Description
24LC64T-I/MC Microchip Technology EEPROM Memory IC 64KBIT, I2C, 400KHZ, DFN-8, Memory Size:64Kbit, EEPROM Memory Configuration:8K x 8bit, Memory Interface Type:Serial I2C (2-Wire), Clock Frequency:400kHz, Memory Case DFN, No. of Pins:8Pins, Supply Voltage Min:2.5V, RoHS
Specifications
Manufacturer: Microchip
Product Category: EEPROM
RoHS
Mounting Style: SMD/SMT
Package / Case: DFN-8
Memory Size: 64 kbit
Organization: 8 k x 8
Interface Type: Serial, 2-Wire, I2C
Access Time: 900 ns
Data Retention: 200 Year
Maximum Clock Frequency: 400 kHz
Supply Current – Max: 3 mA
Supply Voltage – Min: 2.5 V
Supply Voltage – Max: 5.5 V
Minimum Operating Temperature: – 40 C
Maximum Operating Temperature: + 85 C
Series: 24LC64
Packaging: Cut Tape
Packaging: Reel
Height: 1 mm
Length: 3 mm
Width: 4.4 mm
Brand: Microchip Technology
Operating Supply Current: 0.1 mA, 0.05 mA
Operating Supply Voltage: 2.5 V to 5.5 V
Product Type: EEPROM
Programming Voltage: 2.5 V to 5.5 V
Factory Pack Quantity: 2500
Subcategory: Memory & Data Storage
Unit Weight: 0.005573 oz
Manufacturer:Microchip Technology
Datasheet:Microchip/21189T.pdf
