Description
1-1827876-2 TE Connectivity Connector Power Header Wire-To-Board Connector, Dynamic D-1200D Series, Header 4 Pos, 2-Row, 2.5mm Through Hole
Specifications
Manufacturer: TE Connectivity
Product Category: Headers & Wire Housings
RoHS
Product: Headers
Type: Shrouded
Number of Positions: 4 Position
Pitch: 2.5 mm
Number of Rows: 2 Row
Termination Style: Through Hole
Contact Gender: Pin (Male)
Contact Plating: Gold
Termination Post Length: 3.1 mm
Series: D-1000
Tradename: DYNAMIC SERIES
Packaging: Tube
Application: Wire-to-Board
Contact Type: Tab
Current Rating: 5 A
Housing Material: Polyester
Voltage Rating: 250 V
Brand: TE Connectivity / AMP
Contact Material: Copper Alloy
Row Spacing: 3.3 mm
Housing Gender: Plug
Product Type: Headers & Wire Housings
Factory Pack Quantity: 61
Subcategory: Headers & Wire Housings
Part # Aliases: 1-1827876-2
Unit Weight: 1.763698 oz
This robust 1-1827876-2 power connector from TE Connectivity easily retains normal operation in harsh and stressful environments. This HDR connector’s 4 contacts that are made out of copper alloy and plated with gold over nickel. It has a right angle body orientation. Its pitch is 2.5 mm. This connector has a single port. It has a header type gender. It has a maximum voltage rating of 250 VAC. This device has a maximum current rating of 5 A/contact. 1-1827876-2 is housed in polyester.
Manufacturer:TE Connectivity
Datasheet:TE/1777024.pdf
