Embossed/Unmarked
4 = 13” Reel Paper/Unmarked
M = 7” Reel Embossed/Marked
N = 7” Reel Paper/Marked
R = 13” Reel Embossed/Marked
S = 13” Reel Paper/Marked
9 = Bulk/Unmarked
B = Bulk/Marked

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

AVX PART NUMBER: 08052C103KAT2A CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

A = Standard

CROSS REFERENCE GUIDE

Venkel Part Number Structure

01 = 01005
02 = 0201
04 = 0402
10 = 0603
21 = 0805
31 = 1206
32 = 1210
43 = 1812
45 = 1825
55 = 2220
57 = 2225

CG = C0G
X7R = X7R
X5R = X5R
Y5V = Y5V
Z5U = Z5U

1st two digits are significant;
third digit denotes number
of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

B = ± 0.10pF
C = ± 0.25pF
D = ± 0.50pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

CAL-CHIP Part Number Structure

CAL-CHIP

GMC

21 X7R

104 K 50 N T LF

SERIES

SIZE (EIA)

DIELECTRIC

CAPACITANCE

TOLERANCE

VOLTAGE

TERMINATION

PACKAGING

OPTIONAL IDENTIFIER

4R0 = 4V
6R3 = 6.3V
10 = 10V
16 = 16V
25 = 25V
50 = 50V
100 = 100V

N = 100% matte
Tin (Sn) over Nickel

T = Tape and
Reel

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

CAL-CHIP PART NUMBER: GMC21X7R104K50NT-LF CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

LF = Optional Identifier to
designate the part is Lead
Free

CROSS REFERENCE GUIDE

Venkel Part Number Structure

100 = 10V
160 = 16V
250 = 25V
500 = 50V
101 = 100V

R14 = 0603
R15 = 0805
R18 = 1206
R29 = 1808
S43 = 1812
S41 = 1210
S49 = 1825
S48 = 2225

N = C0G/NP0
W = X7R

1st two digits are significant;
third digit denotes number
of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

*C = ± 0.25 pF
*D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
N = ± 30%
* For values
less than
10pF only

Johanson Dielectrics Part Number Structure

JOHANSON DIELECTRICS

500

R15

104

K V 4 T

VOLTAGE

SIZE

(EIA)

DIELECTRIC

CAPACITANCE

TOLERANCE

FAILURE

RATE

MARKING

PACKAGING

V = 100% matte Tin
(Sn) over Nickel
P = Palladium Silver

4 = Unmarked
6 = EIA “J” Code*
*Not available on 0603 sizes

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

JOHANSON DIELECTRICS PART NUMBER: 201R15W103KV4T CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

E = 7” Embossed
T = 7” Paper
U = 13” Embossed
R = 13” Paper
None = Bulk Pack

CROSS REFERENCE GUIDE

Venkel Part Number Structure

0201
0402
0603
0805
1206
1210
1808
1812
1825
2220
2225

C = Standard

1st two digits are significant;
third digit denotes number
of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

B = ± 0.10 pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

Kemet Part Number Structure

KEMET

C 0805

C 104

K 5 R A C TU

CERAMIC

SIZE (EIA)

SERIES

CAPACITANCE

TOLERANCE

VOLTAGE

DIELECTRIC

FAILURE RATE TERMINATION PACKAGING

7 = 4V
9 = 6.3V
8 = 10V
4 = 16V
3 = 25V
5 = 50V
1 = 100V

P = X5R
G = C0G/NP0
R = X7R
U = Z5U
V = Y5V

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

KEMET PART NUMBER: C0805C104K5RACTU CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

A = Standard C = 100%

matte
Tin (Sn) over
Nickel

TU = 7” Reel Unmarked
TM = 7” Reel Marked
Blank = Bulk

CROSS REFERENCE GUIDE

Venkel Part Number Structure

M = 100%
matte Tin
(Sn) over
Nickel
Termination
G =
Palladium
Silver Termi-
nation

03 = 0201
15 = 0402
18 = 0603
21 = 0805
31 = 1206
32 = 1210
42 = 1808
43 = 1812
58 = 2220

2 = 0.2mm
3 = 0.3mm
5 = 0.5mm
6 = 0.6mm
7 = 0.7mm
8 = 0.8mm
9 = 0.85mm
A = 1.0mm
B = 1.25mm
C = 1.6mm
D = 2.0mm

E = 2.5mm
F = 3.2mm
M = 1.15mm
N = 1.35mm
Q = 1.5mm
R = 1.8mm
S = 2.8mm
X = Factory

