Description
MILL-MAX 596-11-120-01001445 IC Sockets and Headers STANDARD BGA SOCKET
Receptacle With A Standard Tail
Accepts .015″ (0.38mm) – .026″ (0.66mm) diameter leads.
Specifications
Product Type IC Socket
RoHS Compliant RoHS Compliant
Socket Type BGA
Contact Plating Gold
BGA adapter/socket systems are a reliable way to make BGAs pluggable, they may also be used as a high density board-to-board interconnect. The BGA device is soldered a 9929 adapter (or a 7929 adapter is soldered to a PCB); and then either one can be plugged into a 9928 surface mount socket. Both socket and adapter have the same footprint as the BGA device. Insertion force is only.41N per pin, and a pry-bar tool (part #828-01-010) is available for extraction. Insulator material is FR-4 epoxy having a TCE to match the BGA device and circuit board. Mill-Max offers the option of having the solder surfaces of the 7929 adapter and 9928 socket pre-tinned. BGA MOUNT ADAPTER PIN TYPE 9929
Manufacturer:Mill-Max
Datasheet:Others/mill-max-170.pdf
