Description
A3-20PA-2SV(71), HIROSE, CONN HEADER 20POS 2MM GOLD SMD
These Hirose miniature SMT PCB headers are light weight, high density connector headers in PPS material, with pin contacts only. Ideal for wire to board connections in a broad range of connector applications.
Part numbers – A3A-xxPS-2SV(71) have a positioning boss.
Features and Benefits
• Operating temperature range -55 to +85°C
Applications:
• VTR
• Vehicle telephones
• Electronic equipment
• Test rigs
Approvals
UL94V-0
2.0mm Pitch Miniature Connectors, Hirose A3-A4 Series
A range of Hirose miniature headers and receptacles connectors which are durable multi-purpose and light weight with a high density of contacts available in miniature form. Ideal for wire to board connections in a broad range of connector applications including video and communications equipment, test rigs and many others.
Specifications
Series A3
Pitch 2mm
Number of Contacts 20
Number of Rows 2
Body Orientation Straight
Mating Pin Length 3.5mm
Mounting Type Surface Mount
Connector System Wire to Board
Termination Method Solder
Type Wire to Board
Contact Plating Gold
Contact Material Brass
Current Rating 2A
Voltage Rating 200 V ac
Manufacturer:Hirose Connector
Datasheet:Hirose/A3_06211008871_spec.pdf