5C = C0G/NP0
R6 = X5R
R7 = X7R
F5 = Y5V
E4 = Z5U

Murata Part Number Structure

MURATA

B R7

104

K A01

PRODUCT ID

SERIES

SIZE (EIA)

THICKNESS

DIELECTRIC

VOLTAGE

CAPACITANCE

TOLERANCE

SPECIAL CODE PACKAGING

0G = 4V
0J = 6.3V
1A = 10V
1C = 16V
1E = 25V
1H = 50V
2A = 100V

1st two digits are significant;
third digit denotes number
of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

MURATA PART NUMBER: GRM21BR71H104KA01L CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

B = ± 0.10 pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

L = 7” Plastic
D = 7” Paper
K = 13”
Plastic
J = 13” Paper
E = 7” Special
F = 13”
Special
B = Bulk

CROSS REFERENCE GUIDE

Venkel Part Number Structure

0201
0402
0603
0805
1206
1210
1808
1812
1825
2225

C0G/NP0
X7R
X5R
Z5U
Y5V

1st two digits are significant;
third digit denotes number
of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

B = ± 0.10 pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

NIC Part Number Structure

NIC

NMC

0805

X7R

104

K 50

TRP

STYLE

SIZE

(EIA)

DIELECTRIC

CAPACITANCE

TOLERANCE

VOLTAGE

PACKAGING

MARKING

4 = 4V
6.3 = 6.3V
10 = 10V
16 = 16V
25 = 25V
50 = 50V
100 = 100V

TRP = Paper Tape / Plastic Reel
TRPLP = Plastic Tape / Plastic Reel

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

NIC PART NUMBER: NMC0805X7R104K50TRPF CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

M = Marked
None =
Unmarked

F = RoHS
Compliant

CROSS REFERENCE GUIDE

Venkel Part Number Structure

0201
0402
0603
0805
1206
1210
1808
1812
1825
2220
2225

N = C0G/NP0
B = X7R
W = X5R
Z = Z5U
Y = Y5V

1st two digits are significant;
third digit denotes number
of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

B = ± 0.10 pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

Novacap Part Number Structure

NOVACAP

0805

B 104

K 500

N T

SIZE

(EIA)

DIELECTRIC

CAPACITANCE

TOLERANCE

VOLTAGE

TERMINATION

PACKAGING

MARKING

100 = 100V
160 = 16V
250 = 25V
500 = 50V
101 = 100V

N = 100% matte Tin (Sn) over Nickel
P = Palladium Silver
Y = Tin & Lead
(90% Tin (Sn) & 10% Lead (Pb)

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

NIC PART NUMBER: 0805B104K500NT CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

T = 7” Paper
N = Bulk

M = Marked
None = Unmarked

CROSS REFERENCE GUIDE

Venkel Part Number Structure

Z = 0201
0 = 0402
1 = 0603
2 = 0805
G = 0805
3 = 1206
D = 1206
M = 1206
4 = 1210
5 = 1812

E = 7” Paper Tape 2mm
V = 7” Paper Tape 4mm
F = 7” Embossed Tape
Y = 7” Embossed Tape
W = 13” 2mm
Z = 13” 4mm
C = Bulk Case

C = C0G/NP0
B = X7R/X5R
F = Y5V

Panasonic Part Number Structure

PANASONIC

ECJ

2 V B 1H

104

STYLE

SIZE

(EIA)

PACKAGING

DIELECTRIC

VOLTAGE

CAPACITANCE

TOLERANCE

0G = 4V
0J = 6.3V
1A = 10V
1C = 16V
1E = 25V
1H = 50V

1st two digits are significant;
third digit denotes number of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

PANASONIC PART NUMBER: ECJ2VB1H104K CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

B = ± 0.10 pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

CROSS REFERENCE GUIDE

Venkel Part Number Structure

03=0201
05=0402
10=0603
21=0805
31=1206
32=1210
43=1812
55=2220

C=C0G/NP0
B=X7R
A=X5R
E=Y5V
F=Z5U

1st two digits
are significant;
third digit
denotes num-
ber of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

B = ± 0.10 pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

Samsung Part Number Structure

SAMSUNG

CL 21 B 104

K B F N N N C

SERIES

SIZE (EIA)

