Description
2EDGK-7.62-06P-14-1000A(H) Degson Electronics Connector Pluggable terminal block; Contacts ph: 5.08mm; 6 ways; socket RoHS
Specification
Manufacturer : DEGSON ELECTRONICS :
Type of connector : pluggable terminal block :
Contacts pitch : 5.08mm :
Number of ways : 6
Spatial orientation : angled 90 :
Connector : socket :
Kind of connector : male :
Mechanical mounting : on PCBs :
Electrical mounting : THT :
Colour : green :
Rated voltage : 320V :
Current rating : 20A :
Type of pin configuration : 1×2 :
Body material : PA66 :
Locking system : latch :
Flammability rating : UL94V-0 :
Conform to the norm : CE, UL, VDE :
Contact plating : tinned :
Operating temperature : -40…105C :
Contact material : brass :
Number of pins : 2 :
Height : 8.2mm :
Depth : 12.1mm :
Length : 11.56mm :
Gross weight: 0.6 g
Manufacturer part number: 2EDGRC-5.08-02P-14-00A(H)
Manufacturer: Degson
MFG Part #: 2EDGK-7.62-06P-14
