Description
GENTEQ 27L877 97F9833 Capacitor In Metal Container, 30 Microfarad +/-1.5%, 370V-440V, 50Hz
30/5 uf 370 volt 27L877/97F9833 Top Of The Line Capacitor Motor Run Capacitor, 30 µF, 5 µF, 370 VAC, Gem III Series, ± 6%
The 97F9833 is a GEM III high grade metalized polypropylene Film Capacitor with quick connect blades termination, aluminum case and terne plate cover. This capacitor is designed specifically for the motor run applications.
30μA Maximum leakage current
Applications
Motor Drive & Control
Specifications
Item Number: 97F9833
Brand: GE Capacitor
Item Category:Capacitors
Subcategory: Motor Run
Series: 97F
Single/Dual: Dual
Capacitance: 5/30 MicroFarads
Voltage AC: 370 Volts AC
Diameter: 2.12 Inches
Tolerance (%): ±6 Percent
Composition: Metallized Polypropylene
Temperature (F): -104 to 158 Degrees F
Package Type: Radial Round
Case Material: Aluminum
RoHS: Yes
Lead Type: Quick Connect
Lead Spacing: 0.81 Inches
Lead Diameter: 0.75 Inches
Lead Length: 0.52 Inches
Picture No.: ROUND_3.88X2.12dia_.250QC-3-1-4BLADES
Comments: 3 Blades on the Left Bushing, 1 Blades on the Top Bushing, 4 Blades on the Right Bushing
H x W x D: 3.88 in x 2 in x 2.12 in
Manufacturer:Genteq
Datasheet:GTC 001 – Motor Run 2011 08 25.pdf
