Description
2503H-02W-L Amtek Technology Co., Ltd. HEADER CONNECTOR,CABLE MNT,RECEPT,2 CONTACTS,SKT,0.098 PITCH,CRIMP TERMINAL,LOCKING
EU RoHS Compliant Yes
^Status Contact Mfr
^Connector Type BOARD CONNECTOR
^Body Breadth 0.2200 inch
^Body Depth 0.3030 inch
^Body Diameter 0.2240 inch
^Body/Shell Style RECEPTACLE
^Contact Design PREASSEM CONN
^Contact Gender FEMALE
^Contact Pattern RECTANGULAR
^Contact Resistance 10 mohm
^Dielectric Withstanding Voltage (V) 1000VAC
^Insulation Resistance 1.00E9 ohm
^Insulator Material NYLON
^Manufacturer Series 2503H
^Mating Contact Pitch (inch) 0.098
^Mounting Option 1 LOCKING
^Mounting Type CABLE
^Number of Rows Loaded 1
^Operating Temperature-Min -25 Cel
^Operating Temperature-Max (Cel) 85
^Polarization Key POLARIZED HOUSING
^Rated Current (Signal) 3 A
^Reference Standard UL
^Reliability COMMERCIAL
^Sub Category Headers and Edge Type Connectors
^Terminal Type CRIMP
^Total Number of Contacts 2
Manufacturer:Amtek Technology
Datasheet:AMTKS00166-1.pdf
