Description
24LC512T-I/SM Microchip EEPROM Serial-I2C 512K-bit 64K x 8 3.3V/5V 8-Pin SOIJ T/R
Specifications
Manufacturer: Microchip
Product Category: EEPROM
RoHS
Mounting Style: SMD/SMT
Package / Case: SOIC-Wide-8
Memory Size: 512 kbit
Organization: 64 k x 8
Interface Type: Serial, 2-Wire, I2C
Access Time: 900 ns
Data Retention: 200 Year
Maximum Clock Frequency: 0.4 MHz
Supply Current – Max: 5 mA
Supply Voltage – Min: 2.5 V
Supply Voltage – Max: 5.5 V
Minimum Operating Temperature: – 40 C
Maximum Operating Temperature: + 85 C
Packaging: Cut Tape
Packaging: Reel
Height: 1.98 mm (Max)
Length: 5.26 mm
Width: 5.25 mm
Brand: Microchip Technology
Moisture Sensitive: Yes
Operating Supply Current: 5 mA
Operating Supply Voltage: 3.3 V, 5 V
Product Type: EEPROM
Programming Voltage: 2.5 V to 5.5 V
Factory Pack Quantity: 2100
Subcategory: Memory & Data Storage
Unit Weight: 0.014110 oz
Manufacturer Part Number: 24LC512T-I/SM
Microchip Technology
