Description
10P-SAN JST Connector Housing RCP 10 Position 2mm Crimp ST Cable Mount Automotive Bag RoHS
Technical Specifications
Type Housing
Gender RCP
Number of Contacts 10
Number of Rows 1
Termination Method Crimp
Terminal Pitch (mm) 2
Body Orientation Straight
Maximum Current Rating (A)2
Maximum Voltage Rating 250VAC|250VDC
Insulation Resistance (MOhm) 1000
Minimum Operating Temperature (C)-25
Maximum Operating Temperature (C) 85
Packaging Bag
Product Length (mm)21.2
Product Depth (mm)3.25
Mounting Cable Mount
Manufacturer: JST
MFG Part #: 10P-SAN