DIELECTRIC

CAPACITANCE TOLERANCE

VOLTAGE

THICKNESS

TERMINATION PRODUCTS

SPECIAL

PACKAGING

R = 4V
Q = 6.3V
P = 10V
O = 16V
A = 25V
B = 50V
C = 100V
D = 200V

3 = 0.30mm
5 = 0.50mm
8 = 0.80mm
9 = 0.90mm
A = 0.85mm
C = 0.85mm
D = 1.00mm
E = 1.10mm
F = 1.25mm
H = 1.60mm
I = 2.00mm
J = 2.50mm
L = 3.20mm
M = 1.15mm

P = 1.15mm
Q = 1.25mm
S = 1.35mm
U = 1.80mm
V = 2.50mm
Y = 1.25mm

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

SAMSUNG PART NUMBER: CL21B104KBFNNNC CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

N = 100%
matte Tin (Sn)
over Nickel

N = Normal

N = Reserved
for Future
Use

B = Bulk
P = Bulk Case
C = Cardboard
Tape, 7” Reel
O = Cardboard
Tape, 13” Reel
D = Cardboard
Tape, 13” Reel
E = Embossed
Tape, 7” Reel
F = Embossed
Tape, 13” Reel
S = E = Em-
bossed Tape,
10” Reel

CROSS REFERENCE GUIDE

Venkel Part Number Structure

0402 = 01005
0603 = 0201
1005 = 0402
1608 = 0603
2012 = 0805
3216 = 1206
3225 = 1210
4532 = 1812
5750 = 2220

C0G/NP0
X7R
X5R
Y5V
Z5U

TDK Part Number Structure

TDK

0805 X7R 1H 104

SERIES

SIZE (EIA)

DIELECTRIC

VOLTAGE

CAPACITANCE

TOLERANCE

0G = 4V
0J = 6.3V
1A = 10V
1C = 16V
1E = 25V
1H = 50V
2A = 100V

1st two digits are significant;
third digit denotes number of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

TDK PART NUMBER: C2012X7R1H104K CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

B = ± 0.10 pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

CROSS REFERENCE GUIDE

Venkel Part Number Structure

A = 4V
J = 6.3V
L = 10V
E = 16V
T = 25V
G = 35V
U = 50V

K = 100%
matte Tin
(Sn) over
Nickel

042 = 01005
063 = 0201
105 = 0402
107 = 0603
212 = 0805
316 = 1206
325 = 1210
432 = 1812
550 = 2220

Taiyo Yuden Part Number Structure

TAIYO YUDEN

U M K 212 B7 104

K Q T

VOLTAGE

SERIES

TERMINATION SIZE (EIA)

DIELECTRIC

CAPACITANCE

TOLERANCE THICKNESS PACKAGING

CG = C0G/NP0
B7 = X7R
BJ = X5R
F = Y5V

1st two digits are significant;
third digit denotes number of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

TAIYO YUDEN NUMBER: UMK212B7104KQ-T CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

B = ± 0.10 pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

C = 0.2mm
P = 0.3mm
V = 0.5mm
K = 0.45mm
A = 0.8mm
D = 0.85mm
G = 1.25mm
L = 1.6mm
N = 1.9mm
Y = 2.0mm
M = 2.5mm

T = Tape (4mm pitch)
F = Tape (2mm pitch)
W = Tape (1mm pitch)
P = Tape (4mm pitch, 1000pcs)

CROSS REFERENCE GUIDE

Venkel Part Number Structure

0402
0603
0805
1206
1210
1812
1825
2220
2225

A = C0G/NP0
Y = X7R
U = Z5U
G = X5R

1st two digits are significant;
third digit denotes number of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

Vishay / Vitramon Part Number Structure

VISHAY / VITRAMON

0805

Y 104

K X A A T

SERIES

SIZE

(EIA)

DIELECTRIC

CAPACITANCE

TOLERANCE

TERMINATION

VOLTAGE

MARKING

PACKAGING

B = ± 0.10 pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

VISHAY / VITRAMON PART NUMBER: VJ0805Y104KXAA CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

X = 100% matte Tin (Sn)
over Nickel
N = Non-Magnetic

S = 4V
Y = 6.3V
Q = 10V
J = 16V
X = 25V
A = 50V
B = 100V

M = Marked
A= Unmarked

R = 13” Plastic
C = 7” Paper
P = 13” Paper
B = Bulk Pack

CROSS REFERENCE GUIDE

Venkel Part Number Structure

0201
0402
0603
0805
1206
1210
1812
2220

Walsin Part Number Structure

WALSIN

0805

B 104

K 500

C T

SIZE (EIA)

