Description
2216S-20G-02-H Neltron Connector Header Male 16-way 2×8 Dual row Right angle P = 2.54mm, Height above PCB = 8.3mm, Row spacing=2.54mm Through hole short ejector
Specifications
CONNECTOR STYLE Shrouded header
NUMBER OF CONTACTS 20
CONFIGURATION Dual row
PIN ARRANGEMENT 2×10
ORIENTATION Vertical
MOUNTING TYPE Through hole
PITCH (mm) 2.54
DISTANCE BETWEEN ROWS (mm) 2.54
HEIGHT (mm) 28
OVERALL LENGTH (mm) 44.9
OVERALL WIDTH (mm) 8.3
CURRENT RATING (A) 3
MAX VOLTAGE (V) 250
CONTACT MATERIAL Copper alloy
CONTACT PLATING Gold
POLARISATION Polarisation
HOUSING MATERIAL High temp plastic (UL94V-0)
APPROVALS UL,
UL FILE NUMBER E144392
FOOT PRINT (mm) 44.9×8.3
OPERATING TEMPERATURE RANGE -40~105 c
PACKING STYLE Tray
Manufacturer:Neltron
Datasheet:Others/2216s-xxg-xx-xx-xx-h.pdf
