M.  HIGH RELIABILITY TESTING

BURN IN

Dielectric formulations and chip capacitors are often tested for reliability under voltage and tem-
perature for specified time periods, a process referred to as “burn in” or “voltage conditioning”.
Specifications applicable to burn in of MLC capacitors are MIL-C-55681, MIL-C-123 and MIL-C-
49467. Burn in may also be performed to particular customer specifications.  The test voltage is
usually twice the working voltage rating of the device, at 85°C or 125°C for a duration of 96 hours,
100, or 168 hours test time, typically.
Burn in is accomplished by loading of units in a fixture, usually a PC board which contacts to a power
supply with access to the rear wall of a standard oven.  Units are monitored for current leakage under
voltage and temperature stress either individually or in tandem, with measurement of leakage from a group
of a hundred units, typically.  Tandem testing is more rapid and used to mass produce burned in product.
Sophisticated equipment is used with automatic data monitoring to record the location and time of test
cycle failures.

Chip capacitors destined for high reliability testing are often designed with an added margin of safety,
namely maximization of the dielectric thickness, and tested extensively for electrical properties prior to
burn in (capacitance, DF and insulation resistance).  These data are compared to post life test data for
evaluation of the reliability of the components.

FAILURE MODES

Capacitors which fail burn in usually lose resistivity at the elevated temperature and voltage, either
catastrophically, or gradually with time, resulting in IR rejects.  The failure rate is usually inversely
proportional with time, i.e. more failures are observed earlier in the test cycle.

Excellent electrical properties at 25°C may not guarantee good performance during life test (hence the
purpose of the test), for several reasons:

Poor dielectric properties: Ceramic dielectrics with elevated insulation resistance at room tem-
perature may nevertheless experience excessive loss of resistivity at 125°C due to improper for-
mulation, whereby charge carriers become mobile and develop a leakage current, decreasing the
insulation resistance below specifications.

Poor microstructure: Voids, cracks or delaminations within the chip structure undermine the intrin-
sic resistivity of the material, providing leakage paths conducive to failure.  This does not imply,
however, that units which survive life testing are always free of microstructural defects.  Experience
has shown that despite rigorous testing, units with delaminations may still perform adequately,

NOVACAP

TECHNICAL BROCHURE

2

while failures may be observed in units with apparent “excellent” microstructure.  This is due to the
fact that delaminations may often affect only the plane of the electrodes, without serious deteriora-
tion of the dielectric between electrodes of opposite polarity.  Cracks, voids or impurities which
straddle the electrode array are more conducive to eventual degradation under voltage and tem-
perature.  The latter defect may be microscopic in magnitude, and not easily observed or located
within the chip microstructure, which may otherwise appear quite normal.

A second failure mode independent of the above, is degradation of the capacitance value and/or
dissipation factor of the chip capacitor, i.e. post burn in data does not correlate well to the original
electrical test data.

Class I dielectrics, which are non-ferroelectric, do not exhibit capacitance aging with time, tempera-
ture or voltage.  Any burn in induced capacitance change in Class I chips is associated with mechani-
cal failure, such as cracking which isolates electrode layers.  Class II dielectrics, however, may
display capacitance and dissipation factor variations after bum in without mechanical failure, as
these dielectrics are time, temperature and voltage dependent.  Most notably, the accelerated aging
of the dielectric constant under burn in conditions must be considered for proper interpretation of
results; units under test may be exposed to three very different aging scenarios, depending on the
method used to terminate the life test.  The following three conditions assume that pre-burn in data
was performed on de-aged units:

a. The voltage is removed while the units are at temperature, and temperature is maintained
with no bias for a minimum of one hour.  Under this condition, total de-aging of capacitors
occurs, and units will display minimal (positive or negative) capacitance change with respect
to the original pre-burn in values.

b. Capacitors remain under dc bias while the oven is



permitted to cool to room temperature.

This in effect is a voltage conditioning process and the units will therefore age with respect
to the original test data, e.g. -7.0%

∆

C.

c. The voltage is removed at the burn in temperature and the units subsequently taken from
the oven and allowed to air cool to room temperature.  In this case, the units do not fully age
during the cooling cycle, as in example (b), nor do they totally de-age as in (a) above.  The
components thus experience a partial aging only, e.g. -3.5%

∆

C.

The %

∆

C values given as examples for the post burn in data above are typical of some Mid-K

dielectrics.  High-K less stable dielectrics may experience more radical capacitance changes, as these
materials have an aging rate of 5% per decade hour typically, three times the average rate of X7R
formulations.  These considerations clearly indicate that procedure (a) only should be followed for
termination of the life test for proper evaluation of performance of Class II dielectrics.

NOVACAP

TECHNICAL BROCHURE

3

In addition to burn in, high reliability often involves other performance tests, as outlined in Table L-
2, per MIL-C-55681 or to customer specifications.  The most common of these additional tests are
dielectric withstanding voltage and insulation resistance at elevated temperature, voltage-tempera-
ture limits, thermal shock, solderability and solder leach resistance of the chip capacitor termination.
In addition, strict visual and mechanical examination of the product may be required, including
Destructive Physical Analysis (DPA).  The various group categories of high reliability testing appli-
cable to MIL specifications are outlined in Table M-1.  Any or all of the Group tests may be specified
by customers requiring high reliability product.

MIL-C-55681

Voltage Conditioning
IR @ Elevated Temperature
Visual & Mechanical Inspection
ESR, when Specified
Solderability

MIL-PRF-49467A
(High Voltage)

Thermal Shock
Voltage Conditioning
Partial Discharge
Radiographic Inspection
Mechanical Examination
Visual Examination
Solderability

MIL-C-123B

Thermal Shock
Voltage Conditioning
Visual & Mechanical Inspection,
Destructive Physical Analysis

MIL-PRF-39014F
(Leaded Devices)

Thermal Shock
Voltage Conditioning
Radiographic Inspection
Mechanical Examination
Visual Examination
Solderability

TABLE  M-1

HIGH RELIABILITY TEST PROCEDURES

Environmental and Life Tests performed for qualification, or to attain
Established  Reliability, applicable to any specification, if required.

Specification

GROUP A

Specification

GROUP A

GROUP B

GROUP C