DIELECTRIC

CAPACITANCE

TOLERANCE VOLTAGE

TERMINATION

PACKAGING

N = C0G/NP0
B = X7R
X = X5R
F = Y5V

1st two digits are significant;
third digit denotes number of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

WALSIN NUMBER: 0805B104K160CT CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

B = ± 0.10 pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

4R0 = 4V
6R3 = 6.3V
100 = 10V
160 = 16V
250 = 25V
500 = 50V
101 = 100V

C = 100% matte Tin (Sn)
over Nickel

T = 7” Reel
R = 7” Reel (2mm pitch)
G = 13” Reel

CROSS REFERENCE GUIDE

Venkel Part Number Structure

CC = MLCC

0201
0402
0603
0805
1206
1210
1808
1812

B = ± 0.10 pF
C = ± 0.25 pF
D = ± 0.50 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10%
M = ± 20%
Z = +80/-20%

R = 7” Paper
K = 7” Plastic
P = 13” Paper
F = 13” Plastic
C = Bulk Case

Yageo Part Number Structure

YAGEO

0805

K R X7R

9 B B 104

SERIES

SIZE (EIA)

TOLERANCE

PACKAGING

DIELECTRIC

VOLTAGE

TERMINATION

PROCESS CODE

CAPACITANCE

C0G/NP0
X7R
X5R
Y5V

5 = 6.3V
6 = 10V
7 = 16V
8 = 25V
9 = 50V
0 = 100V

C 0805

X7R

500

104

K N

CERAMIC CAPACITOR

SIZE

DIELECTRIC

RATED VOLTAGE

CAPACITANCE TOLERANCE CODE

TERMINATION

PACKAGING

01005
0201
0402
0603
0805
1206
1210
1812
2220
2221

C0G
X7R
X5R
Y5V
Z5U

1st two digits are significant
followed by number of zeroes.
4R0 = 4.0VDCW
6R3 = 6.3 VDCW
100 = 10 VDCW
160 = 16 VDCW
250 = 25 VDCW
500 = 50 VDCW
630 = 63 VDCW
101 = 100 VDCW

1st two
digits are
significant,
followed
by number
of zeroes.
Example:
101 = 100pF
“R” denotes
decimal:
6R8 = 6.8 pF

*B = ± 0.1 pF
*C = ± 0.25 pF
*D = ± 0.5 pF
F = ± 1%
G = ± 2%
J = ± 5%
K = ± 10% M = ± 20%
N = ± 30%
Z = +80 - 20%
P = +100 - 0%
* For capacitance values
below 10 pF only.

N = 100%
matte Tin(Sn)
over Nickel
P = Palla-
dium Silver
G = Gold over
Nickel
Pb = 90% Tin
(Sn)/10%
Lead (Pb)
Termination

YAGEO PART NUMBER: CC0805KRX7R9BB104 CROSSES TO VENKEL PART NUMBER: C0805X7R500-104KNE

*For exact cross and confirmation of ESR, please consult our catalog.

D = Paper Tape
(10” Reel)
E = Embossed
Tape (7” Reel)
P = Paper Tape
(7” Reel)
U = Embossed
Tape (13” Reel)
R = Paper Tape
(13” Reel)

B = 100% matte
Tin (Sn) over Nickel

N = NP0
B = Class 2 Products

1st two digits are significant;
third digit denotes number
of zeros.
R = decimal
1R0 = 1.0pF
120 = 12pF
471 = 470pF
102 = 1,000pF
273 = 0.027µF
474 = 0.47µF
105 = 1.0µF

CROSS REFERENCE GUIDE

Competitive Pricing and Delivery

•

Buy direct from us

•

Extensive inventory

•

Competitive lead times

•

Same day shipments up to 4pm CST

Supply Chain Services

•

Full suite of Supply Chain programs

•

Ecommerce solutions

•

BOM scrubbing, barcoding and more

Engineering Support

•

In-house Engineering Team

•

FREE kits and samples

•

Engineering newsletter

•

Comprehensive parts database

•

Contact via live chat, phone or email

•

RoHS, REACH, Conflict

Dedicated Account Team

•

Account Manager (Inside Sales)

•

Regional Account Manager (Outside Sales)*

•

Customer Service

•

Supply Chain Services**

Prototype to Production Support

•

Flexible quantities supported: prototype, small runs,
and high volume production

•

Cut tape: as few as 50 pcs on tape

•

Partial reels: according to your exact quantity
requirements

Need More Technical Data?

GO TO THE TECHNICAL LIBRARY

CROSS REFERENCE GUIDE

www.venkel.com

(800) 950–8365
