Description
Package Type Flat Top
^Emitting Color Yellow Green
^Luminous Intensity 6.3mcd
^Test Current (It) 10mA
^Forward Current 30mA
^Dominant Wave Length 569nm
^Viewing Angle 125
^Forward Voltage 2.7V
^Product Length (mm) 2.21mm
^Product Height (mm) 2.44mm
^Product Depth (mm) 2.34mm
^Mounting Surface Mount
^Packaging Tape and Reel
^Peak Wavelength 565nm
^Shape Type Circular
^Main Category Chip LED
^Number of Elements 1
^Pin Count 2
^Operating Temperature Classification Commercial
^Type Uni-Color
^Lens Type Colorless Non Diffused
^Operating Temp Range -20C to 100C
^Reverse Voltage 5V
^Lens Dimensions 1.91×1.91×0.77mm
Manufacturer Part Number: HLMP-P505-G0021
Manufacturer: Agilent
