Description
5W2503S0-102T0WBLT01 AMTEK Connector, Shrouded Header 2.5mm pitch, 2 postions (Top Entry), Through hole RoHS
Specifications:
Current rating: 3A AC/DC
Contact resistance: 20mO max
Insulation resistance: 1000MO min
Dielectric voltage: 800V AC/minute
Temperature range: -25 to +85C
Materials:
Insulator: polyester, UL94V-0
Terminal: copper alloy
AMTEK 5W2503S0-102T0WBLT01 Through hole type shrouded header 2.5mm pitch, 2 postions (Top Entry) Lead free / RoHS: Compliant
Amtek has evolved into a leading worldwide professional manufacturer of various connectors. Amtek’s connectors are furnished in a wide variety of styles and configurations to suit any design requirements. In addition to standard ranges, custom-built connectors can be designed, developed and manufactured to meet your individual requirements. Amtek’s experienced Research and Development teams are continuously dedicated to product design and development, which enables us to respond most flexibly to your particular desires at low cost.
Manufacturer:Amtek Technology
Datasheet:Amtek/2015PDF-3-43_5X2503-3.pdf
