Description
10SR/B-100KJ ATE Fixed Resistor 100Kohm 5% 13W 30ppm/C Axial
Specifications
Resistance 100 kohm
Power Rating 13W
Tolerance 5%
Technology Wirewound
Series 10SR
Case Style Ceramic
Temperature Coefficient 30ppm/C
Dimensions 9.5 (Dia.) x 50mm
Length 50mm
Diameter 9.5mm
Maximum Temperature Coefficient +30ppm/C
Minimum Temperature Coefficient -30ppm/C
Minimum Operating Temperature -55C
Maximum Operating Temperature +350C
Manufacturer:ATE Electronics
Datasheet:Others/ATE-SR-Series.pdf
