Description
Material Rexolite Polystyrene Plastic
Cross Section Shape Rectangle
Construction Solid
Texture Smooth
Color Off-White
Clarity Semi-Clear
Thickness 1/4″
Thickness Tolerance 0″ to +0.008″
Tolerance Rating Oversized
Width 6″
Width Tolerance 0″ to +1/4″
Length 6″
Length Tolerance 0″ to +1/4″
Hardness Rockwell R130
Hardness Rating Hard
For Use Outdoors No
Temperature Range -75 to 210 F
Impact Strength 1.20 ft.-lbs./in.
Impact Strength Rating Good
Tensile Strength 8,000 psi
Tensile Strength Rating Good
Specifications Met MIL-LP-516A
Density 0.038 lbs./cu. in.
Coefficient of Friction Not Rated
Dielectric Strength 2,000 V/mil
Water Absorption 0.08%
Coefficient of Thermal Expansion 3.8 10-5 in./in./F
RoHS Compliant
Manufacturer Part Number: 1491T12
