L
W
t
■
RGV series
・
High voltage operation is possible because the limiting element voltage is high.
(RGV3225 1000V)
・
Long term stability with inorganic passivation.
・
Resistance tolerance : ±0.1% , TCR : ±25 ppm/
℃
・
Thin film structure enabling low noise and anti-sulfur
・
Automotive electronics
・
Industrial measurement instrumentation, Industrial machines.
・
High voltage circuit and equipment.
T1(1,000pcs)
T5(5,000pcs)
Series code
Size
：RGV3216, RGV3225
Nominal resistance value(all 4 digit)
Temperature coefficient of resistance
E-24, E-96
±5（V）
±25(P)
±50(Q)
Power
ratings
Type
-55℃〜 155℃
1/4W
700V
±0.1%（B）
±0.5%（D）
（ppm/℃）
RGV3216
19
RGV 3216 P - 2004 - B - T5
2MΩ
RGV3216
RGV3225
Type
3.20±0.20
3.20±0.20
L
1.60±0.25
2.50±0.25
W
0.50±0.20
0.50±0.20
a
0.40+0.15/-0.1
0.40+0.15/-0.1
t
（unit：mm）
ｂ
a
b
0.50±0.25
0.50±0.25
Resistance tolerance
T1
T5
Metal thin film chip resistors
(high voltage operation)
Applications
Features
AEC-Q200 Compliant
◆
Part numbering system
◆
Electrical Specification
RGT series
Thin film surface mount resistors
Temperature
coefficient
of resistance
Resistance range(Ω)
Resistance tolerance
Maximum
voltage
Resistance
value series
Operating
temperature
Packaging
quantity
◆
Dimensions
Size
（inch）
1206
1210
RGV3225
120KΩ≦R≦4.3MΩ
±25(P)
±50(Q)
1/3W
1000V
120KΩ≦R≦3MΩ
