Description
The 3DFS512M04VS2722 is a Quad SPI Flash NOR memory organized in 4 banks of 128 Mbit each with distinct chip enable CEn# (n from 0 to 3) controls. It requires only a single 3.0 V power supply for both read and write functions. Thanks to dual SPI and quad SPI interfaces, and Fast Read mode feature, our serial NOR Flash memory can achieve high throughput (up to 133 MHz), which makes it suitable for high speed circuit applications. It is highly suitable for code storage in embedded systems Thanks to the SPI interface, the 3DFS512M04VS2722 achieve s very low pin count. It is packaged in a 18 pin SOP.
Single Power Supply operation: 3.0V read, erase and
program operations.
– 4 x 128M-bit/64M-byte
– Supports standard SPI, Fast, Dual, Dual I/O, QPI, SPI
DTR, and Dual SPI DTR I/O
– 50MHz Normal and 133Mhz Fast Read
– More than 100,000 erase/program cycles
– More than 20-year data retention
– Program 1 to 256 bytes per page
– Program/Erase Suspend & Resume
– Low Instruction Overhead Operations
– Continuous Read 8/16/32/64-Byte burst
– Selectable burst length
– QPI for reduced instruction overhead
