Description
97F6660RC Genteq Lighting Capacitor 12uF 400VAC, Can, HID Lighting, Oval Case “C”, 2.91″x1.91″x2.88″H With Resistor
Specifications
Item Number: 97F6660
Brand: GE Capacitor
Item Category:Capacitors
Subcategory: Lighting
Series: 97F
Single/Dual: Single
Capacitance: 12 MicroFarads
Voltage AC: 400 Volts AC
Tolerance (%): 3 Percent
Composition: Metallized Polypropylene
Temperature (F): -40 to 194 Degrees F
Package Type: Radial Oval
Case Material: Metal Can
RoHS: No
Lead Type: .250 Quick Connect
Lead Spacing: 0.81 Inches
Lead Length: 0.63 Inches
Picture No.: OVAL_2.88X2.91X1.91_.250QC-2BLADES-FORK
Comments: Combo terminal has two .250 quick connect terminals and one solderable fork terminal.
H x W x D: 2.88 in x 2.91 in x 1.91 in
97F Series Information
Proven EIA-456 Compliant 60,000 Hour Reliability
High-Grade Metalized polypropylene Film
Contains Proprietary Dielektrol VI Oil
UL Approved and Patented pressure Sensitive Interrupter
RoHS Compliant
This capacitor series is designed specifically for the HID Lighting applications where the capacitors are used as part of the ballast circuit for mercury vapor, metal halide, and high-pressure sodium lamps. The units are designed to operate at up to 90C, which is the normal requirement for HID ballast capacitors. Due to advances in material technology and breakthroughs in proprietary capacitor manufacturing processes, selected ratings are now available for operation up to 100C for 60,000 Hours.
Manufacturer: Genteq
MFG Part #: 97F6660RC
